Nera F33 Technical specifications

OK
»001/Telenor
002/Stratos
004/Telenor
005/OTE
Sat. Search
Phone setup
» Set Network
Serial Ports
In ormation
Saving data ....
OK
Making a call
1Dial 00, country code and subscriber
number, e.g.:
•When entered,
the display reads:
•When the remote end
answers, the display reads:
The timer starts.
2End the call by pressing
hook ON/OFF , or
replacing the handset
in the cradle.
Use DEL to modify entries:
DEL
pressing DEL
once, erases one digit. Holding the key more
than 0.5 second erases the whole number.
Use the handsfree key to toggle the
loudspeaker ON/OFF.
Alternativedialing:
Press or to get the dialing tone,
then dial the number as described above.
Switching ON
1Insert SIM card (if used).
2Set the Power ON/OFF switch on the
upper end of the Main Communication
Unit to ON. The power indicator lights up.
3Enter SIM code (if SIM card is used)
4Nera F33 starts up. It automatically initial-
izes the system and searches for the satellite.
When idle,
the Nera
ISDN Hand-
set displays:
Nera F33
ON
48V DC
SYNC
ALARM
RS-232 A RS-232 B
USB
ISDN
ISDN
ISDN
TX+
TX-
RX+
RX-
NMEA-
NMEA+
5 4 3 2 1
9 8 7 6
5 4 3 2 1
9 8 7 6
1 8
8 1
RS-422
TX-
TX+
RX-
RX+
ON/OFF
NOT IN USE RFSIM CARD
20-32 VDC / 110W
( 0 TERM)
WHEN CHANGING MODEM UNIT
AND TAKE OUT SIM CARD
REMOVE COVER
SIM CARD INSIDE
Power
ON/OFF
switch
Power
indicator
SIM card
Cover
Main Communication Unit-MC
U
Changing Net service provider
The Net service provider can only be
selected for the Ocean Region in use.
The selected Net service provider is stored
in the Nera F33 memory:
1Open the MENU:
and scroll down to
Set Network.
2Scroll down to
the required Net
service provider:
3Store the new Net
service provider for the
currentOcean Region:
Telenor IOR
Ready or call
Ocean Region
Service provider
Signal strength
indicator
Acceptable strength: at least 4bars
Nera F33 - Brief Operating Instruction
Dash separates
additional dialing
Timer, minutes:seconds
For normal call
For handsfree call
For analogue G fax
and ISDN telephones
Dial (4.8)
004767244700
Calling...
004767244700
Connected 09:46
004767244700-
Disconnected
0 0
7
pqrs
6
mno
2
abc
7
pqrs
4
abc
0 4
abc
7
pqrs
04
abc

148 x 195 mm
Doc. No. 103222 Rev. 1.0.1 May 2003
Nera F33 provides communication with the public telephone
network via satellite, which requires free line of sight.
Four satellites are positioned stationary above equator.
The satellites provide the coverage shown on the map
below.
Nera F33 searches any Inmarsat satellite as default.
IOR
AOR-E
AOR-W
POR
S ee also Nera F33 - Getting Started.
The CD enclosed with the manual contains the Nera F33
vtLiteMarine monitoringand configuration program.
Equator
AOR-E
15.5 E
AOR-W
54 W
POR
178 E
POR
178 E
IOR
64.5 E
5° Elevation 5° Elevation 5° Elevation 5° Elevation
5° Elevation
LONGITUDE
Global beam
(circles)
Spot beam
180E
100 E 120 E 140 E 160 E
140 W 120 W160 W 40 E 60 E 80 E 20 W 0 20 E80 W 60 W 40 W100 W180 W
60 N
30 N
0
30 S
60 S
60 N
30 N
0
30 S
60 S
LATITUDE
LATITUDE
Nera F33 - Brief Operating Instruction
