NEO Smartpen Dimo User manual

User Guide

What’s in the package
This package includes video production application.
Download PaperTube® app and,Showcase Your Story!
<for AOS> <for iOS>
Neo Smartpen dimo(D1 ballpoint pen tip)
AAA Battery 1ea
Stylus tip
Smart Plate
Smart Class Note(Notebook)
Paper Controller
Smart device stand
User Guide

Insert the battery into the pen referring image guide.
Get Ready
Battery Cap Open
(Turn the cap counterclockwise
and open)
Insert the Battery
(With the + mark
facing down)
Battery Cap Close
(Place the mark in a straight line,
close the cap and turn clockwise)
14 32
Press the power button for 1 second,
and connect it to PaperTube™ app.
Power On
1 . Make a video only
with handwriting.
( use a blank notebook )
2 . Annotate PDF imported
( use my own material )
Install App &
connect pen
Select the mode in your preference to make your
lecture video.
click!
Holding the Pen
The recognition rate is affected by the direction of the optical sensor’s
angle. The sensor (oval shaped part adjacent to the pen tip) should
face downwards.Deviating from the appropriate angle, or holding the
pen in the wrong direction could cause difficulties with capturing your
writing or drawing.
Usage Angle
Hold the pen with the ball point nib
facing up
Allowable Recognition Angle
Product’s acceptable recognition
angle is -30º ~ +40º
(90º vertical standard)
LED Color Status Key
Status / 상태 LED Color/Action / 컬러
Power ON / Stand by light on
light on
light on
light on
flashes
flashes
flashes
and light off
Optical lens on the pen cannot
read the code on the paper
Power OFF
Low battery (lower than 20%)
Low battery (lower than 10%)
Connected to App
Firmware update
Fail to update firmware
-----

Introduction of PaperTube™
PaperTube is a video production app that creates visual contents for spreading
your ideas.You can create a variety of videos through your blank notes or your
own material.Also, your own template can be printed with Ncode A4 paper using
blueprint function. Scan the QR code on the right to look around how people use
PaperTube™ app for online lectures and remote classes.
<English>
APP ICON FUNCTION
HOW TO USE
Start record
Record yourself Share your work as jpeg,png and PDF file
Add a title on the video
Add a logo image
Adjustment of tools (pen/highlighter/eraser)
Change color of the background
Change tools (pen/highlighter/eraser
Ncode A4 is a paper where Ncode is imprinted and it is
specialized for printing the contents for PaperTube.
with my own material
Use a printed Ncode A4
Print Mode
Use a Plate
Plate Mode
with blank notebook with my own material
Use a Smart class note

Tips
Pen Firmware Updates
For Android Device Users
For All Users
Turn on flight mode to prevent any possible interruption by notification while recording.
Please update the firmware to the latest version.After connect the pen to App,Go to management > Firmware update.
※Do not disconnect or turn off the power while the update is in progress.
*
For M1(F50),N2(F121) users,please update the pen firmware,to use hover function that indicates the position of the pen on PaperTube app.
Please make sure Bluetooth enabled on your device before connection.
PaperTube™ Controller Function
Connect a Neo smartpen dimo to PaperTube™ app and touch the icon with the pen.
PaperTube controller which can let you select various effects on PaperTube app screen just by touching
with Neo smartpen helps you to create video contents easily without navigating.
1. Start recording
2. Stop recording
3. Undo
4. Redo
5. Eraser
6. Delete all
7. Zoom in
8. Zoom out
9.Page width fit
10.Page height fit
11. Zapplause
12. Magic
13. Drum
14. Pass
15. Fail
16. Disappointed
Sound effectPage Control
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
17. Ballpoint pen
18.Stroke thickness down
19.Stroke thickness up
20. Highlighter
21. Red
22. Yellow
23. Green
24.Light Blue
25. Black
26. White
27. Camera on/off
28.Camera opacity down
29.Camera opacity up
30. Camera full-view
31. Previous Page
32. Next Page
Camera Control For PDF
documents
Pen ColorsThickness
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32

USE A BLANK NOTEBOOK
Connecting the pen to App
Prepare the note Open the app and select
‘blank notebook’ Turn on the pen and connect to App LED turn into green when connected
Writing & Recording Tips!
Notice
1. Click ,if you want to add a title in the beginning of your video.
2. Click , if you want to add logo of your institute.
3. Touch to start recording.
4. Create unique and professional contents with your handwritings.
5. Touch to stop recording
6. Click to save your video work, or click to upload it on
youtube directly.
7. Click to share handwriting as PDF,PNG and JPG
Ncode A4,and other Ncode
imprinted papers work with
the app as well.
Plate works on ‘plate mode’
only.
Please check the storage of your
device before start recording.
Device Storage Minimum required storage
16 Gb 1 Gb
32 Gb 2 Gb
64 Gb or
above 4 Gb

