NEC PlasmaSync®Displays
Best in class image
quality and accurate
image reproduction
Unsurpassed product
reliability and service
Exceptional contrast
and brightness no
matter what the
viewing environment
Flexible features for any
commercial application
42VM5 and 42VP5
Command awe-inspiring brilliance.
NEC’s commercial plasmas include innovative features and technologies from our
renowned design labs.
Inspirational color and image reproduction
°Best in class image quality. Image quality so superior that an NEC PlasmaSync
display has received the DisplayMate “Five-Star” Best Video Hardware Award.
°Capsulated Color Filter (CCF) technology delivers realistic color reproduction.
°AccuCrimson Filter technology further enhances the effects of the CCF producing
better reds and greens.
°Digital AccuDevice. All digital video processing allows for artifact and noise free video.
°Mass Area Superior Sampling (MASS) eliminates jagged lines and corrects color bleeds
to create clear and defined images.
°Color Tune Technology. Adjust individual colors without affecting white balance.
°Gamma 12 provides the highest color processing in a plasma display at 68.7 billion
colors (4096 steps) resulting in increased detail never seen before... no matter what
the viewing environment!
Features and controls to improve upon perfection
°Programmable timer for virtual self-running operation.
°Portrait or landscape display orientation.
°Anti-glare filter (42VP5 only) specifically designed to maintain image brightness and
contrast where direct ambient light is present.
°Complete RS232 control allows command and feedback of the monitor from a
control system.
°Cabinet design enables small form factor PC's to be attached to the back of the plasma.
°High altitude capable with an operating altitude of 9180 feet.
°Complies with ADA508 standards for color blind and hearing impaired users with
black & white menus and closed caption support.
°Zoom. Highlight portions of still or motion video to reinforce your message.
Long term investment protection
°Long lasting. Up to 60,000 panel half-life (that’s 20 years, 8 hours a day)!*
°Ranked #3 by PAC Media for product quality/reliability and product warranty
repair/return programs.
°Executive Order 13221 advanced power saving features include a standby setting
that uses <1 watt and a hard power switch to completely shut down the unit.
°AccuShield provides multiple ways to protect from permanent image retention.
°Low power consumption places NEC among the leaders in the industry.
*60,000 hour panel life is an approximate time for the display panel to reach half of it's original brightness. The panel life is based
on motion video as the input source and all display settings at factory default. This time may vary if the source varies and monitor
settings are not at factory default. The time given does not imply any warranty beyond the products standard warranty.
see back for details on NEC’s
REAL WORLD
CONTRAST MEASUREMENTS

NEC PlasmaSync®Displays
NEC 080461
For more information, call 1.800.NEC.INFO
or visit www.necvisualsystems.com
NEC is a registered trademark of NEC Corporation.
All other trademarks are the property of their respective owners.
All specifications subject to change without notice.
NEC Solutions (America), Inc.
Visual Systems Division
1250 Arlington Heights Rd., Suite 400
Itasca, IL 60143-1248
Specifications
Model Number PX-42VM5A / PX-42VP5A, Diagonal Screen Size 42"
Screen Aspect Ratio 16 to 9
Active Screen Area 36.3" x 20.4", 921 mm x 518 mm
Native Pixel Resolution 853 horizontal dots x 480 vertical rows
Pixel Pitch 1.08 mm square
Front Filter Type AR - Anti-reflective (PX-42VM5A)
AG - Anti-glare (PX-42VP5A)
Color Processing 68.7 billion colors (4096 steps)
Viewing Angle 160 degrees
Horizontal Frequency Range 15.5 to 110.0 kHz auto, step scan
Vertical Frequency Range 50 to120 Hz auto, step scan
PC Signal Compatibility VGA 640x480 @ 60,72,75,85,100, 120 Hz
SVGA 800x600 @ 56, 60, 72,75,85,100,120 Hz
XGA 1024x768 @ 60,70,75, 85, 100 Hz
SXGA 1280x1024 @ 60, 75, 85, 100 Hz
UXGA 1600x1200 @ 60, 65, 70, 75, 85 Hz
WideVGA 848x480, 852 x 480 @ 60 Hz
WideXGA 1360 x 765 @60 Hz
Macintosh Compatibility 640x480, 832x624, 1024x768, 1152x870
Video Signal Compatibility PAL, SECAM, 3.58/4.43 NTSC
HD Video Signal Compatibility 480p 480i, 525p, 525i, 540p, 625p, 625i, 720p,1035i, 1080i
Input Terminals RGB 1 (analog) 15-pin mini D-sub (common use with RGB out, selectable)
