Nero 7433301 User manual

Nero Bluetooth Clock Radio
（Code: 7433301）
OPERATING INSTRUCTIONS
SPEAKER SYSTEM WITH
2 USB CHARGING PORTS
FM RADIO TUNER
AND ALARM CLOCK

The lightning flash and arrowhead within the triangle is a warning sign alerting
you to "dangerous voltage" inside the product.
WARNING:
To reduce the risk of electric shock, do not remove cover (or back). No
user-serviceable parts inside. Refer servicing to qualified service personnel.
CAUTION:
The exclamation point within the triangle is a warning sign alerting you to
important instructions accompanying the product.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
DRIPPING OR SPLASHING LIQUIDS.
THE AC/DC ADAPTOR IS USED AS THE DISCONNECT DEVICE AND IT SHALL REMAIN
READILY OPERABLE. TO COMPLETELY DISCONNECT THE POWER INPUT, THE
AC/DC ADAPTOR OF THE APPARATUS MUST BE DISCONNECTED FROM THE MAINS
COMPLETELY. THE AC/DC ADAPTOR SHOULD NOT BE OBSTRUCTED AND SHOULD BE
EASILY ACCESSED DURING INTENDED USE.
PLEASE NOTE: YOU WILL FIND THE
RATING LABEL FOR THIS PRODUCT
LOCATED ON THE REAR OF THE UNIT.
CAUTION
DO NOT EXPOSE TO DRIPPING
OR SPLASHING LIQUIDS!
CAUTION: GROUNDING OR POLARIZATION - PRECAUTIONS SHOULD BE TAKEN SO
THAT THE WIDER BLADE OF THE AC PLUG MUST MATCH THE SLOT IN RECEPTACLE
"WALL SOCKET".
NOTE: CAUTION SYMBOLS ARE PRINTED ON BOTTOM OF UNIT. PLEASE REFER TO
INSTRUCTION MANUAL.
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED. AVOID EXPOSURE
TO BEAM.
VORSICHT: UNSICHTBARE LASERSTRAHLUNG TRITT AUS, WENN DECKEL GEÖFFNET UND WENN
SICHERHEITSVERRIEGELUNG ÜBERBRÜCKT IST. NICHT DEM STRAHL AUSSETZENI.
VARNING: OSYNLIG LASERSTRÁLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRR ÄR URKOPPLAND.
STRÁLEN ÄR FARLIG.
ADVARSEL: USYNLIG LASERSTRÁLING VED ÁBNING. NÁR SIKKERHEDSAFBRYDERE ER UDE AF
FUNKTION. UNDGÁ UDS/ETTELSE FOR STRÁLING.
ATTNENZIONE: RADIONS LASER INVISIDILE. NON GUARDARE DIRETTAMENTE NELLA SORGENTE DEL
LASER.
ACHTUNG: LASERLINSE NICHT BERÜHREN UNSICHTBARER LASERSTRAHL.
AVISO: A LENTE NUNCA DEVE SER TOCADA.
THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS FILLED
WITH LIQUIDS SHOULD BE PLACED ON THE APPARATUS.
THE MARKING AND RATING LABEL IS LOCATED AT BOTTOM ENCLOSURE OF THE APPARATUS.
UNDER THE INFLUENCE OF ELECTROSTATIC PHENOMENON, THE PRODUCT MAY MALFUNCTION AND
REQUIRE USER TO RESET THE POWER.
- KEEP MINIMUM DISTANCES (5CM) AROUND THE APPARATUS FOR SUFFICIENT
VENTILATION.
- NO NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES, SHOULD BE PLACED
ON THE APPARATUS.
- USE THIS APPARATUS ONLY IN MODERATE CLIMATES.

