Naxa ND-854 User manual

-1-

1
14. OUTDOOR ANTENNA GROUNDING - If an
outside antenna or cable system is connected to
the product, be sure the antenna or cable system is
grounded so as to provide some protection against
voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/
NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the g
rounding electrode. See Figure 1.
15. LIGHTNING - For added protection for this
product during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage
to the product due to lightning and power-line surges.
16. POWER LINES - An outside antenna system
should not be located in the vicinity of overhead
power lines or other electric light or power circuits,
or where it can fall into such power lines or other
electric light or power circuits. When installing an
outside antenna system, extreme care should be
taken to keep from touching power lines or circuits
as contact with them might be fatal.
17. OVERLOADING - Do not overload wall outlets,
extension cords, or integral convenience receptacles
a s this can result in a risk of fire or electric shock.
18. OBJECT AND LIQUID ENTRY - Never push
objects of any kind into this product through
openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the
product.
3. NONUSE PERIODS - The power cord of the
product should be unplugged from the outlet when
left unused for long periods of time.
19. SERVICING - Do not attempt to service this
product yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
20. DAMAGES REQUIRING SERVICE -
Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions.
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen
into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improving adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the product to its normal operation.
e) When the product exhibits a distinct change in
performance - this indicates a need for service.
21. REPLACEMENT PARTS - When replacement
parts are required, be sure the service technician
has used replacement parts specified by the
manufacturer or have the same characteristics as
the original part, Unauthorized substitutions may
result in fire, electric shock or other hazards.
22. SAFETY CHECK - Upon completion of any
service or repair to this product, ask the service
technician to perform safety checks to determine
that the product is in proper operating condition.
23. HEAT - The product should be situated away
from heat sources such as radiators, heat registers,
stoves or other products (including amplifiers) that
produce heat.
ANTENNA
LEAD WIRE
ANTENNA DISCHARGE UNT
(NEC SECTION 810-20)
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250,PART H)
GROUD CLAMP
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND
CLAMP
ELECTRIC
SERVICE
SQUIPMENT
EXAMPLE OF ANTENNA GROUNDING
AS PER NATIIONAL ELECTRICAL CODE
IMPORTANT SAFETY INSTRUCTIONS
DVD PLAYER
-2-

To protect intellectual property, the involved organizations partition the world into six regions, each of
which can only use the DVD player and DVD disc with the given regional code.
The illustration on the right shows symbols of the six regions. One DVD player with a given regional
code cannot play disc of another regional code. The partition of regional codes is shown as follows:
1. Canada, USA;
2. Japan, Europe, South Africa, Middle East
3. Southeast Asia, East Asia
4. Australia, New Zealand, Oceania, Central America, Mexico, Latin America, Caribbean Sea;
5. Russia, India, Africa, Korea, Mongolia.
6. China.
1 2 3456
Connecting to the multi-system TV
Connecting to NTSC TV Connecting to PAL TV
DISC
PAL
NTSC
TV MONITOR
Play in PAL system
Play in NTSC system
DISC
PAL
NTSC
TV MONITOR
No clear images are shown
on the screen.
Play in NTSC system
DISC
PAL
NTSC
TV MONITOR
Play in PAL system
No clear images are shown
on the screen.
TV connections for DVD discs recorded in PAL and NTSC systems
Generally, DVD discs are recorded in PAL or NTSC systems, please refer to the following table:
Note: THE REGION CODE FOR THE UNIT IS 1.
IMPORTANT SAFETY INSTRUCTIONS
DVD PLAYER
-3-

Please read the user manual carefully before connection or operation
TABLE OF CONTENT
Important Safety
Features
Precautions
Accessories
Front Panel
Rear Panel
Speaker Control
Remote Control
Basic Connection
Remote Control Preparation
Operations
Preparation
Play
Stop
Prev/Next
FB/FF
Slow
Step
Number(0-9,10+) button
Mute
VOL+/VOL-
Random
OSD
Zoom
A-B Repeat
Repeat
Angle
Audio
Program
PBC
TIME
Title/Chapter search
Menu
Subtitle
Video
DVD/USB
Clear
Setup
Reference(Menu/Submenu/Options)
Handing Precautions
player Maintenance
Definition of terms
Specifications
Troubleshooting
1-3
5
5
6
6
6
7
8
9-12
13
14
14
14
14
14
14
14
14
14
15
15
15
15
15
15
15
15
15
15
15
16
16
16
16
16
16
16
17
18
19
19
20
20
21
DVD PLAYER
-4-

