Neilsen CT1075 User manual

10MM AIR BELT SANDER CT1075
ORIGINAL INSTRUCTIONS
SAVE THESE INSTRUCTIONS AND PRECAUTIONS.
READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.
Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.

2
EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety and
health requirements of the EC Directive based on its design and type, as brought
into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration will
lose its validity.
Product description: 10MM AIR BELT SANDER
Model: CT1075
Applicable EC Directives:
EC Machinery Directive 2006/42/EC
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2016-08-23

3
SAFETY WARNINGS
SYMBOLS
In this manual and/or on the machine the following symbols are used:
WARNING! Ensure Health & Safety, local authority, and general workshop practice
regulations are adhered to when using this equipment.
WARNING! Disconnect from air supply before changing accessories or servicing.
Maintain the sander in good condition (use an authorised service agent).
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be
dangerous and will invalidate the warranty.
Use in suitable clean and tidy working area, free from unrelated materials and ensure there
is adequate lighting.
Before each use check abrasive belt for condition. If worn or damaged replace immediately.
Use only the correct size and type of sanding belt with this sander.
Ensure there are no flammable or combustible materials near the work area.
WARNING! Always wear approved eye or face and hand protection when operating the
sander.
Use face, dust, or respiratory protection in accordance with COSHH regulations.
Depending on the task, sander noise level may exceed 85dB, in which case wear safety ear
defenders.
Remove ill fitting clothing. Remove ties, watches, rings, other loose jewellery and contain
and/or tie back long hair.
Wear appropriate protective clothing and keep hands and body clear of working parts.
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip
shoes.
Denotes risk of personal injury, loss of life or damage to the tool in
case of non-observance of the instructions in this manual.
Wear hearing protection.
Wear safety goggles.
Contact with or inhalation of dust coming free during use (e.g.
lead-painted surfaces, wood and metal) can endanger your health
and the health of bystanders. Always wear appropriate protective
equipment, such as a dust mask. Always use proper dust
extraction during use.
Wear gloves.

4
Keep children and unauthorised persons away from the work area.
Check moving parts alignment on a regular basis.
Ensure workpiece is secure before operating the sander. Never hold a workpiece by hand.
Check the workpiece to ensure there are no protruding screws, bolts, nuts, nails, rivets, etc.
Avoid unintentional starting.
WARNING! Ensure correct air pressure is maintained and not exceeded. Recommended
pressure 70-90psi.
Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each
use and ensure that all connections are secure.
Prolonged exposure to vibration from this sander poses a health risk. It is the owner’s
responsibility to correctly assess the potential hazard and issue guidelines for safe periods
of use and offer suitable protective equipment.
DO NOT use the sander for a task it is not designed to perform.
DO NOT operate sander if any parts are damaged or missing as this may cause failure
and/or personal injury.
WARNING! DO NOT sand any materials containing asbestos.
DO NOT carry the sander by the hose, or yank the hose from the air supply.
DO NOT force, or apply heavy pressure to, the sander, let the sander do the work.
DO NOT switch the sander on whilst the belt is in contact with the workpiece.
DO NOT operate sander when you are tired or under the influence of alcohol, drugs or
intoxicating medication.
DO NOT use sander where there are flammable liquids, solids or gases such as paint
solvents and including waste wiping or cleaning rags etc.
DO NOT carry the sander with your finger on the power lever.
DO NOT direct air from the air hose at yourself or others.
When not in use disconnect from air supply and store in a safe, dry, childproof location.
LEAD PAINT WARNING!
Paint once contained lead as a traditional ingredient. The dust from the removal of such paint is
toxic if ingested/inhaled and must, therefore, be avoided. The following actions must be taken
before using the sander on a surface that you suspect may contain lead paint.
1. User must determine potential hazard relating to age of paint to be removed.
(Modern paints do not have lead content).
2. DANGER! Keep all persons and pets away from the work area. The following persons are
particularly vulnerable to the effects of lead paint dust: Expectant women, babies and
children.
3. We recommend personal protection by using the following safety items:
a) Paint Spray Respirator.
b) PE Coated Hooded Coverall.
c) Latex Gloves.
4. Take adequate measures to contain the paint dust, flakes and scrapings.
5. Continue to wear safety equipment as in (3) above and thoroughly clean all areas when
task is complete. Ensure paint waste is disposed of in sealed bags or containers and
according to local Authority guidelines.

