NEFF I96CM.7N0 User manual

[en] Instruction manual
EXTRACTOR HOOD
I96CM.7N0, I99CM67N0, I92CM67N0

3
ÚTable of contents [en]Instructionmanual
Important safety information.....................................................3
Environmental protection ..........................................................5
Environmentally-friendly disposal.....................................................5
Operating modes........................................................................5
Exhaust air mode................................................................................5
Circulating-air mode ...........................................................................5
Operating the appliance ............................................................6
Lighting .................................................................................................6
Saturation indicator.............................................................................6
Cleaning and maintenance........................................................7
Trouble shooting ........................................................................8
After-sales service .....................................................................9
Accessories for circulated air mode.........................................9
Produktinfo
Additional information on products, accessories, replacement
parts and services can be found at www.neff-
international.com and in the online shop www.neff-
eshop.com
: Important safety information
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for
future use or for subsequent owners.
The appliance can only be used safely if it
is correctly installed according to the safety
instructions. The installer is responsible for
ensuring that the appliance works perfectly
at its installation location.
This appliance is intended for domestic use
and the household environment only. The
appliance is not intended for use outside.
Do not leave the appliance unattended
during operation. The manufacturer is not
liable for damage which is caused by
improper use or incorrect operation.
This appliance may be used by children
over the age of 8 years old and by persons
with reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around
the appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 8 years old and are
being supervised.
Keep children below the age of 8 years old
at a safe distance from the appliance and
power cable.
Check the appliance for damage after
unpacking it. Do not connect the appliance
if it has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused
by incorrect connection is not covered
under warranty.
Danger of suffocation!
Packaging material is dangerous to
children. Never allow children to play with
packaging material.
Danger of death!
Risk of poisoning from flue gases that are
drawn back in.
Always ensure adequate fresh air in the
room if the appliance is being operated in
exhaust air mode at the same time as room
air-dependent heat-producing appliance is
being operated.
Room air-dependent heat-producing
appliances (e.g. gas, oil, wood or coal-
operated heaters, continuous flow heaters
or water heaters) obtain combustion air
from the room in which they are installed
and discharge the exhaust gases into the
open air through an exhaust gas system
(e.g. a chimney).
In combination with an activated vapour
extractor hood, room air is extracted from
the kitchen and neighbouring rooms - a
partial vacuum is produced if not enough
fresh air is supplied. Toxic gases from the
chimney or the extraction shaft are sucked
back into the living space.

4
■Adequate incoming air must therefore
always be ensured.
■An incoming/exhaust air wall box alone
will not ensure compliance with the limit.
Safe operation is possible only when the
partial vacuum in the place where the heat-
producing appliance is installed does not
exceed 4 Pa (0.04 mbar). This can be
achieved when the air needed for
combustion is able to enter through
openings that cannot be sealed, for
example in doors, windows, incoming/
exhaust air wall boxes or by other technical
means.
In any case, consult your responsible
Master Chimney Sweep. He is able to
assess the house's entire ventilation setup
and will suggest the suitable ventilation
measures to you.
Unrestricted operation is possible if the
vapour extractor hood is operated
exclusively in the circulating-air mode.
Risk of fire!
■Grease deposits in the grease filter may
catch fire.
Clean the grease filter at least every
2 months.
Never operate the appliance without the
grease filter.
Risk of fire!
■Grease deposits in the grease filter may
catch fire. Never work with naked flames
close to the appliance (e.g. flambéing). Do
not install the appliance near a heat-
producing appliance for solid fuel (e.g.
wood or coal) unless a closed, non-
removable cover is available. There must
be no flying sparks.
Risk of fire!
■Hot oil and fat can ignite very quickly.
Never leave hot fat or oil unattended.
Never use water to put out burning oil or
fat. Switch off the hotplate. Extinguish
flames carefully using a lid, fire blanket or
something similar.
Risk of fire!
■When gas burners are in operation without
any cookware placed on them, they can
build up a lot of heat. A ventilation
appliance installed above the cooker may
become damaged or catch fire. Only
operate the gas burners with cookware on
them.
Risk of fire!
■Operating several gas burners at the
same time gives rise to a great deal of
heat. A ventilation appliance installed
above the cooker may become damaged
or catch fire. Never operate two gas
burners simultaneously on the highest
flame for longer than 15 minutes. One
large burner of more than 5 kW (wok) is
equivalent to the power of two gas
burners.
Risk of burns!
The accessible parts become very hot when
in operation. Never touch hot parts. Keep
children at a safe distance.
Risk of injury!
■Components inside the appliance may
have sharp edges. Wear protective gloves.
Risk of injury!
■Items placed on the appliance may fall
down. Do not place any objects on the
appliance.
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the
appliance from the mains or switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.

