Neilsen CT3191 User manual

PALM SANDER CT3191
ORIGINAL INSTRUCTIONS
SAVE THESE INSTRUCTIONS AND PRECAUTIONS.
READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.
Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.UNITED KINGDOM

1
EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety and
health requirements of the EC Directive based on its design and type, as brought
into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration will
lose its validity.
Product description: PLAM SANDER
Model: CT3191
Applicable EC Directives:
EC Machinery Directive 2006/42/EC
EC Directive of Electromagnetic Compatibility 2014/30/EU
Harmonized standards：
：：
：
EN 60745-1, EN 60745-2-4,
EN 55014-1, EN 55014-2,EN 61000-3-2, EN 61000-3-3
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2016-05-30

2
1. DESCRIPTION AND SPECIFICATION
STANDARD ACCESSORIES:
1. Sand paper 1pc
2. Dust box 1pc
3. Carbon brush 1set
Please inspect the product to ensure there is no damage and all parts have
been included prior to use.
2. TECHNICAL DATA
Voltage / frequency 230-240V~50Hz
Power input 240W
No load speed 13000rpm
Pad size 110*100mm
Weight 1.6kg
Protection class II
WARNING! For your own safety, read this manual and the general
safety instructions carefully before using the appliance. Your power
tool should only be given to other users together with these
instructions.
Trigger switch
Dust box

3
3. SYMBOLS
The following symbols are used in this manual and/or on the machine:
Denotes risk of
personal injury or
damage to the tool
Read manual before
use
In accordance with
essential safety
standards of
applicable European
directives
Class II- The
machine is double
insulated; Earthing
wire is therefore no
necessary
Mandatory use of
eye protection
Wear a mask in
dusty conditions
Wear noise protection
4. GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed warnings and
follow instructions may result in electric shock, fire and/or serious injury.
Keep safety warnings and instructions for future reference. The term
"power tool" in the safety warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
4.1 Working area
Keep working area clean and well lit. Untidy and dark areas can lead to
accidents.
Do not operate power tools in potentially explosive surroundings, for
example, in the presence of inflammable liquids, gases or dust. Power
tools create sparks which may ignite the dust or fumes
Keep children and bystanders at a distance when operating a power tool.
Distractions can cause you to lose control of it.
4.2 Electrical safety

4
Always check that the power supply corresponds to the voltage
on the rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use adapter plugs with earthed power tools. Unmodified plugs and
matching outlets will reduce the risk of a lethal electric shock.
Avoid body contact with earthed surfaces such as pipes, radiators,
kitchen ranges and refrigerators. There is an increased risk of a lethal
electric shock if your body is earthed.
Do not expose power tools to rain or wet conditions. If water gets inside a
power tool, it will increase the risk of a lethal electric shock.
Do not damage the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep the cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk of
a lethal electric shock.
When operating a power tool outdoors, use an extension cable suitable
for outdoor use. Using a cord suitable for outdoor use reduces the risk of
a lethal electric shock.
If operating a power tool in a damp location is unavoidable, use a power
supply protected by a residual current device (RCD). Using an RCD
reduces the risk of a lethal electric shock.
4.3 Electrical safety
Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool when you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention when operating a power tool may result in serious personal
injury.
Use safety equipment. Always wear eye protection. Using safety
equipment such as a dust mask, non-skid safety shoes, a hard hat, or
hearing protection whenever it is needed will reduce the risk of personal
injury.
Avoid accidental starts. Ensure the switch is in the off position before
inserting the plug. Carrying power tools with your finger on the switch or

5
plugging in power tools when the switch is in the on position makes
accidents more likely.
Remove any adjusting keys or spanners before turning on the power tool.
A spanner or key left attached to a rotating part of the power tool may
result in personal injury.
Do not reach out too far. Keep your feet firmly on the ground at all times.
This will enable you retain control over the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from the power tool. Loose clothes, jewellery or
long hair can become entangled in the moving parts.
If there are devices for connecting dust extraction and collection facilities,
please ensure that they are attached and used correctly. Using such
devices can reduce dust-related hazards.
4.4 Power tool use and care
Do not expect the power tool to do more than it can. Use the correct
power tool for what you want to do. Apower tool will achieve better results
and be safer if used in the context for which it was designed.
Do not use the power tool if the switch cannot turn it on and off.A power
tool with a broken switch is dangerous and must be repaired.
Disconnect the plug from the power source before making adjustments,
changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
Store power tools, when not in use, out of the reach of children and do not
allow people who are not familiar with the power tool or these instructions
to operate it. Power tools are potentially dangerous in the hands of
untrained users.
Maintenance. Check for misalignment or jammed moving parts,
breakages or any other feature that might affect the operation of the
power tool. If it is damaged, the power tool must be repaired. Many
accidents are caused by using poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to jam and are easier to control.
Use the power tool, accessories and cutting tools, etc., in accordance