USE MY OWN MATERIAL_Plate mode
Connecting the pen to App
Change to stylus tip Prepare the plate Select
‘use my own material’ Turn on the pen and connect to App
Browse and select pdf.
Then, start plate mode
Writing & Recording  필기 & 영상 녹화 Tips!
Notice
1.
2.
1. Click ,If you want to add a title in the beginning of your video.
2. Click , If you want to add logo of your institute.
3. Touch to start recording. Write and draw on the PDF with a Plate.
4. Touch with a pen to move to previous/next page.
5. Touch with a pen to zoom in and out the pages.
6. Touch to stop recording
7. Click share to save your video work,or click upload to upload it on
youtube directly.
Icons on the plate help you to
control functions of the app
more easily.
Smart Class Note and other
notebooks does not work on
‘Plate mode’
If stylus tip is worn out,your
writing cannot be recognized.
Please change stylus tip and
try again.
showcase your story.pdf
make a video with a pen.pdf
<PaperTube App> <Smart Plate>
Position of the pen tip on the plate and
pointer on the display will be proportional.
Camere on/off
Full view

USE MY OWN MATERIAL_Print mode
※Ncode imprinted paper product needed.shop at Amazon.com
※For matching the paper and the screen of PaperTube app, please follow the on-screen instructions.
Connecting the pen to App
Calibration
Prepare Ncode A4
option 1. Share the file
and print on PC.
option 1. option 2.
Insert Ncode A4 into paper
tray of the printer
option 2. Print from
smart devices.
Select ‘use my own material’
When printed Ncode A4
is ready, touch ‘Next’
Browse and select pdf.
Then, start print mode
Turn on the pen and
connect to App
showcase your story.pdf
make a video with a pen.pdf
Ncode A4
Printed
Ncode A4
Adjust calibration
This process will adjust the
writing area and the app screen
area to be synchronised.
Share

FAQ
Reset
Please reset the pen if it does not turn off, won't
charge,or stops working. To reset the pen, press and
hold the power button for 10 seconds or remove and
reinsert the battery, then the pen will be turned off
and restart.
Tips for using the correct battery
• The enclosed alkaline batteries can be natural discharge.
• Batteries are consumables and should be replaced after a
certain period of time.In addition,the usage time varies
depending on the usage environment.
• Be sure to remove the battery when you will not be using
the pen for a long time to prevent paid service due to leakage.
• Manganese battery or rechargeable battery can not
guarantee the use time.
Precautions
Additional
•Storing pen without pen cap may cause degradation of functionality
due to dust and foreign substances on the optical sensor.
•The pen cap should be placed on the pen if not in use and
if the cap gets dirty, please clean with soft cloth or cotton swab.
•If you write on the edge of the page where there is no code,
your handwriting may not be recognized.
Be sure to remove the battery
when you will not be using the pen for a long time.
Prevents paid service due to leakage.
When a strong impact is applied
to the ball pen nib, the product may malfunction.
For more accurate handwriting recognition,
please use the recommended nibs.
(You can check the recommended pen nib
list on the Neo smartpen official website.)
In case of processing ball pen nib with tape,
it may cause malfunction.
Please be careful not to cover the optical
sensor with your fingers.
Otherwise, your writing may not be recognized.
Please check the details and frequently asked questions
on the Neo smartpen homepage and online mall.
www.neosmartpen.com
Please visit official Neosmartpen mall to buy
compatible notebooks and accessories.
https://shop.neosmartpen.com/
Product Specification
Pen Body Material
Connectivity
Receiving/Transmitting Frequency
RF Output Power
Type of emission
Battery
Runtime
Memory
Ink refills
Function
Usage Environment
Length / Diameter / Weight
Model Name
Supported
NWP-F30
140 mm / 14.7mm / 26.5g
Polycarbonate
Bluetooth 4.2 (Classic / BLE)
2402~2480MHz
3mW / Class 2
F1D
Alkaline battery(AAA/R03) 1ea
Nonstop writing : 9.5 Hr
D1 pen ink refills
Real time-transfer mode
2MB of internal memory
(Saves up to about 3 sheets of A4 size)
Temperature for storage(No operation) : -10 ~ 50℃
Relative humidity : ~90%
Operation temperature : 10~35℃
FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and,if not installed and used in
accordance with the instructions,may cause harmful interference to radio communications.However,there is no guarantee
that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or
television reception,which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
Caution
Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
IMPORTANT NOTE : FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your
body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
NOTE : THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED
BY THE PARTY RESPONSIBLE FOR COMPLIANCE.SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS: (1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
IC Information to User
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and (2) This device must accept any interfer-ence,including interference that
may cause undesired operation of the device Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence.L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
Product Name
Product No.(Serial No.)
Purchase Date
Seller
Purchase Price
· Keep the product no.(serial no.) in a safe place as it is required for checking the product warranty
period when requesting customer service / support.
· The product no.is attached on the surface of the product package.
Product Warranty
Please contact the store where you purchased the product or
NeoLAB Convergence for customer service/support.
PRODUCT WARRANTY
Smart Class Kit
OS version Bluetooth version
Android 6.0 Marshmallow
and above
BLE 4.0
and above
iOS IOS 13 and above LE 4.1
and above