5
Causes of damage
Caution!
Risk of damage due to corrosion. Always switch on the
appliance while cooking to avoid condensation. Condensate
can produce corrosion damage.
Always replace faulty bulbs to prevent the remaining bulbs from
overloading.
Risk of damage due to ingress of humidity into the electronic
circuitry. Never clean operator controls with a wet cloth.
Surface damage due to incorrect cleaning. Clean stainless
steel surfaces in the direction of the grain only. Do not use any
stainless steel cleaners for operator controls.
Surface damage due to strong or abrasive cleaning agents.
Never use strong and abrasive cleaning agents.
Risk of damage from returning condensate. Install the exhaust
duct in such a way that it falls away from the appliance slightly
(1° slope).
Environmental protection
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly manner.
Operating modes
This appliance can be used in exhaust-air mode or circulating-
air mode.
Exhaust air mode
Note: The exhaust air must not be conveyed into a functioning
smoke or exhaust gas flue or into a shaft which is used to
ventilate installation rooms which contain heat-producing
appliances.
■Before conveying the exhaust air into a non-functioning
smoke or exhaust gas flue, obtain the consent of the heating
engineer responsible.
■If the exhaust air is conveyed through the outer wall, a
telescopic wall box should be used.
Circulating-air mode
Note: To bind odours in circulating-air mode, you must install
an activated carbon filter. The different options for operating the
appliance in circulating-air mode can be found in the brochure.
Alternatively, ask your dealer. The required accessories are
available from specialist outlets, from customer service or from
the Online Shop. The accessory numbers can be found at the
end of the instructions for use.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning used
electrical and electronic appliances (waste electrical
and electronic equipment - WEEE). The guideline
determines the framework for the return and recycling
of used appliances as applicable throughout the EU.
The air which is drawn in is cleaned by the
grease filters and conveyed to the exterior
by a pipe system.
The air which is drawn in is cleaned by the
grease filters and an activated carbon filter and
conveyed back into the kitchen.

6
Operating the appliance
These instructions apply to several appliance variants. It is
possible that individual features are described which do not
apply to your appliance.
Note: Switch on the extractor hood when you start cooking and
switch it off again several minutes after you have finished
cooking. This is the most effective way of removing the kitchen
fumes.
Remote control
LED status bar
Setting the fan
Switching on
1. Press the @button.
The fan starts at fan level 2.
2. Press the @or A button to set a different fan level.
The set fan level is displayed in the LED status bar.
Switching off
Press the Abutton until the appliance switches off.
Intensive setting
You can use the intensive setting if there is a large build-up of
odours and fumes/vapours.
Press the @button.
˜flashes in the LED status bar.
Note: The run time of the intensive mode is 4 minutes. Once
this time has elapsed, the appliance switches back to fan level
2.
Interval ventilation
With interval ventilation, the ventilation system switches on
automatically at the set level for 10 minutes every hour.
1. Switch off the appliance.
Notes
■Press the Abutton until the appliance switches off.
■or press the 8button.
2. Press the 8button.
3. Set the fan level.
Note: The interval ventilation is only activatable in fan levels
1-3.
4. Press the 8button.
The set fan level and 8flash in the LED status bar.
Fan run-on
With fan run-on, the appliance switches off automatically after
10 minutes.
Press the 9button.
The set fan level and 9light up in the LED status bar.
Note: The fan run-on is only activatable in fan levels 1-3.
Lighting
Switching on
The lighting can be switched on and off independently of the
ventilation system.
Press the 6button.
Switching off
Press the 6button.
Setting the brightness
Press and hold the 6button until the desired brightness is
reached.
Saturation indicator
If the filters are saturated, the following symbols flash:
■Metal grease filters: 1,2 and 7.
■Activated charcoal filters: 3,˜and 7.
If you have not yet done so, perform the following steps now:
■Clean the metal grease filters or replace the activated
charcoal filters; see section Cleaning and maintenance or the
'CleanAir air recirculation module' printed supplement.
■Reset the saturation indicator; see section Cleaning and
maintenance.
Resetting the saturation indicator
Press the 9button.
An audible signal sounds for 3 seconds.
Note: The appliance switches off the saturation signal
automatically after 20 hours.
Explanation
6Light on/off/dimming
@Increase fan level
AReduce fan level
8Interval ventilation
9Fan run-on
Explanation
1 Fan level 1
2 Fan level 2
3 Fan level 3
˜Intensive mode
8Interval ventilation
9Fan run-on
7Saturation indicator