LOCATION OF CONTROLS
POWER SUPPLY
AC OPERATION (EXTERNAL AC-DC POWER ADAPTOR)
- THIS SET IS EQUIPPED WITH A "DC-JACK" CAPABLE OF ACCEPTING
AC-ADAPTORSWITH A RATING OF DC = 5V, 2A, ANDWITH A PLUG
WITH THE FOLLOWING POLARITIES AS SHOWN (CENTER POSITIVE) :
- PLEASE USE ONLY THE SUPPLIED AC-ADAPTOR TO OPERATE THE UNIT.
USE OF OTHER ADAPTORS MAY DAMAGE THE UNIT OR CAUSE IT TO
MALFUNCTION.
- PLUG THE TAIL END OF THE AC-ADAPTOR INTO THE DC-JACK (SOCKET)
ON THE REAR OF THE UNIT.
10. ON / OFF KEY
11. SKIP ( - ) / SEARCH ( - ) KEY
12. SKIP ( + ) / SEARCH ( + ) KEY
13. AL-SET/AL-MODE KEY
14. FUNCTION/CL-SET KEY
15. PLAY/ PAUSE/PAIR KEY
16. SNOOZE/DIMMER KEY
17. AUX INPUT SOCKET
18. DC JACK (DC 5V )
19. FM ANTENNA WIRE
1. SPEAKER
2. LED DISPLAY
3. BACK-UP BATTERY
COMPARTMENT (BOTTOM OF UNIT)
4. USB-1 SOCKET
(DC CHARGER: 5V/1000mA)
5. USB-2 SOCKET
(DC CHARGER: 5V/500mA)
6. VOLUME DOWN ( - ) KEY
7. VOLUME UP ( + ) KEY
8. MEMORY KEY
9. SLEEP KEY

- INSERT THE PLUG OF THE AC-ADAPTOR INTO A WALL OUTLETWITH AC-POWER.
- PRESS THE "ON/OFF" KEY TO SWITCH ON THE UNIT.
- THIS UNIT IS DESIGNED TO OPERATE WITHOUT EVER BEING TOTALLY POWERED
"OFF".
IT WILL EITHER BE "ON" OR IN "STANDBY MODE".
- IN STANDBY MODE, THE BACK-LIGHT OF THE DIGITAL DISPLAY WILL BE DIMMED
BUT THE DISPLAY WILL SHOW THE CURRENT TIME (CLOCK FUNCTION).
- ANYTIME DURING STANDBY MODE, YOU CAN SWITCH "ON" THE UNIT BY PRESSING
THE "ON/OFF" KEY.
- SAVE ENERGY BY SWITCHING THE SYSTEM TO "STANDBY" MODEWHEN NOT IN
USE.
BACK UP BATTERIES
- OPEN THE BATTERY DOOR AT THE BOTTOM OF UNIT.
- INSERT 2 PCS "AAA-CELL" (UM-4/LR03 TYPE) BATTERIES IN THE BATTERY
COMPARTMENT.
THESE 2 BATTERIES ARE FOR BACKUP OF THE CLOCK DURING BRIEF POWER
OUTAGES.
DIMMER FUNCTION
THIS SET HAS A DIMMER FUNCTION TO ADJUST THE BRIGHTNESS LEVEL
OF THE DISPLAY BACKLIGHT. SIMPLY ADJUST IT AS DESIRED BY PRESSING
THE SNOOZE/DIMMER KEY REPEATEDLY (HI-BRIGHTNESS/LOW-BRIGHTNESS/OFF).
THE DISPLAY BACKLIGHT WILL ALWAYS RETURN TO HI-BRIGHTNESS AS THE DEFAULT,
AFTER THE UNIT BEEN RESET.
DIGITAL CLOCK FUNCTION
- THE SET HAS A BUILT-IN DIGITAL CLOCK.
(THE DISPLAY WILL CONTINUOUSLY SHOW THE CURRENT TIME).
HOW TO SET CORRECT TIME:
1.
SWITCH UNIT TO "STAND-BY" MODE
2.
