NEC MultiSync P552 User manual

NEC P Series
40” - 70” professional-grade, full high-definition LCD displays
ideal for digital signage applications
Large-Screen LCD
Expand your messaging options with
superior screen performance. The NEC P
Series, featuring the 40” P402,
46” P462, 55” P552 and 70” P702,
provides a first-class solution for your
digital signage applications. Its high
contrast, industrial-strength design and
Enhanced Digital Signage Technology
Suite (DSTS), which boasts more than 30
advanced features, make these displays
ideal for 24/7 operation in even the
harshest environments. These include
airports, public information, healthcare,
retail and other areas that require a
combination of dazzling images and
the highest level of display management. The built-in expansion slot future-proofs your display investment, allowing
for seamless integration of NEC and third-party components. Plus, the capability to easily integrate touchscreen
technology or protective glass opens these models up to even more applications, including wayfinding and high-trac
areas. The P702’s massive screen turns heads in corporate boardrooms as well as rental and staging applications.
Advantages include a wide array of inputs, including DisplayPort, unrivaled control and communication options and
enhanced video wall capabilities.
IMPROVED MECHANICAL DESIGN*
SLIMMER DEPTH
INTEGRATED 10W SPEAKERS
OPS & CURRENT SLOT SUPPORT
DIGITAL SIGNAGE TECHNOLOGY SUITE
INTEGRATED THERMAL PROTECTION
SEALED PANEL DESIGN
Highlights
* available on select P Series models
ENHANCED VIDEO WALL CAPABILITIES
ECO-FRIENDLY FEATURES
BUILT-IN EXPANSION SLOT
EXTENSIVE CONTROL, DIAGNOSTICS & COMMUNICATION
REAL-TIME CLOCK/ROUND-THE-CLOCK SCHEDULING
CABLECOMP+™ TECHNOLOGY
BUILT-IN TUNER (-AVT MODELS)

P Series Key Features
24/7 full-HD commercial SPVA panels
The professional-grade construction of P Series panels contributes to 24/7 usage, an overall longer panel life, lower likelihood of mura
effect from localized heat, virtually no image retention and the ability to use in landscape or portrait orientations. The panel’s thermal
protection starts with an extra thermal layer on the display panel to diffuse heat, followed by multi-fan-based technology specially
designed to work in both landscape and portrait modes and be controlled locally or remotely. Internal temperature sensors control self-
protective circuits, while special self-diagnostics communicate the status of the thermal characteristics.
P Series panel construction includes:
•Thermal dissipation plate, placed behind the LCD lamps, conducts heat
equally across the plate, preventing “hot spots” on the LCD
•Backlight layer (or lamps) determines the brightness of the display but
is also a key heat component
•Wider air layer allows for increased airflow and improved heat dissipation
•Heat protection plate, located between the LCD panel and the lamps,
provides added heat protection to the panel
•Panel is sealed, preventing contaminants like dust, grease or steam
from damaging the panel*
Green technology helps lead to a lower total cost of ownership
Eco-friendly features are aplenty in the P Series, decreasing energy consumption, lowering your expenses
over the lifecycle of the display and contributing to your environmental consciousness. These include:
•Ambient light sensor ensures consistent brightness no matter the lighting conditions, while allowing
the user to set the brightness level to a pre-determined lower level in order to automatically
compensate and reduce the brightness, thus decreasing power consumption
•Carbon footprint meter helps track and calculate the conservation of green gas emissions in real time
•Real-time clock/round-the-clock scheduling allows for advanced scheduling of monitor powering
up/down, increasing panel lifetime, reducing power consumption and saving the time and expense of
finding and purchasing a third-party scheduling solution
•ENERGY STAR 5.0/5.1** is proudly offered for most P Series displays, which meet strict energy efficiency guidelines set by the U.S.
Environmental Protection Agency and the U.S. Department of Energy, helping you save money and reduce greenhouse gas emissions
Built-in technology to support video wall configurations
Select P Series displays’ thin-bezel design and enhanced video wall capabilities allow you to expand your messaging options.
