NEC 3M V Series User manual

User’s Manual
V Series 3MTM PCAP Touch
MultiSync®V554Q PCAP
MultiSync®V654Q PCAP
MONITOR MODEL: V554Q PCAP, V654Q PCAP
Please find your model name on the label on rear side of the monitor.

Index
Addendum to User’s Manuals of MultiSync V554Q, V654Q, ……..……………………….Page 03
Registration Information……………………………………………………………………….. Page 04
Important Information………………………………………………………………………….. Page 06
Safety Precautions, Maintenance & Recommended Use…………………………………. Page 07
Shipping Content………………………………………………………………………………..Page 08
Unpacking………………………………………………………………………………………. Page 09
General Installation…………………………………………………………………………….. Page 10
Troubleshooting………………………………………………………………………………….Page 13
Specification - MultiSync® V554Q PCAP.…………………………………………………….Page 15
Specifications - MultiSync® V654Q PCAP……………………………………………………Page 18
Manufacturer’s Recycling and Energy Information…………………………………………. Page 21
2

Addendum to User’s Manuals of MultiSync V554Q, V654Q
This user’s manual is an addendum to the standard user’s manual of the base model monitors V554Q,
V654Q.
All specifications listed here supersede those in the standard version of the manual included with this
monitor.
NOTE: Following feature sets are not supported by the Vxx4Q IGB models:
-Table Top Stand Option: Other than the standard monitor, the IGB model does not allow for table
top installations, as the table top brackets has been removed
-Room Light Sensing Sensor: Other than the standard monitor, the IGB model does not allow the
monitor to make automatic adjustments to the backlight setting.
-Intelligent Wireless Data Sensor: Other than the standard monitor, the IGB model does not
include a sensor for wireless communication to the monitor for information and settings.
-NEC ornament logo: Other than the standard monitor, the does not have an ornament logo.
Therefore changing the position of the NEC logo is not possible.
3

Registration Information
Cable Information
CAUTION: Use the provided specified cables with this product so as not to interfere with radio and
television reception. For USB please use a shielded signal cable with ferrite core. For HDMI,
DisplayPort and D-Sub 9-pin, please use a shielded signal cable. For Audio, please use a signal cable
with ferrite core. Use of other cables and adapters may cause interference with radio and television
reception.
DECLARATION OF CONFORMITY
Windows is a registered trademark of Microsoft Corporation.
NEC is a registered trademark of NEC Corporation.
MultiSync is a trademark or registered trademark of NEC Display Solutions, Ltd. in Japan and other
countries.
DisplayPort and DisplayPort Compliance Logo are trademarks owned by Video Electronics Standards
Association in the United States and other countries.
All other brands and product names are trademarks or registered trademarks of their respective
owners.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and
other countries.
Trademark PJLink is a trademark applied for trademark rights in Japan, the United States of America
and other countries and areas.
microSD and microSD SDHC logos are trademarks of SD-3C, LLC.
CRESTRON and CRESTRON ROOMVIEW are trademarks or registered trademarks of Crestron
Electronics, Inc. in the United States and other countries.
Raspberry Pi is a trademark of the Raspberry Pi Foundation.
Adobe and the Adobe logo are either registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
GPL/LGPL Software Licenses
The product includes software licensed under GNU General Public License (GPL), GNU Lesser
General Public License (LGPL), and others. For more
information on each software, see “readme.pdf” inside the “about GPL&LGPL” folder on the supplied
CD-ROM.

Registration Information
DECLARATION OF CONFORMITY
Windows is a registered trademark of Microsoft Corporation.
NEC is a registered trademark of NEC Corporation.
MultiSync is a trademark or registered trademark of NEC Display Solutions, Ltd. in Japan
and other countries.
DisplayPort and DisplayPort Compliance Logo are trademarks owned by Video
Electronics Standards Association in the United States and other countries.
All other brands and product names are trademarks or registered trademarks of their
respective owners.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.
Trademark PJLink is a trademark applied for trademark rights in Japan, the United States
of America and other countries and areas.
microSD and microSD SDHC logos are trademarks of SD-3C, LLC.
CRESTRON and CRESTRON ROOMVIEW are trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and other countries.
Raspberry Pi is a trademark of the Raspberry Pi Foundation.
Adobe and the Adobe logo are either registered trademarks or trademarks of Adobe
Systems Incorporated in the United States and/or other countries.
GPL/LGPL Software Licenses
The product includes software licensed under GNU General Public License (GPL), GNU
Lesser General Public License (LGPL), and others. For more
information on each software, see “readme.pdf” inside the “about GPL&LGPL” folder on
the supplied CD-ROM.
5

