Consolidated Power Supply Unit
Configuration Guide
Introduction
This document contains product and configuration information that will enable you to configure your system. The
guide will ensure fast and proper configuration of your unit.
October 2011
Revision 2.1
NEC Corporation

CONFIGURATION GUIDE –Consolidated Power Supply Unit
NEC Corporation Revision 2.1, October 2011 2
Contents
TECHNICAL SPECIFICATION........................................................................................3
Key Features..........................................................................................................................................3
Specification..........................................................................................................................................3
EXTERNAL VIEWS .........................................................................................................4
Front and Rear Views ...........................................................................................................................4
Dimensions (mm)..................................................................................................................................5
CONFIGURATION DIAGRAM.........................................................................................5
UNIT CONFIGURATION..................................................................................................6
1Enclosure........................................................................................................................................6
2Power Supply Module ...................................................................................................................6
3DC Power Cable.............................................................................................................................7
REFERENCES.................................................................................................................8
Unit Management ..................................................................................................................................8
Copyright Notice and Liability Disclaimer..........................................................................................9
REVISION HISTORY .....................................................................................................10

CONFIGURATION GUIDE –Consolidated Power Supply Unit
NEC Corporation Revision 2.1, October 2011 3
Technical Specification
Key Features
High energy efficiency with 80PLUS® Gold power supply
Full manageability by integrated EXPRESSSCOPE Engine 2
Specification
Model
Consolidated PSU
Part Number
N8142-36F
Interfaces
1 x VGA (15-pin mini D-sub,1x front)
1 x Serial (9-pin mini D-sub, RS232-C, Serial B, 1 x front)
2x USB2.0 (2 x front)
1 x Management LAN connector (100BASE-TX / 10BASE-T,
RJ-45, 1 x rear)
Power Supply
Input
(AC)
Number of
Power Module
Standard : 2 / Maximum : 4
Redundant
PSU
Supported 1, hot plug
Type
650 Watt 80 PLUS® Gold certified hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Output
(DC)
Power
Connector
4 x Propriety 12VDC Connector
Max. Output
1,700 Watt 2
Power Consumption (Operating)
2,091 VA / 2,063 Watt
Dimensions (W x D x H )
444.0 x 671 x 43.5 mm / 17.5 x 26.4 x 1.7 in (1U)
Weight (Minimum / Maximum)
13 kg / 15 kg, 28.66 lbs. / 33.07 lbs.
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, CE, BSMI, CCC, UL, CB, RoHS, WEEE
1Optional power modules may be required in accordance with output power required.
2The maximum output per 1 DC connector cannot exceed 840 Watt.

NEC Corporation Revision 2.1, October 2011 4
External Views
Front and Rear Views
Front View
Legend
A.
Power Button
G.
Maintenance LED
B.
Power LED
H.
Serial Connector
C.
UID LED
I.
USB Connectors
D.
UID LED Button
J.
VGA Connector
E.
System Status LED
K.
Pull-out Tab
F.
Maintenance LED Button
Rear View
Legend
A.
Power Supply Bays
F.
UID LED
B.
Power Supply Module
G.
AC Inlet
C.
DC Output LED
H.
DC Outlet
D.
DC Output Button
I.
Pull-out Tab
E.
UID LED Button
J.
Management LAN Connector
K
H
ABCDE
F
IJ
G
A
G
B B D
G H JI
E FC DC DC DC

NEC Corporation Revision 2.1, October 2011 5
Dimensions (mm)
Configuration Diagram
Legend: Standard components
444.0 465.6
671.0
718.0
43.5
CHASSIS
FRONT
CHASSIS
REAR
Power Supply Bay #1
Power Supply Module
Power Supply Module
Power Supply Bay #2
DC out
DC out
DC out
DC out

NEC Corporation Revision 2.1, October 2011 6
Unit Configuration
1 Enclosure
Product Name / Description
Part Number
Consolidated PSU
1U height enclosure
Including
2 x 650 Watt 80 PLUS® Gold certified hot plug PSU
N8142-36F
2 Power Supply Module
Available bays: 2
Product Name / Description
Part Number
Power Supply Module
650 Watt 80 PLUS® Gold certified hot plug PSU
N8181-76F
Maximum Installable Servers
See the table below for maximum installable server in accordance with number of power supply modules.
Please consult our sales representative if other estimation is needed.
E110b-M
Server Configuration
Number of Power
Supply Modules
Number of
Installable Server
Remark
1 GB memory, no-HDD
2
20
508 Watt total
3
40
985 Watt total
4
80
1,938 Watt total
2 GB memory, no-HDD
2
20
567 Watt total
3
40
1,104 Watt total
4
74
2,041 Watt total
1 GB memory, 1 x HDD
2
20
597 Watt total
3
40
1,163 Watt total
4
70
2,031 Watt total
2 GB memory, 1 x HDD
2
20
657 Watt total
3
40
1,282 Watt total
4
63
2,050 Watt total
1 GB memory, 1 x SSD
2
20
508 Watt total
3
40
985 Watt total
4
80
1,938 Watt total
2 GB memory, 1 x SSD
2
20
567 Watt total
3
40
1,104 Watt total
4
74
2,041 Watt total

NEC Corporation Revision 2.1, October 2011 7
E120b-1
Type of Processor
Number of Power
Supply Modules
Number of
Installable Server
Remark
Xeon L5630
2
2
670 Watt total
3
4
1,158 Watt total
4
7
1,918 Watt total
8
2,032 Watt total,
Up to 4x HDD can be installed
Xeon L5640
2
2
788 Watt total
3
4
1,421 Watt total
4
6
2,048 Watt total
3 DC Power Cable
Available DC outlet ports: 4
Product Name / Description
Part Number
DC Power Cable (Y-splitter, 80cm)
1 x DC output to 2 x DC input
NOTE: The maximum DC output per 1 DC connector cannot exceed 840 Watt.
K410-213(1A)

NEC Corporation Revision 2.1, October 2011 8
References
Unit Management
The EXPRESSSCOPE Engine 2, integrated into the unit, provides superior remote control and system
management features listed in the table below.
Standard
Hardware
monitoring
Temperature/voltage/power/fan

Hardware event log collection

Boot monitoring
BIOS/POST stall monitoring

Alerting
HW error and Boot error
(by SNMP, E-Mail)

Remote console
POST/BIOS setup, DOS utility

(via LAN)
Boot screen

Remote control
(via LAN)
Remote reset/power supply management
controller power on-off

System Management Command Line
Protocol (DMTF compliant)

Remote control via Web browser
(without dedicated app)

Remote batch

Scheduling (without UPS)
-
Others
Set automatic IP address via DNS/DHCP

Centralized
management
Monitoring and control of multiple servers

Industry standard
IPMI
2.0

NEC Corporation Revision 2.1, October 2011 9
Copyright Notice and Liability Disclaimer
The information contained herein is subject to change without notice.
All other products, brands, or trade names used in this document are trademarks or registered trademarks
of their respective holders.
NEC shall not be liable for technical or editorial errors or omissions contained herein.

NEC Corporation Revision 2.1, October 2011 10
Revision History
Revision
Date
Description
2.1
October 18th, 2011
Other:
Correct incorrect information in Specification, 3 DC Power Cable, and
References.
2.0
April 8th, 2011
Other:
Added section of maximum installable servers for E120b-1
1.0
September 6th, 2010
Initial release
