NEC NEAX2000 IVS User manual

ND-46550 (E)
ISSUE 2
STOCK # 151944
Remote PIM System Manual
®
SEPTEMBER, 1998
NECAmerica,Inc.

LIABILITY DISCLAIMER
NEC America Inc. reserves the right to change the specifications,
functions, or features, at any time, without notice.
NEC America Inc. has prepared this document for use by its em-
ployees and customers. The information contained herein is the
property of NEC America Inc. and shall not be reproduced without
prior written approval from NEC America Inc.
NEAX and Dterm are registered trademarks of NEC Corporation.
Copyright 1998
NEC America, Inc.
Printed in the U.S.A.

ND-46550 (E)
ISSUE 2
SEPTEMBER, 1998
NEAX2000 IVS
Remote PIM System Manual
TABLE OF CONTENTS
Page
LIST OF FIGURES............................................................................................................................................. iii
LIST OF TABLES............................................................................................................................................... v
ND-46550 (E) TABLE OF CONTENTS
Page i
Revision 2.0
CHAPTER 1 INTRODUCTION................................................................................................................. 1
1. OUTLINE OF THIS MANUAL ................................................................................................................ 1
2. REFERENCE MANUALS....................................................................................................................... 1
CHAPTER 2 SYSTEM DESCRIPTION.................................................................................................... 3
1. SYSTEM OUTLINE................................................................................................................................ 3
2. PIM CONFIGURATION.......................................................................................................................... 4
3. SYSTEM CONFIGURATION................................................................................................................. 5
4. REQUIRED EQUIPMENT...................................................................................................................... 6
5. SYSTEM CAPACITY ............................................................................................................................. 8
6. SYSTEM CONDITIONS......................................................................................................................... 9
7. TIME SLOT ALLOCATION .................................................................................................................... 10
CHAPTER 3 INSTALLATION................................................................................................................... 13
1. PRECAUTION IN HANDLING ............................................................................................................... 13
2. INSTALLATION PROCEDURE.............................................................................................................. 16
2.1 Installation Procedure for Main Site....................................................................................................... 18
2.1.1 Switch Setting of DAIA Card..................................................................................................... 18
2.1.2 Mounting of DAIA Card............................................................................................................. 23
2.1.3 Switch Setting of DAIC Card..................................................................................................... 24
2.1.4 Mounting of DAIC Card............................................................................................................. 28
2.1.5 BUS Cable Connection............................................................................................................. 29
2.2 Installation Procedure for Remote Site .................................................................................................. 34
2.2.1 Switch Setting of DAIB Card..................................................................................................... 34
2.2.2 Mounting of DAIB Card............................................................................................................. 39
2.2.3 Switch Setting of DAIC Card..................................................................................................... 41
2.2.4 Mounting of DAIC Card............................................................................................................. 41
2.2.5 BUS Cable Connection............................................................................................................. 44

TABLE OF CONTENTS ND-46550 (E)
Page ii
Revision 2.0
TABLE OF CONTENTS (CONTINUED)
Page
2.2.6 Mounting of Line/Trunk Card on Small Platform PIM................................................................ 45
2.2.7 Mounting of Line/Trunk Card on 1000 IVS PIM ........................................................................ 48
2.2.8 Mounting of Line/Trunk Card on PIM N - UB (64 port PIM) ...................................................... 51
2.2.9 Power Failure Transfer (PFT) ................................................................................................... 54
2.3 Connection Between Main Site and Remote Site.................................................................................. 62
2.3.1 DTI Connection at Main Site..................................................................................................... 62
2.3.2 DTI Connection at Remote Site................................................................................................ 65
2.4 MP Reset............................................................................................................................................... 66
CHAPTER 4 TROUBLESHOOTING........................................................................................................67

