Naxa NF-502 User manual

7TFTLCD Digital Photo Frame
with USB/SD/MMC CardSlot
MODELNO.:NF-502
USER MANUAL
 Thankyouvery muchforselectingourproduct.
 Pleaseenjoythewonderfulfeatures ofthelatestdigitaltechnology.
 You will learnhowtouse itwithinaminutewiththis usermanual.

Page 1
IMPORTANTINSTRUCTIONS
CAUTION: To reducetherisk offireorelectricshock,donotexposethisproductto
water,rain ormoisture. To preventtheriskofelectricshock,do notremove
thecoverorbackofthisproduct. In case ofproductfailure, onlyqualified
personnelcan repair.Thereareno user-serviceablepartsinside.
-Thedigital photo frameisforindooruseonly!
-Toavoid theriskoffireorelectricshock do notexposethisappliancetorain or
moisture.
-Do notblocktheventilation holesonthebackoftheunitatanytime.
-Keep theproductoutofstrong sunlight.Directsunlightmaycausedamage.
-Donotopenthecoverofthedigitalphotoframe.Therearenouserserviceableparts
inside.
-Unplug ACadaptorfrompowersocketiftheunitisnotinuse.
-Forpluggableproduct,thepoweroutletshouldbeinstallednearbyandshould be
accessible.
Maintenance:
-Touchthescreengently.Thescreeninthedigitalphotoframeismadeofglassand is
canbeeasilyscratchedorbroken.
-DisconnecttheACadaptorbeforemaintaining theplayer.
-Wipetheplayerwithadry,softcloth.
-Ifthesurfaceisextremelydirty,wipeitwithacleanclothwhich has beendippedintoa
weaksolution.Useanotherclothtodryup thesurface.
-Neverusealcohol, benzine,thinner,cleaningfluid orotherchemicals. And do notuse
compressedairto removedust.

Page 2
FEATURES
THANKSFORYOURPURCHASINGTHISDIGITALPHOTOFRAME.
THESE INSTRUCTIONSCANHELPYOUTOMAKETHEBESTUSEOFTHISPLAYER.
THEUNITSUPPORTSTHEFOLLOWINGMEMORYCARDFORMATS: SD, MMC.
-7inchTFT LCD
-Resolution:480(RGB)x234
-SupportsSD,MMCcardreader.
-SupportsUSB (not supportsremovableHDD).
-Supportsformat:JPG.
-Supportsstaticimage: slidedisplay, shrink,zoom,rotate.
-Supportscopyordeletepictures.
-Supportsmultilanguagesmenu: Englishandotherlanguages.
-Supportsclock andcalendar.
-Storeabout3piecesofpictureinbuilt-inmemory.

Page 3
TABLEOFCONTENTS
IMPORTANTINSTRUCTION.....................................................................................1
FEATURES................................................................................................................2
MAINUNIT..............................................................................................................4-5
BASICCONNECTION...............................................................................................6
BASICOPERATION...............................................................................................7-8
PHOTOPLAYBACK.............................................................................................8-10
LOGOOPERATION.................................................................................................10
COPY&DELETEOPERATION..........................................................................11-12
INITIALSETUP....................................................................................................13-15
SPECIFICATION......................................................................................................16
TROUBLESHOOTING.............................................................................................16
ACCESSORIES......................................................................................................16

Page 4
MAINUNIT
Frontview
Top view
1.Modebutton- Toswitchthedisplaymode:
AUTO, FULL,ORIGINAL.
2.Rightnavigation button- Tomoveright.
3.Leftnavigation button- Tomoveleft.
4.Upnavigationbutton- Tomoveup.
5.Down navigation button- Tomovedown.
6.MENUbutton- Toenterthemainmenu,or
exit.
7.ENTERbutton- Toenteratoolbar,press
left/rightbutton toselect, ortoconfirma
selection.
8.STANDBYbutton- TopowerON/OFFthe
unit.
TFT displaywindow

Page 5
Sideview
1.DC 5Vinput jack
2.USBconnection
3.SD/MMCcardslot
NOTE: Pleaseinsert thecardintocorrect position!
Back view
Stand holder

