NEC P506QL User manual

—i —
Important Information .......................................................................................................... iii
1Getting Started .................................................................................................................. 1
1-1 Packing Checklist ........................................................................................................................1
1-2 Views of Projector Parts...............................................................................................................2
Front-right View..........................................................................................................................2
Top view.....................................................................................................................................3
Rear view-On-screen Display (OSD) buttons..................................................................................4
Rear view (Terminal Panel)........................................................................................................... 5
Bottom view ...............................................................................................................................6
Reference drawings for stand.......................................................................................................7
1-3 Remote Control Specification ......................................................................................................8
1-4 Remote Control Operating Range .............................................................................................. 10
1-5 Projector and Remote Control Buttons .......................................................................................10
2Setup and Operation........................................................................................................ 11
2-1 Inserting the Remote Control Batteries....................................................................................... 11
2-2 Starting and Shutting down the Projector ..................................................................................12
2-3 Adjusting the Projector Level.....................................................................................................14
2-4 Adjusting Projected Image Position Using Lens Shift................................................................... 15
Adjusting the vertical image position.........................................................................................16
Adjusting the horizontal image position..................................................................................... 16
2-5 Adjusting the Zoom, Focus and Keystone................................................................................... 17
2-6 Adjusting the Volume................................................................................................................18
3On-Screen Display (OSD) Menu Settings .......................................................................... 19
3-1 OSD Menu Controls...................................................................................................................19
Navigating the OSD...................................................................................................................19
3-2 Setting the OSD Language.........................................................................................................20
3-3 OSD Menu Overview .................................................................................................................21
3-4 INPUT Menu..............................................................................................................................23
COMPUTER Menu...................................................................................................................... 24
3D Setting ................................................................................................................................ 25
3-5 ADJUST Menu...........................................................................................................................26
DETAIL SETTINGS Menu............................................................................................................. 27
WHITE BALANCE ....................................................................................................................... 28
ADVANCED Feature...................................................................................................................29
COLOR CORRECTION................................................................................................................. 30
3-6 DISPLAY Menu..........................................................................................................................31
3-7 NETWORK Menu .......................................................................................................................32
LAN_RJ45................................................................................................................................. 33
Wired LAN Terminal functionalites .............................................................................................33
Supported External Devices....................................................................................................... 33
LAN_RJ45................................................................................................................................. 34
3-8 SETUP.......................................................................................................................................39
LIGHT MODE.............................................................................................................................40
STANDBY MODE........................................................................................................................ 41
MENU.......................................................................................................................................42
SECURITY..................................................................................................................................43
3-9 INFO. Menu............................................................................................................................... 44

Table of Contents
–ii –
4Maintenance and Security................................................................................................ 45
4-1 Cleaning the Projector...............................................................................................................45
Cleaning the Lens .....................................................................................................................45
Cleaning the Case ..................................................................................................................... 45
4-2 Using the Physical Lock .............................................................................................................46
Using the Security Slot...............................................................................................................46
Using the Security Bar Lock........................................................................................................46
5Troubleshooting .............................................................................................................. 47
5-1 Common Problems and Solutions.............................................................................................. 47
5-2 Tips for Troubleshooting ...........................................................................................................47
5-3 LED Error Messages...................................................................................................................48
5-4 Image Problems........................................................................................................................48
5-5 Light Source Problems ..............................................................................................................49
5-6 Remote Control Problems.......................................................................................................... 49
5-7 Audio Problems ........................................................................................................................49
5-8 Having the Projector Serviced....................................................................................................49
5-9 HDMI Q & A............................................................................................................................... 50
6Specifications................................................................................................................... 51
6-1 Specifications............................................................................................................................ 51
6-2 Projection Distance vs. Projection Size........................................................................................53
Projection Distance and Size Table.............................................................................................54
6-3 Timing Mode Table ................................................................................................................... 55
Table of Supported Frequency...................................................................................................55
Table of Supported Frequency For 3D mode...............................................................................57
6-4 Projector Dimensions................................................................................................................ 58
7Appendix I........................................................................................................................ 59
7-1 RS-232C Protocol ...................................................................................................................... 59
REGISTER YOUR PROJECTOR! (for residents in the United States, Canada, and Mexico)......................... 60