Technologies include:
•TileMatrix™ allows you to create video walls (up to 100 displays in
a 10x10 matrix)
•TileComp™ works in tandem with TileMatrix to compensate for
the bezel width and create a more seamless video wall
•Copy function allows the user to apply the settings from one
display to all others in the RS-232 daisy chain, reducing setup time
and saving money
•Individual and Group ID functions allow users to control settings
for a defined individual display or group
of displays within a video wall
•Optional Display Wall Calibrator
Kit (KT-LFD-CC; pictured) provides a
quick, accurate and easy-to-use means
of automatically matching all displays in
color and brightness to create uniformity across the video wall
*use under the environmental conditions noted in the specifications and user’s manual
**available on select models

Full connectivity and control with the option for expansion in every display
The P Series touts the industry’s most extensive control, diagnostics and communication, providing the highest level of remote display
management. These include:
•RS-232 enables multi-display control and daisy chain, allowing for individual and group-addressable control, and simple,
effective setup and monitoring of the display
•Ethernet connectivity adds the same RS-232 control plus automatic email notification for diagnostic purposes
•NaViSet™ software offers an intuitive graphical interface, allowing for easy adjustment of display settings via mouse and
keyboard. NaViSet Administrator provides all the advanced control to remotely located IT professionals.
•DDC/CI standard allows for PC control of the display based on the VESA command set
•CableComp+ uses a digitized signal delay circuit to automatically compensate for each red, green and blue cable’s length and
video signal delay, ensuring sharp image reproduction despite long cables and low output level*
•Expanded connectivity with digital loop through (DVI-D and DisplayPort)
A built-in expansion slot future-proofs your display investment, allowing for seamless integration of optional NEC and third-party
components, including:
•Open Pluggable Specification (OPS): The first industry-wide standardization in option slots, simplifying installation, use and
maintenance of digital signage.
•HD-SDI card (SB-L007KK): Achieve broadcast-grade video with this internal card that provides an HD-SDI input without using
additional space or power.
•Single board computer (NET-SBC-01/02/03/04, OPS-PCAF-WH/WS/H/S, N8000-8830): This option provides for a seamless
internal PC solution that is both cost-efficient and flexible. It eliminates the need for external cabling, mounting and power supply,
providing for a clean look that simplifies installation and reduces maintenance.
•Digital IP tuner (MPD-DTi): This IPTV card enables you to stream up to 1080p content directly to the display as well as ATSC/NTSC/
Clear QAM signals. Other features include auto scan, DTV signal strength, parental controls, closed caption and network settings—
all adjustable from the display.
•CAT5 receiver: Using NEC-approved third-party solutions, you’ll be able to safely send your video over longer distances.
The P Series sets the standard for connectivity. Improved input options include quick input change, customized detection and naming.
See below for the complete list of P Series input/output terminals.
*use under the environmental conditions noted in the specifications and user’s manual
RS-232 In/Out
Speaker Out
LAN Port
IR In/Out
5 BNC In (RGBHV,
DVD/HD or
Composite Video)
HDMI In
VGA D-Sub In
Audio
Mini-Jack
In/Out
BNC Composite
Video In/Out
DisplayPort
In/Out
DVI-D In/Out
RCA Audio In
S-Video
In

MODEL P402 P462 P552 P702
LCD MODULE
Panel Technology SPVA (P-DID)
Viewable Image Size 40” 46” 55” 70”
Native Resolution 1920 x 1080
Backlight Type CCFL
Brightness (Typical) 500 cd/m2420 cd/m2
Contrast Ratio (Typical) 3000:1 3500:1 4000:1 2000:1
Viewing Angle 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Response Time (G-to-G) 8ms
Aspect Ratio 16:9