ND-46550 (E) LIST OF FIGURES
Page iii
Revision 2.0
LIST OF FIGURES
Figure Title Page
2-1 Remote PIM System Outline .............................................................................................................. 3
2-2 System Configuration ......................................................................................................................... 5
2-3 Time Slot Allocation............................................................................................................................ 10
2-4 Time Slot Allocation (Continued) ........................................................................................................ 11
3-1 Static Electricity Guard ....................................................................................................................... 13
3-2 Static-Sensitive Attention Symbol....................................................................................................... 14
3-3 Installation Procedure for Main Site.................................................................................................... 16
3-4 Installation Procedure for Remote Site............................................................................................... 17
3-5 PN-DAIA Card .................................................................................................................................... 18
3-6 Mounting Location of DAIA Card........................................................................................................ 23
3-7 PN-DAIC Card .................................................................................................................................... 24
3-8 Mounting Location of DAIC Card (Main Site)...................................................................................... 28
3-9 BUS-DAIA Cable Connection ............................................................................................................. 29
3-10 DAIA-DAIC Cable Connection............................................................................................................ 30
3-11 DAIA-DAIC Cable Connection (Continued)........................................................................................ 31
3-12 DAIA-DAIC Cable Connection (Continued)........................................................................................ 32
3-13 DAIA-DAIC Cable Connection (Continued)........................................................................................ 33
3-14 PN-DAIB Card .................................................................................................................................... 34
3-15 Mounting Location of DAIB Card........................................................................................................ 39
3-16 Mounting Location of DAIB Card (Continued) .................................................................................... 40
3-17 Mounting Location of DAIC Card (Remote PIM).................................................................................41
3-18 Mounting Location of DAIC Card (Remote PIM) (Continued)............................................................. 42
3-19 Mounting Location of DAIC Card (Remote PIM) (Continued)............................................................. 43
3-20 DAIB-DAIC Cable Connection............................................................................................................ 44
3-21 Mounting Location of Line/Trunk Card (Small Platform)..................................................................... 45
3-22 Location of Each LEN (Small Platform) .............................................................................................. 46
3-23 LTC Connector Pin Arrangement (Small Platform)............................................................................. 47
3-24 Mounting Location of Line/Trunk Card (1000 IVS) .............................................................................48
3-25 Location of Each LEN (1000 IVS)....................................................................................................... 49
3-26 LTC Connector Pin Arrangement (1000 IVS)..................................................................................... 50
3-27 Mounting Location of Line/Trunk Card................................................................................................ 51
3-28 Location of Each LEN (PIM N_UB)..................................................................................................... 52
3-29 LTC Connector Pin Arrangement (PIM B - UB)..................................................................................53
3-30 PFT Connection Outline (PN-AUCA).................................................................................................. 54
3-31 MDF Cross Connection for PFT (PN-AUCA)......................................................................................55
3-32 PFT (PZ-8PFTA) Connection Outline................................................................................................. 56

LIST OF FIGURES ND-46550 (E)
Page iv
Revision 2.0
LIST OF FIGURES (CONTINUED)
Figure Title Page
3-33 Connection of 25-Pair Cable and PZ-8PFTA...................................................................................... 57
3-34 Mounting PZ-8PFTA Card to PIM....................................................................................................... 58
3-35 PFT Connector Pin Assignment ......................................................................................................... 59
3-36 MDF Cross Connection for PFT (PZ-8PFTA).....................................................................................60
3-37 DTI Cable Connection via LTC Connector ......................................................................................... 62
3-38 Example of DTI Cable Connection via LTC Connector ...................................................................... 63
3-39 DTI Cable Connection via CN Connector (Main Site)......................................................................... 64
3-40 DTI Cable Connection via CN Connector (Remote Site).................................................................... 65

ND-46550 (E) LIST OF TABLES
Page v
Revision 2.0
LIST OF TABLES
Table Title Page
2-1 PIM Configuration............................................................................................................................... 4
2-2 Required Equipment........................................................................................................................... 6
2-3 System Capacity................................................................................................................................. 8
3-1 Lamp Indications on PN-DAIA Card................................................................................................... 19
3-2 Switch Settings on PN-DAIA Card .................................................................................................... 20
3-3 Switch Settings When Clock Signal Supplied From Master Office..................................................... 22
3-4 Lamp Indications on PN-DAIC Card................................................................................................... 25
3-5 Switch Settings on PN-DAIC Card ..................................................................................................... 25
3-6 Lamp Indications on PN-DAIB Card................................................................................................... 35
3-7 Switch Settings on PN-DAIB Card ..................................................................................................... 36
3-8 LTC Connector Accommodation (Small Platform).............................................................................. 45
3-9 LTC Connector Accommodation (1000 IVS) ...................................................................................... 48
3-10 LTC Connector Accommodation......................................................................................................... 51
4-1 Remedial Action on Each Lamp Status ............................................................................................. 67

LIST OF TABLES ND-46550 (E)
Page vi
Revision 2.0
This page is for your notes.

