Navman iCN 620 User manual

NAVMAN
User Manual
iCN 620

2
NAVMAN iCN 620 user manual
WELCOME
Congratulations on the purchase of your iCN 620 In-Car Navigation Unit. Whether you travel frequently in
your own country, or need to nd your way around overseas, this unit will direct you to your destination
without the need for map books and second-hand instructions.
The Global Positioning System is available free of charge, at any time, and is accurate to within 5 m
(16.5 ft). The maps in the iCN 620 provide street level detail allowing door to door navigation  they even
include points of interest such as hotels, railway stations and airports. With this unit, you will never be lost
again!
Use this manual to help you install your unit, learn how to operate it effectively and safely, plus nd out all
of the different features available to you.
IMPORTANT NOTICE
When using your iCN 620 in a vehicle, it is your sole responsibility to place, secure, and use the device in a manner
that will not cause accidents, personal injury or property damage, or in any manner obstruct your view or vehicle safety
equipment. The user of this product is solely responsible for observing safe driving practices. Do not operate your iCN
620 while driving. Park the vehicle rst. It is your sole responsibility that the vehicle mount installation instructions are
read carefully, understood, and used consistent with the laws of operation for each country in which you use the device.
Navman NZ Limited disclaim all liability for any use of this product in a way that may cause accidents,
damage or that may violate the law.

3
NAVMAN iCN 620 user manual
SAFETY FIRST
It is your sole responsibility to adhere to the following safety instructions at all times.
ý Do not operate this unit while driving.
ý This unit must be placed in a position where it cannot obstruct the drivers view of the road.
ý This unit must not interfere with the normal operation of any airbags or other
vehicle safety equipment.
ý For security purposes and to avoid overheating, do not leave this unit on the dash or windscreen while your
vehicle is unattended, especially in strong sunlight. Do not use or handle if the unit is hot - leave it to cool out
of the sun.

4
NAVMAN iCN 620 user manual
CONTENTS
1 WHAT IS GPS?................................................................................................................................................... 8
2 UNPACKING THE iCN 620................................................................................................................................. 9
ý Memory Cards ........................................................................................................................................... 11
ý Other Accessories...................................................................................................................................... 11
3 INSTALLING SOFTWARE AND NEW MAPS ................................................................................................... 12
ý Installing iCN Desktop ................................................................................................................................ 12
ý Step 1: Connecting the iCN 620 to Your Computer .................................................................................... 14
Windows XP Users ................................................................................................................................ 15
Windows 2000 Users ............................................................................................................................ 17
Windows ME/98SE................................................................................................................................ 18
ý Step 2: Installing iCN Application................................................................................................................ 20
ý Step 3: Installing Maps ............................................................................................................................... 21
ý Step 4: Reading User Manuals and Quick Start Guides.............................................................................. 26
ý Other iCN 620 Options............................................................................................................................... 26
Backing up Device Settings ................................................................................................................... 26
Visit Navman Website ............................................................................................................................ 28
4 INSTALLING THE iCN 620 IN YOUR VEHICLE ............................................................................................... 29
ý Suction Mount to Windshield...................................................................................................................... 30
ý Suction or Adhesive Mount to Dash ........................................................................................................... 33

5
NAVMAN iCN 620 user manual
5 CONTROLS AND KEYBOARD......................................................................................................................... 39
ý Using the Control Buttons ......................................................................................................................... 39
ý Using the Menus ....................................................................................................................................... 41
ý Moving around the Settings Screens .......................................................................................................... 42
ý Entering text with the On-Screen Keyboard ................................................................................................ 43
ý Changing the Brightness and Volume......................................................................................................... 44
6 GETTING STARTED ......................................................................................................................................... 46
ý Powering Up .............................................................................................................................................. 46
ý Main Menu ................................................................................................................................................. 47
ý Driver Protection ........................................................................................................................................ 47
ý Getting a GPS Fix....................................................................................................................................... 48
7 SETTING YOUR DESTINATION ....................................................................................................................... 49
ý Using a Shortcut ........................................................................................................................................ 50
ý Setting a New Destination .......................................................................................................................... 51
- Heading to an Address ......................................................................................................................... 51
- Heading to an Intersection .................................................................................................................... 54
- Heading to a Point of Interest................................................................................................................ 57
ý Using a Saved Favourite............................................................................................................................. 60
ý Heading to a Recently Used Address ......................................................................................................... 61
ý Straight from the Map ................................................................................................................................ 63
8 VIEWING YOUR ROUTE .................................................................................................................................. 65
ý Map Browser ............................................................................................................................................ 65
ý Navigation Map ......................................................................................................................................... 66

