NEC PowerMate eco User manual

PowerMate eco™ Microdesktop Computers
POWERMATE eco
SERVICE AND REFERENCE MANUAL

Copyright — August 2002
NEC Solutions (America), Inc.
15 Business Park Way
Sacramento, CA 95828
All Rights Reserved
Proprietary Notice and Liability Disclaimer
The information disclosed in this document, including all designs and related materials, is the valuable
property of NEC Solutions (America), Inc. (hereinafter “NECSAM”) and/or its licensors. NECSAM and/or its
licensors, as appropriate, reserve all patent, copyright and other proprietary rights to this document, including
all design, manufacturing, reproduction, use, and sales rights thereto, except to the extent said rights are
expressly granted to others.
The NECSAM product(s) discussed in this document are warranted in accordance with the terms of the
Warranty Statement accompanying each product. However, actual performance of each such product is
dependent upon factors such as system configuration, customer data, and operator control. Since
implementation by customers of each product may vary, the suitability of specific product configurations and
applications must be determined by the customer and is not warranted by NECSAM.
To allow for design and specification improvements, the information in this document is subject to change at
any time, without notice. Reproduction of this document or portions thereof without prior written approval of
NECSAM is prohibited.
As an ENERGY STAR partner, NECSAM has determined that this product meets the ENERGY STAR guidelines
for energy efficiency.
PowerMate eco is a trademark of NEC Solutions (America), Inc.; NEC is a registered trademark of NEC Corporation
and/or one of its subsidiaries. All are used under license. ENERGY STAR is a U.S. registered trademark of the U.S.
government. Microsoft and Windows are registered trademarks of Microsoft Corporation. Transmeta and Crusoe are
trademarks of Transmeta Corporation. Intel is a registered trademark of Intel Corporation.
All other trademarks and registered trademarks are the property of their respective trademark owners.

Contents iii
Contents
Preface...........................................................................................................................vii
Abbreviations .................................................................................................................ix
1 System Overview
Product Description.......................................................................................................1-2
External Features ..........................................................................................................1-4
Internal Components.....................................................................................................1-7
LCD Unit...............................................................................................................1-8
Base Unit...............................................................................................................1-9
Software..................................................................................................................... 1-10
Preloaded Software .............................................................................................. 1-10
PowerMate eco Application and Driver CD.......................................................... 1-10
PowerMate eco Product Recovery CD..................................................................1-10
SoftDVD and CD-RW Software...........................................................................1-10
Security......................................................................................................................1-10
Password Security................................................................................................1-10
Windows Network Security Features....................................................................1-11
Security Lock Slot................................................................................................1-11
Anti-theft Bracket ................................................................................................1-11
Rear Cover Lock..................................................................................................1-11
2 Setup and Configuration
System Setup................................................................................................................2-2
Jumper Settings.............................................................................................................2-3
BIOS Setup Utility........................................................................................................2-6
How to Start BIOS Setup........................................................................................2-6
How to Use Setup...................................................................................................2-6
Main Menu ............................................................................................................2-7
Advanced Menu...................................................................................................2-11
Security Menu......................................................................................................2-13
Power Menu......................................................................................................... 2-14
Boot Menu...........................................................................................................2-15
Exit Menu............................................................................................................2-16
FLASH Utility............................................................................................................ 2-16
PowerMate eco Application and Driver CD.................................................................2-17
PowerMate eco Product Recovery CD.........................................................................2-17
Performing Full Disk Restore ...............................................................................2-17
Performing Partition Only Restore........................................................................2-19
3 Disassembly and Reassembly
Optical Drive Removal..................................................................................................3-3
Rear Cover Removal.....................................................................................................3-4
Memory Module Removal.............................................................................................3-6
Hard Drive Removal .....................................................................................................3-8
System Board Shield Removal ......................................................................................3-9
Legacy Board Removal...............................................................................................3-10
System Board Removal...............................................................................................3-11
CMOS Battery Removal.............................................................................................. 3-13
PC Card Bay Removal ................................................................................................ 3-15
Front LCD Cover Removal .........................................................................................3-16
Power Button Assembly Removal ............................................................................... 3-17
LCD Panel Removal ................................................................................................... 3-17
Power Inverter Board Removal....................................................................................3-18
Operation Board Removal........................................................................................... 3-19
Brightness Button Assembly Removal......................................................................... 3-20