7
Switching over the appliance to air recirculation
1. Switch off the appliance.
2. Press and hold the 9button for 4 seconds until an audible
signal sounds.
In the LED status bar, 1,2,3,˜and 7light up.
The electronic control is switched over to air recirculation.
Switching over the appliance to air extraction
1. Switch off the appliance.
2. Press and hold the 9button for 4 seconds until 2 audible
signals sound.
In the LED status bar, 1, 2 and 7light up.
The electronic control is switched over to air extraction.
Cleaning and maintenance
: Risk of burns!
The appliance will become hot during operation, especially
near the bulbs. Allow the appliance to cool down before
cleaning.
: Risk of electric shock!
Penetrating moisture may result in an electric shock. Clean the
appliance using a damp cloth only. Before cleaning, pull out the
mains plug or switch off the circuit breaker in the fuse box.
: Risk of electric shock!
Do not use any high-pressure cleaners or steam cleaners,
which can result in an electric shock.
: Risk of injury!
Components inside the appliance may have sharp edges. Wear
protective gloves.
Cleaning agents
Observe the information in the table to ensure that the different
surfaces are not damaged by using the wrong type of cleaning
agent. Do not use
■harsh or abrasive cleaning agents,
■cleaning agents with a high concentration of alcohol,
■hard scouring pads or sponges,
■high-pressure cleaners or steam cleaners.
Wash new sponge cloths thoroughly before use.
Follow all instructions and warnings included with the cleaning
agents.
Cleaning the metal mesh grease filters
: Risk of fire!
Grease deposits in the grease filter may catch fire.
Clean the grease filter at least every 2 months.
Never operate the appliance without the grease filter.
Notes
■Do not use any aggressive, acidic or alkaline cleaning
agents.
■When cleaning the metal mesh grease filters, also clean the
holder for the metal mesh grease filters in the appliance
using a damp cloth.
■The metal mesh grease filters can be cleaned in the
dishwasher or by hand.
In the dishwasher:
Note: If the metal mesh grease filters are cleaned in the
dishwasher, slight discolouration may occur. This has no effect
on the function of the metal mesh grease filters.
■Do not clean heavily soiled metal mesh grease filters together
with utensils.
■Place the metal mesh grease filters loosely in the dishwasher.
The metal mesh grease filters must not be wedged in.
By hand:
Note: You can use a special grease solvent for stubborn dirt. It
can be ordered via the Online Shop.
■Soak the metal mesh grease filters in a hot soapy solution.
■Clean the filters with a brush and then rinse them thoroughly.
■Leave the metal mesh grease filters to drain.
Area Cleaning agents
Stainless steel Hot soapy water:
Clean with a dish cloth and dry with a
soft cloth.
Clean stainless steel surfaces in the
direction of the grain only.
Special stainless steel cleaning prod-
ucts are available from our after-sales
service or from specialist retailers.
Apply a very thin layer of the cleaning
product with a soft cloth.
Painted surfaces Hot soapy water:
Clean using a damp dish cloth and
dry with a soft cloth/towel.
Do not use any stainless steel clean-
ers.
Aluminium and
plastic
Glass cleaner:
Clean with a soft cloth.
Glass Glass cleaner:
Clean with a soft cloth. Do not use a
glass scraper.
Operating controls Hot soapy water:
Clean using a damp dish cloth and
dry with a soft cloth.
Risk of damage to the electronics
from penetrating moisture. Never
clean operator controls with a wet
cloth.
Do not use any stainless steel clean-
ers.
Area Cleaning agents

