NEC VERSA 6060 WINDOWS 98 - UPGRADE INFORMATION User manual

First Printing — September 1997
Copyright 1997
NEC Computer Systems Division, Packard Bell NEC, Inc.
1414 Massachusetts Avenue
Boxborough, MA 01719
All Rights Reserved
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related materials, is
the valuable property of NEC Computer Systems Division, Packard Bell NEC, Inc.
(NECCSD, PBNEC) and/or its licensors. NECCSD and/or its licensors, as appropriate, re-
serve all patent, copyright and other proprietary rights to this document, including all de-
sign, manufacturing, reproduction, use, and sales rights thereto, except to the extent said
rights are expressly granted to others.
The NECCSD product(s) discussed in this document are warranted in accordance with the
terms of the Warranty Statement accompanying each product. However, actual
performance of each such product is dependent upon factors such as system configuration,
customer data, and operator control. Since implementation by customers of each product
may vary, the suitability of specific product configurations and applications must be
determined by the customer and is not warranted by NECCSD.
To allow for design and specification improvements, the information in this document is
subject to change at any time, without notice. Reproduction of this document or portions
thereof without prior written approval of NECCSD is prohibited.
FaxFlash is a service mark of NEC Computer Systems Division (NECCSD), Packard Bell NEC, Inc.
NEC is a registered trademark, Versa is a U.S. registered trademark, MiniDock, VersaBay, VersaGlide, and
PortBar are trademarks, and UltraCare is a U.S. registered service mark of NEC Corporation, used
under license.
All other product, brand, or trade names used in this publication are the property of their respective owners.

xi
Preface
This service and reference manual contains the technical information necessary to set up and
maintain the NEC Versa®6060 notebook computer.
The manual also provides hardware and interface information for users who need an over-
view of the system design. The manual is written for NEC-trained customer engineers, sys-
tem analysts, service center personnel, and dealers.
The manual is organized as follows:
Section 1 Technical Information, provides an overview of the hardware and interface
components. System specifications are listed including computer dimensions, weight, envi-
ronment, safety compliance, power consumption, and system memory specifications.
Section 2  Setup and Operation,takes the authorized service technician or dealer from
unpacking to setup and operation. The section includes a description of operating controls,
setting parameters and accessing the NECCSD bulletin board system (BBS).
Section 3  Troubleshooting, lists troubleshooting procedures as well as helpful
servicing hints.
Section 4  Field Service Guidelines,provides disassembly and assembly procedures,
and an exploded-view diagram of the NEC Versa system with part numbers.
Appendix A  Connector Locations and Pin Assignments,provides a list of the main
board internal connector pin assignments and a list of external pin assignments.
Appendix B  Video Modes,lists NEC Versa supported video modes.
An Index is included for convenience.

xiii
Abbreviations
Aampere
AC alternating current
ACPI advanced control power
interface
APM advanced power management
AT advanced technology
(IBM PC)
BBS Bulletin Board System
BCD binary-coded decimal
BCU BIOS Customized Utility
BIOS basic input/output system
bit binary digit
bpi bits per inch
bps bits per second
BUD BIOS Upgrade Diskette
C Celsius or centigrade
Cache high-speed buffer storage
CAM constantly addressable memory
CAS column address strobe
CCFT cold cathode
CD-ROM compact disk ROM
CGA Color Graphics Adapter
CGB Color Graphics Board
CH channel
clk clock
cm centimeter
CMOS complementary metal oxide
semiconductor
codec compressor/decompressor
COM communication
CONT contrast
CPGA ceramic pin grid array
CPU central processing unit
CRT cathode-ray tube
DAC digital-to-analog converter
DACK DMA acknowledge
DC direct current
DIMM dual-inline memory module
DIP dual in-line package
DLAB Divisor Latch Address bit
DMA direct memory access
DMAC DMA controller
DOS disk operating system
DRAM dynamic RAM
DTE data terminal equipment
ECC error checking and correction
ECP extended capabilities port
EDO enhanced date out
EDS error detecting system
EGA Enhanced Graphics Adapter
EMS Expanded Memory
Specification
EPP enhanced parallel port
EPROM erasable and programmable
ROM
EVGA Enhanced Video Graphics
Array
F Fahrenheit
FAX facsimile transmission
FCC Federal Communications
Commission
FDD floppy disk drive
FG frame ground
FIR fast infrared
FM frequency modulation
Fn function
FPU floating-point unit
FRU field-replaceable unit
GB gigabyte
GND ground
GUI graphical user interface
HDD hard disk drive