iv Contents
Speaker Assembly Removal........................................................................................ 3-20
Base Cover Assembly Removal................................................................................... 3-21
Interface Board Assembly Removal ............................................................................ 3-23
Optical Drive Bracket Assembly................................................................................. 3-24
4 Board Layouts
System Board ............................................................................................................... 4-2
Operation Board ........................................................................................................... 4-4
Legacy Board ............................................................................................................... 4-4
Interface Board............................................................................................................. 4-5
5 Illustrated Parts Breakdown
Replaceable Parts List................................................................................................... 5-2
Illustrated Parts Breakdown........................................................................................... 5-4
6 Preventive Maintenance
System Cleaning........................................................................................................... 6-2
Keyboard Cleaning....................................................................................................... 6-2
Mouse Cleaning............................................................................................................ 6-3
7 Troubleshooting
Checklist ...................................................................................................................... 7-2
System Problems.................................................................................................... 7-2
External Diskette Drive Problems........................................................................... 7-3
LCD Panel Problems.............................................................................................. 7-3
Keyboard/Mouse Problems .................................................................................... 7-4
Optical Drive Problems.......................................................................................... 7-4
Speaker Problems................................................................................................... 7-5
Diagnostics................................................................................................................... 7-5
8 Service and Support
Contact Information...................................................................................................... 8-2
Web Site Services......................................................................................................... 8-2
E-mail to Support Service ............................................................................................. 8-3
Technical Support Services........................................................................................... 8-3
9 Specifications
Microdesktop System.................................................................................................... 9-2
Keyboard...................................................................................................................... 9-5
Mouse...........................................................................................................................9-5
AC Power Adapter........................................................................................................ 9-5
Environmental and Safety............................................................................................. 9-6
Compliance................................................................................................................... 9-6
Glossary
Index
Regulatory Statements

Contents v
List of Figures
PowerMate eco Main System Components....................................................................1-2
PowerMate eco System — Front Features......................................................................1-4
System Controls and LEDs............................................................................................1-4
Typical Optical Drive Features......................................................................................1-5
PowerMate eco System — Rear Features.......................................................................1-5
I/O Connectors..............................................................................................................1-6
Right Side Features.......................................................................................................1-6
Left Side Features.........................................................................................................1-7
PowerMate eco Main Parts............................................................................................1-7
LCD Unit Components — Front....................................................................................1-8
LCD Unit Components — Rear.....................................................................................1-9
Base Unit Components..................................................................................................1-9
Locating the System Board Jumpers..............................................................................2-3
Positioning the Optical Drive Release Button ................................................................3-3
Locating the Optical Drive ............................................................................................3-3
Releasing the Rear Cover..............................................................................................3-4
Locating the Cover Slots and Cover Lock Bracket.........................................................3-5
Securing the Rear Cover................................................................................................3-5
Locating the Memory Slot Cover and Screw..................................................................3-6
Removing the Memory Module.....................................................................................3-7
Installing the Memory Module ......................................................................................3-7
Replacing the Memory Slot Cover.................................................................................3-8
Removing the Hard Drive..............................................................................................3-9
Removing the System Board Shield.............................................................................3-10
Locating the Connector Screws ................................................................................... 3-10
Removing the Legacy Board .......................................................................................3-11
Removing the System Board Shield and Side Panels....................................................3-12
Removing the System Board .......................................................................................3-13
Locating the CMOS Battery........................................................................................ 3-13
Removing the CMOS Battery......................................................................................3-14
Locating the PC Card Bay Screws............................................................................... 3-15
Locating the PC Card Bay Connector .......................................................................... 3-15
Removing the Front LCD Cover..................................................................................3-16
Removing the Power Button Assembly........................................................................3-17
Removing the LCD Panel............................................................................................3-17
Disconnecting LCD Panel Cables................................................................................ 3-18
Removing the Inverter Board ...................................................................................... 3-19
Removing the Operation Board...................................................................................3-19
Removing the Brightness Button Assembly................................................................. 3-20
Removing the Left Speaker Assembly.........................................................................3-21
Removing the Front and Rear Base Bezels...................................................................3-21
Removing the Rear Hinge Cover.................................................................................3-22
Removing the Base Cover...........................................................................................3-22
Removing the Bottom Base Plate ................................................................................3-23
Disconnecting the Interface Board Cables.................................................................... 3-23
Removing the Interface Board Assembly.....................................................................3-24
Removing the Optical Drive Bracket Assembly........................................................... 3-24
System Board Connectors and Sockets — Side 1...........................................................4-2
System Board Jumper Location — Side 1......................................................................4-3
System Board Battery Socket Location — Side 2...........................................................4-3
Operation Board Connectors, LEDs, and Controls.........................................................4-4
Legacy Board Connectors .............................................................................................4-4
Interface Board Connectors...........................................................................................4-5
Removing a Typical Mouse Ball Cover .........................................................................6-3