Placement
Non-use Periods
Turn off the power when the unit is not used.
It should be unplugged when the unit is idle for a long period of time.
No fingers or other objects inside
Touching internal parts of this unit is dangerous, and may cause serious damage to the unit and
even human injury.
Do not try to disassemble this unit.
Do not put any other object on the disc tray.
Keep away from water and magnets
Keep the unit away from flower vases, tubs, sinks, etc. If liquids are spilled into the unit, serious
damage could occur.
Never place magnetic objects such as speakers near the unit.
The internal parts may be seriously damaged if the unit is placed in areas of:
Direct sunlight or heating radiators or closed automobiles;
High temperature (over 35 C) or high humidity (over 90%)
Excessive dust;
Strong magnetic or static electricity;
Vibration, impact or where the surface is tilted.
Stacking
Place the unit in a horizontal position and do not place anything heavy on it.
Do not put the unit on amplifiers or other equipment.
Condensation
Moisture may form on the lens under the following conditions:
In a steamy or very humid room.
Immediately after a heater is turned on.
If moisture forms inside this unit, it may not operate properly. In this case, turn on the power and
wait for about 1 hour to evaporate it.
Interference for the TV broadcast
Depending on the reception condition of the TV, interference may appear on the TV screen while
you are watching a TV broadcast and the unit is turned on, This is not a malfunction of the unit of
the TV. Just ensure that the unit is turned off when you watch a TV broadcast.
DVD - A completely new dimension in video entertainment
Subtitles may be displayed in one of a maximum of 32 languages available (multi-subtitles
DVD only).
Audio soundtrack can be heard in up to 8 languages (multi-languages DVD only).
Multi-angle function allows you to choose the viewing angles of scene
(for DVD with multiple camera angles only).
Other convenient features
A full function remote control provides quick access to DVD functions.
Compatible with PAL DVD and NTSC DVD
This player can play discs recorded in either PAL or NTSC system.
Power cord protection
To avoid any malfunctions of the unit, and to protect against electric shock, fire or personal injury,
please observe the following.
Hold the plug firmly when connecting or disconnecting the AC power cord to this unit.
Do not connect or disconnect the AC power cord when your hands are wet.
Keep the AC power cord away from heating appliances.
Never put any heavy object on the AC power cord.
Do not attempt to repair or reconstruct the AC power cord.
Remove dust, dirt etc. on the plug regularly.
If the unit has been dropped or otherwise damaged, turn off the power and disconnect the AC
power cord.
If you find smoke, unusual odour or noise from the unit, turn off the power and disconnect the AC
power cord.
DVD PLAYER
FEATURES
Compatible with CD besides DVD, MP3, CD-R
This player could play various discs such as DVD, CD (8cm/12cm discs).
PRECAUTIONS
Please read these precautions before operating this unit.
-5-

ACCESSORIES
(Please check whether all the following accessories are available after unpacking.)
Remote control
Instruction
Manual
Video/Audio cord
FRONT PANEL
DVD PLAYER
REAR PANEL
Note:
Unplug the plug-in and keep the power cord well when the player is idle for a long period in order
to avoid electricity leak and shock resulted from scratched power cord.
1. Disc tray
2. OPEN/CLOSE button
3. Play/Pause key
1. Right audio output jack
2. Video output
3.Left audio output jack
4. S-video output jack
4. Stop key
5.Power switch key
6.Remote control sensor
2
7
5
3 1 4
6
2
13 4 5 6 7
7.USB
5.AC power cord
6.Coaxial digital audio output jack
7.Component output jacks (Y, Pb/Cb,Pr/Cr)
PBC
TIME
CLEAR
DVD/USB
ND-8 54
-6-
ND-854