xiv Abbreviations
HEX hexadecimal
HGA Hercules Graphics Adapter
Hz hertz
IC integrated circuit
ID identification
IDE intelligent device electronics
IDTR interrupt descriptor table
register
IMR Interrupt Mask register
in. inch
INTA interrupt acknowledge
IPB illustrated parts breakdown
IR infrared
IRR Interrupt Request register
ISA Industry Standard Architecture
ISR In Service register
I/O input/output
IPC integrated peripheral controller
ips inches per second
IRQ interrupt request
K kilo (1024)
k kilo (1000)
KB kilobyte
kg kilogram
kHz kilohertz
kV kilovolt
lb pound
LCD liquid crystal display
LDTR local descriptor table register
LED light-emitting diode
LSB least-significant bit
LSI large-scale integration
Mmega
mA milliamps
max maximum
MB megabyte
MDA Monochrome Display Adapter
MFM modified frequency modulation
Mhz megahertz
mm millimeter
ms millisecond
MSB most-significant bit
NASC National Authorized Service
Center
NC not connected
NDP numeric data processor
NMI Non-maskable Interrupt
ns nanosecond
NSRC National Service Response
Center
NTFS NT file allocation
PAL programmable array logic
PC personal computer
PCB printed circuit board
PCI peripheral component
interconnect
PFP plastic flat package
PIO parallel input/output
pixel picture element
PJQFP plastic J-lead quad flat pack
PLCC plastic lead chip carrier
PLL phase lock loop
p-p peak-to-peak
PnP Plug and Play
PPI programmable peripheral
interface
PROM programmable ROM
QFP quad flat pack
RAM random-access memory
RAMDAC RAM digital-to-analog
RAS row address strobe
RGB red green blue
RGBI red green blue intensity
ROM read-only memory
rpm revolutions per minute

Abbreviations xv
R read
RTC real-time clock
R/W read/write
Sslave
SCSI Small Computer System
Interface
SDLC Synchronous Data Link
Control
SG signal ground
SIMM single inline memory module
SIR serial infrared
SOIC small outline integrated circuit
SQFP silver quad flat package
SVGA Super Video Graphics Array
SW switch
TCP thin chip package
TFT thin film transistor
TQFP thin-quad flat package
TSC Technical Support Center
TTL transistor/transistor logic
tpi tracks per inch
UART universal asynchronous
receiver/transmitter
USB Universal Serial Bus
Vvolt
Vdc volts, direct current
VESA Video Electronics Standards
Association
VFO variable frequency oscillator
VGA Video Graphics Array
VLSI very large-scale integration
VRAM virtual RAM
Wwatt
µf microfarad
µPD microprocessor
µs microsecond
Ωohm

iii
Contents
Preface......................................................................................................................... xi
Abbreviation................................................................................................................ xiii
Section 1 Technical Information
Hardware Overview—Front.........................................................................................1-2
Liquid Crystal Display (LCD)................................................................................1-2
Power Button .......................................................................................................1-3
LCD Status Bar and Power Indicator....................................................................1-4
Status Icons...................................................................................................1-5
Keyboard..............................................................................................................1-5
NEC VersaGlide...................................................................................................1-6
Diskette Drive and the NEC VersaBay II ..............................................................1-7
Infrared (IR) Assembly..........................................................................................1-7
Hardware Overview—Right Side.................................................................................1-8
Hardware Overview—Left Side...................................................................................1-9
PC Card Slots.......................................................................................................1-9
Battery Bay Cover Release....................................................................................1-9
Hardware Overview—Rear Side..................................................................................1-10
Keyboard/Mouse Port...........................................................................................1-10
Parallel Port (LPT1)..............................................................................................1-10
Expansion Port .....................................................................................................1-11
External Monitor (Video) Port..............................................................................1-11
Serial Port (COM1) ..............................................................................................1-11
Hardware Overview—Internal Components.................................................................1-11
Battery Pack.........................................................................................................1-11
Hard Disk Drive....................................................................................................1-11
Diskette Drive.......................................................................................................1-12
Versa Bay II SuperDisk LS-120 Drive..................................................................1-12
20X CD-ROM Reader..........................................................................................1-12
CPU Board...........................................................................................................1-12
Audio Board.........................................................................................................1-13
AMP Board ..........................................................................................................1-14
I/O Board .............................................................................................................1-14
CMOS Battery......................................................................................................1-14
Bridge Battery......................................................................................................1-14

