NCR Invenco 6005-0014-8801 User manual

Retrofit G6-300 + InvencoLink Wayne Vista 3V
(US) Installation Guide00
Kit Number: 6005-0014-8801
B005-0000-2507
497-0526831
Issue C

Document Number
DCV-00470
Date Released
Jul. 2020
Revision Number/Security level
R03 S2
Retrofit G6-300 + InvencoLink Wayne Vista 3V (US) Installation Guide
Retrofit G6-300 +
InvencoLink
Wayne Vista 3V (US)
Installation Guide
Kit Part Number: 6005-0014-8801

2
Document Number
DCV-00470
Date Released
Jul. 2020
Revision Number/Security level
R03 S2
Retrofit G6-300 + InvencoLink Wayne Vista 3V (US) Installation Guide
Release History
Version
Prepared by
Date
Change description
0
Michael Doh
05-Dec-2019
Based on the G6 US version (DCV-
00402). Initial version to be approved
by UL
1
Michael Doh
09-Dec-2019
Corrected typing errors
2
Michael Doh
06-Apr-20
Updated panel assembly part
number
3
Michael Doh
10-Jul-20
Updated the PSU assembly to CID2
PSU variant
© 2020 by Invenco Group Limited
All rights reserved
No part of this document may be copied or reproduced in any form without prior written consent from Invenco.
Invenco has taken great effort to verify the accuracy of this document but assumes no responsibility for any technical
inaccuracies or typographical errors

3
Document Number
DCV-00470
Date Released
Jul. 2020
Revision Number/Security level
R03 S2
Retrofit G6-300 + InvencoLink Wayne Vista 3V (US) Installation Guide
Contents
Release History.....................................................................................................................2
1 Introduction....................................................................................................................4
1.1 Tools Required .......................................................................................................4
1.2 Installation Kit Contents..........................................................................................5
2 Safety & Compliance Information...................................................................................6
2.1 Preliminary Precautions..........................................................................................6
2.2 Emergency Total Electrical Shut-Off.......................................................................6
2.3 Total Electrical Shut-Off Before Access ..................................................................6
2.4 Evacuation, Barricading and Shut-Off.....................................................................6
2.5 Read the Manual ....................................................................................................6
2.6 Follow the Regulations............................................................................................7
2.7 Replacement Parts .................................................................................................7
3 Safety Symbols and Terminology...................................................................................7
3.1 Prevent Explosions and Fires .................................................................................7
3.1.1 No Open Flames..............................................................................................8
3.1.2 No Sparks - No Smoking .................................................................................8
3.1.3 Working Alone .................................................................................................8
3.1.4 Working with Electricity Safety.........................................................................8
3.1.5 Hazardous Materials........................................................................................8
3.1.6 In an Emergency..............................................................................................8
3.1.7 Approvals.........................................................................................................9
3.2 Computer Programs and Documentation................................................................9
4 Disassembly Procedure...............................................................................................10
5 Pre-Installation Procedure............................................................................................40
6 Installation Procedure..................................................................................................41
6.1 Wiring Completion.................................................................................................57
7 First Power-Up.............................................................................................................58

4
Document Number
DCV-00470
Date Released
Jul. 2020
Revision Number/Security level
R03 S2
Retrofit G6-300 + InvencoLink Wayne Vista 3V (US) Installation Guide
1 Introduction
The documentation provides some basic guidelines for installing the Optic 5 Touch/ G6-300 Outdoor
Payment Terminal (OPT).
This Retro-Fit Kit can be installed into either Side A or Side B of a Wayne Vista 3V dispenser;
•For a single-sided installation, or if this Kit will be installed into Side A (i.e. the first side
installed) of a double-sided installation, it requires the pre-installation of UL Listed by Report
Retrofit Kit Part Number 6009-0008-8801 (InvencoLink Converter) before installation into the
dispenser. The process is covered in §4.2 Pre-Installation Procedure of this instruction, by reference
to the instructions in that Kit.
•For a double-sided installation, two of these Kits are required.
1.1 Tools Required
The following tools are required to mount the G6-300 OPT:
•Torx T25 security screwdriver
•Short Philips #1 screwdriver
•Philips #1 screwdriver with >5” shaft
•Flat 5mm screwdriver
•Small adjustable spanner
•Side cutters
•Cable (zip) ties
•Pliers
•¼” Socket or Nut Driver
•3mm Hex Key
•3” wide jaw Vice Grips
•Standard Vice Grips
•7/32” Socket or Nut Driver
•Flat File
•Disposable drop cloths (eg large
kitchen cloths)
•Magnets
•Neodymium magnets
•Small plastic bag
•Nail polish
•Hacksaw
WARNING
Do NOT use power tools if working on a fuel station
forecourt.
Any spark could cause an explosion.