Important Information
This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this unit
has been included. Therefore, it should be read carefully in order to avoid any problems.
CAUTION: Please use the power cord provided with this display in accordance with the table below. If a
power cord is not supplied with this equipment, please contact NEC. For all other cases, please use the power
cord with the plug style that matches the power socket where the monitor is located. The compatible power cord
corresponds to the AC voltage of the power outlet and has been approved by, and complies with, the safety
standards in the country of purchase.
This equipment is designed to be used with a power cord that has a protective earth pin connected to earth. If the
power cord is not connected to the earth, it may cause electric shock. Please make sure the power cord is
earthed properly.
* When operating this monitor with its AC 125-240V power supply, use a power supply cord that matches the
power supply voltage of the AC power outlet being used.
NOTE: This product can only be serviced in the country where it was purchased.
Use the power cord which has BSMI mark at both ends when you use this monitor in Taiwan.
• The intended primary use of this product is as an Information Technical Equipment in an office or domestic
environment.
• The product is intended to be connected to a computer and is not intended for the display of television
broadcast signals.

Safety Precautions, Maintenance & Recommended Use
Safety Precautions and Maintenance
Refer to the instruction explained on page English-3 of the standard user’s manual of the monitor.
Cleaning the Glass Surface
•The glass surface should be cleaned regularly with a soft, lint free cloth.
•It is recommended to use an anti-static plastic and glass cleaner suited for PMMA/acrylic
glass/Plexiglas, or water with a small amount of washing-up liquid.
Cleaning the Cabinet
•Unplug the power supply.
•Gently wipe the cabinet with a soft cloth.
•To clean the cabinet, dampen the cloth with a neutral detergent and water, wipe the cabinet and
follow with a dry cloth.
NOTE: DO NOT clean with benzene thinner, alkaline detergent, alcoholic system detergent, wax,
polish cleaner, soap powder or insecticide. Rubber or vinyl should not be in contact with the cabinet for
an extended period of time. These types of fluids and materials can cause paint to deteriorate, crack or
peel.
7

Shipping Content
MultiSync V554Q PCAP
1. 55” 3MTM PCAP Touch Monitor
2. Remote Control
3. CD-ROM (User Guides/Manuals)
4. Addendum to User’s Manuals
5. Power Cable
6. DisplayPort Cable
7. 2x USB Cable 300cm
MultiSync V654Q PCAP
1. 65” 3MTM PCAP Touch Monitor
2. Remote Control
3. CD-ROM (User Guides/Manuals)
4. Addendum to User’s Manuals
5. Power Cable
6. DisplayPort Cable
7. 2x USB Cable 300cm

Unpacking
Unpacking the Display
Unpack the display (V554Q PCAP / V654Q PCAP) from the carton box by removing the white clips on
the bottom of the box.
NOTE: Due to the weight of the product, for installation and handling 4 people are required. DO NOT
start unless you have enough people available. Working with less people may result in injuries and
damaged product.
Lift the carton box upwards. Make sure to have one additional person to secure the display from
tipping over.
NOTE: Remember to save your original box and packing material to transport or ship the monitor.
For further instructions, please refer to the printed instruction on the carton box.
9

Unpacking
Due to edge-to-edge glass extra care is required when unpacking V554Q PCAP / V654Q PCAP. For
additional support cupboard corners have been added to the displays.
NOTE: To avoid glass damage, please do not put the weight of the displays on the edge-to-edge glass
during installation..
After the display is mounted to the wall or the optional table legs, remove the foil from the front glass.
10

General Installation
This device cannot be used or installed without a mounting accessory for support. For proper
installation it is strongly recommended to use a trained, NEC authorized service person. Failure to
follow NEC standard mounting procedures could result in damage to the equipment or injury to the
user or installer. Product warranty does not cover damage caused by improper installation. Failure to
follow these recommendations could result in voiding the warranty
Mounting
For customer:
CAUTION
DO NOT mount the monitor yourself. For proper installation it is strongly recommended to use a
trained, qualified technician. Please contact your supplier, as they may be able to provide a list of
qualified installation professionals. Mounting on a wall or ceiling and hiring a technician is the
customer’s responsibility.
Maintenance
•Periodically check for looses screws, gaps, distortions, or other problems that may occur with the
mounting equipment. If a problem is detected, please refer to qualified personnel for service.
•Regularly check the mounting location for signs of damage or weakness that may occur over time.
DO NOT block ventilated openings with mounting accessories or other accessories.
For NEC Qualified Personnel:
Stability Hazard.
The device may fall, causing serious personal injury or death. To prevent injury, this device must be
securely attached to the floor/wall in accordance with the installation instructions. Carefully inspect the
location where the unit is to be mounted. Not all walls or ceilings are capable of supporting the weight
of the unit. Weight of this monitor is mentioned in Specification (see V554Q IGB on page 15, V654Q
IGB on page 18, V754Q IGB on page 21, V864Q IGB on page 24). Product warranty does not cover
damage caused by improper installation, remodeling, or natural disasters. Failure to comply with these
recommendations could result in voiding the warranty.
To ensure safe installation, use two or more brackets to mount the unit. Mount the unit to at least two
points on the installation location.
For further instructions, please refer to standard user’s manual of the base model monitors
V554Q, V654Q.
11

