NEC ShieldPRO N22A User manual

マスタ タイトルの書式設定
High Performance Strengthened Practicality
N22A
NEC Ruggedized Notebook
FC-NOTE Series
Durability and toughness.
ShieldPRO provides the
better operation even under
the severe environments.
■Guarantee a wide operating
temperature range
(-20 to 50 degrees C)
Even with using battery or AC adapter
■Improved dust and water
resistance (conforming to IP65)
Conforming to IP54 when connecting to
dust and water resistant cable
■Long lasting battery
Lasts up to 12 hours of life
(when using long lasting battery)
■High performance CPU
Intel® Core™ 2 Duo Processor
U7500(1.06GHz)
■High brightness LCD
Max. 750cd/m2
(adjustable values 1cd/m2to 750cd/m2)
■HDD and battery are detachable
from the side of the body
■IEEE1394 port, Express Card slot
■Built-in Bluetooth® models are
available
■Equipped with the touch stylus
on the side of LCD
■USB port x1 on the right side,
x2 on the back side
Long Term Supply / Maintenance
■Maintain the system long
- Product supply until Dec 2012
- Long term maintenance until Dec
2018
Great Deal of Choice
■English keyboard, Backlight
Keyboard and silicon disk
model are available
Convertible Screen
■Both Note Type and Tablet
Type usage are available
http://www.nec.com/global/prod/indpc/
Notes:
The configuration cannot be changed after purchase.
For Windows® XP pre-installed model, Microsoft® Windows® XP Professional operating system (Service Pack 2) is installed. Please note that Service Pack cannot be deleted or downgraded.
■Selection Menu The following combinations are available in accordance with your demands.
Selection Menu
Keyboard Memory
1GB
(1GB×1)
2GB
(2GB×1)
Disk, Battery
Standard HDD×1
(Serial ATA: 80GB)
Standard battery
Base
FC-N22A
Wireless LAN/Fingerprint Sensor/Bluetooth
Wireless LAN : ○
Fingerprint Sensor : ×
Bluetooth® : ○
FC-N22A /
Please note your choices,
Model Number
English,
Standard
Keyboard
P S4 S
6
English,
Backlight
Keyboard
8
Silicon disk ×1
(Serial ATA: 32GB)
Standard battery
N
Wide temperature HDD ×1
(Ultra ATA: 40GB)
Wide temperature battery
W
Standard HDD×1
(Serial ATA: 80GB)
Long lasting battery
T
Silicon disk ×1
(Serial ATA: 32GB)
Wide temperature battery
K
Wireless LAN : ○
Fingerprint Sensor : ○
Bluetooth® : ○
W
Wireless LAN : ×
Fingerprint Sensor : ○
Bluetooth® : ×
F
Wireless LAN : ×
Fingerprint Sensor : ×
Bluetooth® : ×
Z
OS
Windows®7
Professional
(English)
6
Windows®XP
Professional
(English)
Y

NEC Corporation 7-1, Shiba 5-chome, Minato-Ku, Tokyo 108-8001 Issued in Apri 2011
Contact us
The specifications may be changed without any notification.
●Microsoft, Windows is registered trademark of the Microsoft Corporation in the United States and other countries.
●Intel, Intel Core and Intel Speed Step are trademarks or registered trademarks of the Intel Corporation or its affiliates in the United States and other countries.
●Other registered trademarks and trademarks used in this catalog are the property of their respective companies.
●Product names in this catalog are the trademarks or registered trademarks of their respective companies.
■Specifications
■Environmental Conditions *1 *4 ■Peripherals
*1 In case ShieldPRO operate continuously for a long time, even under the environment described in this conditions, it may not operate rightly. In addition, in case of using 3rd party components, ShieldPRO will be subject to the environment
conditions of the component. If ShieldPRO is kept under the temperature at the range below 0 degree and/or over 50 degrees, it may be possible that the clock of ShieldPRO will be fast or slow. In such case please set the clock again.
*2 The battery of ShieldPRO can be charged under the temperature at the range from 5 to 40 degrees C with non-operational mode.
*3 This does not guarantee the durability for sympathetic vibrations occurring at close to the natural frequency of the ShieldPRO.
*4 This environmental conditions are for ShieldPRO main unit. The environmental conditions for peripherals are different from it.