PRESS & HOLD FUNC./CL-SET KEY FOR 3 SECONDS DISPLAY SHOWS
HOUR OR HOUR (FLASHING)
3.
PRESS SKIP- / SEARCH- AND SKIP+ /SEARCH+ KEY TO SELECT 12-HOUR OR
24-HOUR CLOCK DISPLAY SYSTEM & PRESS FUNC./CL-SET KEY TO CONFIRM YOUR
SELECTION.
4.
PRESS SKIP- / SEARCH- AND SKIP+ /SEARCH+ KEY TO SET
THE CORRECT HOUR IN THE DISPLAY & PRESS FUNC./CL-SET KEY TO CONFIRM.
5.
PRESS SKIP- / SEARCH- AND SKIP+ /SEARCH+ KEY TO SET
THE CORRECT MINUTE IN THE DISPLAY & PRESS FUNC./CL-SET KEY TO CONFIRM.
6.
CORRECT TIME IS NOW SET & WILL BE SHOWN IN THE DISPLAY.
ALARM FUNCTION
- THIS SET IS EQUIPPED WITH 2 ALARM MODES: BUZZER AND RADIO.
BEFORE SETTING THE ALARM, BE SURE TO SET THE CLOCK (SEE "DIGITAL
CLOCK FUNCTION" IN THE PREVIOUS SECTION) .
PREPARE FOR THE ALARM SETTINGS
A. "ALARM" TIME SETTING
1. PRESS THE ON/OFF KEY TO PUT THE SET INTO "STANDBY" MODE
2. PRESS AND HOLD AL-SET/AL-MODE KEY UNTIL THE DISPLAY SHOWS:

3. PRESS SKIP- / SEARCH- AND SKIP+ /SEARCH+ KEY TO REACH THE HOUR
OF THE DESIRED WAKE UP TIME THEN PRESS AL-SET/AL-MODE KEY TO
CONFIRM. THE DISPLAY WILL NOW SHOW:
4. PRESS SKIP- / SEARCH- AND SKIP+ /SEARCH+ KEY TO REACH THE
MINUTES OF THE DESIREDWAKE UP TIME, THEN PRESS THE AL-SET/AL-MODE
KEY TO CONFIRM.
5. ADJUST THE VOLUME LEVEL AS DESIRED (FROM LEVEL 03-30) BY PRESSING
VOL. UP + OR VOL. DN - KEY. PRESS THE AL-SET/AL-MODE KEY
TO CONFIRM.
B. "ALARM" MODE SETTING
NOW SELECT THE SOURCE THAT YOU WISH THE UNIT TO PLAY AT THE "WAKE UP"
TIME AS BELOW:
FOR RADIO :
PRESS THE ON/OFF KEY TO SWITCH ON THE SET (DISPLAY BACKLIGHT WILL
BE "ON").
TUNE IN THE DESIRED STATION.
ONCE THE DESIRED SOURCE IS READY, PRESS THE ON/OFF KEY TO PUT THE
SET INTO STANDBY MODE AND THEN SHORT PRESS THE AL-SET /AL-MODE KEY
REPEATEDLY TO SELECT THE SOURCE AS DESIRED.
*REMARK: = BUZZER ALARM / FM = RADIO
1. THE ALARM TIME IS NOW FULLY PROGRAMMED AND THE ALARM SYMBOL WILL
APPEAR TO INDICATE THAT THE ALARM FUNCTION IS "ACTIVE".
(DISPLAY SHOWS AS FOLLOWS)
2. THE SET WILL NOW AUTOMATICALLY SWITCH "ON" AT THE WAKE-UP TIME YOU
HAVE CHOSEN, AS LONG AS THE ALARM FUNCTION IS "ACTIVE".
3. TO TURN OFF THE UNIT AFTER IT HAS AUTOMATICALLY SWITCHED ON,
SIMPLY PRESS THE ON/OFF KEY ONCE. THIS WILL SWITCH OFF THE SET
BUT WILL NOT CLEAR THE ALARM SETTINGS, AND THE SET WILL SWITCH ON
AGAIN AUTOMATICALLY ON THE NEXT DAY AT EXACTLY THE SAME PRESET TIME.
