ASSEMBLY INSTRUCTIONS
MOBILE SCIENCE CART SERIES
1-800-261-4112Page 1 of 2 www.nationalpublicseating.com
MOBILE SCIENCE CART COMPONENTS
1x Cart
B
4x Caster
C
1x Outlet
Power Strip
A
TOOLS FOR ASSEMBLY
4
Screw Driver Open End
Wrench
5
2Secure each caster from the
inside using 4 Bolts from the
inside and 4 Washers and 4
Lock Nuts from the outside.
C
1
3
2
1
C
2
3
1Lay the cabinet on its back on a
clean surface. Remove shelves,
drawers if necessary.
INCLUDED HARDWARE
1
Bolt16x Lock Nut16x
2 3
Washer16x
Ensure that all screws are fastened
tightly.
Slide the Outlet Power Strip over
the screws on the side of the cart
- .Roll the cable onto the side
bracket .
A
B
B2
B1
B
A
B2
B1
OUTLET POWER STRIP INSTALLATION
ONLY APPLICABLE FOR CARTS
MSC01, MSC02 AND MSC03

Dear Customer, Thank you for your purchase. Although extreme care goes into manufacturing & packaging of
this product, mistakes are possible. If you encounter any missing parts or diculty in assembly, please contact
our customer service Toll Free at 1-800-261-4112 or [e-mail] for courteous & immediate
resolution to your problem.
1-800-261-4112Page 2 of 2 www.nationalpublicseating.com
1 Insert tapered end Posts
into tube sockets .
B
B1
B
B1
2Tighten the Post Clamp in the
desired location using the Rear
Knob .
C
C1
C
C1
B
3Slide Crossbar through holes on
side of Whiteboard/Mirror frame.
Adjust the desired angle with the
Front Knobs .
D1
D
D
D1
D1
4Slide Crossbar through holes of
the Post Clamp , tighten using
the Front Knobs .
D
C
C2
C2
D
C
1x Cart
A
1x Crossbar
D
2x Post
B
1x Mirror/
Whiteboard
D
2x Post
Clamp
C
WHITEBOARD/MIRROR INSTALLATION - MSC01, MSC02 AND MSC03
Congratulations, your Mobile Science Cart is now assembled and ready to be used!
of