8
Removing metal grease filter
1. Press the lock on the filter cover.
Note: The filter cover is heavy. Grip the filter cover with two
hands.
2. Open the filter cover downwards.
Note: Open the filter cover slowly and without any jerky
movements.
3. Press the lock on the metal grease filters.
Note: To avoid causing damage, do not bend the metal
grease filter.
4. Take the metal grease filter out of the holder.
Note: Fat may accumulate in the bottom of the metal grease
filter. Hold the metal grease filter level to prevent fat from
dripping out.
5. Clean the appliance from the inside.
6. Clean the metal grease filter and let it dry before re-fitting.
Installing the metal mesh grease filter
1. Insert metal grease filter.
While doing this, place your other hand under the metal
grease filter.
2. Fold up metal grease filter and engage the lock.
3. Close the filter cover upwards.
Note: Ensure that the filter cover lock engages correctly.
Trouble shooting
Malfunctions often have simple explanations. Please read the
following notes before calling the after-sales service.
: Risk of electric shock!
Incorrect repairs are dangerous. Repairs may only be carried
out and damaged power cables replaced by one of our trained
after-sales technicians. If the appliance is defective, unplug the
appliance from the mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
LED lights
Defective LED lights must only be replaced by the
manufacturer, their customer service department or a licensed
technician (electrician).
Malfunction table
--------
Fault Possible cause Solution
The appliance does not work The plug is not plugged into the mains Connect the appliance to the power
supply
Power cut Check whether other kitchen appliances
are working
The fuse is faulty Check in the fuse box to make sure that
the fuse for the appliance is in working
order
The lighting does not work The bulbs are faulty Call the after-sales service
1,2 and 7light up. The grease filter is saturated. Clean the filter; see section Cleaning
and maintenance.
3, ˜and 7light up. The activated charcoal filter is saturated. Replace the filter; see the 'CleanAir air
recirculation module' printed supple-
ment.

9
Replacing the batteries in the remote control
1. Undo screws.
2. Remove cover.
3. Remove the batteries.
4. Correctly insert the new batteries (23AE 12 V).
5. Dispose of flat or faulty batteries according to local
regulations.
Note: Do not dispose of batteries in general household waste.
After-sales service
Our after-sales service is there for you if your appliance needs
to be repaired. We will always find the right solution in order to
avoid unnecessary visits from a service technician.
When calling us, please give the product number (E no.) and
the production number (FD no.) so that we can provide you with
the correct advice. The rating plate with these numbers can be
found inside the appliance (remove the metal mesh grease
filter to gain access).
You can make a note of the numbers of your appliance and the
telephone number of the after-sales service in the space below
to save time should it be required.
Please be aware that a visit by an after-sales engineer will be
charged if a problem turns out to be the result of operator error,
even during the warranty period.
Please find the contact data of all countries in the enclosed
customer service list.
To book an engineer visit and product advice
Rely on the professionalism of the manufacturer. You can
therefore be sure that the repair is carried out by trained service
technicians who carry original spare parts for your appliances.
Accessories for circulated air mode
(not included in the delivery)
E no. FD no.
After-sales serviceO
GB 0344 8928989
Calls from a BT landline will be charged at up to
3 pence per minute. A call set-up fee of up to
6 pence may apply.
IE 01450 2655
0.03 € per minute at peak. Off peak 0.0088 € per
minute.
Z5190X0
Z5170X1

www.neff-international.com
Register your product online *9001021577*
9001021577 940708
Constructa Neff
Vertriebs-GmbH
Carl-Wery-Straße 34
D-81739 München
