NetComm VELOCITY NP805N User manual

NETCOMM VELOCITY™ SERIES
Gigabit Wireless Router
NP805N
USER GUIDE

NP805N –Gigabit Wireless Router
2
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
Copyright
Copyright©2011 NetComm Wireless Limited. All rights reserved.
The information contained herein is proprietary to NetComm Wireless Limited. No part of this document may be translated,
transcribed, reproduced, in any form, or by any means without prior written consent of NetComm Wireless Limited.
Please note: This document is subject to change without notice.
Save Our Environment
When this equipment has reached the end of its useful life, it must be taken to a recycling centre and processed separately from
domestic waste.
The cardboard box, the plastic contained in the packaging, and the parts that make up this device can be recycled in accordance
with regionally established regulations. Never dispose of this electronic equipment along with your household waste. You may be
subject to penalties or sanctions under the law. Instead, ask for disposal instructions from your municipal government.
Please be responsible and protect our environment.
This manual covers the following products:
NetComm NP805N
DOCUMENT VERSION
DATE
1.0 - Initial document release
03/12/2011

www.netcomm.com.au
3
NetComm NP805N –Gigabit Wireless Router
YMLO-805N
Table of Contents
Overview ........................................................................................................................................................................................4
Introduction...................................................................................................................................................................................................4
Target Users..................................................................................................................................................................................................4
Prerequisites..................................................................................................................................................................................................4
Notation ........................................................................................................................................................................................................4
Product Introduction .....................................................................................................................................................................5
Product Overview ..........................................................................................................................................................................................5
Package Contents .........................................................................................................................................................................................5
Product Features...........................................................................................................................................................................................5
Physical Dimensions and Indicators............................................................................................................................................6
LED Indicators...............................................................................................................................................................................................6
Physical Dimensions ......................................................................................................................................................................................7
NP805N Default Settings ...............................................................................................................................................................................7
Integrated Interfaces .....................................................................................................................................................................8
Safety and Product Care ...............................................................................................................................................................9
Transport and Handling.................................................................................................................................................................9
Installation and Configuration of the NP805N ............................................................................................................................10
Placement of your NP805N.......................................................................................................................................................................... 10
Hardware installation....................................................................................................................................................................................11
Connecting via a cable................................................................................................................................................................................. 11
Connecting wirelessly ..................................................................................................................................................................................11
Web Based Configuration Interface............................................................................................................................................12
First-time Setup Wizard................................................................................................................................................................................12
Advanced Configuration...............................................................................................................................................................................18
Status .................................................................................................................................................................................................19
Network Setup ....................................................................................................................................................................................20
Forwarding Rules.................................................................................................................................................................................30
Security Settings..................................................................................................................................................................................32
Advanced Settings...............................................................................................................................................................................39
NAS Settings.......................................................................................................................................................................................50
Toolbox............................................................................................................................................................................................... 55
Additional Product Information ...................................................................................................................................................57
Establishing a wireless connection................................................................................................................................................................57
Troubleshooting...........................................................................................................................................................................................58
Technical Data .............................................................................................................................................................................59
Electrical Specifications................................................................................................................................................................................ 59
Environmental Specifications / Tolerances .................................................................................................................................................... 59
Legal & Regulatory Information...................................................................................................................................................60
Contact.........................................................................................................................................................................................62

NP805N –Gigabit Wireless Router
4
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
Overview
Introduction
This manual provides information related to the installation, operation, and utilisation of the NP805N.
Target Users
The individual reading this manual is presumed to have a basic understanding of telecommunications terminology and concepts.
Prerequisites
Before continuing with the installation of your NP805N, please confirm that you comply with the minimum system requirements
below.
An activated ADSL, activated 3G, or configured WAN connection.
Computer with Windows, Macintosh, or Linux-based operating systems with a working Ethernet adapter with TCP/IP
Protocol installed.
A Web Browser such as Internet Explorer, Netscape Navigator, Mozilla Firefox, Opera, Safari etc.
Wireless Computer System Requirements:
oComputer with a working 802.11b, 802.11g or 802.11n wireless adapter.
Notation
The following symbols are utilised in this user manual:
-
The following note requires attention
-
The following note provides a warning
-
The following note provides relevant information