M/D : 1901- 01-20 12
Speaker Control
1.FRONT panel:
Master volume control
Bass volume control
Power ON/OFF
Audio Input Jack Audio Output Jack
2.Rear panel:
DVD PLAYER
-7-

Note:
The same buttons on remote control and front panel have identical functions.
REMOTE CONTROL
PBC
1
2
3
4
5
7
8
9
10
11
12
13
14
15
16
17
18
19
21
22
23
24
25
26
27
28
29
6
20
1. Open/Close button
2. 0-9/10+ button
3. Menu button
4. Move ▲▼◄►/ Enter
5. Prev/Next button
6. Fast reverse/Fast forward button
7. OSD button
8. Subtitle button
9. DVD/USB button
10. Angle button
11. Zoom button
12. Repeat button
13. A-B button
14. Program button
15. Clear button
16. Power button
17. Vol+/ - button
18. Mute button
19. Setup button
20. Play/Pause button
21. Title button
22. Audio button
23. Stop button
24. Video button
25. PBC button
26. Step button
27. Slow button
28. Time button
29. Random button
TIME
CLEAR
DVD/USB
ND-854
-8-

BASIC CONNECTION
Ensure that the power switch of this unit and other equipment to be connected is turned off before
commencing connection.
Read through the instructions before connecting other equipment.
Ensure that you observe the colour-coding when connecting audio and video cords.
A: Connecting to a TV with an AV Cable or S-VIDEO Cable
1. TV set (optional)
2. DVD/CD player
3. Video, R/L audio
4. To TV Audio, Video input connection
5. Video
6. To TV S-Video input connection
Note:
DVD/CD player Output Jack
DVD/CD player S- Output Jack(Video Output and S-Video Output optional insert).
Video = yellow, Audio Left = white, and Audio Right = red
DVD PLAYER
White Red Yellow
White
Red
Yellow
1
2
3
4
S-Video Cable
(not included)
5
6
AV Cable
-9-

BASIC CONNECTION
B:
1. TV set (optional)
2. DVD/CD player
3. DVD/CD player audio Output Jack
4. To TV set audio input Jack
5. DVD/CD player (Y/ Pb/Cb/ Pr/Cr) Video Output Jack
6. To TV set (Y/ Pb/Cb/ Pr/Cr) Video input Jack
Connecting to a TV with an AV Cable and Y/ Pb/Cb/ Pr/Cr Cable.
Audio Left = white, Audio Right = red. The yellow cable do not input. Note:
DVD PLAYER
1
2
5
6
White
Red
Yellow
White
Red
Yellow
AV Cable
Y / PbPr/ CbCr Cable
(not included)
4
3
-10-

DVD PLAYER
BASIC CONNECTION
M/D: 1 901-0 1-201 2
2
1
6
C: Connection to speaker
1. TV set (optional)
2. DVD/CD player
3. audio
5. The main speaker Audio Input Jack
6. To TV Video input connection
7. The main speaker Audio Jack
8. Connecting Speakers
DVD/CD player Output Jack
4. DVD/CD player Video Output Jack(
(
Output
The white and red cable do not input).
The white and red cable do not input).
3
5
4
7
8
White
Red
Yellow
Yellow
Red
White
-11-

BASIC CONNECTION
DVD PLAYER
D: Connecting to an Audio Receiver with a Coaxial Cable
1. TV set (optional)
2. DVD/CD player
3. DVD/CD player Video Output Jack(
4. To TV set Video input Jack(
5. DVD/CD player Coaxial Output Jack
7. Amplifier with decoder(Digital Speaker)Coaxial input Jack
The white and red cable do not input).
The white and red cable do not input).
1
2
White
Red
Yellow
White
Red
Yellow
AV Cable 4
3
5
6
-12-

