NetComm V90
IP Telephone with Ethernet Over Power Support
Features
NetComm’s V90 is the ideal device to take advantage of the benefits of VoIP
Telephony services. Adding to the V90’s elegant design are a host of features
including Full Duplex Speaker Phone with echo cancellation, speed dials, phone
book, call transfer, mute and a unique volume control for both the handset
speaker/microphone.
Standards Based
The V90 is fully compliant with IETF SIP 2.0 specification which ensures that it
will run smoothly and error free.
POE Support
Power-over-Ethernet (PoE) or “Active Ethernet” lets you run a single CAT5 Ethernet
cable to carry both power and data to devices on the LAN. This eliminates the need
to run separate 240 Volt power to devices on a wired LAN.
It also allows greater flexibility in locating IP Phones and significantly decreases
installation costs. With Power over Ethernet, you can power network devices up to
328 feet (100 meters) away, using standard CAT5 Ethernet cable.
As standard, the V90 is supplied as both a POE and DC powered terminal (with DC
powerpack available as an option). With full 802.3af compliance, the V90 can be
powered over Ethernet by any standards based POE switch or power injector.
KEY FEATURES
Power over Ethernet (802.3af) Support
Setup Wizard for different types of network environment and IP phone accounts
Auto Configuration Support via TFTP and HTTP (Plug-n-Play operation)
Smart Firmware Management Support via TFTP and HTTP
Primary and Backup SIP server support for primary proxy server failover and network redundancy (single server mode only)
Programmable QoS Marking (both 802.1q VLAN and ToS/DiffServ)
Compatibility in multi- vendor open architecture VoIP networks
Retrieving time via NTP Servers and SIP message
NAT/ Firewall Traversal Support with Border Session Controller or Stun Server
Support for 4 VoIP Accounts/SIP Proxies

NETCOMM LIMITED ABN 85 002 490 486 PO Box 1200, Lane Cove NSW 2066 Australia
P: 02 9424 2070 F: 02 9424 2010 E: [email protected] W: www.netcomm.com.au
Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are
subject to change without notice. Images shown may vary slightly from the actual product.
NetComm V90
IP Telephone with Ethernet Over Power Support
TECHNICAL SPECIFICATIONS
Your NetComm dealer:
Standards Supported
•SIP V2.0 Standard (RFC 3261)
•SDP (RFC 2327)
•Digest authentication and MD5 encryption (SIP)
•ITU-T G.711 Alaw/Ulaw, G.729A, G.729AB,
G.723.1
•RTP (Real Time Transmission Protocol) RFC1889
•RTCP (Real Time Transport Control Protocol)
RFC 3550
•Proprietary Firewall-Pass-Through Technology
•Simple Traversal of UDP over NAT (STUN)
•Web-based Management
•PPP over Ethernet (PPPoE)
•PPP Authentication Protocol (PAP)
•Internet Control Message Protocol (ICMP)
•TFTP Client
•Hyper Text Transfer Protocol (HTTP)
•Dynamic Host Configuration Protocol (DHCP)
•Domain Name System (DNS)
•Out-band DTMF Relay: RFC 2833 and SIP Info
•SIP proxy address in DHCP (RFC 3361)
Software Features
•Built-in HTTP, Phone Menu for accessing internal
parameters
•PPPoE Client
•NAT Broadband Router functions
•DHCP Client
•DHCP Server
•Firmware On-line upgrade
•Phone Book
•Memory Dial
•Speed Dial
•Caller ID
•Multiple Language Support
Hardware Interface
•Ethernet PC & Network Port (2 x RJ-45,
10/100BaseT)
•DC Jack
• Headset Port
Centralised configuration and management
The V90 terminal can download a configuration file from an HTTP server that will prompt it to upgrade its
firmware file. A DHCP server is used to assign an IP address to the V90 phone and inform the V90 of the HTTP
address of the configuration file.
Programmable Function Keys
The V90 features 5 user programmable keys that can be used for speed dialling or any number of common
everyday tasks.
Quality of Service
The built in QoS of the V90 guarantees that call quality is maintained and monitored to give you crisp clear
calls with no drop out or stuttering.
Key Features
SIP 2.0 standardization deployed throughout
Advanced audio processing – jitter buffer with packet delay and packet loss concealment
Voice packetization & flexible voice compression
Programmable voice packet payload size
Centralised control of codec negotiation
In-band and Out-band DTMF transport
G.168 Echo Cancellation
Two Ethernet ports supporting router and bridge mode
Call Redial, Flash, Mute
Caller ID / Call Waiting
Call Hold/Forward/Conference/Transfer (attended/unattended call transfer)
Phone Book Memory Dialing
Speed Memory Dialing
Hands Free Dialing
Hotline Dialing
Call history for incoming, outgoing and missed calls
Programmable Generic Function Key Definitions (automatic adding prefixes/customized LCD menu)
Soft Login/Logout key for SIP registration
128x64 dot matrix LCD with back light
Full Duplex Speakerphone
Auto Provisioning Support
Firmware upgrading, loading configuration, phone status reports via Centralized Management tool
Local Music on Hold
