NearBeBe Care Plus User manual

NearBéBé Care
Infant Health Monitoring System
NearBéBé Care
Product & Mobile APP User Guide Book
Manual

Prologue
Product Introduction
Safety Precautions
Disposal
Product Service
Part Names
Product Description
How to Use the Product
Appendix
Product Specifications
Electromagnetic Compatibility
Certification Indication
Symbol Description
Product description
Product features
Main unit
NearBéBé Station
Components
Usage Preparation
Product management
Product storage
Battery charging method 
Power on and off
03
04
04
04
05
05
06
06
06
07
07
07
08
08
08
09
10
11
14
15
20
21
Contents
P - Page Number
Product Manual

02
03
04
05
06
07
09
10
12
13
M - Page Number
Mobile APP Manual
App Installation Preparation
App Usage Guide (NearBéBé Plus)
Nearbebe Station
App launch
User registration
Station registration
Wi-Fi connection
Profile registration
Linking Station and Care
Station settings
App icon function
˙˙˙˙˙˙˙˙˙˙˙˙
˙˙˙˙˙˙˙˙˙˙˙˙
˙˙˙˙˙˙˙˙˙˙˙˙
˙˙˙˙˙˙˙˙˙˙˙˙
˙˙˙˙˙˙˙˙˙˙˙˙
˙˙˙˙˙˙˙˙˙˙˙˙
˙˙˙˙˙˙˙˙˙˙˙˙
˙˙˙˙˙˙˙˙˙˙˙˙
˙˙˙˙˙˙˙˙˙˙˙˙
˙˙˙˙˙˙˙˙˙˙˙˙

P - 01
Care main unit user guidebook
Product Manual

P - 02
Thank you for purchasing NearBéBé Care.
In order to use this product for a long time with safe operation without troubles,
please read the user's manual of the product before using the product, and fully
understand the operation method and precautions before use.
“
”
❖ Users should follow the instructions below.
- When using this product, be sure to follow the instructions in the user manual.
-The company is not responsible for product problems caused by user's careless operation or careless management.
- All repairs to this product may only be serviced by the company or an authorized dealer.
- If this product does not operate normally, contact the service center or company that has been certified.

P - 03
If you have any questions or problems related to the
use of this product, please contact us at any time. In the
event that a user or patient is injured due to the user's
negligence or misuse, the company or the authorized
dealer is not held responsible.
The following terms are used in this manual to highlight
safety and precautions to be followed when using the
product.
Caution Warning Prohibition Note
It indicates content that may
cause personal injury or
property damage if handled
improperly.
It indicates that a person
could be killed or injured if
handled improperly.
It indicates what should not
be done when using the
product.
It is a term explanation or
additional operation method
that is used for normal
product use.
❖ Users should be fully aware of the warnings, cautions,
prohibitions, and notes indicated in the entire manual of this
product to use the product safely.
Prologue

P - 04
Product Features
NearBéBé Care is a product that mearsures the body's skin
temperature by wearing it on diappers of clothing. Infant sleeping
postures and abdominal movements can be monitored in real
time, and the alert setting function makes it possible to safely
check the child's condition condition even when the guardian is
sleeping or monitoring intermittently. Since the measured skin
temperature or abdominal movement is stored as a trend graph in
the mobile app, the guardian can check it later.
This product measures the skin temperature
of the abdomen by wearing it in a diaper or
clothing without attaching it to the skin as a
separate patch. Body temperature range(the
following is an average of normal body
temperature ranges), environment, time, and
physical activity may vary.
This product can be used for all ages, but if it
is a user who needs caregiving. Please use it
under the supervision or management.
Normal body
temperature
by body part
Forehead 35.0 ~ 37.5℃
Armpit 34.7 ~ 37.3℃
Oral 35.5 ~ 37.5℃
Anal 36.6 ~ 38.0℃
Ear 35.8 ~ 38.0℃
Normal body
temperature by age
0~2years 36.4 ~ 38℃
3~ 10years 36.1 ~ 37.8℃
11 ~
65years 35.9 ~ 37.6℃
65years or
older 36.8 ~ 37.5℃
Continuous skin temperature monitoring and recording
Through the mobile app, you can measure the skin temperature of
infants in real time and monitor them for along time.
❖ Among the functions of the product, sleep posture and abdominal
movement are not medical functions except for skin temperature
measurement.
Note
Caution
Product Introduction