iv Contents
System Memory...........................................................................................................1-14
Memory Map........................................................................................................1-14
System Video...............................................................................................................1-15
Parallel Interface..........................................................................................................1-15
Serial Interface.............................................................................................................1-16
NEC Versa Chip Set....................................................................................................1-16
Intel Pentium P55CLM Microprocessor................................................................1-17
M-Triton System Controllers ................................................................................1-17
256K X Flash ROM..............................................................................................1-17
ROM BIOS....................................................................................................1-17
VGA Controller....................................................................................................1-18
Parallel Interface...................................................................................................1-18
Keyboard Controller .............................................................................................1-18
PC CardBus Controller.........................................................................................1-19
Sound Integrated Circuit.......................................................................................1-19
Interrupt Controllers.............................................................................................1-20
Power Management Overview .....................................................................................1-21
System Power Management ..................................................................................1-22
Local Power Management.....................................................................................1-22
Plug and Play...............................................................................................................1-23
Specifications...............................................................................................................1-24
Section 2 Setup and Operation
Unpacking the System..................................................................................................2-1
Hardware Setup...........................................................................................................2-1
Cable Connections................................................................................................2-3
Power Sources.............................................................................................................2-4
Using the AC Adapter...........................................................................................2-4
Using the Main Battery Pack.................................................................................2-5
Checking Battery Power Levels......................................................................2-5
What to Do When Battery Power Gets Low...................................................2-5
Returning the Battery to Full Operation..........................................................2-6
When to Change the Battery..........................................................................2-6
Battery Handling............................................................................................2-6
Replacing the Battery Pack ............................................................................2-7
Battery Precautions........................................................................................2-10
Recharging Battery Precautions......................................................................2-10

Contents v
NEC VersaBay II Battery and Adapter Kit (Optional)...........................................2-11
Extending Battery Life..........................................................................................2-11
Using the DC Car Adapter....................................................................................2-11
Operating Controls ......................................................................................................2-12
Status Bar.............................................................................................................2-13
Status Icons...................................................................................................2-13
Function Keys (Fn Keys).......................................................................................2-14
Smart Power Switch .............................................................................................2-14
Dip Switch............................................................................................................2-15
Updating the System BIOS ............................................................................2-15
Customizing BIOS Message...........................................................................2-17
Power-on Self-Test (POST).........................................................................................2-17
POST Errors.........................................................................................................2-18
Setup Utility ................................................................................................................2-19
Accessing Setup....................................................................................................2-20
With an Error at POST ..................................................................................2-20
With No Errors at POST................................................................................2-20
Setup Utility Main Menu.......................................................................................2-20
How to Use Setup..........................................................................................2-21
Looking at Screens ........................................................................................2-21
Using Keys.....................................................................................................2-22
Checking/Setting System Parameters..............................................................2-22
Setup Menus.........................................................................................................2-25
Standard CMOS Setup...................................................................................2-27
Advanced CMOS Setup.................................................................................2-26
Power Management Setup Power Management Setup....................................2-26
Peripherals Setup ...........................................................................................2-28
Change User Password...................................................................................2-28
Change Supervisor.........................................................................................2-28
Auto Configuration with Defaults...................................................................2-28
Save Setting and Exit.....................................................................................2-28
Exit Without Saving.......................................................................................2-29
Using Setup to Set Power Management ................................................................2-29
Using the Save to File (STF) Feature..............................................................2-29
STF Benefits..................................................................................................2-30
Automatic Power-Saving Features........................................................................2-31