vi Contents
List of Tables
PowerMate eco System Configuration Summary........................................................... 1-3
System Board Jumper Settings...................................................................................... 2-5
Setup Key Functions..................................................................................................... 2-7
Main Menu Items.......................................................................................................... 2-8
Advanced Menu.......................................................................................................... 2-11
Security Menu Items................................................................................................... 2-13
Power Menu Settings.................................................................................................. 2-15
Boot Menu Settings .................................................................................................... 2-15
Exit Menu Items......................................................................................................... 2-16
PowerMate eco Series Disassembly Sequence............................................................... 3-2
PowerMate eco Replacement Parts List......................................................................... 5-2
PowerMate eco IPB ...................................................................................................... 5-4
Problems and Solutions................................................................................................. 7-5
NEC Solutions (America), Inc. Support Services........................................................... 8-2
PowerMate eco Specifications....................................................................................... 9-2
System Specifications................................................................................................... 9-2
Keyboard Specifications ............................................................................................... 9-5
Mouse Specifications.................................................................................................... 9-5
AC Power Adapter Specifications.................................................................................9-5
Environmental and Safety Specifications....................................................................... 9-6
System Compliance ...................................................................................................... 9-6

Preface vii
Preface
This manual contains technical information for servicing NEC PowerMate eco™ microdesktop
computers sold by NEC Solutions (America), Inc.
The manual contains hardware and interface information for those who need an overview of the
system design. The manual includes system setup and configuration information, disassembly
procedures, an illustrated parts list, maintenance information, and troubleshooting procedures.
The manual is prepared for NEC Solutions (America), Inc.-trained customer engineers, service
center staff, and depot repair personnel.
The content of this manual is organized as follows.
 Chapter 1, “System Overview,” provides an overview of system features and includes brief
descriptions of system components.
 Chapter 2, “Setup and Configuration,” includes information for getting the system up and
running, setting system board jumpers, and using the BIOS Setup utility to configure the
system hardware. The chapter also contains information for using the BIOS FLASH utility,
PowerMate eco Application and Driver CD, and PowerMate eco Product Recovery CD.
 Chapter 3, “Disassembly and Reassembly,” provides system disassembly and reassembly
procedures. Each procedure is supported by disassembly illustrations.
 Chapter 4, “Board Layouts,” contains information about the boards in the system.
Illustrations show connector and socket locations on each board and callouts identify the
features on the board.
 Chapter 5, “Illustrated Parts Breakdown,” includes a parts list for replaceable parts and an
illustrated parts breakdown diagram.
 Chapter 6, “Preventive Maintenance,” provides recommended maintenance information for
maintaining the system in top condition.
 Chapter 7, “Troubleshooting,” includes information to help isolate and repair system
malfunctions.
 Chapter 8, “Services and Support,” lists contact information for the services and support
available from NEC Solutions (America), Inc.
 Chapter 9, “Specifications,” provides detailed specifications for the major components in
the system, including the chassis, system board, and LCD panel.
Text conventions used in this manual are as follows.
 Warnings, cautions, and notes have the following meanings:
Warnings alert you to situations that could result in serious personal
injury or loss of life.
Cautions indicate situations that can damage the hardware or software.
Note Notes give particularly important information about what is being described.
 Names of keys are printed as they appear on the keyboard, for example, Ctrl, Alt, or Enter.
 Text that you must type or keys that you must press are presented in bold type. For
example, type dir and press Enter.