4. TO DEACTIVATE THE ALARM, PRESS & RELEASE THE AL-SET/ AL-MODE KEY. THE
ALARM SYMBOL "AL" WILL DISAPPEAR FROM THE DISPLAY.
5. TO ACTIVATE THE ALARM AGAIN, REPEAT THE PROCEDURE OF "ALARM TIME
SETTING" AS DESCRIBED.
SNOOZE FUNCTION
- WHENEVER THE ALARM COMES ON, IT CAN BE TEMPORARILY SUSPENDED
FOR A SHORT PERIOD OF 9 MINUTES, BY PRESSING THE “SNOOZE/ DIMMER” KEY
ONCE.
- THE ALARMWILL THEN AUTOMATICALLY COME ON AGAIN AFTER THE 9 MINUTE
“SNOOZE” PERIOD HAS ENDED.
- THE PROCEDURE CAN BE REPEATED FOR APPROXIMATELY 90 MINUTES FROM

ORIGINAL ALARM WAKE-UP TIME.
AUTOMATIC POWER OFF SLEEP FUNCTION
- THIS SET HAS A SPECIAL SLEEP TIMER FUNCTION WHICH CAN AUTOMATICALLY
SWITCH OFF THE UNIT. THIS IS USEFUL FOR SLEEPING WITH MUSIC AT NIGHT.
- AT ANY TIME WHILE THE UNIT IS OPERATING, PRESS & HOLD THE SLEEP KEY
UNTIL THE "SL" SYMBOL FLASHES, THEN PRESS THE SLEEP KEY REPEATEDLY
TO CHOOSE THE AUTOMATIC POWER OFF TIME.
(*OFF MEANS SLEEP TIMER IS DEACTIVATED)
BLUETOOTH® PAIRING
PREPARE THE UNIT:
- PRESS THE ON / STANDBY KEY TO TURN THE UNIT ON.
- PRESS THE FUNC. KEY UNTIL BT SYMBOL APPEARS.
- THE LED INDICATOR WILL FLASH TO INDICATE THE UNIT IS ON AND WAITING
FOR PARING.
- THE LED INDICATOR WILL REMAIN LIT WHEN PAIRED.
*NOTE ONLY ONE DEVICE CAN BE PAIRED AT ANY GIVEN TIME.
TO PREPARE YOUR PHONE OR OTHER BLUETOOTH® DEVICE:
- TURN ON THE BLUETOOTH® FUNCTION. THIS IS FOUND UNDER
GENERAL SETTINGS OR OPTIONS.
*PLEASE REFER TO YOUR DEVICE’S MANUAL FOR FURTHER BLUETOOTH®
DETAILS.
MAKE THE CONNECTION:
- GO TO YOUR DEVICE’S BLUETOOTH® SETTINGS
- ADD OR SEARCH FOR DEVICES
- IF ASKED FOR A PASS CODE, ENTER “0000”
DISABLING THE CONNECTION:
TO UNPAIR A BLUETOOTH® DEVICE THAT IS ALREADY PAIRED, PRESS AND HOLD
THE PAIR KEY FOR A FEW SECONDS.
VOLUME CONTROL:
INCREASE AND DECREASE VOLUME USING THE VOLUME UP AND VOLUME DOWN KEYS
ON THE UNIT OR USING THE VOLUME CONTROLS ON YOUR BLUETOOTH® ENABLED
DEVICE.
*NOTE: IF THERE IS NO PLAYBACK, ENSURE THAT NEITHER THE UNIT NOR
YOUR BLUETOOTH® DEVICE ARE SET TO ZERO VOLUME AND THE CORRECT DEVICE
FOR PLAYBACK IS PAIRED.