—iii —
Important Safety Information
Itisstronglyrecommendedthatyoureadthissectioncarefullybeforeusingtheprojector.Thesesafetyand
usageinstructionswillensurethatyouenjoymanyyearsofsafeuseoftheprojector. Keep thismanual for
futurereference.
AbouttheSymbols
To ensure safe and proper use of the product, this manual uses a number of symbols to prevent injury to
you and others as well as damage to property.
The symbols and their meanings are described below. Be sure to understand them thoroughly before read-
ing this manual.
Failing to heed this symbol and handing the product erroneously could
result in accidents leading to death or major injury.
Failing to heed this symbol and handing the product erroneously could
result in personal injury or damage to surrounding property.
Examplesof Symbols
This symbol indicates you should be careful of electric shocks.
This symbol indicates you should be careful of high temperatures.
This symbol indicates something that must be prohibited.
This symbol indicates something that must not be get wet.
This symbol indicates you should not touch with wet hands.
This symbol indicates something that must not be disassembled.
This symbol indicates things you must do.
This symbol indicates that the power cord should be unplugged from the power outlet.

Important Information
–iv –
Safety Caution
Handling the power cord
Please use the power cord supplied with this projector. If the supplied power cord
voltage and
current for your region, make sure to use the power cord that conforms to and sat-
isfies them.
The power cord you use must be approved by and comply
with the safety standards of your country.
Rated voltage by country is listed below for your reference.
Forselectinganappropriate powercord,please check rated
voltage for your region byyourself.
AC 230V
Europeancountries
AC 120V
North America
The power cord included with this projector is exclusively for use with this projec-
tor.Forsafety, donotuseitwith otherdevices.
Handle the power cord with care. Damaging the cord could lead to fire or electric
shock.
-Do not place heavy objects on the cord.
-Do not place the cord under theprojector.
-Do not cover the cord with a rug,etc.
-Do not scratch or modify thecord.
-Do not bend, twist or pull the cord with excessiveforce.
-Do not apply heat to the cord.
Should the cord be damaged (exposed core wires, broken wires, etc.), ask your
dealer to replaceit.
Donottouchthepowerplugshouldyouhearthunder.Doingsocouldresult in
electric shock.

Important Information
–v –
Installing theProjector
This projector is designed to be used with a 100 240 V AC, 50/60 Hz power supply.
Beforeusingtheprojector,checkthatthepowersupplytowhichthe projector is to
be connected meets theserequirements.
Use
directly to electrical light wiring. Doing so isdangerous.
Donot use in places such as those described below. Doing so could lead to fire or
electric shock.
-Shaky tables, inclined surfaces or other unstable places
-Near heating appliances or places with heavy vibrations
-Outdoors or humid or dusty places
-Places exposed to soot or steam
-Near cooking appliances, humidifiers, etc.
Donotuseinplacessuchasthosedescribedbelowwheretheprojectorcouldget
wet. Doing so could lead to fire or electric shock.
-Do not use in the rain or snow, on a seashore or waterfront, etc.
-Do not use in a bathroom or shower room.
-Do not place vases or potted plants on the projector.
-Do not place cups, cosmetics or medicines on theprojector.
Shouldwater,etc.getinsidetheprojector,firstturnoffthe power,then
unplugthepowercordfrom thepower outletandcontact yourdealer
Do not insert or drop metal or combustible objects or other foreign materials into
the projector from the vents. Doing so could lead to fire or electric shock. Be par-
ticularly careful if there are children in the home. Should a foreign object get inside
the projector, first turn off the projectors power, then unplug the power cord from
the power outlet and contact your dealer.
Unplugthe power cord if the projector malfunctions.
Should the projector emit smoke or strange odors or sounds, or if the projector has
been dropped or the cabinet broken, turn off the projectors power, then unplug
the power cord from the power outlet. Failure to do so could not only lead to fire
or electric shock, visual impairment or burn. it could also result in vision impair-
ment. Contact your dealer for repairs.
Never try to repair the projector on your own. Doing so is dangerous.
Do not disassemble the projector.
Do not remove or open the projectors cabinet.
Also, do not modify the projector. There are high voltage areas in the projector.
Modifying the projector could lead to fire, electric shock, or could lead to visual
impairment or burn by cause leakage of laser beams.
Have qualified service personnel perform inspection, adjustments and repairs of
the interior.

