Business Desktop
Maximize the space and eco-friendliness of your work environment. The NEC
MultiSync EX Series, featuring ultra-slim, full HD LCD monitors, sets the bar for
“green” displays. The 23” MultiSync EX231W and EX231Wp feature a handful of
components that lower total cost of ownership by saving energy, tracking carbon
footprint emissions and minimizing packaging. In addition, these are our lightest,
thinnest and most ergonomically designed models to date; and boast outstanding
screen performance and advanced display technologies to optimize your desktop
computing productivity.
It’s easy to be green. The MultiSync EX Series uses LED backlighting, which optimizes
energy efficiency. Compared to conventional LCDs, these models consume up to
less power overall, radiate less heat, use less packaging, weigh less, utilize recycled
plastics in their production and are free of hazardous materials such as mercury and
arsenic. Other eco-friendly benefits include ECO Mode™ and auto brightness for further
energy savings, a resettable carbon footprint meter for tracking the conservation of
green gas emissions, and a significant reduction in packaging materials.
NEC MultiSync®EX Series
Ultra-slim, LED-backlit desktop LCD monitors ideal for corporate environments
Features & Benefits
Minimalist design, featuring an ultra-thin bezel
width (14.6mm) and depth (16.4mm), puts the focus
on the screen vs. the cabinet
LED backlight technology provides for industry-
leading low power consumption and less
hazardous materials
Height-adjust, pivot, tilt and swivel capabilities add
flexibility and comfort to your viewing preferences
XtraView® technology provides for some of the
widest viewing angles available
Human sensor monitors the presence of a user in
front of the display and can go into power saving
mode if the user leaves
Ambient light sensor minimizes power consumption
by automatically adjusting the brightness to the
optimal setting depending on ambient lighting,
screen content or both
ECO Mode allows you to manually adjust the
display’s brightness to two preset settings, saving
more power and reducing your energy costs
Intelligent Power Manager (IPM) system and off
timer provide innovative power-saving methods and
reduce CO2emissions by shifting to a lower power
consumption level or automatically powering down
when the monitor is on but not in use
Carbon footprint meter helps track and calculate
the conservation of green gas emissions via OSD
and NaViSet™Administrator
6-preset Dynamic Video Mode enhances video and
images with real-time optimization of brightness,
color and contrast
Compact packaging helps reduce paper usage,
shipping costs and waste
EPEAT Gold compliance ensures the displays
reduce hazardous waste and electricity usage,
resulting in lower energy costs and increased
protection for the environment
ENERGY STAR 5.0 compliance reduces electrical
costs and lowers total cost of ownership
NEC Display Solutions’ quality and reliability
provide peace of mind with a 3-year limited parts
and labor warranty (including backlight) and
unrivaled customer service and technical support
The EX Series’ human and ambient
light sensors (L) automatically
detect your work conditions to
determine the proper display
brightness, thereby conserving
power (up to 94%). Touch-sensitive
OSD® controls (R) are integrated
into the bezel, making display
adjustments easier than ever.

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
MultiSync and XtraView are registered trademarks and ECO Mode
and Rapid Response are trademarks of NEC Display Solutions. All
other brand or product names are trademarks or registered trade-
marks of their respective holders. Product specifications subject to
change. 5/11 ver. 1.
©2011 NEC Display Solutions of America, Inc. All rights
reserved.
The MultiSync EX Series features a 4-way ergonomic stand with capabilities of
pivot (A), height-adjustment (up to 110mm) (B), tilt (C) and swivel (D), allowing you
to create an ideal ergonomic display orientation for maximum viewing comfort.
For simple transport, a quick release lever (E) allows you to quickly and easily
remove the display from the stand, while the built-in recessed handle (F) helps
avoid damage to the bezel and screen while carrying.
B
C
E
G H
F
D
A
A top-mounted USB pass-through (G) allows for the easy addition of a webcam,
microphone or other peripherals. The input panel (H) includes a second USB pass-
through as well as a mini-AC adapter, and DisplayPort and DVI-I connections.
MODEL EX231W EX231Wp
LCD MODULE
Viewable Size (Diagonal) 23”
Aspect Ratio 16:9
Panel Technology TN PVA
Native Resolution 1920 x 1080
Pixel Pitch 0.265mm
Pixels Per Inch 96
Brightness (Typical) 250 cd/m2
Contrast Ratio (Typical) 1000:1 3000:1
Viewing Angle (Typical)
170° Vert., 176° Hor.
(85U/85D/88L/88R)
(CR>5)
178° Vert., 178° Hor.
(89U/89D/89L/89R)
(CR>5)
Response Time (Typical) Rapid Response (5ms) Rapid Response
(25ms)
Display Colors More than 16.7 million
SYNCHRONIZATION RANGE
Horizontal 31.5-83 KHz
Vertical 56-75 Hz
INPUT SIGNAL
Video Analog 0.7 Vp-p / 75 Ohms
Sync Separate Sync: TTL Level (positive/negative)
INPUTS DVI-I and DisplayPort
ADDITIONAL FEATURES Auto brightness with ambient light sensor;
Human sensor; USB pass-through; ECO Mode;
Carbon footprint meter; Resettable cost meter;
Integral power meter; Off timer; Ultra-thin
frame; Tilt; Swivel; Pivot; Height-adjustable
stand; Quick release stand; Carrying handle;
Rapid Response; Ambix; XtraView; Touch-
sensitive OSD user controls; NaViSet software;
Cable management; VESA mount; HDMI-
capable via DVI adapter; HDCP; DDC/CI; No
Touch Auto Adjust; Plug and Play (VESA DDC
2B); VESA DPMS power management; Dynamic
Video Mode; 6-preset color control system
(EX231Wp); Digital smoothing; Digital controls
POWER
Voltage Rating AC 100-120V / AC 220-240V
Power Consumption (Typical) 31W 27W
Power Consumption (Savings Mode) 0.37W
PHYSICAL SPECIFICATIONS
Dimensions (with stand; WxHxD) 21.3 x 15.8-20.1 x 8.5 in. /
540.2 x 401.3-511.3 x 215mm
Dimensions (without standl; WxHxD) 21.3 x 12.5 x 1.9 in. / 540.2 x 318.3 x 47.7mm
Weight (with stand) 9.3 lbs. / 4.2 kg
Weight (without stand) 6.2 lbs. / 2.8 kg
VESA Hole Configuration 100 x 100mm
ENVIRONMENTAL CONDITIONS
Operating Temperature 5 - 35°C / 41 - 95°F
Operating Humidity 20 - 80%
Operating Altitude 2000m / 6562 ft.
Storage Temperature -10 - 60°C / 14 - 140°F
Storage Humidity 10 - 85%
Storage Altitude 12,192m / 40,000 ft.
ACCESSORIES
Included Setup sheet; User manual; Power cord; DVI
cable; USB cable; Audio cable
WARRANTY/SERVICE
Limited Warranty 3 years parts and labor, including backlight*
* Warranty restrictions apply.
Contact your representative for details.