Abbreviations ix
Aampere
AC alternating current
ACK acknowledge
AGP accelerated graphics port
ASIC application-specific integrated circuit
AT advanced technology (IBM PC)
ATA AT attachment
ATAPI AT attachment packet interface
ATM asynchronous transfer mode
BBS Bulletin Board Service
BCD binary-coded decimal
BCU BIOS Customized Utility
BIOS basic input/output system
bit binary digit
BUU BIOS Upgrade Utility
bpi bits per inch
bps bits per second
C capacitance
C centigrade
Cache high-speed buffer storage
CAM constantly addressable memory
CAS column address strobe
CD-ROM compact disk-ROM
CH channel
clk clock
cm centimeter
CMOS complementary metal oxide
semiconductor
COM communication
CONT contrast
CPGA ceramic pin grid array
CPU central processing unit
DAC digital-to-analog converter
DACK DMA acknowledge
dB decibels
DC direct current
DCC direct cable connection
DCE data communications equipment
DDC Display Data Channel
DDR Double Data Rate
DIMM Dual In-Line Memory Module
DIP dual in-line package
DMA direct memory access
DMAC DMA controller
DMI Desktop Management Interface
DOS disk operating system
DRAM dynamic RAM
DVD digital versatile disc
DVMT Dynamic Video Memory Technology
ECC error checking and correction
ECP extended capabilities port
EDO extended data output
EGA Enhanced Graphics Adapter
EIDE Enhanced IDE
EISA enhanced ISA
e-mail electronic mail
EMI electromagnetic interference
EPP enhanced parallel port
EPROM erasable and programmable ROM
ESD electrostatic discharge
EVGA Enhanced Video Graphics Array
F Fahrenheit
FAX facsimile transmission
FCC Federal Communications Commission
FDD floppy disk drive
FG frame ground
FM frequency modulation
FP fast page
FRU field-replaceable unit
FSB front side bus
ftp file transfer protocol
GB gigabyte
GND ground
HEX hexadecimal
HGA Hercules Graphics Adapter
Hz hertz
IC integrated circuit
ID identification
IDE intelligent device electronics
IDTR interrupt descriptor table register
in. inch
INTA interrupt acknowledge
I/O input/output
IPB illustrated parts breakdown
Abbreviations

x Abbreviations
IPC integrated peripheral controller
ips inches per second
IR infrared
IrDA Infrared Data Association
IRR Interrupt Request register
ISA Industry Standard Architecture
ISP internet service provider
IRQ interrupt request
K kilo (1024)
k kilo (1000)
KB kilobyte
Kbps Kilobits per second
kg kilogram
kHz kilohertz
lb pound
LAN local area network
LCD liquid crystal display
LED light-emitting diode
LDCM LANDesk Client Manager
LSB least-significant bit
LSI large-scale integration
LVDS low voltage differential signaling
M mega (million)
mA milliamps
max maximum
MB megabyte
MFM modified frequency modulation
MHz megahertz
MIDI musical instrument digital interface
mm millimeter
MMX multimedia extensions
modem modulator/demodulator
MOS metal-oxide semiconductor
MPEG Motion Picture Experts Group
ms millisecond
MSB most-significant bit
NC not connected
NIC networked information center
NIC network interface card
NMI Non-maskable Interrupt
ns nanosecond
NSRC National Service Response Center
OCR optical character recognition
OS operating system
PAL programmable array logic
PC personal computer
PCB printed circuit board
PCI Peripheral Component Interconnect
PCMCIA Personal Computer Memory Card
International Association
PDA personal digital assistant
PFP plastic flat package
PIO parallel input/output
pixel picture element
PLCC plastic leaded chip carrier
PLL phase lock loop
POST Power-On Self-Test
p-p peak-to-peak
PPI programmable peripheral interface
PROM programmable ROM
PS/2 personal system/2
QFP quad flat pack
Rread
RAM random-access memory
RAMDAC RAM digital-to-analog converter
RAS row address strobe
RGB red green blue
RGBI red green blue intensity
rms root mean square
ROM read-only memory
rpm revolutions per minute
RTC real-time clock
R/W read/write
Sslave
SCSI Small Computer System Interface
SDRAM synchronous dynamic random access
memory
S.E.C. single edge contact cartridge
S.E.P.P. single edge processor package
SG signal ground
SGRAM synchronous graphics random access
memory
SIMM single inline memory module
S/N signal to noise ratio
SNMP simple network management protocol
SO-DIMM Small Outline-Dual Inline Memory
Module
SPM standard page mode
SRAM static random access memory
SRS Sound Retrieval System
SSI small scale integration