ND-46550 (E) CHAPTER 1
Page 1
Revision 2.0
CHAPTER 1 INTRODUCTION
1. OUTLINE OF THIS MANUAL
This manual provides the system description and installation procedure for providing the Remote PIM System to
the NEAX2000 IVS.
2. REFERENCE MANUALS
Refer to the following manuals for additional information on equipment and programming installation:
• Installation Procedure Manual
• Small Platform System Manual
• Circuit Card Manual
• Command Manual
• Office Data Programming Manual
• Maintenance Manual

CHAPTER 1 ND-46550 (E)
Page 2
Revision 2.0
This page is for your notes.

ND-46550 (E) CHAPTER 2
Page 3
Revision 2.0
CHAPTER 2 SYSTEM DESCRIPTION
1. SYSTEM OUTLINE
Remote PIMs can be installed separately in the same building or between the offices via the Public Switching
Telephone Network (PSTN).
The customers in the remote site can use the same service features as in the main site. Remote PIMs are connected
to the main site by T1 (1.5 Mbps) digital interface.
Figure 2-1 shows an outline of the Remote PIM System.
Figure 2-1 Remote PIM System Outline
Note: The remote PIM contains station and trunk cards. A CPU card is not required in the remote offices.
PIM
1.5M(T1)
(Main Site)
OFFICE A
NEAX2000 IVS
PIM
OFFICE D
(Remote Site)
PIM
OFFICE B
(Remote Site)
PIM
OFFICE C
(Remote Site)
1.5M(T1)
1.5M(T1)

CHAPTER 2 ND-46550 (E)
Page 4
Revision 2.0
2. PIM CONFIGURATION
One PIM can be installed respectively as a remote site. A maximum of 3 remote sites can be provided. The number
of remote sites determines the number of PIMs in one system. Table 2-1 shows the available PIM configuration for
the Remote PIM System.
Table 2-1 PIM Configuration
NUMBER OF PIM AT MAIN SITE AVAILABLE NUMBER OF REMOTE SITE
1 PIM
(1 FP) 123
2 PIM
(1 FP) 123
3 PIM
(2 FP) 12 _
4 PIM
(2 FP) 12 _
5 PIM
(3 FP) 1__
6 PIM
(3 FP) 1__
7 PIM
(4 FP) ___
8 PIM
(4 FP) ___

ND-46550 (E) CHAPTER 2
Page 5
Revision 2.0
3. SYSTEM CONFIGURATION
Figure 2-2 shows the system configuration.
Figure 2-2 System Configuration
TDSW
DAIA 1
(FP1)
DAIC 1
DAIC 2
DAIB
(FP1)
DAIC 1
DAIC 2
DAIA 2
(FP2)
DAIC 3
DAIC 4
DAIB
(FP2)
DAIC 3
DAIC 4
DAIA 3
(FP3)
DAIC 5
DAIC 6
FP0MP
DAIB
(FP3)
DAIC 5
Line/TRK
Line/TRK
Line/TRK
DAIC 6
Remote PIM 1
Remote PIM 2
Remote PIM 3
Remote SiteMain Site
23 B Channel
1 D Channel
24 B Channel
24 B Channel
23 B Channel
1 D Channel
24 B Channel
24 B Channel
23 B Channel
1 D Channel
24 B Channel
24 B Channel

