Neilsen CT1913 User manual

GREASE OR HYDRAULIC OIL REEL 3/8’’ x 50FT
CT1913 Ref no. ZYS07-1-15
ORIGINAL INSTRUCTIONS
Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
SAVE THESE INSTRUCTIONS AND PRECAUTIONS.
READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.

2
EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety
and health requirements of the EC Directive based on its design and type, as
brought into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration
will lose its validity.
Product description: GREASE OR HYDRAULIC OIL REEL 3/8” x 50FT
Model: CT1913 (Ref no. ZYS07-1-15)
Applicable EC Directives:
EC Machinery Directive 2006/42/EC
Harmonized standards
EN ISO 12100：2010
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2019-10-08

3
Attention: Read through the complete manual prior to the initial use.
SPECIFICATIONS
TOOL USE AND CARE
1. Do not force the tool. Use the correct tool for the application. The correct
tool will do the job better and safer at the rate for which the tool is designed.
2. Disconnect the tool from the air source before making any adjustments,
Changing accessories, or storing the tool. Such preventive safety measures
reduce the risk of starting the tool unintentionally.
3. Store the tool when it is idle out of reach of children and other untrained
persons. A tool is dangerous in the hands of untrained users.
4. Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that affects the tool’s operation. If damaged, have the tool
serviced before using.
Many accidents are caused by poorly maintained tools. There is a risk of
bursting if the tool is damaged.
5. Use only accessories that are identified by the manufacturer for the
specific tool model. Use of an accessory not intended for use with the specific
tool model, increases the risk of injury to persons.
SERVICE
1. Tool service must be performed only by qualified repair personnel.
2. When servicing a tool, use only identical replacement parts. Use only
authorized parts.
3. Use only the lubricants supplied with the tool or specified by the
manufacturer.
HOSE LENGTH
MAX PSI
AIR INLET
AIR OUTLET
15+1Meters
2250 PSI
1/4”
3/8” BSPT

4
AIR SOURCE
SET-UP
REPOSITIONING BRACKET
1. Remove the Bolts on the Support Post and reposition to move the guide rollers,
if needed,for the desired mounting location (wall, floor or ceiling).
2. Replace the Bolts and tighten.
MOUNTING REEL
1. Choose a mounting location that is free of electrical wiring or other obstructions,
and is sturdy enough to support the weight of the Reel and hose as well as the
force used to extend and retract it.
2. Make a paper template from the mounting plate of the Reel. Mark the center of
the bolt holes in the desired mounting location.
3. Check for hidden wiring, then, drill holes to accommodate 1/2” bolts (not
included).
4. Mount the Reel and secure in place with four bolts.
OPERATION
ADJUST THE SPRING TENSION
1. Pull out approximately six feet of Hose.
2. Remove the Hose Stopper from the Hose and slide the Hose out of the Roller
Guide so the Hose is hanging loose.
a. To increase tension, wrap the loose hose one time around the Reel Drum.
b. To decrease tension, unwrap the hose one time from the drum.
3. Run the hose back through the guide and re-attach the hose stopper.
4. Pull the Hose out several feet to check the tension.
WARNING
• Never connect to an air source that is capable of exceeding 2250 psi. Over
pressurizing the tool may cause bursting, abnormal operation, breakage of the
tool or serious injury to persons.
• Use only clean, dry, regulated compressed air at the rated pressure or within the
rated pressure range as marked on the tool. Always verify prior to using the tool
that the air source has been adjusted to the rated air pressure or within the rated
air-pressure range.
• Never use oxygen, carbon dioxide, combustible gases or any bottled gas as an
air source for the tool. Such gases are capable of explosion and serious injury to
persons.

5
GENERAL OPERATING INSTRUCTIONS
1. Check the Wheel operation by slowly pulling the Hose out. You should hear a
clicking noise.
2. To lock the Hose, pull it out a minimum of 1/2 revolution and it will stay locked
after the first, second, or third click.
3. To unlock, slowly pull until the clicking stops, and let it retract until the Hose
Stopper hits the Hose Guide.
CAUTION
• Hold on to the Hose while it is rewinding, to avoid damage to the Hose Reel.
4. Attach a coupler (sold separately) to your air compressor hose and apply
thread seal tape to the Inlet fitting on the Reel. Connect the coupler to the Inlet
fitting.
5. Connect your air tool to the other end of the Hose using another coupler
and thread seal tape.
6. Follow all instructions from the air tool and compressor for set up and use.
7. When finished using the Hose, disconnect the air tool and retract the hose.
Wipe the Hose Reel clean with a dry cloth.
MAINTENANCE
WARNING
• To prevent serious injury :
Detach air supply from this product before performing any inspection,
maintenance, or cleaning procedures.
• To prevent serious injury from tool failure:
Do not use damaged equipment. If abnormal noise, vibration, or leaking air
occurs, have the problem corrected before further use.
CLEANING, MAINTENANCE, AND LUBRICATION
NOTICE
• These procedures are in addition to the regular checks and maintenance
explained as part of the regular operation of the Hose Reel.
1. BEFORE EACH USE, inspect the general condition of the tool. Check for:
• loose hardware or housing,
• misalignment or binding of moving parts,
• cracked or broken parts, and any other condition that may affect its safe

6
operation.
2. AFTER EACH USE, re-wind the hose onto the reel and wipe the Hose Reel
clean with a dry cloth.
WARNING
• Internal spring is not user serviceable or user-replaceable
HOSE REPLACEMENT
1. Remove the Hose Stopper from the hose and set aside.
2. Pull out the old Hose and securely lock the Hose Reel.
3. Disconnect the old hose from the swivel joint and remove the hose.
4. Run the new hose through the Guide Roller and through the opening in the
drum flange.
5. Use thread seal tape on the hose fitting threads and screw the fitting onto the
swivel and tighten.
6. Attach the Hose Stopper on the end of the Hose near the Outlet fitting.
7. Carefully release the Drum Latch and allow the Hose to wind onto the reel,
evenly distributing the Hose across the Reel.

7

8
CANNON TOOLS LTD
Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K.
Made in China
