NC-link NC-AP212 User manual

User Manual of 5.8G Outdoor CPE
This is the manual of outdoor CPE, which will approximate guide you how to set and apply the outdoor CPE, it provide
a convenient graphical interface for network construction and maintenance person, as well as a user through a simple
and accurate operation, and configuration management of the CPE.
1st Connection and Power Supply

1st：Port Connection and power supply
Instruction of different port：
P1 CPE Port Connection
1) Please use a power supply of 12V DC adapter or 24V POE adapter, WAN / LAN port is the PoE Port.
2) Reset:
There are two ways to reset the CPE:
a).CPE Manage page: Click “Management”, then “Save/Reload Settings”, then click“Reset Settings”to finish the CPE
Reset
b) Press the Reset Button on CPE more than 15 seconds, then release, the device will reboot and restore to factory
settings
3) The connection way of CPE, PoE Adapter and PC:
PayAttention
Pls make sure the CPE’s power supply is normal in reset process, or the CPE will be
damaged and can’t reboot

P2 Connection diagram of CPE and PoE adapter
2nd Steps：Login
1）Connect the CPE with computer as P2 picture
2）Configure the PC’s local connection IP address as 192.168.188.X (X is number from 2 to 252), subnet mask is
255.255.255.0, follow P3 and P4 to finish.
P3 Setting of computer’s IP address
PayAttention
Incorrect Connection or the use power adapter and PoE adapter not from our
factory, the CPE will be damaged

P 4 Setting of computer’s IP address
3) Input http://192.168.188.253 into IE browser, then pop up the login page, the default login user name: admin,
Passwords: admin, pls do following P5
P5 Login

4) After login, then P6 will be showed:
P6: Device Status
3rd：Quickly Configure CPE
1) Gateway Mode configuration
A. Login the Web management page, click “Gateway Mode”, then you can start configure “Gateway Mode”
P7 Gateway Mode
WAN Access Type: Dynamic IP or PPPOE(ADSL)
a).Dynamic IP:
①. If your access type is Dynamic IP, then you can get the IP address from the ISP. It means you only need connect
the ISP line with internet to the router’s WAN port, needn’t configure.

②. Wireless Basic Settings
SSID:Wireless LAN status authentication name ,User can access the wireless networking through status
authentication name only.
Channel:Choose a channel which few users use, it is clear and better. Can use Intelligent Analysis to choose the best
channel.
Key: Wi-Fi password, default password is :66666666
b).PPPOE(ADSL)
If your access type is PPPoE, with ADSL virtual dialing, you need to fill in following details:
User Name: Fill in ADSL access user name which supply by ISP, if you not sure can check with ISP.
Password: Fill in ADSL access password which supply by ISP, if you not sure can check with ISP.
2) Repeater Mode configuration
A. Login the Web management page, click “Repeater Mode”, then “Scan AP”
P8 CPE Station Mode configuration
B. Click “Scan AP”, pop up the picture of P9, Take WirelessAP 2 as example, choose wirelessAP 2 and click “Select
AP” after “Refresh”

P9: Scan AP and Select AP
C. Input the AP’s password in P10
P10: Password
D.Click “Apply Changes”, the system will reboot again
3) AP Mode Configuration:
Choose “AP mode”, outdoor CPE can work as a wireless access point in AP operation mode:
Instruction
If your computer can’t pop up the window of P9, pls check your IE explorer and see whether it is blocked
already. And if this CPE can’t scan any SSID, pls check if there are 5G wireless signal.

Set the SSID user required, then set it in right Authentication and input Key for outdoor CPE, thenApply Changes.
P11AP Operation Mode
SSID:Wireless LAN status authentication name ,User can access the wireless networking through status
authentication name only.
Channel:Choose a channel which few users use, it is clear and better. Can use Intelligent Analysis to choose the best
channel.
Key: Wi-Fi password, default password is :66666666
4) WISP Mode
Click “WISP” mode, outdoor CPE will work with WISP mode
P12 WISP Mode
WANAccess Type: Dynamic IP or PPPOE(ADSL),choose the right way.
a).Dynamic IP:
①. If your access type is Dynamic IP, then you can get the IP address from the ISP. It means you only need connect
the ISP line with internet to the router’s WAN port, needn’t configure.
②. WISP

Then “Scan AP”, choose the AP which do you want to link and select it
Take WirelessAP 2 as example, choose wirelessAP 2 and click “Select AP” after “Refresh”
P13 Scan AP
Key: Input WirelessAP 2’s password
b).PPPOE(ADSL)
If your access type is PPPoE, with ADSL virtual dialing, you need to fill in following details:
User Name: Fill in ADSL access user name which supply by ISP, if you not sure can check with ISP.
Password: Fill in ADSL access password which supply by ISP, if you not sure can check with ISP.
5) LAN Setting
Click ”Advanced Setting”, can check as p14
P14 Advanced Settings
Click “Network Settings”→ “ LAN Interface, P15 will be showed

IP address: it is CPE’s management address. =
DHCP Sever, “ Enaled”, the default DHCP sever is Enabled, no need to change.
P 15 LAN Setting
After finish the LAN setting, user can check the LAN status from P16:
P16: LAN Status
6) Management
Time Zone Settings: User can choose the right time zone, then Apply
P17 Time Zone Setting
Log: Log info on outdoor CPE

Upgrade Firmware: Select the right firmware, then upgrade, after upgrade it, pls reset outdoor CPE and
waiting for reboot.
Save/Reload Settings: User can save or upload outdoor CPE’s settings, then can reset or reboot outdoor
CPE.
Password: Set Administrator’s Password, then Apply changes
Advanced Setting: User can use more functions if required.

7) PC setting
Set computer’s TPC/IP as Obtain an IP address automatically, Obtain DNS server address automatically as
following picture showed. the computer will abtain the IP address from router or base station.
8) Trouble Shooting:
F 1 The Failure phenomenon and solution
Failure phenomenon
Solution
SYS Indicator off
Pls make sure the PoE module connection is right. POE Port
connect with CPE, LAN port connect with computer
Can’t land to CPE through Web page
Pls check the IP address of computer and CPE to see whether they
are in same networking segment, The method is click “start”-“Run”
input“cmd”，ping 192.168.1.1 to test the CPE connectivity.
Reset CPE and load it again；
Pls make sure the IP address 192.168.1.1 is not occupied by other
device in CPE’s networking;
Check computer and cable problem, recommend to use 10/100M
UTP unshielded cable;
Clean up Arp binding from “Start”-“Run” input“cmd” arp –d
Clean the IE Brower’s temporary files and Cache file。
CPE can’t connect with AP
（the status display unconnected）
Try to scan the avaliable wireless networking again；
Make sure the CPE’s wireless standard（11b/g/n, 5.8G）is correct；
The Security and passwords are matched between CPE and AP；
The signal strength of AP is too weak to connect, should be more
than -75dBm；
Can’t scan the wireless AP
Scan it several times more；
Make sure there are 5G signal existed.
Reset the CPE, scan it again after CPE restart；
The connection of CPE and AP is
success, but the computer can’t share
Pls Check the computer’s IP address and DNS setting. If it is
dynamin, set the network card as automatically obtain. If it is static

internet
IP, pls contact with ISP for correct IP address and DNS address.
How to Reset CPE
Press the “Reset” button more than 15 seconds after power on. The
CPE will restore factory default after the CPE restart.