Connections
NOTE: Do not connect or disconnect cables when turning on the monitor’s main power or other
external equipment’s power as this may result in a loss of image.
NOTE: Do not use an attenuating (built-in resistor) audio cable. Use an audio cable without a built-in
resistor. Using an audio cable with a built-in resistor will lower the sound level.
Before making connections:
•Turn off the device’s power before connecting it to the monitor.
•Refer to the device’s user manual for available connection types and instructions for the device.
•We recommend turning off the monitor’s main power before connecting or disconnecting a USB
storage device or a microSD memory card to avoid data corruption.
For further instructions on connections, please refer to standard user’s manual of the base
model monitors V554Q, V654Q.
For using Touch Panel
1. Turn off the monitor.
2. Install the equipment.*1
Using slot -in PC (OPS): Connect the OPS slot -in PC into the option board slot. Touch function will
be activated automatically.
NOTE: Please refer to the slot 2 type PC’s manual for connection.
NOTE: When you set option board accessory other than OPS slot-in PC, touch function may not work.
Using external computer: Connect the B type connector to the USB upstream port on the left back
side of the monitor and the A type connector to the downstream port on the external computer.
3. Turn on the monitor.
*1: Please contact your NEC customer support for more detailed information. Please contact your NEC
customer support for the setting of the touch panel function in multiple screens.

Connections
Monitor Setting
Select the input signal.
Using slot 2 type PC: Select [OPTION]
Using external computer: Select the input signal which is supplied by the computer connected to
USB connector.
NOTE: Please refer to “The touch panel does not respond” in “Troubleshooting” when the touch panel
function does not work.
Enable the USB Hub
Use the short 10 cm USB cable supplied with the monitor. Connect
USB cable from USB Type-B input marked with “Hub” (located
above external speaker terminals) to USB Type-A input marked
with “USB 1”on the side of the monitor. The red LED on the USB
hub will light up.
NOTE: To enable USB 3.0 on USB ports on the USB hub you
need to connect the 3 m USB cable supplied with the monitor to
one of the USB 3.0 ports of the OPS slot-in PC.
NOTE: When connected to an external PC, use the 3 m USB
cable supplied with the monitor. Connect USB cable from USB
Type-B input marked with “Hub” to USB Type-A input of the
external PC.
7
HUB
TOUCH
USB 1

Troubleshooting
For general instructions on troubleshooting, please refer to standard user’s manual of the base model
monitor V554Q, V654Q.
Troubleshooting –Touch Monitor
The touch panel does not respond
Make sure that PIP (picture in picture), PBP (picture by picture), TILE MATRIX, ROTATE and
ZOOM are not selected.
Check the input signal setting.
The touch panel function does not support the media player function. Please use the remote control
to set the media player while the touch panel function is working.
Make sure that TOUCH POWER setting in USB in CONTROL is “ON”.
Check the PC SOURCE setting in USB in CONTROL.
Using slot 2 type PC:
Make sure that PC SOURCE is AUTO or OPTION, and the input signal is set to OPTION.
Make sure the slot 2 type PC is connected properly.
Using external computer:
Make sure that PC SOURCE is AUTO or EXTERNAL PC, and the input signal is set to which
supplied by the connected computer.
Make sure the USB cable is connected properly.
The touch panel function may not work depending on the specification of an external computer and
connecting method.
If the TOUCH POWER setting in USB in CONTROL is set to “ON”, change it to “OFF” and back to
“ON” again after a moment.
When using touch function at the display edge, there may be a slight gap between touch position
on the screen and where you touched. It is the specification and not a failure of product.
The response of the touch screen is not correct
Avoid direct sunlight or strong light on the screen.
If there are some obstacles near the TOUCH screen, it may malfunction.
Sensor bar module may be dusty or dirty, wipe gently with a soft cloth.
The computer’s power management does not work
It is recommended to choose “S1” at the “Power Management” item in the BIOS (abbreviation of Basic
Input / Output System) computer’s setup screen

Specifications –MultiSync® V554Q PCAP
15

Specifications –MultiSync® V554Q PCAP
16

Specifications –MultiSync® V554Q PCAP
NOTE: Technical specifications are subject to change without notice.
17

Specifications –MultiSync® V654Q PCAP
18

Specifications –MultiSync® V654Q PCAP
19

Specifications –MultiSync® V654Q PCAP
NOTE: Technical specifications are subject to change without notice.
20