CHAPTER 2 ND-46550 (E)
Page 6
Revision 2.0
4. REQUIRED EQUIPMENT
Table 2-2 shows the required equipment for establishing the Remote PIM System.
Table 2-2 Required Equipment
EQUIPMENT NAME DESCRIPTION
SN1308 PIM P-A (PIM Q-UA) Port Interface Module for Small Platform System/Remote PIM system
(remote site)
A PIM provides 13 card slot for common control, Line/Trunk cards. It
also houses a AC/DC power supply and optional batteries for protection
from short-term power interruption.
Three champ connectors for line/trunk (LTC0 to 2) and a connector for
Power (PWR) are located at the lower front side of the PIM.
SN1420 PIMAB-A Port Interface Module (PIM) for 1000 IVS/Remote PIM system (remote
site).
A PIM provides 10 card slots for common control, Line/Trunk, and
Application Processor (AP) cards. It is also houses a AC/DC Power Sup-
ply and batteries for protection from short-term power interruption.
Two champ connectors for line/trunk (LTC0 to 1) and a connector for
Power (PWR) are located at the lower front side of the PIM.
PN-DAIA (DAIA Card) Interface card for Remote PIM System at main site
This card provides 1.5 Mbps (24 channel) digital interface, firmware
processor, and BUS interface; 1 through 3 DAIA cards must be provided
at main site, which corresponds to the number of the remote site.
PN-DAIB (DAIB Card) Interface card for the Remote PIM System at remote site
This card provides 1.5 Mbps (24 channel) digital interface, firmware
processor; 1 card is required per Remote PIM at the remote site.
PIM N-UB Port Interface Module for 128/512 port systems/Remote PIM system.
This PIM can be a Remote PIM or main office PIM.
This PIM provides 19 slots forcommon control line and trunk cards. This
PIM houses an AC/DC power supply and optionalbatteriesfor short-term
power interruption.
Three champ connectors for line/trunk (LTC0 to 2) and a connector for
Power (PWR) are located at the lower front side of the PIM.

ND-46550 (E) CHAPTER 2
Page 7
Revision 2.0
PN-DAIC (DAIC Card) Digital Interface Channel Expansion Card.
This card provides the 1.5Mbps (24 channel) digital interface.
1 through 6 DAIC cards can be provided at main site.
In Remote PIM, 2 DAIC cards can be provided.
Small Platform PIM: up to 64 line/trunks can be accommodated.
1000 IVS PIM: up to 47 line/trunks can be accommodated.
PN-BS00/BS01 (BUS interface Card) BUS interface cards for PIM0 or PIM1 through PIM7
For Remote PIM System, BS00 card is required at the main site, even if
the system is 1-PIM configuration.
PN-CP01 (FP Card) Firmware processor card
For Remote PIM System, CP01 card must be mounted on PIM0 at the
main site, even if the system is 1-PIM configuration.
RMT PCM-0.3 CA 1 ft. (30 cm) PCM signal cable
This cable is used for connection between DAIA card and BUS interface
card.
17-TW-0.3 CONN CA-A 1 ft. (30 cm) connection cable between DAIA cards
This cable is required when plural DAIA cards are mounted in a PIM at
the main site.
48-TW-0.2 CONN CA 1ft. (30 cm) connection cable.
This cable is used for connecting between DAIA card and DAIC card or
DAIB card and DAIC card.
Table 2-2 Required Equipment (Continued)
EQUIPMENT NAME DESCRIPTION

CHAPTER 2 ND-46550 (E)
Page 8
Revision 2.0
5. SYSTEM CAPACITY
Table 2-3 shows the system capacity.
Note 1: 1 port is used for the control signaling channel.
Note 2: This number refers to the maximum number of remote offices. The remote office can have only one re-
mote PIM.
Note 3: When the main site consists of 7 or 8 PIMs, a Remote PIM cannot be provided.
Table 2-3 System Capacity
DESCRIPTION
CAPACITY
REMARKS
MAIN PIM REMOTE PIM
2000 IVS SMALL PLATFORM
(72 Port)
1000 IVS
(48 Port)
Max. number of DAIA card 3 - -
Max. number of DAIB card - 1 1
Max. number of DAIC card 6 2 1
Max. number of ports on
Remote Site -24
Note 1 24 Note 1 Main PIM :DAIA
Remote PIM :DAIB
48
Note 1 48 Note 1 Main PIM :1 DAIA, 2 DAIC
Remote PIM :1 DAIB, 2 DAIC
64
Note 1 -Main PIM :1 DAIA, 2 DAIC
Remote PIM :1 DAIB, 2 DAIC
Number of PIM
1, 2 3
Note 2 3Number of PIM depends on the
number of Main PIM and
Remote PIM. (Refer to Chapter,
Section 2.)
3, 4 2
Note 2 2 Note 2
5, 6 11
Note 2
7, 8 0
Note 3 0 Note 3