Abbreviations xi
SVGA Super Video Graphics Array
SW switch
T&D test and diagnostics
TFT thin film transfer
TSC Technical Support Center
TTL transistor/transistor logic
tpi tracks per inch
UART universal asynchronous
receiver/transmitter
UHF ultra high frequency
UL Underwriter’s Laboratories
UMA unified memory architecture
UPS uninterruptible power supply
URL uniform resource locator
USB universal serial bus
Vvolt
Vac volts, alternating current
VCR video cassette recorder
Vdc volts, direct current
VDT video display terminal
VESA video electronics standards
association
VFC VESA-compliant feature connector
VGA Video Graphics Array
VHF very high frequency
VLSI very large scale integration
VRAM video RAM
Wwatt
WAN wide area network
WRAM Windows RAM
W write
www world wide web
XGA Extended Graphics Array

1
System Overview
 Product Description
 External Features
 Internal Components
 Software
 Security

1-2 System Overview
This chapter provides an overview of the NEC PowerMate eco™ system and includes
descriptions of:
 system hardware
 front, rear, and side features
 internal components
 software features
 security features.
Product Description
The NEC PowerMate eco is a microdesktop computer featuring a space-saving “boxless”
design. Most system components are built into the liquid crystal display (LCD) unit. Some
components are integrated in the base of the system.
Based on the low-power Transmeta™5800 (TM5800) Crusoe™ processor, the PowerMate eco
runs cool and requires no fan. System operation is very quiet. The boxless system includes the
flat-screen monitor/base system, a USB keyboard, and a USB mouse. The following figure
shows the main system components.
PowerMate eco Main System Components
A– PowerMate eco System D– AC Power Cord
B– USB Mouse E– AC Power Adapter
C– USB Keyboard
The PowerMate eco features a 15-inch high-resolution thin-film transistor (TFT) display, a
Crusoe 900-MHz or higher processor, 256 MB of random access memory (RAM), a hard drive,
an optical drive (CD-ROM or combination DVD-ROM/CD-RW drive), and built-in stereo
speakers.
The monitor can tilt up 35 degrees, tilt down 5 degrees, and swivel 80 degrees in each direction
for an optimum viewing angle.
Externally, the PowerMate eco offers a wide choice of ports and connectivity, such as two PC
Card slots, four universal serial bus (USB) ports, built-in local area network (LAN), two
personal system/2 (PS/2)-style ports, a serial port, printer port, and audio ports (line-out, line-in,
and microphone).

