NEC MultiSync LCD1530V User manual

Superior image quality, wide compatibility and renowned quality – the
MultiSync LCD1530 is the first monitor designed by the joint venture
NEC-Mitsubishi Electronics Display of America, leader in visual display
technology. Users who work in environments with space or weight
constraints but still need a monitor that provides superior image quality will benefit from this NEC
MultiSync LC monitor. Offering a slim footprint, low emissions, and bright, color saturated images,
the NEC LC 1530V is perfectly suited for demanding applications in corporate, medical and govern-
ment environments, as well as retail, manufacturing and transportation. The MultiSync LC 1530V is
the latest NEC Value Series LC monitor. It offers an ideal balance of features and price, and is avail-
able in our standard mist white or contemporary black cabinet colors.
Space-saving design for superior versatility. Weighing in at only 10.4 pounds, the MultiSync
LC 1530V is only 2.7” deep (without stand) and offers a 60% weight and space reduction over tradi-
tional CRT monitors. For enhanced flexibility, the LC 1530V monitor features VESA-standard wall- and
arm-mounting capabilities.
Superior image quality brightness and control. The MultiSync LC 1530V monitor delivers flicker-
free images and a high brightness level exceeding that of notebook LC s. OSM™ on-screen controls
enable quick and easy image adjustments.
Wide compatibility for ease of use. The MultiSync LC 1530V accepts RGB input directly and sup-
ports multiple resolutions from 640 x 480 to the recommended optimal resolution of 1024 x 768.
The NEC LC 1530V monitor is compatible with PC and Macintosh computers, Sun, Silicon Graphics,
and other workstations and x-terminals.
Dependability and quality in a
space-saving (15.0" viewable image
area) LC monitor
Slim footprint liberates you and
your desk (60% weight and space
reductions over comparable CRT
monitors)
Supports multiple resolutions up
to 1024 x 768 for image clarity
Wall/arm mounting capabilities
which comply with VESA standards,
offering flexibility and enhanced
versatility
New stand design offers ergonomic
benefits by featuring a more com-
fortable viewing height
Low power consumption(50% less
than comparable CRT monitors) and
reduced emissions conserve energy
and reduce costs
Internal power source frees up
valuable workspace
NEC’s quality and reliability of
NEC/Mitsubishi provides peace of
mind (backed by a 3-year warranty
and outstanding service and sup-
port)
Kensington Security Lock compati-
bility protects your investments
AccuColor Control System allows
you to adjust on-screen colors to
your personal preference
see more.
lcd series
©2000 NEC-Mitsubishi Electronics isplay of America, Inc. All rights reserved.
Multisync®lcd1530V™
MultiSync®LCD1530VTM
Screen 15"
Native Resolution 1024 x 768
LCD series

NEC MultiSync LCD1530V
15.0"/38 cm
15.0"/38 cm
ANALOG 0.7 Vp-p/75 ohms
Separate sync: L Level (Pos/Neg)
Over 16 million
31.0 KHz - 60.0 KHz
56.2 Hz - 75.0 Hz
720 x [email protected] Hz -
640 x [email protected] Hz - 75.0 Hz
800 x 600@ 56.0 Hz - 75.0 Hz
832 x 624@ 75.0 Hz - Hz
1024 x 7[email protected] Hz - 75.0 Hz (recommended resolution)
Digital Smoothing, digital controls, color control, OSM, Plug and Play
AC 100-120/220-240 V 50/60 Hz (Internal Power Supply)
A @ 100-120 V A @ 220-240 V
370.0 mm x 370.0 mm x 160.0 mm /14.6" x 14.6" x 6.3"
370.0 mm x 309.3 mm x 68.0 mm /14.6" x 12.2" x 2.7"
4.7 kg/10.4 lbs
UL/C-UL or CSA, UV/GS, ENERGY SAR , CE, FCC CLASS B/CANADAIAN DOC, UV/ERGONOMIE, CO ’99( CO’95 for
black cabinet monitor), Ctick
D-sub to D-sub Straight Cable
Operating emperature: 5ºC to +35º (Storage emperature: -10ºC to +90ºC)
Operating Humidity: 10% to 80% (Storage Humidity: 10% to 90%)
Operating Altitude: 3,000 m to 9,843 feet (Storage Altitude: 9,500 m to 31,168 feet)
3 years parts and labor, including backlight
MultiSync is a registered trademark and LCD1530V is a trademark of
NEC-Mitsubishi Electronics Display of America. ENERGY SAR is a U.S.
registered trademark. All other brand or product names are trade-
marks or registered trademarks of their respective holders. 11/00
ver.1.
NEC-Mitsubishi Electronics
Display of America
1250 N. Arlington eights Road
Itasca, Illinois 60143-1248
888-NEC-MITS
www.necmitsubishi.com
Display:
Diagonal
Viewable Image Size
Input signal:
Video
Sync
Display Colors: Analog Input
Synchronization Range:
orizontal
Vertical
Resolutions Supported
Functions
Power Supply
Current Rate
Dimensions (W x x D)
Net (with stand)
Net (without stand)
Weight
Net (with stand)
Regulatory Approvals
Signal Cable
Environmental Conditions
Limited Warranty