vi Contents
Section 3 Troubleshooting
Quick Troubleshooting ................................................................................................3-1
Helpful Questions ........................................................................................................3-4
Section 4 Field Service Guidelines
Preventive Maintenance ...............................................................................................4-1
Cleaning the Notebook’s Exterior.........................................................................4-1
Cleaning the Notebook’s Interior ..........................................................................4-2
Protecting the Disk Drives ....................................................................................4-2
Handling the Battery Packs...................................................................................4-3
Maintaining the LCD Quality................................................................................4-3
Required Tools and Equipment ....................................................................................4-3
Disassembly and Reassembly........................................................................................4-4
Hard Disk Drive....................................................................................................4-5
Diskette Drive.......................................................................................................4-7
Main Battery Pack (Li-Ion Type) ..........................................................................4-8
LCD and Top Cover.............................................................................................4-10
Power Button, Microphone Assembly, Keyboard..................................................4-12
LCD Status Bar, VersaGlide Assembly, Metal Keyboard Supports........................4-14
Bridge Battery, CMOS Battery, Buzzer ................................................................4-15
CPU Board...........................................................................................................4-16
AMP Board ..........................................................................................................4-17
I/O Board .............................................................................................................4-17
Illustrated Parts Breakdown.........................................................................................4-18
Service Information......................................................................................................4-22
Technical Support........................................................................................................4-22
Product Information.....................................................................................................4-23
Ordering Information from FaxFlash............................................................................4-24
Appendix A Connector Locations and Pin Assignments
Appendix B Video Modes
Index

Contents vii
List of Figures
1-1 NEC Versa 6060 Notebook ........................................................................... 1-1
1-2 LCD Panel..................................................................................................... 1-3
1-3 Power Button Location.................................................................................. 1-4
1-4 System Status Bar.......................................................................................... 1-4
1-5 Keyboard Layout ........................................................................................... 1-6
1-6 VersaGlide Location...................................................................................... 1-6
1-7 NEC VersaBay II Location............................................................................ 1-7
1-8 Right Side Features........................................................................................ 1-8
1-9 Left Side Features.......................................................................................... 1-9
1-10 Rear Features................................................................................................. 1-10
1-11 CPU Board Layout ........................................................................................ 1-12
1-12 Audio Board Layout ...................................................................................... 1-13
2-1 Connecting the AC Adapter ........................................................................... 2-1
2-2 Powering on the System................................................................................. 2-2
2-3 Power and I/O Connector Locations .............................................................. 2-3
2-4 NEC Versa AC Adapter................................................................................. 2-4
2-5 Removing the Cover ...................................................................................... 2-8
2-6 Removing the Battery .................................................................................... 2-8
2-7 Inserting the Battery Pack.............................................................................. 2-9
2-8 Replacing the Cover....................................................................................... 2-9
2-9 Connecting the Car DC Adapter..................................................................... 2-11
2-10 Keyboard Panel LEDs and Controls............................................................... 2-12
2-11 Status Bar Location ....................................................................................... 2-13
2-12 Dip Switch Location...................................................................................... 2-16
2-13 Setup Main Menu........................................................................................... 2-21
2-14 Advanced CMOS Setup Menu....................................................................... 2-22
4-1 Removing the Drive Bay Cover...................................................................... 4-5
4-2 Removing the Hard Disk Drive ...................................................................... 4-6
4-3 VersaBay II Release Latches.......................................................................... 4-7
4-4 Removing the Standard Diskette Drive........................................................... 4-8
4-5 Removing the Battery Compartment Cover.................................................... 4-9
4-6 Removing the Battery .................................................................................... 4-9
4-7 Removing the Bottom Base Screws................................................................ 4-10
4-8 Disconnecting the LCD Connectors ............................................................... 4-11

viii Contents
4-9 Removing the Power Button, Microphone Assembly, Keyboard..................... 4-12
4-10 Disconnecting Keyboard Cables..................................................................... 4-13
4-11 LCD Status Bar, VersaGlide Assembly, Metal Keyboard Supports................. 4-14
4-12 Bridge Battery, CMOS Battery, Buzzer ......................................................... 4-15
4-13 Removing the CPU Board.............................................................................. 4-16
4-14 Removing the I/O Board................................................................................ 4-18
4-15 NEC Versa Model 6060 Illustrated Parts Breakdown..................................... 4-26
A-1 CPU Board Layout ........................................................................................ A-1
A-2 I/O Board Layout........................................................................................... A-2
List of Tables
1-1 Model Configurations .................................................................................... 1-2
1-2 Memory Map................................................................................................. 1-15
1-3 NEC Versa Series Chip Types and Technologies............................................ 1-16
1-4 Interrupt Controllers...................................................................................... 1-20
1-5 Automatic Power-Saving Features ................................................................. 1-21
1-6 Maximum Performance Default Settings......................................................... 1-23
1-7 Specifications................................................................................................. 1-24
2-1 I/O Connector Descriptions............................................................................ 2-3
2-2 Control and Switch Functions ........................................................................ 2-12
2-3 Fn Key Operations......................................................................................... 2-14
2-4 POST Error Messages.................................................................................... 2-18
2-5 Setup Key Functions...................................................................................... 2-22
2-6 Setup Parameters........................................................................................... 2-22
3-1 Quick Troubleshooting................................................................................... 3-1
4-1 NEC Versa 6060 Series Disassembly Sequence.............................................. 4-4
4-2 NEC Versa 6060 Series Field-Replaceable Parts............................................. 4-20
4-3 NEC Service and Information Telephone Numbers......................................... 4-22
A-1 CPU Board Connectors.................................................................................. A-2
A-2 I/O Board Connectors.................................................................................... A-2
A-3 Keyboard/Mouse Connectors......................................................................... A-3
A-4 Serial Port Connector Pin Assignments .......................................................... A-3