P - 05
Main
unit
①
③
②
④
⑤
⑥
① Operation LED status indicator
② Power button
③ Battery LED status indicator
④ Charging terminal (terminal contacting the
charging cradle)
⑤ Temperature probe (skin temperature sensor)
⑥ Clip (for wearing on diapers or clothing)
Operation LED status display information
Battery LED Status Display Information
Common Operation during product
charging
Blue
(flashing)
Low battery
or abnormal
condition
Blue
(light on) Charging product
Blue
(light off)
Product charging
complete
Status display before Bluetooth connection
Sky blue (flashing) Ready for Bluetooth connection
Product not worn (always on)
Green (flashing) Temperature/hygrometer
operation display
Wearing the product
(Operates when the power button is pressed)
Pink (3 flashes) Product normal connection
Part names

P - 06
NearBéBé
Station
Components
NearBéBé Care NearBéBé Station USB cable
※ Image and
actual product may
be different, and
some items may
be changed due to
circumstances.
+ 1 copy of Quick Manual
Download the product manual and
Mobile app manual from the homepage.
Note
Note
The battery charge may be
low when the product is
shipped. Be sure to use it
after charging.
For more details on Nearbebe Station, please
refer to the Mobile APP Manual
Product Description
Part names
① Cradle cover
② Charging pogo pin (body charging contact)
③ Status indicator
④ Micro 5-pin USB terminal (USB cable insertion part)
①
②
④
③

P - 07
Usage
preparation
Product
management
Product storage
① Open the packaging box and check the product components.
② Please read the product manual and mobile app manual carefully before use.
③ Use within an ambient temperature of 10 ℃ to 40 ℃ and relative humidity (non-condensing)
within 15% to 85%.
① Before using the product, wipe the back side with an alcohol pad.
② After using the product, always keep it clean.
③ If the body is stained, wipe it with a dry soft towel.
④ In the case of severe contamination, remove water from a towel moistened with water or a
neutral detergent and wipe again with a soft cloth.
① Please store the product in the charging cradle.
② Ambient temperature : Store within -20℃ ~ 60℃ and relative humidity (non-condensing) within
15% ~ 95%.
③ Keep it out of the reach of water.
④ Be careful and store it in a stable state such as inclination, vibration, and shock (including
transportation).
⑤ Do not store in chemical storage or gas generating areas.
⑥ Do not store in a place with high temperature and humidity, in direct sunlight, near a heating/
heating device, in a dusty place, or in places affected by salty atmosphere.
Product Description

P - 08
How to charge the battery
Power on and off
① Place the product on the NearBéBé Station.
② Charge it by connecting it to the 5V output adapter using the
USB cable provided as a component in the NearBéBé Station
equipped with the product.
③ The battery LED (blue) lights up during battery charging.
④ When charging is complete, the battery LED (blue) turns off.
① If the power button is pressed when the product is turned
off, the power turns on with the blue LED blinking.
② If you press the power button for 2 seconds, the vibration
will sound and the power will turn off.
If nothing happens when
you press the power button,
proceed with charging. If the
problem still occurs, please
contact us.
Note
How to use the product