REMOTE CONTROL PREPARATION
Battery Installation
Insert the batteries while observing the positive (+)
and Negative (-) polarities as Figure A.
Service life of batteries
The batteries normally last for a year although this
depends on the operation and on how often the remote
control is used.
If the remote control unit fails to work even when it is
operated near the player, replace the batteries with
new ones. Use size AAA UM-4 batteries (2 pieces).
Notes:
Do not use rechargeable (Ni-Cd) batteries.
Do not attempts to recharge, short circuit,
disassemble, heat or throw the batteries into fire.
Do not drop, step on the remote control, otherwise
it may damage the parts or lead to malfunctioning.
Do not mix old and new batteries. If the remote
control is not going to be used for a long time remove
the batteries. Otherwise, electrolyte may leak and
lead to malfunctioning or even burns by electrolyte.
Wipe away any electrolyte leaking inside the remote
control, and install new batteries.
If the leaking electrolyte has contact with some parts
of your body, wash it off thoroughly with water.
Remote control operation range .
The operation range of the remote control is no more
than 5m from and within about 60 degree wide in
front of the unit (Figure B).
The operating distance may vary according to the
brightness of the room.
Notes:
Do not point bright lights to the remote control sensor.
Do not place objects between the remote control and
the remote control sensor.
Do not use this remote control together with the
remote control of any other equipment.
DVD PLAYER
Remoto control sensor
Among 5 meters
30
。
30
。
ND- 854
POW ER USB
PBC
TIME
CLEAR
DVD/USB
ND-8 54
-13-

OPERATION
PREPARATION BEFORE PLAYING DISC
The option of display language catalogue is preset to English. Please refer to Setup operation
Most functions are operated by remote control. Either operation of remote control of front panel is
effective when their buttons indicate the same function.
Preparation
Turn the TV on and select AV as the TV input.
Switch on the related system power if the player has been connected to amplifier equipment etc.
PLAY/PAUSE
1. Connect AC power cord to AC outlet.
2. Switch on the power, the displayed LOADING indicates the normal power supply. (Note: the disc
information appears after several seconds if there has disc after LOADING displayed otherwise
appears NO DISC).
3. Press OPEN/CLOSE button.
4. Place a disc (8cm or 12cm) onto the tray. (For one-sided disc, position it with printed title side facing
up. For two-sided disc, position side to be playback facing down).
5. Press OPEN/CLOSE again to close disc tray.
6. Press PLAY/PAUSE to playback disc. You may operate according to MENU indication after MENU shows on
screen then press ENTER button to play back.
Some discs may play automatically after loaded.
STOP
Press STOP button to stop playing (TV show “PRESTOP” ). When play back is stopped the
unit records the point where STOP was pressed (resume function). Press PLAY again, and play will
resume from this point. Press STOP button twice, resume function will be cancelled. Resume function
is suitable for discs showing playing time during playback.
PREV/NEXT
Press PREV button or NEXT button on remote control when playing a disc, a chapter (DVD) or a track
(CD) is skipped backward or forward correspondingly each time the button is pressed.
FB/FF
Press FB/FF button on the remote control during playback, the disc will be played in a status of forward
or reverse correspondingly. Forward or Reverse speed is relatively slow at first. When press again, the
speed becomes faster. The more times that you press the buttons, the faster the Fast forward or
reverse speed will be. There are 5 levels of speed available: X2, X4, X8, X16and X32. To return to normal
play, press PLAY button on the player or the remote control.
SLOW
Press SLOW button on the remote control during playback and the unit will enter slow forward status.
There are 5 speeds available: 1/ 2, 1/ 4, 1/8, 1/16 and 1/32. To return to normal play. Press PLAY button
on player or remote control again.
Note: Some discs including MP3 disc have no such function.
DVD PLAYER
STEP
Press STEP button during play, the player will enter the still picture mode. If the button is pressed
again, the disc is advanced by one frame (step). When the button is kept pressed, consecutive frame
advance works. To return to normal play, press PLAY button.
Note: Some discs do not have such function.
Press PLAY/PAUSE key to stop playing and restore play by pressing PLAY/PAUSE key again.
Number (0-9,10+) button
By pressing the Number (0-9) button, you can access directly to the desired track or chapters while a
disc is played. For track or chapter over 10, press 10+ and then 0-9 button.
-14-