System Overview 1-3
Internally, the system board provides a Small Outline Dual Inline Memory Module (SO-DIMM)
socket supporting synchronous dynamic random access memory (SDRAM) and a Mini PCI
socket for an optional Mini PCI module. Main system memory is upgradeable to a total of
640 MB of RAM (128 MB on the system board and a 512-MB SO-DIMM). The system board
has an ATI Mobility M6DC graphics chip and 16 MB of video memory.
The PowerMate eco design features easy access to the optical drive, hard drive, SO-DIMM
socket, and Mini PCI socket for easy upgrades and service. A release button at the rear of unit
releases the optical drive from its bay. The rear cover and the hard drive assembly are removable
without tools. Easy access to front panel and LCD panel components makes servicing simple.
For a summary of PowerMate eco system configuration features, see the following table. See
Chapter 9 for a detailed list of PowerMate eco specifications.
PowerMate eco System Configuration Summary
Component Description
System Board NEC proprietary board
Processor Transmeta Crusoe TM5800, 133-MHz or higher Front Side Bus (FSB)
Cache 64-KB x 2 L1 cache and 512-KB L2 cache
Chip Set North Bridge —TM5800
South Bridge —ALi M1535+
Super I/O —ALi M1535+
Main Memory 128 MB minimum on the system board (DDR) to 640 MB maximum (128 MB
on system board and 512-MB SO-DIMM); one SO-DIMM socket (SDR)
Graphics Graphics accelerator chip —ATI Mobility M6DC
Video memory —16 MB (included in M6DC)
LCD Panel 15-inch, high-resolution, TFT Extended Graphics Array (XGA) color display
Audio Yamaha YMF753 Codec chip integrated on the system board; M1535+ audio
chip; two integrated 1-watt speakers; volume control on front panel
Hard Drive* Mobile EIDE Ultra DMA/66
Optical Drive* VersaBay™IV type; CD-ROM or combination DVD-ROM/CD-RW drive
LAN 10Base-T/100Base-TX on system board
PC Card Slots Two PCMCIA CardBus slots for Type II and Type III cards
Speakers Two Pioneer 1-watt speakers integrated in base of the LCD panel
Keyboard USB keyboard
Mouse USB mouse
Power AC power adapter with built-in power converter and detachable AC power
cord: 80 watt, 100 to 240 Vac, 50-60 Hz
*Component varies by system

1-4 System Overview
External Features
See the following figures to identify PowerMate eco features on the front, rear, and sides of the
system.
PowerMate eco System — Front Features
A– LCD Panel D– Optical Drive
B– Left Speaker E– Right Speaker
C– LCD Display/Audio Controls F– Control Panel
System Controls and LEDs
A– Optical/Hard Drive LED D– Decrease LCD Brightness Button
B– Power Button E– Increase LCD Brightness Button
C– Power LED F– Volume Control

System Overview 1-5
Typical Optical Drive Features
A– Drive Status LED C– Emergency Eject Hole
B– Disc Eject Button
PowerMate eco System —Rear Features
A– Optical Drive Release Button F– DC Power Port
B– Kensington®Lock Slot G– Rear Cover Lock
C– LAN Port H– I/O Connector Cover
D– USB Ports (2) I– Vents
E– USB Cable Lock
Do not block vents while the NEC PowerMate eco system is in use.

1-6 System Overview
I/O Connectors
A– Serial Port C– PS/2 Mouse Port
B– PS/2®Keyboard Port D– Parallel Printer Port
Right Side Features
A– Line Out Jack C– Microphone Jack
B– Line In Jack

System Overview 1-7
Left Side Features
A– PC Card Eject Buttons (2) C– USB Ports (2)
B– PC Card Slots (2)
Internal Components
The PowerMate eco system has two main parts, the LCD unit and the base unit. See the
following sections for a description of components in these main parts. See Chapter 4 for board
layouts.
PowerMate eco Main Parts
A– LCD Unit B– Base Unit