P - 09
Warning
Caution
˙Self-diagnosis and treatment of body temperature measurements are dangerous. Please follow the guidance of
a doctor.
˙If an abnormality is found in the product, immediately stop the operation of the product and contact the
manufacturer for inspection.
˙This product can be used for all ages. However, in case of high fever, be sure to use it according to the doctor's
instructions.
˙Be careful not to let anyone other than the user come into contact with the product, and contact the manufacturer
in the following situations.
- In case of abnormal reaction (skin, allergy, etc.) on the skin
- When an error occurs in the overall product
- When used in combination with other medical devices, when the measured skin temperature changes significantly
˙Be sure to use a USB 5V power source that is rated. Be careful not to damage the product.
˙Be careful not to let liquids or foreign objects get into the body.
˙If heat is detected in the product, be sure to remove it from the human body.
˙Since this product is used in conjunction with a mobile app, it may not operate properly depending on the
location and power status of the mobile device. Therefore, use it in accordance with the following.
- For continuous measurement of skin temperature, use an auxiliary battery or adapter on the mobile device to
maintain the power supply.
- Make sure that the product and mobile device do not deviate more than 15m (based on open area).
- If your child is lying down, the communication distance between the mobile device may be significantly reduced.
- When multiple apps are used at the same time or not used for a long time, the apps may be automatically
terminated under the mobile operating system, and in this case, the notification may not sound normally.
Safety precautions

P - 10
˙ Use after 30 minutes has elapsed after the measurement target has entered the room from the outside or the
thermometer has been moved to a location with a different temperature environment.
˙ When wearing the product, wear it as close to your skin as possible. If it is not in close contact, it may malfunction
when it detects skin temperature, sleeping position, and abdominal movement.
˙ Do not touch the product with wet hands.
˙ Sleep posture, abdominal motion measurement and notification functions cannot be used for medical purposes.
˙ Be careful for the infant to not to swallow the product or put it in themouth.
˙ Do not disassemble, repair or modify the product.
˙ This product is not waterproof. Do not immerse or wash in water.
Dispose of products and accessories appropriately in accordance with local regulations.
Caution
Prohibition
Disposal
Safety precautions

P - 11
Product name Place of purchase
Model name Date of purchase
Serial No. Customer name
Contact E-mail
Address
Consumer damage types
Compensation
Within the
warranty period
After the warranty
period
Normall use
When defect occurs Free repair Paid repair
When the same defect occurs twice Product Exchange Paid repair
Consumer's
intention or
negligence
Failure due to user error Paid repair Paid repair
Failure and damage caused by
disassembly, modification of
structure, performance and function
Paid repair Paid repair
Product Warranty
Consumer damage
compensation
standard
Product service

P - 12
Consumer damage
compensation
standards
ⓛ This product secures excellent quality through strict inspection.
② The basic warranty period for this product is 1 year from the date of purchase.
③ If any of the following situations occur within the quality guarantee period, it will be
charged for processing.
- Malfunction caused by improper use, such as operation not in accordance with the
instruction manual
- Failure or damage caused by a drop or external impact after purchasing the product
- Natural disasters such as fires, earthquakes, floods, and lightning
- When damage occurs due to use and storage in an environment where the use of
products such as high temperature, high humidity, compounds, microorganisms, etc.
- Failure caused by sand, dirt, etc.
- If the contents of the purchase date, customer name, store name, manufacturing
number, etc. are changed arbitrarily
- If there is no evidence of product purchase along with the product warranty
- Failure or damage caused by other types of consumer negligence
Product service

P - 13
Product specifications and electromagnetic compatibility
Appendix

P - 14
Product specification
Product name NearBéBé Care Plus Model name NB-TM1, NB-WC1
Electrical rating - Charging voltage : DC5V (USB voltage)
- Battery : DC 3.7V, 100mAh, Lithium polymer Measuring range 30.0℃ ~ 42.0℃
Measurement
precision
±0.2℃ within the temperature range from 30.0℃
to 42.0℃ (based on room temperature)
Storage
environment
conditions
- Temperature : -20℃ ~ 60℃
- Humidity : 15%~95% (non-condensing)
- Air pressure : 700 ~1060hPa
Environmental
conditions
- Temperature : 10℃ ~ 40℃
- Humidity : 15%~85% (non-condensing)
- Air pressure : 700 ~1060hPa
Dimension &
Weight
Main unit (43x43x16mm, 15g)
Charging cradle (72.5x55x27mm, 40g) USB
cable (100cm, 15g)
Classification of
mounting BF type mount Minimum scale
unit 0.1℃
Abdominal skin
temperature
display
Displayed in app
Continuous
measurement
time
Within 20 hours (based on battery charge)
Minimum
measuring time Within 1 minute Operation mode Direct mode
Distance from skin
temperature display
device
Within 15m of open area Components Main unit 1EA, Charging cradle 1EA, USB cable
1EA, Product User Quick Guide
App compatibility Android4.3 or higher, iOS8.0 or higher Product color Sky Blue, Pink, Shine Orange