MUSIC PLAYBACK IN BLUETOOTH® MODE
- PRESS THE PLAY/PAUSE KEY TO START PLAYBACK.
- AT ANYTIME DURING PLAYBACK, PRESS THE PLAY/PAUSE KEY TO PAUSE
OPERATION. PRESS AGAIN TO RESUME OPERATION AT THE SAME TRACK &
POSITION.
- AT ANYTIME DURING PLAYBACK, “PRESS AND RELEASE” THE NEXT OR BACK KEY :
OR TO SKIP BACKWARDS OR FORWARDS BY ONE TRACK, AS DESIRED.
USING THE AUDIO LINE IN CONNECTION (AUX-INPUT)
- YOU CAN CONNECT THE AUDIO OUTPUT OF AN EXTERNAL DEVICE SUCH AS AN MP3
PLAYER TO THIS UNIT, TO LISTEN TO THE SOUND OF THAT DEVICE THROUGH
THE HIGH QUALITY AMPLIFIER OF THIS MUSIC SYSTEM.
- TO CONNECT THE EXTERNAL DEVICE PLEASE USE A STANDARD STEREO

HEADPHONE (3.5MM TO 3.5MM PLUGS) CABLE TO CONNECT THE "HEADPHONE-
OUT OR AUDIO LINE-OUT" OF THE DEVICE TO THE AUX-INPUT SOCKET OF THIS
UNIT.
- SELECT THE FUNCTION TO "AUX IN" BY PRESSING THE FUNCTION KEY ONCE.
- SWITCH ON THE EXTERNAL DEVICE (EG. MP3-PLAYER).
- START PLAYBACK OF THE EXTERNAL DEVICE AND ADJUST THE VOLUME CONTROL
OF THE UNIT TO THE DESIRED LEVEL.
- REMEMBER TO SWITCH OFF THE UNIT AND THE EXTERNAL DEVICE WHEN YOU
ARE FINISHED USING THE EXTERNAL DEVICE.
- SWITCH BACK TO BLUETOOTH® MODE ANYTIME BY PRESSING THE FUNCTION KEY
AGAIN.
ELECTRONIC VOLUME CONTROL
- THIS UNIT USES AN ELECTRONIC VOLUME CONTROL (PUSH BUTTON TYPE) .
- TO INCREASE OR DECREASE THE LOUDNESS OF UNIT, PRESS
THE VOLUME UP (VOL +) OR VOLUME DOWN (VOL -) KEYS RESPECTIVELY.
- RELEASE THE KEY WHEN VOLUME LEVEL IS AT THE DESIRED LOUDNESS.
- OCCASIONALLY, ESPECIALLY DURING LISTENING TO THE RADIO, YOU MAY NOTICE
A "CLICK-CLICK-CLICK" (REPEATING) SOUND WHEN YOU ARE INCREASING OR
DECREASING THE VOLUME. THIS IS A NORMAL CONDITION & THE SOUND WILL
DISAPPEAR WHEN YOU RELEASE THE VOLUME KEY (WHEN YOU REACH THE
DESIRED VOLUME LEVEL).
OPERATION OF RADIO
- PRESS THE "ON/ OFF" KEY ONCE TO SWITCH ON THE UNIT.
- PRESS THE FUNC./CL-SET KEY REPEATEDLY UNTIL THE DISPLAY SHOWS "FM".
- EXTEND AND ADJUST THE FM-WIRE ANTENNA TO OBTAIN THE BEST RECEPTION.
- USE THE PLAY/ PAUSE KEY TO SELECT THE DESIRED MODE (STEREO/ MONO).
IN SOME CASES, WHERE RECEPTION IS POOR, IT MAY BE ADVISABLE TO
SELECT “MONO” MODE, TO IMPROVE CLARITY OF THE RADIO SIGNAL.