Important Information
–vi –
Installing suspended from the ceiling
Should special works be required, for example to suspend the projector from the
ceiling, consult your dealer.
Never try to install the projector yourself in such cases. The projector could drop
and cause injury.
Suspending the projector from the ceiling requires sufficient ceiling strength to
support the projector, and the building standards laws in your particular country
must be followed.
It is also necessary to take measures to prevent the projector from dropping in an-
ticipation of a malfunction occurring in the projector, ceiling mounting device and
installation location.
When installed suspended from the ceiling, etc. do not hang from the projector.
The projector could drop and cause injury.
When installing suspended from the ceiling, use a power outlet that is within reach
so the power cord can be easily plugged and unplugged.
Do not place objects in front of the lens while the projector is operating.
Do not leave the lens cap on the lens while the projector is operating. The lens cap
could get hot and be warped.
Do not place objects in front of the lens that obstruct the light while the projector
is operating. The object could get hot and be broken or catch fire.
The below pictogram indicated on the cabinet means the precaution for avoiding
to place objects in front of the projector lens.

Important Information
–vii –
Strong light that could damage your eyes is projected when the projector is oper-
ating. Be especially careful when children are around.
Do not look at the projected light using optical devices (magnifying glasses, reflec-
tors, etc.). Doing so could result in vision impairment.
Check that there is no one looking at the lens within the projection range before
turning on the projector.
Do not allow children to operate the projector alone. When a child is operating the
projector an adult should always be present and watch the child carefully.
The below pictogram, that is indicated near the lens on the cabinet, describes this
projector is categorized in the risk group 2 of IEC/EN 62471-5:2015.
When cleaning the projector
Do not use flammable gas sprays to remove dust from the lens, cabinet, etc. Doing
so could lead to fire.
As with any bright light source, do not stare into the beam, RG2 IEC/EN 62471-
5:2015.

Important Information
–viii –
Connecting the power cord to earth
This equipment is designed to be used in the condition of the power cord con-
nected to earth. If the power cord is not connected to the earth, it may cause
electric shock. Please make sure the power cord is earthed properly.
Do not use a 2-core plug converter adapter.
Handling the powercord
connector is fully and firmly inserted. Loose connection of the power cord could
lead to fire or electric shock.
Do not connect or disconnect the power cord with wet hands. Doing so could
result in electric shock.
When cleaning the projector, for safety purposes unplug the power cord from the
power outlet beforehand.
When moving the projector, first be sure to turn off the power, unplug the power
cord from the power outlet and check that all connection cables connecting the
projector to other devices have been disconnected.
When planning not to use the projector for long periods of time, always unplug
the power cord from the power outlet.
Do not use on networks subject to overvoltage.
Connect the projectors Ethernet/HDBaseT port and LAN port to a network for
which there is no risk of overvoltage being applied.
Overvoltage applied to the Ethernet/HDBaseT or LAN port could result in electric
shock.
Lens shift, focus and zoom operations
When shifting the lens or adjusting the focus or zoom, do so from either behind or
to the side of the projector. If these operations are performed from the front, your
eyes could be exposed to strong light and get injured.
Keep your hands away from the lens area when performing the lens shift
operation. If not, your fingers could get caught in the gap between the cabinet and
the lens.

Important Information
–ix –
Handling batteries
Handle batteries with caution. Failure to do so could lead to fire, injury or contami-
nation of the surroundings.
-Do not short-circuit or take apart batteries or dispose of them in flames.
-Do not use batteries other than those specified.
-Do not use new batteries together with old ones.
-When inse
be sure to insert them as indicated.
Contact your dealer or local authorities when disposing of batteries.
About the vents
Do not obstruct the projectors vents. Also, do not place such soft objects as paper
or cloths underneath the projector. Doing so could lead to fire.
Leave sufficient space between the place where the projector is installed and its
surroundings (as a general rule, at least 50cm/19.69 inches for the intake vent,
50cm/19.69 inches for the exhaust vent).
Do not touch the exhaust vent area while projecting or immediately after project-
ing images. The exhaust vent area may be hot at this time and touching it could
cause burns.
Moving the projector
When moving the projector, do not hold the lens section. The focus ring could
turn, causing the projector to drop and resulting in injury. Also, if you put your
hand on the gap between the cabinet and the lens, the projector may be
damaged, falling and causing injury.
Inspecting the projector and cleaning the inside
Consult with your dealer about once per year for cleaning of the inside of the
projector. Dust could accumulate inside of the projector if it is not cleaned for
extended periods of time, leading to fires or malfunction.