Contents ix
A-5 CRT Connector Pin Assignments ................................................................... A-4
A-6 Parallel Printer Pin Assignments..................................................................... A-4
A-7 Power Connector........................................................................................... A-5
A-8 Hard Disk Drive Connector............................................................................ A-5
B-1 LCD Display Mode Setting (800x600 TFT Color LCD and
Simultaneous CRT Display) ....................................................................... B-1
B-2 LCD Display Extended Video Mode.............................................................. B-2
B-3 CRT Display Mode (CRT only)...................................................................... B-3
B-4 CRT Display Extended Video Mode .............................................................. B-4
B-5 Panning Video Mode (800x 600 TFT Color LCD and
Simultaneous CRT Display) ....................................................................... B-4

Section 1
Technical Information
The NEC Versa 6060 notebook computer is lightweight, compact, and fully IBM compati-
ble. This is the latest addition to the NEC Versa family.
NOTE
This service manual covers only the NEC
Versa 6060 model. All figures in this manual re-
flect this model.
Figure 1-1 NEC Versa 6060 Notebook
This section of the manual provides system configuration information, including an over-
view of hardware and interface components. See the following table for a systems specific
breakdown of hardware.

1-2 Technical Information
Table 1-1 Model Configurations
FEATURE NEC Versa 6060
CPU Intel Pentium® with
MMX Technology
P55CLM/166 MHz
On-Board DRAM 16-MB
Video Memory 2-MB included in
video chip
Hard Disk Drive 2.1 GB or 3.2 GB
CD-ROM Reader 20X CD ROM Reader
FDD or
SuperDisk LS-120 3 ½” 1.44MB 120MB
Color LCD 12.1” CCFT Super
VGA(SVGA),TFT
Color Display
HARDWARE OVERVIEW—FRONT
Take a moment to become familiar with the location and function of controls located on the
front of the system.
Liquid Crystal Display (LCD)
The LCD operates with NeoMagic NMG4 VGA controller. The controller supports XGA,
uses a 64-bit accelerator with a Peripheral Component Interconnect (PCI) interface.
The NEC Versa 6060 LCD features the following:

12.1-inch Thin Film Transistor (TFT) CCFT Super VGA (SVGA) single-backlite
color

0.306 mm dot pitch

16-bit digital interface

800 x 600 resolution

64K colors.
Additional LCD panel features:

Power LED that indicates the current power status. This LED is visible with the
LCD panel opened or closed.

Slide switch that adjusts screen brightness.

Technical Information 1-3
Figure 1-2 LCD Panel
Another video feature includes a CRT port on the system's rear panel that allows the user to
connect an optional monochrome or color external display to the system. The computer can
support the LCD and external display simultaneously.
Power-saving features for controlling the LCD's backlighting include the ROM-based hot
key combination Fn F5, and Auto Setup power management settings. See Section 2, Setup
and Operation, for information on using these settings. In addition, the automatic LCD
status feature conserves the backlight. When the LCD is closed the backlight shuts off
automatically, saving battery power.
Power Button
Slide the Power button to the right to power on and power off the computer. The Power
button is a “smart” switch, meaning that it recognizes when the system is in Suspend mode.
If in Suspend mode, you cannot power off until you press the Suspend button again to bring
the system out of Suspend mode.

1-4 Technical Information
Figure 1-3 Power Button Location
LCD Status Bar and Power Indicator
The LCD status bar is situated right below the LCD screen. It provides an easy way to de-
tect system status. Different graphic icons appear on the LCD bar indicating that a device is
accessed, an operation performed, or a power mode activated. The graphic icons displayed
on the LCD bar resemble either their physical characteristics or their primary function. See
the LCD Status Bar figure shown next, and the descriptions that follow for the specific
meaning of each icon.
The power indicator is located just above and to the right of the status bar. The power indi-
cator lights green when computer power is on, blinks green when in Suspend mode and
blinks amber to indicate that the battery power is low.
Figure 1-4 System Status Bar

Technical Information 1-5
Status Icons
The following list defines the status icons displayed in the system status bar.

