Neostar Electronics 318 4303 User manual

3D Oscillating Circulation Fan
Product Code: 318 4303
Instruction Manual

1
Scotts Ltd. Cotswold House, 1 Crompton Road, Groundwell, Wiltshire. SN25 5AW. Enquiries: 0344 482 9700
Product Part Names
Control Panel and Remote Control

2
Scotts Ltd. Cotswold House, 1 Crompton Road, Groundwell, Wiltshire. SN25 5AW. Enquiries: 0344 482 9700
PRODUCT INSTRUCTIONS
Power
When the fan is plugged in and it is in standby mode, touch this button once to turn on the fan at the 1st
level of speed (Mode: Normal). Touch this button one more time, the fan goes off to be in standby
mode.
Speed
When the fan is in Normal mode, sliding the speed bar from left to right will increase the speed from 1 to
8 levels (s). Sliding the speed bar from right to left will decrease the speed from 8 to1level (s). The
digital display will indicate the speed number every time the speed is adjusted.
Oscillation
1. In running mode, touch this button once to activate left-right oscillation.
2. Touch this button twice to deactivate left-right oscillation an d activate up-down oscillation.
3. Touch this button the third time to active both left-right and up-down oscillation.
4. Touch this button the fourth time to deactivate left-right and up-down oscillation.
5. When oscillation is activated, digital display will indicate corresponding icons.
Timer / Pre-set
1. In running mode, touch this button to set time of auto shutdown within 1~9 hours. Digital display will
indicate corresponding number of time.
2. In standby mode, touch this button to set time of auto power on within 1~9 hours. Digital display will
indicate corresponding number of time. User can also set level of speed, oscillation or wind mode.
Timer / Pre-set is done without further adjustment after 5 seconds.
Wind Mode & Eco Mode
1. After the fan is powered on, the default mode is Normal mode with corresponding icon lit up on the
digital display. Touch this button to select other wind modes such as Natural or Sleep with
corresponding icon lit up.
2. When the fan is in Normal mode, touch this button once to select Natural mode. Touch this button
twice to select Sleep mode. Touch it the third time to return to Normal mode.
3. When the fan is in running mode, hold this button for over 3 seconds to enter ECO mode with icon lit
up on the digital display. In ECO mode, the fan is automatically shifting level of speed according to
temperature. Hold this button for over 3 seconds to return to running mode.
4. In Natural mode, Sleep mode and Eco mode, speed bar is not adjustable until the fan returns to
Normal mode.
Reference Table –Speed vs Temperature in ECO Mode
Temp
<20
20 –22
22 –24
24 –26
26 –28
28 –30
30 –32
>32
Level of Speed
1
2
3
4
5
6
7
8

3
Scotts Ltd. Cotswold House, 1 Crompton Road, Groundwell, Wiltshire. SN25 5AW. Enquiries: 0344 482 9700
CLEANING AND MAINTENANCE
1. Please clean the fan regularly in case of dust causing weaker wind speed and malfunction.
2. Please be sure to power off the fan and unplug the cord before cleaning and please ensure the
temperature of the fan is safe for handling.
3. Please do not use bleaching water, alcohol, or the like to clean the fan in case the fan discolours,
deforms or malfunctions.
Disassembly Method
1. [Remove the screw]: Use a screw driver to remote the Set Screw of the Front Fan Guard.
2. [Remove the front fan guard]: After step 1, hold the Front Fan Guard and turn it counter clockwise
until it loosens from the Main Body.
3. [Remove the fan blade]: Turn the Screw Cap for Blade clockwise and take off the Blade. Clean the
component with a soft cloth dampened in the water or neutral detergents then wipe them with a soft dry
cloth thoroughly.
TROUBLE SHOOTING
FAQ
Possible Causes
Troubleshooting
Fails to operate
Power cord disconnected
Please plug it in
Motor malfunction
Please return for maintenance
PCB malfunction
Abnormal noise during working
Fan is not on a flat surface
Please place the fan onto a flat
surface
The front guard or blade is
not assembled properly
Please assemble correctly
Motor malfunction
Please return for maintenance.
Weaker wind speed
Too much dust on blade
Please clean the fan regularly
Abnormal noise during OSC
Normal phenomenon at the
1st time of use
Not malfunction
OSC motor malfunction
Please return for maintenance

4
Scotts Ltd. Cotswold House, 1 Crompton Road, Groundwell, Wiltshire. SN25 5AW. Enquiries: 0344 482 9700
Product Specification
Recycling Information
The crossed-out Wheelie Bin logo is used to highlight electrical products that should not be
disposed of with normal household waste. Scotts Ltd has contributed to the funding of an
alternative network of UK recycling facilities. Please visit www.recycle-more.co.uk to find
where your nearest recycling point is and recycle this product at the end of its life.
Made in China for Scotts Ltd
Name
3D Oscillating Circulation Fan
Model No
318 4303
Rated Voltage
AC 220V
Rated Frequency
60Hz
Rated Power
28W
Country of Origin
China
Product Size
342(W)*205(D)*344(H)mm
Packing Dimension
355(W)*250(D)*385(H)mm
Product Material
ABS
Product Accessory
Remote Control x 1