Page 6
BASICCONNECTION
Ensureall thecablesaredisconnectedfromthemainunitbeforeconnectingtoACpower
sourcebyACpoweradaptor.
Connecting topowersource
MAINUNIT
Topoweroutlet
ACadaptor

Page 7
BASICOPERATION
ONand OFF
Afterinstalltheunitand connectittothepowersocket, press STANDBYbutton,theunitwill
turnon.If you wanttoturnofftheunit youshouldpress thisbutton again.
AUTO-PLAY
Whenturnon theunit, itwillautomaticallyplaythepictures/photosinUSB, CARDorNOR
FLASHmemory. (IfinsertCARD orUSB intotheunit)
The playingorderis:
1.USBand CARDintheunit
Beforeconnectingpowersource,insert USB andCARDmemorydevicessimultaneously,then
thisunitwillplaythefilesin USB device. Connectpowersource,andinsertUSBand CARD
memorydevices, then thisunitwillplaythefilesinUSB orCARD memorydevice,depending
on whichdeviceisinsertedfirst.
2.OnlyCARDorUSBin theunit
The unit will playthefilesinCARDorUSB continuously.
3.No USBand CARDin theunit
The unit will playthefilesintheinternal memory(NORFLASH). IftheNORFLASHmemory
hasnopictures/photosfiles,thescreen willdisplayMAINMENUinterface.
Note: Whenautomaticallyplaying thefiles,if youpress MENUbutton, thescreen willdisplay
MAINMENU interfaceandauto-playaction willbestopped.Inthistime,youcan select SLIDE
SHOWitemtoplaythefiles.
Basicdisplay
-Press MENU button then thescreen will displayasbelow,choosetheitemyouwanttoplay.
-WithUSB device/Memorycardsrightlyinsertedintotheunit.
1.SLIDESHOW
-Press LEFT/RIGHT buttontoselect thisitemand press ENTERbutton toenterthebelow
interface, selectthestoragedevicewhatyouwanttoplayandpress ENTERbutton toconfirm.

Page 8
2.CALENDAR
-Press UP/DOWN/LEFT/RIGHTbutton toselectthisitem,thescreenwilldisplaythecalendar
asbelow:
PHOTOPLAYBACK
ACTIONS
1.During playback,press ENTERbutton toshowthetoolbar.
2.SelectafunctionitembypressingLEFT/RIGHTbutton,andthen press ENTERtoperform
thecorrespondingfunction.
TOOLBAR
1.PREVIOUSFILE: Toplaythepreviousfile.
2.PLAY/PAUSE: Toplaythefileorpausethefile.
3.NEXTFILE: Toplaythenextfile.
4.ROTATEFILE: Torotatethepictureplaying(clockwise)by90 .
5.SCREENMODE: Toswitchthescreen modeinauto,full, original(exceptfullscreen picture).
6.ZOOM/SHRINK: Tozoomorshrinkthepicturein 1x,1.5x,2x,0.5x,0.7x,then press MENU
button toentertheslidemode.
7.PICTUREINFORMATION: Todisplaytheinformation ofthepicture.
8.MINIATURIZED: Todisplay9piecesof miniaturized picture.
Year&monthdisplay
Picturedisplay Daydisplay
Currenttime
TOOLBAR

Page 9
PLAYBACK OPERATION
1.Select PREVIOUS/NEXT, then press ENTERtoplaypreviousornextpicture.
2. Select ROTATEthenpress ENTERtorotateonepictureclockwiseby90o.
3. SelectMINIATURIZED, then press ENTERtoenterpreviewmode, anine-pictureimage
displayson thescreen.Then press navigationbuttontoenternext pageorselect aphoto.
4. SwitchingtheCARD/USB/NORFlash
Onceyouinsert aCARD/USB,youwant toplaythefilesintheCARD/USB/NORFLASH.
YouneedswitchtheCARD/USB/NORFlashmodefirst.
1) Press UPnavigationbutton ontheunit continuouslytoswitchthemodewhichyouwanted
when theunitinslideshowmode.
2)Themodewilldisplayon thepictureinshort timewhen theunitinslideshowmode.
Asfollows:
3)Afteryouswitchingthemodewhichyouwanted, theunitwill playthepicturesin it.
SWITCH SWITCH
The mode in NOR FLASH. The mode in SD/MMCCARD mode. The mode in USB mode.
