Nemco 8050SX-RC Reference manual

Model Series: 8050SX-RC, 8075SXW-RC, Flat Roller Grills
8050SX-SLT-RC, 8075SXW-SLT-RC Slant Roller Grills
INTRODUCTION
1. Please read instr ctions before sing.
2. This roller grill will be HOT d ring se and for a short time after it is t rned off – BE CAREFUL!
INSTALLATION
1. Set the roller grill on a flat s rface.
2. Position the roller grill near the power o tlet. Avoid the se of extension cords.
3. Pl g the roller grill into a certified electrical o tlet with a corresponding voltage rating as listed on the
roller grill model label.
4. Clean the roller grill thoro ghly before se.
OVERVIEW OF CONTROLS
1. This machine has two zones, a front zone which is closest to the controls, and a rear zone which is
f rthest from the controls. Each zone is designated by the color of the bearings, black bearings for the
front zone, and white bearings for the rear zone.
2. There are two lighted rocker switches to t rn the motors on, one for each zone.
3. There are two thermostats to t rn the heat on, one for each zone.
4. There are two pilot lights to indicate when the heat is on, one for each zone.
5. There is also a display that shows the approximate temperat re of the zone once it reaches temperat re.
This display has two lights that cycle back and forth to indicate which zone’s temperat re is being
displayed. This display is an approximation; prod ct sho ld be probed with a thermometer to verify that
it is above the safe serving temperat re.
STARTUP
1. T rn on/off switches to the on position and make s re rollers are t rning.
2. T rn temperat re controls to desired temperat re
♦Knob setting #2: temperat re is approximately 140º ; HOLD
♦Knob setting #4: temperat re is approximately 160º ; HOLD
♦Knob setting #6: temperat re is approximately 200º ; REHEAT
♦Knob setting #8: temperat re is approximately 250º ; REHEAT
3. Allow rollers to heat for 5 to 10 min tes before placing prod ct on rollers.
4. Plastic tongs are incl ded with the nits. Use plastic to prevent serio s damage to these rollers. Never
se metal tensils or tools on the GripsIt rollers.
5. Once the prod ct has finished reheating; t rn the grill down to the hold zone. Never leave prod ct on
reheat as it will overcook the prod ct and dry it o t.

2
CLEANING
1. T rn the temperat re controls on high and t rn the rollers on before cleaning.
2. ALWAYS START AT THE END OF THE ROLLERS AND WIPE TOWARD THE CENTER. This prevents
extra grease from entering the sides of the roller grill and into the bearings.
♦Use a wet, soft cloth to wipe the rollers clean. NOTE: never se any metal object on the GripsIt rollers
at any time. Metal will ca se serio s damage to the rollers.
3. After cleaning the rollers, remove the drip pan and clean with mild soap and water.
SERVICE INSTRUCTIONS
PREVENTATIVE MAINTENANCE
NOTE: Proper maintenance plays an important part in the life span and f nctioning of the roller grill.
1. The chains that drive the rollers sho ld be inspected and greased once a year to be s re that they
contin e to operate correctly. This will allow the machine to operate for a m ch longer time.
2. IMPORTANT: Disconnect the roller grill from the power so rce before disassembly.
3. Nemco offers a greasing kit, ordering n mber 80586. Alternatively, any food grade grease with a
temperat re rating of at least 500°F can be sed to grease the chains.
IF ROLLERS WON’T TURN
1. Check power so rce to be s re the roller grill is pl gged into the proper voltage o tlet and that the o tlet
is in proper working order.
2. IMPORTANT: Disconnect the roller grill from the power so rce before disassembly.
3. Remove the end covers.
4. If the drive chain is off the idler sprocket, reinstall it.
5. Remove the drive chain from the sprocket on the motor shaft and if the rollers t rn easily, then replace
the motor.
6. Remove the chain g ard and inspect the sprockets on the end of each roller. If they are loose, worn, or
o t of alignment, then replace the roller.
7. If the rollers are hard to t rn by hand (witho t the chain attached) remove and clean o t any
acc m lated foreign matter in the bearings and on the rollers.
8. IMPORTANT: Reassemble the roller grill completely before reconnecting to the power so rce.
IF ROLLER GRILL BLOWS A FUSE OR CIRCUIT BREAKER
1. Check the capacity of the circ it being sed to be s re it is not overloaded.
2. Unpl g the roller grill and check it’s wiring for short circ its.
IF ROLLERS WON’T HEAT
Check the power so rce to be s re the roller grill is pl gged into the proper voltage o tlet and the receptacle
is working. If properly connected and still no heat call NEMCO c stomer service at 1-800-782-6761.

3
NEMCO FOOD EQUIPMENT 301 Meuse Argonne, Hicksville, OH 43526
Phone: [phone] Fax: [phone] Toll free: 1-800-782-6761 80XX-RC
www.nemcofoodequip.com 10-4-11
