Express5800/320F
Next-GeNeratioN Fault toleraNt Server
Key Benets
Continuous availability for » 99.999% system uptime
Affordable fault tolerance using Intel Xeon based technology »
Hardware redundancy of all components »
Enhanced Processing Performance
The Express5800/320F FT server features Quad-Core Intel Xeon
processors, achieving a 20% performance gain over existing fault
tolerant servers.
Virtualization Operating System Support
Virtualization software support allows for multiple guest operating
systems to run in a single physical server, simplifying server
consolidation and migration. Application failure risk may increase
in virtual environments if the server hardware fails, because all of
the applications in the virtual environment will be affected. With
Fault Tolerant servers and their redundant modular architecture,
the risk of these applications going down is eliminated due to the
server’s continuous computing capability.
Reduction in Maintenance Time
The optional Active Upgrade™ splits the FT server into two
independently running systems and allows one of the systems
to run critical applications without interruption while Windows
security patches and program updates are being installed on the
other system.
Servers for Mission Critical Applications
NEC Fault Tolerant (FT) servers provide an innovative solution
to address planned and unplanned downtime for mission-critical
IT infrastructure worldwide. The Express5800/320F server
delivers exceptional uptime through dual modular hardware
redundancy featuring Quad-Core Intel® Xeon® processors. These
servers provide high availability through hardware redundancy
in all components: CPU, memory, I/O, hard disk drives, and
cooling fans.
The heart of this dual modular architecture is the GeminiEngine™
chipset, which is designed to enable “lockstep” processing.
Lockstep enables the processing of the operating system
and application software on both modules concurrently,
eliminating potential downtime if a hardware component fails on
either module.

NEC Corporation of America
Departmental Servers Division
2880 Scott Blvd.
Santa Clara, CA 95050
[e-mail]
1 866 632-3226 | 1 408 844-1299
www.necam.com/servers
© 2009 NEC Corporation of America. All rights reserved. Specications are
subject to change without notice. NEC is a registered trademark and Empowered
by Innovation is a trademark of NEC Corporation. All other trademarks are the
property of their respective owners. (DS106-2_0209)
Logical
Processor
Processor 320F-MR
Intel®Xeon®
E5450-3.00GHz
320F-LR
Intel Xeon
E5405-2.00GHz
FSB 1333MHz
Package LGA771
L2 cache 6MB x2
Chipset Intel 5000X Chipset + ESB2M + NEC FCPGA
Logical
Memory
Type DDR2-667 FB-DIMM
Support DIMM 2x 1GB, 2x 2GB, 2x 4GB
Sockets 6
Max 24GB (6x 4GB)
ECC Supported
Chipkill Supported
Logical Hard
Drive
Type 3.5” SAS
Supported
drives
SAS 15K: 73GB, 146GB, 300GB
Max SAS: 3x 300GB (RAID-1)
SPAN Optional
Logical LAN Channel 2x 1000BASE-T
Controller ESB2
Wake On LAN Supported
AFT Supported
PXE boot Supported
Video Controller ATI ES1000
VRAM 32MB
Resolution 640x480 - 1280x1024
Peripherals Optical disk Slim CD-RW/DVD Combo or DVD-RAM
Floppy disk Optional (USB Floppy)
Logical
I/O Slot
PCI-X 1x 64 bit/133 MHz (MD2)
1x 64 bit/133 MHz (FH/FL)
PCI-e 1x 8 lane slot
Hot-plug -
External
Interface
LAN 4x RJ-45
USB2.0 3x Type A
Serial 2x D-Sub 9pin
Management Optional (2x RJ-45)
Device Bay 3.5 INCH H/S 6x 1 INCH height
5 INCH SLIM 2
Logical
Storage I/F
SAS/ SATA 8(2x 4i)x SAS or 4(1x 4i)x SATA II/300
IDE 1x UATA
Management Baseboard Integrated
Remote Optional F-RMC
Serviceability Hot-swappable
components
CPU/IO Module, Hard drive
Security Security key Front Key
Chassis Type 4URackmount
Dimension 483 mm (W) × 762 mm (H) × 178 mm (D)
Power Supply Type 650 W x 2
Input 100-240 VAC, 50/60 Hz
LED Front Power, Disk Act., FT-Status, System-Status,
Express Scope Monitor
Rear LAN Speed*, LAN Act.*
Switch Front Power
Rear Dump(NMI)
Regulatory Refer Section 4.5.2
Supported OS Windows®2003 Server®R2 EE
Windows 2008 Server EE (planned)
Red Hat™Linux™5.2 Advanced Platform (EM64T)
VMware®ESX 3.02ft
VMware™ESX 3.2S (Special version for Fault
Tolerant Servers)