MANUAL FREQUENCY ADJUSTMENT (SCAN MODE)
- PRESS (AND IMMEDIATELY RELEASE) THE SKIP- / SEARCH- AND
SKIP+ /SEARCH+ KEYS TO “SCAN” (MANUALLY ADJUST) THE RADIO
FREQUENCY “UP” OR “DOWN” BY 1-STEP AT A TIME.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY AT EACH
STEP’S POSITION.
- WHEN A DESIRED FREQUENCY OR STATION IS REACHED. IT CAN BE SAVED INTO
ONE OF THE “MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
AUTOMATIC FREQUENCY ADJUSTMENT (SEEK MODE)
- PRESS AND HOLD (FOR 2 SECONDS) THE SKIP- / SEARCH- AND
SKIP+ /SEARCH+ KEYS TO “SEEK” (AUTOMATICALLY ADJUST) THE RADIO
FREQUENCY “UP” OR “DOWN” TO THE NEXT AVAILABLE RADIO STATION.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY OF THE
NEXT STATION THAT IS FOUND.
- WHEN A DESIRED STATION IS REACHED. IT CAN BE SAVED INTO ONE OF THE
“MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
RADIO MEMORY (STATION PRESET MEMORY STORAGE)
- AT ANY TIME, THE CURRENTLY DISPLAYED STATION OR FREQUENCY CAN BE
STORED INTO ONE OF THE MEMORY POSITIONS.
- PRESS MEMORY KEY UNTIL "P01" FLASHES IN THE DISPLAY.
- PRESS SKIP- / SEARCH- AND SKIP+ /SEARCH+ KEYS TO SELECT DESIRED

MEMORY POSITION. (THERE ARE TOTAL 20 MEMORY POSITIONS).
- PRESS MEMORY KEY ONCE TO SAVE THE SELECTED STATION INTO THE
SELECTED MEMORY POSITION.
- TO RECALL ANY SAVED MEMORY, SIMPLY PRESS MEMORY KEY ONCE THEN
SELECT THE MEMORY POSITIONS BY PRESSING SKIP- / SEARCH- AND
SKIP+ /SEARCH+ KEYS. THE SAVED RADIO-BAND WILL BE RECALLED.
- TO CLEAR THE MEMORY OF ANY POSITION, SIMPLY SAVE A NEW STATION TO THE
SAME MEMORY POSITION.
2 X USB CHARGING FUNCTION
THIS UNIT IS DESIGNED TO ALLOW YOU TO CONVENIENTLY CHARGE UP TO 2 USB
DEVICES.
THE USB PORTS ALLOW FOR CHARGING NOT ONLY MOBILE PHONES BUT ALSO
HUNDREDS OF OTHER DEVICES, INCLUDING MOST BLUETOOTH® HEADSETS,
PORTABLE GAME CONSOLES AND MANY MORE. TO USE THE USB PORTS CHARGING
CAPABILITY:
CONNECT THE TAIL END OF THE USB CABLE (SUPPLIED WITH YOUR MOBILE PHONE
OR OTHER DEVICE) INTO ONE OF THE USB PORTS, AND CONNECT THE OTHER END
OF THE USB CABLE INTO YOUR MOBILE PHONE OR DEVICE.
THE UNIT WILL THEN AUTOMATICALLY BEGIN CHARGING THE RESPECTIVE DEVICE.
USB CHARGING PORT:
USB-1 SOCKET: 5V/1000MA (FAST CHARGING)
USB-2 SOCKET: 5V/500MA (NORMAL CHARGING)
SPECIFICATIONS
POWER SUPPLY : ............... DC 5V, 2A THOUGH BUILT-IN DC JACK
EXTERNAL AC-DC POWER ADAPTOR 110V-240V ~
50/60Hz
SPEAKER : ........................... SPEAKER 2" X 2
FREQUENCY : ..................... FM 87.5 - 108 MHz
Imported By R. Weatherdon & Co Pty Ltd
Sydney - Australia
www.weatherdon.com.au
Made in China