OPERATION
MUTE
Press MUTE button during play, the player shows mute and there is no audio output (silence), press
again to cancel MUTE.
VOL+/VOL-
Press VOL+/VOL- button play may change volume for audio output.
RANDOM
Press to select a random chapter.
OSD
Press OSD button during play to show the disc s relevant information on TV screen(such as playing
time, chapter number, playback status).
ZOOM
Zoom function can only be operated in JPEG disc and VCD/DVD format disc. By pressing zoom
button
When playing JPEG disc, there 5 levels of zoom available(150%, 200%, 25%, 50%, 100%)
when playing DVD/VCD discs, there are 3 levels of zoom available (ZOOMx2, ZOOMx4,
OFFx1).
Note: Note: Zoom function is not working on PAL system DVDs.
MP3 does not have this function
A-B REPEAT
Press A-B button during playback at the point where repeat play is to commence (a) then press again
at the point where repeat play is to be concluded (B). Repeat playback between point (A) and point (b)
starts. Press A-B button once more where TV screen appears REP OFF to return to normal play.
REPEAT
Press the repeat key to choose repeat play chapter or title (DVD) and play single audio or full disc
(VCD, CD, MP3).
Note: Some VCD do not have repeat function with PBC ON state.
DVD PLAYER
PBC function (only VCD)
When playing VCD 2.0 press PBC button to display title menu use number key choice and ENTER
button to play music.
PROGRAM
Press PROGRAM button, the program pl a y b a c k screen appears on the TV monitor, 20 t r a c k s
or chapters can be programmed. Us e bu t t o n on the remote control to s e le ct your
preferred track (CD/VCD) or title an d chapter (DVD), then press ENTER bu t t o n to confirm(also
you can press the number bu t t o n to input the track number o r title/chapter number directly).
ANGLE
Press ANGLE continuously during playback DVD disc to toggle the disc between available angles
recorded on the disc if the disc has multi-angle function. Press AUDIO button during playback to
toggle between available audio language recorded on the disc if the disc has this multi-language.
Note: Press AUDIO button could toggle available audio language soundtracks.
Note: It is invalid to input the number larger than available. Use CLEAR button to amend false or
unsatisfied settings. You can only press the PLAY button on the remote control to start playing after
you finish the program setting. Press the PROGRAM button directly to return to normal play mode.
In this case, the program is not confirmed.
: SELECT : PLAY shown on screen is only used for indication, no function for cursor.
AUDIO
Press AUDIO button during playback to toggle between available audio language recorded on the
disc if the disc has this multi-language.
Note: Press AUDIO button could toggle available audio language soundtracks.
-15-

OPERATION
TIME
In the play, you press TIME button on the remote control. You can search the disc based on its title/
chapter/track as shown in the figure. Press TIME button, a search menu will display. Use or
button to select the search item/time/titel/chapter. The selected will be shown in highlight.
Use number button to select the search item/time/title/chapter, and press ENTER button to play. For
example:
Time search: To search 16 min 50 secretary: input 1,6,5 and0.
To search 1 hr 14 min: input 1,1,4,0,0.
Title/chapter search:
To search titel 1/chapter 2: input 1 in the highlight titel column, move the cursor right to the highlight
area and input 2.
Note:
For some DVD discs which cannot be searched, invalid will be appear on TV screen.
Input the time, title and chapter of the disc to search.
For VCD in PBC mode is ON, it can only search for the time.
MENU
Press MENU button on remote control when playing a disc, a list of titles on the disc (depends on discs)
will be displayed on TV monitor. Use the direction or number button to select your preferred items then
press ENTER button to play as selected.
SUBTITLE
Press SUBTITLE button on remote control during playback. Subtitle: [1] will be displayed on TV monitor
that means a kind of language. Press once more, Subtitle: [2] appeared on TV monitor means another
kind of language and accordingly subtitles appear that represents how many kind os language being
selected. Subtitle: [OFF] appears that toggle subtitle.
Note: This function is valid only for DVD discs with subtitle function. It is invalid for DVD disc with single
subtitle function.
◆DVD/USB
When reading disc, press STOP button to stop playing, press USB button on remote, on TV screen will
display USB option, use direction button to choose your desired option, press ENTER button to confirm,
then player will play the content from the option that you selected.
DVD PLAYER
VIDEO
Press VIDEO button to use direction to select the video output progressive scan (YPbPr) or other mode
(S-VIDEO,YUV,YPbPr).
◆CLEAR
Delete entries from the programmed playback window.
-16-