P - 15
Guidance and manufacturer's marking-electromagnetic radiation
This product is designed to be used in the following electromagnetic field environment.
Consumers or users of this product must use the product in the following environments.
Radiation check Compliance Electromagnetic environment-guidelines
Radioactive (RF) radiation CISPR 11 Class 1
This product radiates RF energy only for its internal function. Therefore, the RF
radiation of this product is low and there is very little possibility of interference
with nearby electronic products.
Radioactive (RF) radiation CISPR 11 Class B
This product is suitable for use in any domestic facility, including domestic
facilities that directly connect to public low voltage power supplies supplied for
use in building purposes
Harmonic radiation IEC 61000 -3-2 Class A
Voltage fluctuations/flicker emission
IEC 61000-3-3 Application
Electromagnetic compatibility
Guidance and manufacturer marking-Electromagnetic immunity
This product is designed to be used in the following electromagnetic field environment.
Consumers or users of this product must use the product in the following environments.

P - 16
Immunity Check IEC 60601 inspection level Compliance level Electromagnetic environment-guidelines
Electrostatic discharge (ESD)
IEC 61000-4-2
±6 kV Contact
±8 kV Air
±6 kV Contact
±8 kV Air
Flooring should be made of wood, concrete or
porcelain tiles. If the floor is covered with synthetic
materials, the relative humidity should be at least
30%.
Electrical rapid conversion/
explosion IEC 61000-4-4
±2 kV for power supply line
±1 kV for input/output lines Not applicable The power quality of the power source must be from
a typical commercial or hospital environment
Surge IEC 61000-4-5 ±1 kV differential mode
±2kV common mode
Voltage drop, short circuit
interference and voltage
fluctuations in the power
supply input line IEC 61000-4-
11
< 5 % UT for 0.5 cycle (95 % reduction of UT) The power quality of the power source should be that
of a typical commercial or hospital environment. When
the user of this product needs to use it even during a
power outage, it is recommended that the product
be powered from an uninterruptible power supply
system or battery.
40 % UT for 5 cycles (60% reduction of UT)
70% UT for 25 cycles (30% reduction of UT)
<5% UT for 5 seconds (>95% reduction of UT)
Power frequency (50/60 Hz)
magnetic field IEC 61000-4-8 3 A/m 3 A/m The power frequency magnetic field should be at the
level of a typical ommercial or hospital environment.
※ Note UT means AC voltage power before applying the check level.
Electromagnetic compatibility

P - 17
Susceptibility check IEC 60601 test
conditions
Compliance
level Electromagnetic environment-guidelines
Conducted RF IEC
61000-4-6
3 Vrms
150 kHz ~ 80 MHz 3 A/m
Portable and mobile radios should not be located near any part of the product,
including cables, that is closer than the recommended separation distance
calculated from the equation for the transmit frequency. (Recommended
separation distance : Not applicable)
80 MHz ~ 800 MHz
800 MHz ~ 2.5 GHz
P is the rated maximum output power (W) specified by the transmitter
manufacturer and d is the recommended separation distance (m). The
electromagnetic field strength c of the fixed RF transmitter, determined by the
electromagnetic site survey, must be less than the compliance level for each
frequency range. Disturbance may occur in the vicinity of medical devices
marked with the symbol below.
Radiated RF IEC
61000-4-3
3 V/m
80 MHz ~ 2.5 GHz 3 V/M
※ Note1 The higher frequency range applies in the 80 MHz and 800 MHz ranges.
※ Note2 These guidelines do not apply in all situations. Electromagnetic transmission is reflected and absorbed by buildings, objects, and
people
Electromagnetic compatibility