6
with these instructions and in the manner intended for the particular type
of power tool, taking into account the working conditions and the work
which needs to be done. Using a power tool in ways for which it was not
intended can lead to potentially hazardous situations.
4.5 Service
Your power tool should be serviced by a qualified specialist using only
standard spare parts. This will ensure that it meets the required safety
standards.
5. SPECIFIC SAFETY WARNINGS FOR SANDER
When working with the machine, always hold it firmly with both hands
and provide for a secure stance. The power tool is guided more
securely with both hands.
Do not work with materials containing asbestos. Asbestos is
considered carcinogenic.
Take protective measures when dust can develop during working that
is harmful to one’s health, combustible or explosive. Wear a dust
mask and work with dust/chip extraction devices.
Keep your workplace clean. Blending of certain materials can be
particularly dangerous.
Never use the machine with a damaged cable. Do not touch the
damaged cable and pull the mains plug when the cable is damaged.
Damaged cables increase the risk of an electric shock.
Use the machine only for dry sanding. Penetration of water into the
machine increases the risk of an electric shock.
Use suitable detectors to determine if utility lines are hidden in the
work area or call the local utility company for assistance. Contact with
electric lines can lead to fire and electric shock. Damaging a gas line
can lead to explosion. Penetrating a water line causes property
damage or may cause an electric shock.
6. FUNCTIONAL DESCRIPTION
CAUTION:
Always be sure that the tool is switched off and unplugged before
adjusting or checking function on the tool.

7
Switch action
CAUTION:
Before plugging in the tool, always check to see that the switch trigger
actuates properly and returns to the “OFF” position when released.
Switch can be locked in “ON” position for ease of operator comfort during
extended use.
Apply caution when locking tool in “ON”position and maintain firm grasp
on tool.
To start the tool, press the “ON (I)” side of the switch. To stop the tool,
press the“OFF (O)”side of the switch.
ASSEMBLY
CAUTION:
Always be sure that the tool is switched off and unplugged before
carrying out any work on the tool.
Installing or removing abrasive paper
To install the abrasive paper, operate the
clamp lever to open the paper clamp. Insert
the paper end into the clamp. Center the
paper and align the edges parallel to the
pad, then lower the clamp lever to secure
the paper. (Pretending paper makes
attachment easier.) 1.Lever 2.Clamp
Repeat the same process for the other end of the base, maintaining the
proper paper tension. After inserting the paper, make sure the teeth of the
clamp hold it securely. Otherwise the paper will be loose and subject to
slippage, resulting in uneven sanding operation.
7. FITTING THE SANDING PAPER (See Fig.A) Fig.A
Fit the sanding paper over the base. Make
sure the sanding paper is even with the edges
and that the dust collection holes in the base
and sanding paper is aligned and that the
sanding paper is taut on the base.

8
Dust box
The use of the dust box makes sanding operations clean and dust collection
easy. To attach the dust box, fit the box’s entry port onto the dust spout on the
tool. Make sure that the hole in the box’s entry port is just over the pimple-like
protrusion on the dust spout. For the best results, empty the dust box when it
becomes approximately half full, tapping it lightly to remove as much dust as
possible.
OPERATION:
Sanding operation
CAUTION:
Never run the tool without the abrasive paper. You may seriously damage
the pad.
Never force the tool. Excessive
pressure may decrease the sanding
efficiency, damage the abrasive
paper or shorten tool life.
Hold the tool firmly. Turn the tool on and
wait until it attains full speed. Then gently
place the tool on the workpiece surface.
Keep the pad flush with the workpiece and apply slight pressure on the tool.
8. CLEANING AND MAINTENANCE
Attention ! Before performing any work on the equipment, pull
the power plug.
Cleaning
Keep the ventilation slots of the machine clean to prevent overheating of the
engine. Regularly clean the machine housing with a soft cloth, preferably after
each Keep the ventilation slots free from dust and dirt. If the dirt does not
come off use a soft cloth moistened with soapy water. Never use solvents
such as petrol, alcohol, ammonia water, etc. These solvents may damage the
plastic parts.

9
Lubrication
The machine requires no additional lubrication.
Faults
Should a fault occur, e.g. after wear of a part, In the back of this manual you
find an expanded view of the parts that can be ordered.
ENVIRONMENT
Should your appliance need replacement after extended use, do
not discard it with the household rubbish but dispose of it in an
environmentally safe way.
Waste produced by electrical machine items should not be
handled like normal household rubbish. Please recycle where
recycle facilities exist. Check with your Local Authority or retailer for
recycling advice.

10
9. PARTS DIAGRAM

11
10. PARTS LIST
NO. Description Qty NO Description Qty
1 Power plug and cord 1 22 1mm Shim 1
2 Screw 2 23 Fan 1
3 Cover 1 24 Mantle 1
4 Top housing 1 25 Screw 2
5 Screw 2 26 Bearing 1
6 Cord protector 1 27 Bracket 2
7 Cord clamp 1 28 Washer 1
8 Screw 2 29 Spring mattress 1
9 Switch pole 1 30 Screw 1
10 Screw 1 31 Screw 2
11 Left housing 1 32 Press plate 2
12 Left fastener 1 33 Steel clamp 2
13 Stator 1 34 Base 1
14 Carbon brush assembly 2 35 Screw 4
15 Bearing 1 36 Foam base 1
16 Rotor 1 37 Sand paper 1
17 Connection pole 1 39 Right fastener 1
18 Screw 5 40 Dust box 1
19 Screw 1 41 Dust cover 1
20 Right housing 1
21 Bearing 1

12
CANNON TOOLS LTD
Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K.
Made in China
