NEC M Series
40" and 46" full high-definition LCDs
Multi-Function
Designer piece, entertainer and sales professional –
the M Series reflects a new age in visual communica-
tion. Refined yet extroverted, the 40” M40 and 46”
M46 attract people’s attention and adapt seamlessly
to even the most sophisticated architectural setups.
A strong presence for brands in flagship stores and
designer shops. A fashionable focus point in trendy
bars, restaurants, hotel lobbies and fitness studios.
An image carrier in business conference rooms and
control centers. The M Series fascinates in all kinds
on environments – as a stand-alone solution on an
elegant aluminium stand, mounted or in multi-display
installations. These displays tout the Digital Sig-
nage Technology Suite (DSTS), nearly 30
advanced features that enhance display
management, improve screen performance
and lower your total cost of ownership.
¤ Full 1080p HD resolution provides stunning detail for video and broadcast applications
¤ Built-in expansion slot future-proofs your display investment, allowing for seamless integration of NEC and third-party components,
including an HD-SDI card, single-board computer and DVI daisy chain capability
¤ Digital video interface with HDCP supports high-definition components
¤ Thermostatic cooling fans protect the display from overheating and extends its life
¤ On Screen Display (OSD®) menu navigation simplifies image adjustments
¤ GammaComp™ programmable lookup table, SpectraViewII™ Color Calibration Solution and adjustable color temperature
(2600 - 10,000K) provide unrivaled control of color performance
¤ CableComp™ long cable compensation provides flexibility when installing the display at distances far from a connected PC and keyboard
¤ Six-way color control allows for precise and simplified color, color temperature and saturation adjustment
¤ Rapid Response™ technology delivers virtually uninterrupted, undistorted viewing of high-speed, full- motion video
¤ Advanced AccuBlend™ converts non-native resolutions to the display’s resolution
¤ Multiple aspect ratio control allows flexibility with today’s many source choices
¤ Clear QAM/ATSC/NTSC tuner available on -AVT units only
¤ Available speakers and wall mount enhance the visual experience
¤ Environmental friendliness (RoHS-compliant, low power consumption, biodegradable plastics) maximizes the user’s investment and
helps them be “green”
¤ 3-year parts and labor warranty, including backlight, provides peace of mind

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
OSD is a registered trademark, and CableComp, GammaComp and SpectraViewII
are trademarks of NEC Display Solutions. All other brand or product names are
trademarks or registered trademarks of their respective holders. Product specifications
subject to change. 10/08 ver. 3.
©2008 NEC Display Solutions of America, Inc. All rights reserved.
MODEL M40-2 (-AV, -AVT) M46-2 (-AV, -AVT)
LCD MODULE
Viewable Size (Diagonal) 40” 46”
Panel Technology SPVA
Native Resolution 1920 x 1080
Pixel Pitch 0.641mm 0.53mm
Brightness (Typical) 450 cd/m2
Contrast Ratio (Typical) 3000:1
Active Screen Area (W x H) 34.9 x 19.6 in. / 885.6 x 498.2mm 40.1 x 22.5 in. / 1018.1 x 572.7mm
CONNECTIVITY
Input Terminals
RGB1 (Digital) DVI-D 24 pin (HDCP)
RGB2 (Analog) 15-pin D-sub
RGB3 (Analog) 5 BNC (RGBHV)
Video 1 Composite (Shared RCA and BNC)
Video 2 S-Video
Video 3 HDMI
Component Video 1 (DVD/HD) Component BNC (Y,Cb/Pb, Cr/Pr)
Audio RCA (L/R) x 2: Stereo MiniJack + external speaker jacks
Output Terminals
RGB Yes
Video Yes
Audio Yes
Audio Amplifier 15W Stereo
External Control RS-232 for multiple monitor control, IR, DDC/CI
Digital Tuner M40-2-AVT M46-2-AVT
FEATURES
Additional Features Power management, Plug and Play (DDC/CI, DDC2B), PIP (remote), multi-level zoom, FullScan, 6-axis color, CableComp, TileMatrix, TileComp, screen saver,
Rapid Response,video ready (tuner available), infrared remote control included, motion-adaptive 3D-Y/C comb filter, sRGB color, sleep timer, 24x7 scheduler
POWER
Power Requirements AC 100-120V / AC 220-240V @ 50/60 Hz
Power Consumption (Typical) 175W 235W
Power Consumption (Standby Mode) <4W
PHYSICAL SPECIFICATIONS
Bezel Width (L/R, T/B) 1.8 in. / 1.6 in. , 46.6mm / 40.6mm
Dimensions (with stand; WxHxD) 38.7 x 24.7 x 15.7in. / 981.8 x 627.4 x 400mm 43.8 x 27.7 x 15.7 in. / 1112.8 x 704.4 x 400mm
Dimensions (without stand; WxHxD) 38.7 x 22.9 x 5.6 in. / 981.8 x 582.4 x 142.5mm 43.8 x 26 x 5.6 in. / 1112.8 x 659.4 x 142.5mm
Packaging Dimensions (WxHxD) 45.2 x 30.7 x 21.3 in. / 1147 x 780 x 540mm 50.3 x 34.4 x 21.3 in. / 1278 x 875 x 540mm
Net Weight (with stand) 71.9 lbs. 86.6 lbs.
Net Weight (without stand) 64.8 lbs. 79.6 lbs.
Gross Weight (with box) 92.4 lbs. 109.6 lbs.
VESA Hole Configuration 200 x 200mm (8 hole) / 200 x 100mm (6 hole)
ENVIRONMENTAL CONDITIONS
Operating Temperature 5-40°C / 41-104°F
Operating Humidity 10-80%
ACCESSORIES
Included Stand, power cord, 15-pin D-sub cable, user manual, setup sheet, wireless remote control, batteries, CD-ROM
Optional External speakers (SP-M40), tilt wall mount kit (WMK3260-L), Digital Signage
Kit (DSK3260), black bezel (BB-M40), black speaker bezel (BBS-M40), Spec-
traViewII Color Calibration Solution (SVII-KIT), single board computer (MPD-
SBC-8/16-2), DVI daisychain (SB-L008WU), internal HD-SDI card (SB-L007KK)
External speakers (SP-M46), tilt wall mount kit (WMK3260-L), Digital Signage
Kit (DSK3260), black bezel (BB-M46), black speaker bezel (BBS-M46), Spec-
traViewII Color Calibration Solution (SVII-KIT), single board computer (MPD-
SBC-8/16-2), DVI daisychain (SB-L008WU), internal HD-SDI card (SB-L007KK)
WARRANTY/SERVICE
On-Site Limited Warranty 3 years parts and labor, including backlight
Specifications for M40/M46