Active Screen Area (W x H) 34.9 x 19.6 in. / 885.6 x 498.2mm 40.1 x 22.5 in. / 1018.1 x 572.7mm 47.6 x 26.8 in. / 1209.6 x 680.4mm 61 x 34.3 in. / 1549.4 x 871.6mm
Orientation Landscape/Portrait
Displayable Colors More than 16.7 million
CONNECTIVITY
PC/Mac Signal Compatibility Yes
Input Terminals
Digital DisplayPort, HDMI, DVI-D
Analog VGA 15-pin D-sub, 5 BNC (RGBHV, DVD/HD or Video), S-Video, BNC Composite
Audio RCA Audio, Stereo Mini-Jack (2), HDMI Audio
External Control RS-232C, LAN, IR Remote, DDC/CI
Output Terminals
Digital DisplayPort, DVI-D
Analog BNC Composite
Audio Stereo Mini-Jack, External Speaker Jack (2)
External Control RS-232C, IR Remote
Digital Tuner P402-AVT P462-AVT P552-AVT P702-AVT
Speakers Integrated 10W (2), Optional 15W (2; SP-4046PV) Integrated 10W (2), Optional 15W (2; SP-RM1)
POWER CONSUMPTiON
On (Typical) 145W 155W 255W 545W
ECO Mode Standby <0.5W
PHYSICAL SPECIFICATIONS
Bezel Width (L/R, T/B) 0.61 in./0.61 in., 0.61 in./0.61 in. ;
15.5mm/15.5mm, 15.5mm/15.5mm 0.65 in./0.65 in., 0.65 in./0.65 in. ; 16.5mm/16.5mm, 16.5mm/16.5mm 0.73 in./0.73 in., 0.73 in./0.73 in. ; 18.5mm/18.5mm, 18.5mm/18.5mm 2.5 in./2.5 in., 2.5 in./2.5 in. ; 62.4mm/62.4mm, 63.4mm/63.4mm
Net Dimensions
(without stand; WxHxD) 36.2 x 21.0 x 4.1 in. / 919.7 x 532.2 x 103mm 41.6 x 24.0 x 4.1 in. / 1055.4 x 608.6 x 103mm 49.2 x 28.4 x 4.9 in. / 1250.2 x 721.1 x 125.4mm 66.1 x 39.5 x 7.8 in. / 1680 x 1004 x 198mm
Net Weight (without stand) 45.9 lbs. / 20.8 kg 52.5 lbs. / 23.8 kg 88.2 lbs. / 40 kg 208.3 lbs. / 94.5 kg
VESA Hole Configuration 300 x 300mm (4-hole) 400 x 400mm (4-hole)
ENVIRONMENTAL CONDITIONS
Operating Temperature 41-104°F / 5-40°C
Operating Humidity 20 - 80%
Operating Altitude 9843 ft. / 3000m
LIMITED WARRANTY 3 years parts and labor, including backlight*
ADDITIONAL FEATURES Advanced thermal capabilities; Advanced cooling system; Sealed panel design; Thin bezel; TileMatrix (10x10); TileComp; Separate group/Monitor ID function;
CableComp+; Ethernet Control and Communication; RS-232 Control and Communication; Landscape/portrait capable; Carbon footprint meter; AccuBlend; Plug and Play
(DDC/CI, DDC2B); Scheduler (w/ real-time clock); Sharpness/softness adjustment; Screen saver function; Ambient light sensor (AmbiBright); 6-axis color adjustment;
Metal rear cabinet; POP; Side-by-Side; Kensington lock; 10-bit gamma; Handles; Touch- and protective screen-ready; Variable picture modes; Movie Settings; Input
labeling; Backlight adjust; Aspect ratio control; Built-in speakers; OPS/Expansion slot; Input detect options; TAA-compliant
SHIPS WITH Power cord; VGA cable (Mini 15-pin D-sub); Wireless remote control; Batteries; Cable cover; CD-ROM (user manual); Clamp; Screws
OPTIONAL ACCESSORIES
NEC Speakers (SP-4046PV for P402/P462; SP-RM1 for P552/P702); Stand (ST-4020 for P402; ST-4620 for P462; ST-5220 for P552; ST-701 for P702); Single Board Computer
(NET-SBC-01/02/03/04); External Single Board Computer (TNETPC-ION); Internal HD-SDI Card (SB-L007KK); DVI Daisychain (SB-L008WU); Digital IP Tuner (MPD-DTi);
Wall Mount Kit (WMK-3257 for P402/P462/P552); Accessory pack for Wall Mount Kit (MIS513); Display Wall Calibrator Kit (KT-LFD-CC); OPS with Intel Core i5 (N8000-
8830), OPS with AMD Dual Core Fusion, 160GB Hard Drive, W7P (OPS-PCAF-WH); OPS with AMD Dual Core Fusion, 32GB SSD, W7P (OPS-PCAF-WS); OPS with AMD
Dual Core Fusion, 160GB Hard Drive, No OS (OPS-PCAF-H); OPS with AMD Dual Core Fusion, 32GB SS, W7P (OPS-PCAF-S); OPS Adapter (SB-02AM); Adaptor Mount Kit
(AMK-P4046 for P402/P462; AMK-V422 for P552); OPS HD/SDI/3G-SDI Card (SB-04HC)
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
Specifications for P402/P462/P552/P702
* Warranty restrictions apply. Contact your representative for details.
CableComp+, NaViSet, TileComp and TileMatrix are trademarks
of NEC Display Solutions. All other brand or product names are
trademarks or registered trademarks of their respective holders.
Product specifications subject to change. 2/12 ver. 14.
©2012 NEC Display Solutions of America, Inc. All rights reserved.