ND-46550 (E) CHAPTER 2
Page 9
Revision 2.0
6. SYSTEM CONDITIONS
For providing the Remote PIM System to the NEAX2000 IVS, observe the following conditions:
(1) The main site must be the NEAX2000 IVS. The Small Platform System cannot be the main site. The main
site must be a medium platform (320 ports) or a large platform (512 ports). The small platform (72 ports)
cannot be used.
(2) The Remote PIM can be a PIM N-UB, a PIM Q-UA, or a PIM AB-A.
(3) The Remote PIM can be installed at a maximum of 1312 ft. (399 m) distance from the main site. Using line
extension equipment (repeater, MUX etc.), the distance can be extended.
(4) A maximum of 23 lines/trunks can be accommodated in one Remote PIM.
(5) On the remote site, the line/trunk circuit cards can be used as same as the main site, except the CSI card for
wireless system according to UTAM regulation. However, the application circuit cards cannot be used at the
remote site. When providing the ILC card to the remote site, the ICH card must be installed on the main site.
(6) For the Remote PIM System, the installation procedures for modules, circuit cards and peripheral equipment
are the same as those for the regular NEAX2000 IVS, except the DAIA card and the DAIB card installation
and the BUS cable connection. Refer to the applicable manuals for detailed information.
(7) When the link between the main site and the remote site is lost, the system activates PFT (Power Failure
Transfer) automatically on the remote site, if provided.
(8) The resident system programming cannot be set to the remote site while the main site can be set.
(9) When the LC cards thatuse an AP card directly (i.e., ILC requires ICH, and 4COTB requires 4RSTC.) If ILC
or COTB are mounted in the Remote PIM, the T1 link between the main and remote sites must be configured
as 64 Kbps with ESF and B8ZS.
(10) In the remote site, if the Remote PIM is a 72-portPIM or a 48-port PIM, when installing a 4-circuit card (LC,
DLC, COT, etc.), assign a phantom DK00 to Level 4 and Level 6 of that LT slot. This assignment will shift
the time slots over enabling the use of additional card slots. (This action is not required if the Remote PIM is
a 64-port PIM.)

CHAPTER 2 ND-46550 (E)
Page 10
Revision 2.0
7. TIME SLOT ALLOCATION
One time slot of the last 24 time slots provided by the DAIA-DAIB connection is used for the control signaling
channels. Figure 2-3 shows an example of time slot allocation when mounting 8 port cards to the Small Platform
PIM.
Figure 2-3 Time Slot Allocation
LT00 LT01 LT02 LT03 LT04 LT05 LT06 LT07 LT08 LT09 LT10
DAIB
DAIA
•23 time slots for Line/Trunks
•1time slot for control signaling
channel Note
•23 time slots for Line/Trunks
•1time slot for control signaling
channel Note
•Max. 47 time slots for Line/Trunks
per Remote Site
Remote Site
Main Site
00-23
LT00 LT01 LT02 LT03 LT04 LT05 LT06 LT07 LT08 LT09 LT10
DAIC
DAIC
•24 time slots for Line/Trunks
Remote Site
Main Site
00-23
DAIB
DAIA
24-47
Highway Channel
Highway Channel
TDSW
TDSW
(1) When using 1 DAIA card and 1 DAIB card
(2) When using 1 DAIA card, 1 DAIB card, and 2 DAIC cards.
Note: The control signalling channel is set by SW2 of DAIA/DAIB. Refer to Chapter 3 sections 2.1.1
and 2.2.1 for the switch settings.

ND-46550 (E) CHAPTER 2
Page 11
Revision 2.0
Figure 2-4 Time Slot Allocation (Continued)
LT00 LT01 LT02 LT03 LT04 LT05 LT06 LT07 LT08 LT09 LT10
DAIC 0 DAIC 1 DAIB
DAIC 0 DAIC 1 DAIA
TDSW
•23 time slots for Line/Trunks
•1 time slot for control signaling
channel Note
•24 time slots for Line/Trunks
•24 time slots for Line/Trunks
•Max. 64 time slots for Line/Trunks
per Remote Site
Remote Site
Main Site
00-23 24-47 48-63
Highway Channel
(3) When using 1 DAIA card, 1 DAIB card, and 4 DAIC cards
Note: The control signalling channel is set by SW2 of DAIA/DAIB card. Refer to Chapter 3 sections 2.1.1 and
2.2.1 for the switch settings.

CHAPTER 2 ND-46550 (E)
Page 12
Revision 2.0
This page is for your notes.