SETUP
Once the initial settings have been completed, the player can always be operated under the same
conditions (especially with DVD discs). The settings will be retained in the memory even after turning
off the power until the settings are changed. We set the initial language to English when the player is
out of factory. You may change the language into that you preferred.
Operation
1. In stop mode, Press SETUP button to enter setup interface as followed, you can setup Language,
Screen, Custom.
SETUP
DVD PLAYER
2. Press and to choose the desired section and ENTER button to enter submenu or press SETUP
to leave the setup screen. Following is the language setup screen for your reference where you can
set OSD menu, DVD menu, Audio Language and Subtitle Language.
Language Setup
OSD
Menu
Audio
Subtitle
Language Setup
OSD
Menu
Audio
Subtitle
English
German
Spanish
French
-17-

REFERENCE
Menu, Submenu and Options
DVD PLAYER
MENU SUBMENU OPTIONS DESCRIPTION
LANGUAGE
SETUP
OSD
MENU
Audio
English
French
Geman
Spanish
English On Screen Display
French On Screen Display
Geman On Screen Display
Spanish On Screen Display
Subtitle
English
French
Geman
Spanish
others
English On Screen Display
French On Screen Display
Geman On Screen Display
Spanish On Screen Display
English
French
Geman
Spanish
others
English On Screen Display
French On Screen Display
Geman On Screen Display
Spanish On Screen Display
English
French
Geman
Spanish
others
Off
English On Screen Display
French On Screen Display
Geman On Screen Display
Spanish On Screen Display
-18-

DVD PLAYER
REFERENCE
MENU SUBMENU OPTIONS DESCRIPTION
SCREEN
SETUP
TV Type
4:3 PS
4:3 LB
16:9
Screen Saver On
Off
TV System
NTSC
PAL
AUTO
Video output
CVBS+S-Video
Brightness
Normal
Bright
Soft
Contrast
-4
-3
-2
-1
0
+1
+2
+3
+4
CUSTOM
Angle Mark On
Off
Default Reset
Set TV screen at 4:3 Pan Scan
Set TV at screen 4:3 Letter Box
Set TV at screen 16:9
Output signal as AUTO
Output signal as PAL
Output signal as per default of disc
CVBS+S-Video output
Select normal, bright, or soft to personal
preference.
Select various levels to adjust the contrast
according to personal preference.
Set screen saver to ON or OFF.
Set the Angle mark to ON or OFF
Return to factory setup
Style
Style 1
Style 2
Style 3
Style 4
Digital out
Audio Setup
Lo/Ro
Lt/Rt
Handling Precautions
Maintenance
Hold the disc by the edge so the surface will not be soiled with fingerprints. Fingerprints, dirt and
scratches can cause skipping and distortion. Do not use record cleaning sprays, benzene, thinner.
Static electricity prevention liquids or any other solvent. Be careful not to drop or bend the disc. Do not
try to close the disc tray when disc is not installed properly. Be sure to store the disc in its exclusive
case when not in use.
Handling
Wipe gently with a soft, damp (water only) cloth. Move the cloth from the centre hole towards the outer
edge. lmproper disc disc storage: Discs may be damaged if they are stored in the following places: Areas
exposed to direct sunlight; Humid or dusty areas; Areas directly exposed to a heat outlet or heating
appliance.
Player Maintenance
Be sure to turn the unit off and disconnect the AC power cord before maintaining the unit. Keep the unit
clean. If the surfaces are extremely dirty, wipe the unit with a dry soft cloth. Never use alcohol, benzene
or other chemicals. Do not use compressed air to remove dust. Ask the technician to maintain the unit
when trouble happens.
Change the background colour of OSD
Left only/Right only
Left total/Right total
Spdif/pcm
Spdif/raw
off
CVBS+YUV
YUV P-SCAN
YUV video output
SCAN video output
Down mix
-19-
