LED SLIMLINE
FLOOD LIGHT
INSTALLATION
GUIDE
SLIMLINE FLOOD LIGHT NET-15-04-XX
KEY DATA
Important Warranty Information
The LED Slimline Flood Light has a 3 year
warranty. To claim, you must provide the product
part number and date of manufacture, which can
be found on the label attached to the luminaire
housing along with the original purchase invoice.
NET LED Ltd.
Evolution Business Park
Milton Road, Impington
Cambridge
CB24 9NG
sales@netled.co.uk
www.netled.co.uk
Technical Helpline: 01223 851505
Email: support@netled.co.uk
Safety Information
>All electrical work must be undertaken by
a qualied contractor to ensure compliance
with latest edition BS 7671 and IEE/IET wiring
regulations.
> Before installing an LED Slimline Flood Light or
doing any maintenance, ensure power supply is
turned off at the circuit breaker or fuse box.
> This product is designed for permanent
connection to xed wiring; the circuit should be
protected with the appropriate MCB or fuse.
Environment
> Please DO NOT dispose of electrical items or
packaging as unsorted waste. Use the recycling
facilities provided by your local authorities.
PRODUCT DIMENSIONS
ISO 9001:2008
FS 590684
ISO 9001:2004
EMS 590685
Floodlight A B C D E F
10W 120 213 125 100 40 135
30W 225 300 220 208 50 170
50W 285 367 275 245 55 177
80W 290 420 290 272 90 225
100W 290 420 290 272 90 225 Drawing No: NET-15-04-SL-IG_V2
www.netled.co.uk/downloads
SUPPLY/EARTH CLASS
Fig.1 Mains Input Termination
100-240V AC 50/60 Hz
Class I
Luminaire Mains Supply
Stirrup bracket for
quick and simple
installation
B
A
D
C
Distributed by
E
F
Light Source LED
Power 10W 30W 50W 80W 100W
Luminous Flux 650lm 2650lm 4350lm 7100lm 9000lm
Luminous Ecacy >100lm/W
Colour Temperature 6000K
Colour Rendering >75 CRI
Housing Material Aluminium
Diffuser Material Glass
IP Rating IP66
Manufacturer Leyond
All units are in mm