6
NAVMAN iCN 620 user manual
ý Next Instruction......................................................................................................................................... 68
ý Next Four Instructions ............................................................................................................................... 69
ý Back-on-Track Feature .......................................................................................................................... 70
ý Automatic Restart Feature......................................................................................................................... 70
9 PROGRAMMING SHORTCUTS....................................................................................................................... 71
ý Adding a New Shortcut ............................................................................................................................. 71
ý Deleting a Shortcut.................................................................................................................................... 74
10 PROGRAMMING FAVOURITES ....................................................................................................................... 75
ý Adding a New Favourite ............................................................................................................................ 75
ý Editing or Deleting a Saved Favourite ........................................................................................................ 78
11 USING THE GPS STATUS INFORMATION ...................................................................................................... 80
ý GPS Reception ......................................................................................................................................... 81
ý Satellite Signal Strengths........................................................................................................................... 82
ý Satellite Positions ...................................................................................................................................... 83
12 MODIFYING THE SETTINGS ........................................................................................................................... 84
ý Display Settings ........................................................................................................................................ 85
ý Route and Guidance Settings.................................................................................................................... 85
ý Points of Interest Settings.......................................................................................................................... 87
ý GPS Settings ............................................................................................................................................ 88
ý User Settings ............................................................................................................................................ 91
ý Maps......................................................................................................................................................... 92
13 AUTOMATIC ROUTE SIMULATOR .................................................................................................................. 93

7
NAVMAN iCN 620 user manual
14 ACCESSORIES ................................................................................................................................................ 95
ý External or Re-radiating Antennae ............................................................................................................. 95
ý Memory Cards .......................................................................................................................................... 96
ý Memory Card Writers ................................................................................................................................ 96
15 AVAILABLE MAPS............................................................................................................................................ 98
16 FREQUENTLY ASKED QUESTIONS.............................................................................................................. 100
17 TROUBLESHOOTING .................................................................................................................................... 101
18 ADDITIONAL INFORMATION......................................................................................................................... 103
ý End User and Warranty Agreement ......................................................................................................... 103
ý Specications........................................................................................................................................... 105
ý Contact Us.............................................................................................................................................. 106
ý FCC Statement ....................................................................................................................................... 107
ý Copyright ................................................................................................................................................ 107

8
NAVMAN iCN 620 user manual
WHAT IS GPS?
The Global Positioning System (GPS) is a network of satellites launched by the US military in the 1970s. The satellites
continuously transmit accurate time and position information, which is freely used by commercial and military
applications worldwide. GPS receivers such as the iCN 620 are designed to pick up the high frequency radio signals
from these satellites, and use the information to determine your exact location. Today, there are many applications that
use GPS, from marine to automotive, aviation and military.
There are 24 satellites in total, orbiting the earth at around 12,000 miles. While a GPS receiver can detect signals from
up to 12 satellites at any one time, only three are needed to provide the two-dimensional position or x (latitude
and longitude) that is required for vehicle and marine navigation systems. Aviation applications also need altitude and
therefore need information from at least four satellites.
The iCN 620 In-Car navigation unit is designed specically to use GPS information to nd your current position, and to
calculate the best route to your desired destination using the road maps stored in its memory. The iCN 620 will then
guide you with voice and visual commands to your destination using the continuous stream of GPS data to track your
position as you take a trip.
1

9
NAVMAN iCN 620 user manual
UNPACKING THE iCN 620
Heres what you should nd in the box. If there is anything missing, contact your retailer for assistance.
2
3
1
5
4
6
7
2
8
*
*
This will vary depending on the country of purchase

10
NAVMAN iCN 620 user manual
Key:
1 - iCN 620 unit with integral GPS receiver.
2 - CD-ROMs includes:
§ smartMAP In-Car Digital Navigation Software
§ Maps (refer to Section 15 for the maps included in your country)
§ User Manual and Quick Start Guide in Adobe Acrobat PDF format
§ Adobe Acrobat Reader.
3 - Vehicle windshield and dashboard mounting bracket:
(a) Ball foot
(b) Locking nut
(c) Mounting clip
(d) Sucker pad
4 - 12/24 V Vehicle power cable.
5 - Mains power pack for indoor programming, demonstration and training (This will vary depending on the
country of purchase).
6 - USB cable for map and application downloading from a PC.
7 - Protective carry case and screen cleaner.
8 - Quick Start Guide.