Suspend — appears when the system is in Suspend mode. Suspend mode con-
serves system power by shutting down devices in the system while retaining data
and system status.

Power Management — shows the current power management mode in use, in-
cluding Off, Custom, High Performance or Longest Life.

Diskette or Versa Bay II SuperDiskLS-120 drive — appears when the NEC
Versa writes data to or retrieves data from a diskette.

Hard Disk — shows when the NEC Versa writes data to or retrieves data from
the hard disk.

Caps Lock — appears when Caps Lock is in effect.

Scroll Lock — shows that Scroll Lock is in effect.

Num Lock — appears when Num Lock is in effect. Num Lock lets the user enter
numbers for calculations via the numeric keypad.

Battery Status — displays the total percentage of battery power available.
Battery 1 appears when you have the main battery installed in the battery bay.
Battery 2 appears when you have an optional battery installed in the
VersaBay II.
Keyboard
The built-in, 83-key keyboard (U.S.) or 79-key keyboard (UK and Germany) uses the stan-
dard QWERTY format. The keyboard provides 12 function keys and 7 cursor control keys,
with an Fn key for ROM-based key functions. The numeric keypad is embedded in the stan-
dard key layout.

1-6 Technical Information
Figure 1-5 Keyboard Layout
NEC VersaGlide
The NEC VersaGlide is a built-in mechanism that functions as the system’s mouse. It con-
trols the on-screen pointer (cursor). To use the VersaGlide, move your finger across the
NEC VersaGlide pad, and the cursor follows. The buttons below the NEC VersaGlide al-
low the user to select or deselect menu items. Tap and double-tap are supported on the
VersaGlide pad.
If an external mouse is installed, the NEC VersaGlide is deactivated. A serial mouse is not
supported.
Figure 1-6 VersaGlide Location

Technical Information 1-7
Diskette Drive, CD-ROM Reader and the NEC VersaBay II
A standard 1.44-MB diskette drive or Versa Bay II SuperDiskLS-120 drive comes in-
stalled in the VersaBay II slot on the front of the computer. The VersaBay II expansion slot
lets the user replace the standard diskette drive with the 20X CD-ROM reader that also
ships with the system. In addition to the CD-ROM reader, the VersaBay II accepts NEC
options including a second battery pack, or an additional hard disk.
Figure 1-7 NEC VersaBay II Location
Infrared (IR) Assembly
The IR assembly consists of a small board with one infrared LED and one pin photo diode,
attached to the CPU board. The board allows the NEC Versa computer to communicate
with other infrared-ready computers. For example, the infrared port allows the user to
transfer files between the NEC Versa and an IR-equipped computer, or print to an IR-
equipped printer without using cables.
NOTE
Do not use the IR port directly under fluo-
rescent or incandescent light.

1-8 Technical Information
HARDWARE OVERVIEW—RIGHT SIDE
Review the following section for a description of the hardware on the right side of the NEC
Versa.
Figure 1-8 Right Side Features

Volume Control — Allows you to control the speaker volume.

Headphones/Line-Out — Lets you connect external headphones, speakers or
audio system to your NEC Versa system. Using this port disables the built-in
system speakers.

Line-In — Lets you use another audio system, like a home stereo, as an input
source. Use a the cable to connect to the Line-Out port on the other audio sys-
tem to record or play.

Microphone (MIC) — Allows you to connect an external microphone for
monophonic recording or amplification through the unit. Plugging in an external
microphone disables the built-in microphone.

Hard Disk Drive Bay Cover — The hard disk drive bay contains the removable
hard disk drive. Depending on your NEC Versa’s configuration, it contains a
2.1-GB hard disk drive or 3.2-GB hard disk drive.

Kensington Lock Connection — Lets you provide added security by installing
an optional Kensington Lock.

USB Port — The Universal Serial Bus (USB) allows the connection of up to
127 peripheral devices (printers, monitors, scanners, etc.) to your NEC Versa.

Fan Exhaust Port — This port provides air flow from the interior of the com-
puter to assist in keeping the system running at optimal performance.