Approx. 2.5kg (Including a standard battery)Weight
290 (W) ×255 (D) ×47 (H) mm (Excluding protruding and bumper section)Dimensions
15W (Max: 45W)Power consumption (approximately)
Designed in accordance with RoHS directives. Power supply (AC Adapter)is designed in accordance with EMC directives (EN55022, EN61000-6-2)*, and
on Low Voltage directives (EN60950-1)* *Required for CE marking
Standards
[Option] FC-VA01N (12V Car(7A) / 24VCar(3.5A) compatible Connection: Cigar socket)Car adapter
AC100～240V±10%, 50/60HzAC adapter
[Selection]
Standard Battery: 8 hours, Charging time: 4 hours, Weight: 0.4kg
Wide Temperature Battery: 9 hours, Charging time: 4.5 hours, Weight: 0.5kg
Long Lasting Battery: 12 hours, Charging time: 4.5 hours, Weight: 0.55kg
Battery
Operating time
16V±5％Boot-up voltage
Power
Automatic or discretionary settings are available (CPU and hard disk control, power-saving monitor function, and standby or hibernation functions)Power management
[Selection] Built-in（line type sensor）
Fingerprint recognition enable users to log on to OS or unlock screen saver
Fingerprint
sensor
Security Feature
ExpressCard/54 slot×1, Express Card x1Express Card slot
TypeⅠ/Ⅱ×1 slot (TypeⅢuse not supported), PC Card Standard compliant, Card Bus compatiblePC card slot
SD/SDHC memory card compatible x1Memory card slot
Card slot
Built-in PCM record/replay feature and monaural speaker (front-side), Microphone input port (stereo, mini jack) and output port shared with headphone/line
(stereo, mini jack)
Audio-related
[Selection]Bluetooth®
[Selection] Triple wireless LAN, IEEE802.11a/b/g compliant (11a: W52/W53/W56 compatible) WEP compatible [encryption key 64/128 bit (user-setting key
40/104 bit), WPA-PSK (TKIP/AES) compatible, WPA2-PSK (AES) compatible
Wireless LAN
RJ45 (1000BASE-T/ 100BASE-TX/ 10BASE-T) LAN connector x1Built-in LAN
Network
External monitor connector (Analog RGB) Mini D-sub 15 pin (female)Display
Max. 115,200bps D-sub9 pin×1 (male）Serial
4 pin x1, IEEE1394a compatibleIEEE1394
3 ports (including 1 port that enhanced plug life), USB2.0 compatibleUSB
Interface
Optional features can be allocated as user requested (Max. 10 buttons)Tablet button
Touchpad, Touch panelPointing device
[Selection] Backlight keyboardKeyboard
Input
devices
[Selection] 32GB (Serial ATA)Silicon disk drive
[Selection] 80GB (Serial ATA) or 40GB (Wide temperature: Ultra ATA)Hard disk drive
[Option] FC-DV002UA (USB connection)DVD super multi drive
Secondar
y Storage
LCD: Max 1024×768 pixels (16.77million colors) External monitor: Max 1600×1200 pixels (16.77million colors)Resolution / Display colors
Internal Mobile Intel® GME965 Express chip set (Video RAM：Max 384MB (using main memory) )Graphic accelerator
12.1”,TFT LCD (XGA)Display device
Display
functions
Max: 4GB SO-DIMM slot ×2 DDR2-SDRAM (PC2-4200 (DDR2-533))Memory
TPM v1.2 compliantSecurity chip
Mobile Intel® GME965 Express Chipset, ICH8-MChipset
533MHz (memory bus: 533MHz）System bus
2048KB (internal CPU)Secondary
32KB×2 for instruction / 32KB×2 for data (built-in CPU)Primary
Cache memory
Intel® Core™ 2 Duo Processor Ultra Low Voltage U7500 (Extended Intel SpeedStep® technology) [1.06GHz]CPU
FC-N22A
: IEC60068-2-6
: MIL-STD-810F, Method 514.5 Category 24 FIGURE 514.5C-17
Sine wave excitation
Random wave oscillation
Non-
operation
: IEC60068-2-6Sine wave excitation
During
operationAssessment
criteria
Frequency 10～55Hz:0.15mm (0-P)
Frequency 55Hz～500Hz:19.6m/s2 (0-P)
Frequency 20Hz～1000Hz:0.04G2/Hz
Frequency 1000Hz～2000Hz:-6dB/Octave
[Sine wave]
[Random wave]
Non-operation
Frequency 10～55Hz:0.075mm (0-P)
Frequency 55Hz～500Hz:9.8m/s2 (0-P)
[Sine wave]During operation
Vibration
Resistance*3
IEC 60068-2-27 / MIL-STD-810F, Method 516.5Assessment criteria
490m/s2, 11ms, half-sine waveNon-operation
147m/s2, 11ms, half-sine waveDuring operation
Shock
Resistance*3
IEC 60068-2-13 / MIL-STD-810F, Method 500.4Assessment criteria
2,000 ft/min（609.6m/min）Rate of change
40,000ft (12,190m)Non-operation
15,000ft (4,572m)During operation
Altitude
IEC 60068-2-30 / MIL-STD-810F, Method 507.4Assessment criteria
5％to 95％RH (no condensation）Non-operation
5％to 95％RH (no condensation）During operation
Humidity
IEC 60068-2-1,2,14 / MIL-STD-810F, Method 501.4 502.4Assessment criteria
-40 to 70 degrees CNon-operation
-20 to 45 degrees C5 to 40 degrees CTablet
-20 to 50 degrees C5 to 45 degrees CNoteDuring
operation*2
Temperature
Wide Temperature Hard disk /
Wide Temperature Battery,
Silicon Disk / Wide Temperature Battery
Standard Hard disk and Standard Battery,
Standard HDD, Long lasting Battery,
Silicon Disk and Standard Battery
Conditions
Items
Keyboard cover (US)FC-KC01N/US
Mounting bracketFC-RK02N
Shoulder beltFC-BL01N/L
Hand beltFC-BL01N/S
Protection filmFC-N019
Dust and water resistance PC card coverFC-SC05N
Dust and water resistance PC plug coverFC-SC04N
Dust and water resistance USB cableFC-SC03N
Dust and water resistance Serial cableFC-SC02N
Dust and water resistance LAN cableFC-SC01N
Car adapterFC-VA01N
Battery chargerFC-BC01N
AC adapterFC-AA01N
Spare battery (Long lasting)FC-BP01N/L
Spare battery (Wide temperature)FC-BP01N/W
Spare battery (Standard)FC-BP01N
External DVD super multi driveFC-DV002UA
Silicon disk drive (32GB SATA)FC-SD32KN/S
Hard disk drive (Wide temperature)FC-HD40KN/S
Hard disk drive (Standard)FC-HD80KN/S
Extended RAM board (2GB, PC2-6400)FC-UG-M028
Extended RAM board (1GB, PC2-6400)FC-UG-M027
Product NameModel Name
ShieldPRO N22A