5
SPECIFICATION
Belt size: 10 x 330mm
Operating air pressure: 90 Psi (6.3 Bar)
Average air consumption: 6 cfm
Free speed: 16000 rpm
Hose Size: 3/ 8"
Air inlet: 1/ 4" BSP
PREPARING FOR USE
Air Supply (Recommended hook-up procedure is shown in fig.1).
1. Ensure the sander air valve (or throttle) is in the "off" position before connecting to the air
supply.
2. You will require an air pressure between 70-90psi, and an air flow of 6cfm.
3. WARNING! Ensure the air supply is clean and does not exceed 90psi.
Too high an air pressure and unclean air will shorten the product life due to excessive wear,
and may be dangerous causing damage and/or personal injury.
4. Drain the air tank daily. Water in the air line will damage the sander and will invalidate your
warranty.
5. Clean compressor air inlet filter weekly.
6. Line pressure should be increased to compensate for unusually long air hoses (over 8
metres).The minimum hose size should be 3/8” I.D. and fittings must have the same inside
dimensions.
7. Keep hoses away from heat, oil and sharp edges. Check hoses for wear, and make certain
that all connections are secure.
Couplings
Vibration may cause failure if a quick change coupling is connected directly to the air sander. To
overcome this, connect a leader hose to the sander. Aquick change coupling may then be used
to connect the leader hose to the air line recoil hose. See figs.1 & 2.
OPERATING INSTRUCTIONS
1. Unpack the product and check contents against the parts listed below. If there is anything
damaged or missing contact your supplier immediately.
WARNING! Ensure that you have read and understood the safety instructions in
Section “SAFETY WARNINGS”.

6
2. Loosening clamp bolt (fig.3.1. on the top of sander) allows the angle between the grip and
the belt to be altered to suit the job in hand.After adjustment retighten the clamp bolt.
3. Once connected to the air supply the sander is started by squeezing the trigger (2).
4. To remove and replace the sanding belt push the idle pulley (3) towards the drive pulley (4)
against spring pressure. The pulley bracket (5) will retract and lock allowing removal/fitting
of the belt. When the new belt is in position release the pulley bracket by pushing in and
holding the idle pulley, then press and hold the tension bar (6) whilst releasing the pressure
on the idle pulley.
5. The tracking of the belt can be altered by adjusted cross head screw (7).
MAINTENANCE
WARNING! Disconnect sander from air supply before changing accessories, servicing or
performing maintenance. Replace or repair damaged parts. Use genuine parts only.
Unauthorised parts may be dangerous and will invalidate the warranty.
1. If the air supply system does not have an oiler lubricate the sander daily with a few drops of a
good grade air tool oil dripped into the air inlet (fig.3.8) before use.
2. Clean the sander after use and change belt when required.
3. Loss of power or erratic action may be due to the following:
a) Excessive drain on the air supply. Moisture or restriction in the air line. Incorrect size or
type of hose connectors. To remedy, check the air supply and follow instructions in
Section “PREPARING FOR USE”.
b) Grit or gum deposits in the sander may also reduce performance. If your model has an air
filter (located in the area of the air inlet), remove the filter and clean it. Flush the sander out
with gum solvent oil or an equal mixture of SAE No.10 oil and kerosene. Allow to dry before
use.
If you continue to experience problems, contact your local service agent.
4. For a full service contact your local service agent.
5.When not in use, disconnect from air supply, clean and store in a safe, dry, childproof
location.

7
