Naxa NRC-165 User manual
Easy-Read Dual Alarm Clock Radio
with USB Charger
NRC-165
Instruction Manual
Please read carefully before use and keep for future reference.
Important Safety
Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that maybe of suf-
cient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instruc-
tions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accor-
dance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including am-
pliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the pro-
vided plug does not t into your outlet, consult an elec-
trician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specied by the man-
ufacturer.
Page 2 Naxa Electronics
12. Use only with the cart, stand, tripod,
bracket, or table specied by the manu-
facturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servic-
ing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the ap-
paratus, the apparatus has been exposed to rain or mois-
ture, does not operate normally, or has been dropped.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must ac-
cept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
CAUTION ON MODIFICATIONS
Any changes or modications not expressly approved by the
grantee of this device may void the authority granted by the
FCC to operate the equipment.
www.naxa.com Page 3
Page 4 Naxa Electronics
At a Glance
1SNOOZE/SLEEP button
2SOURCE/AL.OFF button
3MEM/M+/TIME button
4VOL−/AL2 button
5VOL+/AL1 button
6DIMMER button
7TUN−/MIN button
8TUN+/HR indicator
9PM indicator
10 AL1-B indicator
11 AL1-R indicator
12 AL2-B indicator
13 AL2-R indicator
14 LED clock display
15 Battery compartment
16 DC in jack
17 FM wire antenna
18 USB port
19 Speaker
www.naxa.com Page 5
Connecting the Unit
to Power
Plug one end of the AC adapter into the DC IN
jack, and then plug the other end into AC wall
outlet. Before switching on the unit, make sure
that the voltage of your electricity supply is the
same as that indicated on the rating plate.
Battery Backup
Battery backup will preserve the current time,
alarm settings, and stored radio stations in
the case of power failure or interrupted AC
power.
Insert two UM-4 batteries (AAA) into the bat-
tery compartment. Be sure to observe the
proper polarity (the “+” and “-” signs) as indi-
cated inside the battery compartment.
Setting the Clock
1. With the unit in CLOCK mode (i.e., the ra-
dio is off), press and hold the MEM/M+/
TIME button for about 1 second. The time
will begin to ash on the display.
2. Press the TUN+/HR button to adjust the
hour; press the TUN−/MIN button to ad-
just the minute.
3. When the correct time is set, press the
MEM/M+/TIME button again to conrm.
Page 6 Naxa Electronics
Setting the Alarms
1. With the unit in CLOCK mode, press the
VOL+/AL1 to set Alarm 1 (or press VOL−/
AL2 button to set Alarm 2). The ALARM
time will begin to ash on the display.
2. Press the TUN+/HR button to adjust the
hour; press the TUN−/MIN button to ad-
just the minute.
3. When the correct alarm time is set, press
the VOL+/AL1 button (or VOL−/AL2) to
conrm.
4. Press the VOL+/AL1 button (or VOL−/AL2)
to toggle between “wake to buzzer” or
“wake to radio” modes. The current alarm
wake mode is indicated on the display.
Snooze Function
1. Whenever the alarm (radio or buzzer) ac-
tivates, it can be temporarily suspended
for 9 minutes by pressing the SNOOZE/
SLEEP button once.
2. The buzzer or radio will then sound again
automatically after 9 minutes.
3. This procedure can be repeated for up to
approximately one hour.
Turning o the Alarm
Press the POWER/AL.OFF button to turn the
alarm off when it sounds.
www.naxa.com Page 7
Listening to the FM
Radio
1. Press the SOURCE/AL.OFF button to turn
on the FM radio
2. Press the TUN+/HR or TUN−/MIN button
to manually tune to a radio station.
3. Press and hold the TUN+/HR or TUN−/
MIN button for approximately 1 second to
scan to the next station with a strong sig-
nal. Stations with a weak signal can only
be tuned in manually.
Saving a Radio Station to
Memory
1. Tune the radio to the desired station.
2. Press and hold the MEM/M+/TIME button
for approximately 1 second to save the
current radio station to preset memory.
3. Up to 10 FM radio stations can be stored
in preset memory.
To Listen to a Saved Radio
Station
1. Press the SOURCE/AL.OFF button to turn
on the FM radio.
2. Press the MEM/M+/TIME button to tune
to the next preset station.
Turning O the Radio
While in radio mode, press the SOURCE/AL
OFF button to turn off the radio.
Page 8 Naxa Electronics
Sleep to Music Function
Place the radio on a timer so that you can lis-
ten to music as you fall asleep.
1. Press the SNOOZE/SLEEP button. The
display will show the default sleep time
of 90 minutes
2. Continue to press the SNOOZE/SLEEP
button toggle through the timer length
options.
3. The options are 90-80-70-60-50-40-
30-20-10-min. or OFF.
4. The radio will turn off automatically after
the set time has elapsed.
Charging Your De-
vices
Connect the standard end of a USB cable (not
included) to the USB port on the rear of the
unit and connect the other end to the charg-
ing port of your device. USB cables may dif-
fer by manufacturer, so be sure to use the one
provided with your device.
Some devices may not support
USB charging or may require a
higher power rating than this
product provides. Observe the
charging status on your device, or
refer to the manufacturer’s spec-
ications. There are many differ-
ent devices with different power
requirements; we cannot guaran-
www.naxa.com Page 9
tee charge support for all devices.
Ensure that your device is work-
ing properly before attempting to
charge it.
Dimmer Control
Press the DIMMER button to adjust the bright-
ness of the display.
Specications
Frequency Range FM 87.5 – 108 MHz
Power Supply AC 100-240V ~ 60/50 Hz
USB Charge Output DC 5V, 1A
Back-Up Battery 2 pc. UM-4 (AAA)
Specications are subject to change without
prior notice.
Support
If you have problems with your device, please consult the instructions in this manual. Please
also visit us on the web at www.naxa.com to get up to the minute news, alerts, and documenta-
tion for your device. For additional assistance, please contact Naxa Technical Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
http://www.naxa.com/naxa_support/