1-8 System Overview
LCD Unit
The LCD unit contains most of the system components (see the following figures):
 LCD panel components —located at the front of the LCD unit; includes the LCD front
panel, LCD panel, and power inverter board.
 Operation board —located below the LCD panel at the front of the LCD unit; includes the
power button, brightness buttons, volume control, power LED, optical/hard drive LED, and
connectors for the speaker cables and cable to the system board.
 Speaker assemblies —stereo speakers are located at the front of the LCD unit and below
the LCD panel. Cables connect the speakers to the operations board.
 System board (main board) —located at the rear of the LCD unit and behind the system
board shield; includes the processor, SO-DIMM socket, Mini-PCI socket, PC Card bay, two
USB ports, microphone jack, line-in port, line-out port, and cable connectors (see “System
Board”in Chapter 4 for connector and socket locations).
 Legacy board —located on the inside of the system board shield; provides a serial port, a
PS/2 mouse connector, PS/2 keyboard connector, and a parallel port. The ports are
accessible behind an easy-to-remove cover.
 Hard drive assembly —located at the rear of the LCD unit below the system board. The
hard drive is connected to the system board by a single signal and power ribbon cable. A
pull-tab on the hard drive bracket allows easy removal without tools.
 Hinge assembly —located at the rear of the LCD unit and above the pedestal. The hinge
design allows for easy movement of the LCD unit. It also provides an area for interface
cables to pass through from the system board in the LCD unit to the legacy board in the
base unit.
LCD Unit Components —Front
A– Speaker Assemblies C– LCD Panel
B– Operation Board

System Overview 1-9
LCD Unit Components —Rear
A– System Board (under system board shield) D– Hard Drive Assembly
B– Legacy Board (behind system board shield) E– Hinge Assembly
C– System Board Shield
Base Unit
The base unit contains the following components:
 Optical drive assembly —located at the front of the base unit. The optical drive assembly
provides a bay for an optical drive (CD-ROM drive or combination DVD-ROM/CD-RW
drive).
 Interface board —located at the rear of the base unit. The interface board provides the
optical drive release assembly, LAN connector, two USB ports, and the DC power
connector. Cables connect the interface board to the system board.
Base Unit Components
A– Bottom Base Plate C–Interface Board
B– Optical Drive Assembly

1-10 System Overview
Software
NEC Solutions (America), Inc. provides a variety of applications and hardware utilities with the
system to take advantage of the system hardware capabilities.
Preloaded Software
The system comes preloaded with the Microsoft®Windows®2000 Professional/Windows XP
Professional operating system.
On the initial power-on, you must choose the operating system you want to load. The operating
system you choose is the only operating system and is the one that the Product Recovery
program restores.
PowerMate eco Application and Driver CD
Use the PowerMate eco Application and Driver CD to install on the hard drive the applications,
drivers, and utilities provided by NEC Solutions (America), Inc. Also use the PowerMate eco
Application and Driver CD to reinstall the NEC Solutions (America), Inc. supplied software if
the software becomes corrupted. See “PowerMate eco Application and Driver CD”in Chapter 2
for information about installing software from the CD.
The Application and Driver CD includes Microsoft Internet Explorer, Norton AntiVirus™
software, and Adobe®Acrobat®Reader.
PowerMate eco Product Recovery CD
The system comes with a PowerMate eco Product Recovery CD. Should a problem occur that
causes data loss or corruption, you can use the Product Recovery CD to restore the system to its
original factory state. A full system restore loads the operating system and the factory-supplied
software that comes on the hard drive. See “PowerMate eco Product Recovery CD”in Chapter 2
for information about using the restore options.
SoftDVD and CD-RW Software
To take full advantage of both DVD-ROM and CD-RW technologies, NEC Solutions
(America), Inc. ships the following CDs with the combination DVD-ROM and CD-RW drive:
 SoftDVD Software CD —contains SoftDVD drivers and the CyberLink®PowerDVD™XP
DVD software program for playing DVD movies.
 CD-RW Software CD —contains Easy CD Creator®software which allows you to write
information to a CD and to back up information from the hard drive to a CD.
Security
The system has hardware, software, and mechanical security features that offer protection
against unauthorized access to the system and data. The following security features are
available.
Password Security
The BIOS Setup utility includes an option that allows a user to set a user or supervisor
password, or both.
The user password controls booting of the system and controls access to the Setup utility and the
keyboard. User access to the BIOS Setup Utility is limited when a supervisor password is set.
The supervisor password allows full access to the system and the BIOS.