RGB 2 (analog) 5 BNC (RGB/HV) (common use with 5BNC Y/Pb/Pr input, selectable)
RGB 3 (digital) 24-pin DVI-D HDCP (EIA/CEA-861-A) compatible
Video 1 Composite BNC x 1 (common use with video out, selectable)
Video 2 Composite RCA x 1
Video 3 S-Video 4-Pin DIN
HD Video 1 1 set RCA Component (Y,Pb,Pr/Y,Cb,Cr)
HD Video 2 1 set BNC Component (Y,Pb,Pr/Y,Cb,Cr)
(common use with 5BNC Y/Pb/Pr input,selectable)
Audio 3 sets RCA stereo + external speaker jacks
Output terminals RGB (analog) 15 PIN mini D-sub (common use with RGB1, selectable)
Video Composite BNC (common use with Video1, selectable)
Audio Internal amplifier, 8W x 2 output power
External Control 9-pin mini D-Sub, RS232
User Controls Direct Access Power on/off, input selection, volume up/down, OSM access, (Control
Lock Switch located on input panel)
Remote Control Power on/off, input select, volume, mute, wide, display, off-timer, OSM
control, cursor, pointer, zoom, auto, select
OSM Picture - Contrast, brightness, sharpness, color, tint, color temperature, white
balance, picture mode, noise reduction, gamma, low tone and color tune
Audio - bass, treble, balance and audio input
Image Adjust - aspect ratio mode, vertical position, horizontal position,
vertical height, horizontal width, fine picture, picture adjust, auto picture
Option 1 - OSM on/off, BNC Input, D-sub Input, RGB select, HD select,
Input Skip, All Reset
Option 2 - Pwr. Management, Cinema Mode, Long Life Mode,
Closed Captioning, DVI Setup
Option 3 - Timer, Pwr. On mode, Control Lock, IR Remote, Loop Out,
ID Number, Video Wall Advanced OSM, Language, Color System, Source
Information
Plug & Play DDC1, DDC2B (RGB3 is DDC2B only)
Power Requirements 120V 50/60 Hz
Power Consumption 270W Typical, 4.5A max
Standby Power 0.80W
Dimensions (WxHxD) - 40.1" x 24.0" x 3.5", 1018 mm x 610 mm x 89 mm (without base)
Weight 63.0 lbs., 28.5 kg (without tabletop stand)
Environmental Considerations Operating Temperature 32 - 104 degrees F (0 - 40 degrees C)
Operating Humidity 20 - 80%
Operating Altitude 0 - 9180 feet (0 - 2800m)
Storage Temperature14 - 122 degrees F (-10 - 50 degrees C)
Storage Humidity 10 - 90%
Storage Altitude 0 to 9840 feet (0 - 3000m)
Warranty 1 Year Parts & Labor Standard
Regulatory FCC Class A, UL1950, CSA950
Included Accessories AC Power Cord, User Manual, Remote Control, Batteries, Cable Clamps
Optional Accessories Tabletop Stand PX-ST1U
Fixed Wall Mount FWMK
Tilt Wall Mount TWMK
Ceiling Mount CMK
Fixed Wall Mount for PC FWMKPC
Tilt Wall Mount for PC TWMKPC
Ceiling Mount for PC CMKPC
Attachable Speakers PX-42SP1U
Input Terminal Cover PX-CV2U
Stand Plug PX-PL1U
*Signal DA is required for sending a signal to more than 4 monitors simultaneously.
Service and Support
The PlasmaSync 42VM5 and 42VP5 are supported by NEC’s industry leading
service and support programs. They come with a standard 1-year manufacturer’s
warranty plus an extended warranty option that provides two additional years of
coverage and is available from your authorized NEC Visual Systems Division dealer.
36.3”
(921mm)
40.1”
(1018mm)
24”
(610mm)
3.5”
(89mm)
20.4”
(518mm)
42VM5 and 42VP5
DVI-D
15 pin
D-Sub
RGBHV/
component
component
S-Video
composite
video
°
°
°
°
°
°
VCR security
camera
VCR DVD
game
system DVD satellite/ cable
DVD PC
PC
satellite/
cable PC
document
camera
document
camera satellite/
cable
satellite/
cable
Contrast measurements for the real world.
To date, the plasma display market has not followed a consistent standard to
determine contrast ratio with most measurements taken in unrealistically dark
viewing conditions.
NEC takes pride in its contrast measurements, which reflect true-to-life viewing
conditions typically found in environments that would incorporate a plasma display,
such as an office, school, airport, shopping mall or home. By providing plasma
displays that are optimized for “real world” conditions, users are assured more
accurate image depth and detail that is real and not washed out.
NEC is setting the standard for high contrast in real world applications. This standard
is validated by the PlasmaSync 61XM2’s Five-Star DisplayMate Best Video Hardware
Award. According to Dr. Raymond Soneira, President of DisplayMate Technologies,
“The NEC 61XM2 Plasma monitor delivered impressive image and picture quality for
both computer and video applications. Performance in both the laboratory tests and
viewing tests was outstanding. The colors were bright, saturated and an excellent
match to our professional studio reference monitor.”