www.netcomm.com.au
5
NetComm NP805N –Gigabit Wireless Router
YMLO-805N
Product Introduction
Product Overview
Supports Wireless N standard with data speeds up to 300Mbps
One WAN port for alternate wired Internet connection (DSL/Cable/Satellite via Ethernet)
Four LAN ports to connect wired devices like PCs or gaming consoles
Easy Wi-Fi Protected Setup (WPS) by the single touch of a button to establish a secure wireless connection
Full Wireless security - WEP, WPA, WPA2
Browser based interface for configuration and management: OS independent and easy to use
File server (FTP / NAS)
Download assistant
Web HDD function
Speeds are dependent on network coverage. See your 3G provider coverage maps for more details. The total number of Wi-Fi users can also affect data speeds.
Maximum wireless signal rate and coverage values are derived from IEEE Standard 802.11g and 802.11n specifications. Actual wireless speed and coverage are
dependent on network and environmental conditions included but not limited to volume of network traffic, building materials and construction/layout.
Package Contents
The NP805N package consists of:
Gigabit Wireless Router - NP805N
Quick Start Guide
Power Supply Unit
Ethernet Cable (RJ-45)
Wireless Security Card
Warranty Card
If any of these items are missing or damaged, please contact NetComm Support immediately by visiting the NetComm Support
website at: http://www.netcomm.com.au/contact-us/technical-support
Product Features
The NetComm NP805N integrates a Wireless LAN and gigabit WAN into one unit. Connection to the Internet is achieved through a
connection to the NP805N’s WAN port.
Users are able to share a single Internet connection via both a wired and wireless connection to the NP805N. With a built in and
external antenna providing a 2 transmit, 2 receive (2T2R) 802.11n wireless access point, this router provides wireless speeds of up
to 300Mbps.
On top of this, the NP805N has four LAN ports for wired connections to multiple devices. The NP805N allows the user to simply
connect an Ethernet based WAN device for Internet connectivity.
The NP805N also includes advanced security features such as VPN pass-through, a full complement of wireless security options
and a built in firewall.

NP805N –Gigabit Wireless Router
6
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
Physical Dimensions and
Indicators
LED Indicators
The NP805N has been designed to be placed on a desktop. All of the cables exit from the rear for better organization. The display is
visible on the front of the NP805N to provide you with information about network activity and the device status. See below for an
explanation of each of the indicator lights.
LED
INDICATOR
ICON
COLOUR
ACTIVITY
DEFINITION
WIFI
Green
Off
The WiFi function is disabled.
On
The WiFi function is enabled.
Flashing
The NP805N is waiting for a WPS PBC connection.
USB
Green
Off
No USB device is connected.
On
A USB device has been connected.
Flashing
The USB device is being accessed by a connected client.
POWER
Green
Off
The NP805N is powered off.
On
The NP805N is powered on and operating normally.
Flashing
The NP805N is starting up.
WWW
Green
Off
No Internet configuration present.
On
The NP805N is connected via an Ethernet WAN based service.
Flashing
Data is being sent or received via the Ethernet WAN port.
LAN 1 - 4
Green
Off
No device is connected to the Ethernet LAN port.
On
A device is connected to the Ethernet LAN port.
Flashing
Data is being sent or received via the Ethernet LAN port.

www.netcomm.com.au
7
NetComm NP805N –Gigabit Wireless Router
YMLO-805N
Physical Dimensions
The following page lists the physical dimensions of the NP805N.
NP805N
Length
215 mm
Width
145 mm
Height
37 mm
Weight
403 grams
NP805N Default Settings
The following tables list the default settings for the NP805N.
LAN (MANAGEMENT)
Static IP Address:
192.168.20.1
Subnet Mask:
255.255.255.0
Default Gateway:
192.168.20.1
WIRELESS (WI-FI)
SSID:
(Refer to the included Wireless Security Card)
Security:
WPA-SPK/WPA2-PSK (mixed mode)
Security Key:
(Refer to the included Wireless Security Card)
NP805N WEB INTERFACE ACCESS
Username:
admin
Password:
admin

NP805N –Gigabit Wireless Router
8
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
Integrated Interfaces
The following integrated interfaces are available on the NP805N:
REAR PANEL
INTERFACE
FUNCTION
WIFI Antenna
Connect one of the supplied WIFI antennas here; It should be screwed on in a clockwise direction.
LAN 1-4
Connect Ethernet based devices here
WAN
Connect an Ethernet based WAN device here
Power Jack
Connect the power supply here
Power button
Power the NP805N on or off
WIFI Antenna
Connect one of the supplied WIFI antennas here; It should be screwed on in a clockwise direction.
FRONT PANEL
INTERFACE
FUNCTION
USB
Connect a USB storage based device here to provide access to connected clients.
RESET
Press and hold the reset button for 5 seconds to restore the NP805N to Factory Defaults.
WPS / USB OFF
-Press for WPS mode
-Hold for 5 seconds to disable the USB functionality.

www.netcomm.com.au
9
NetComm NP805N –Gigabit Wireless Router
YMLO-805N
Safety and Product Care
With reference to unpacking, installation, use and maintenance of your electronic device, the following basic guidelines are
recommended:
Do not use or install this product near water to avoid fire or shock hazard. For example, near a bathtub, kitchen sink,
laundry tub, or near a swimming pool. Also, do not expose the equipment to rain or damp areas (e.g. a wet basement).
Do not connect the power supply cord on elevated surfaces. Allow it to lie freely. There should be no obstructions in its
path and no heavy items should be placed on the cord. In addition, do not walk on, step on or mistreat the cord.
To safeguard the equipment against overheating, make sure that all openings in the unit that offer exposure to air are
unobstructed.
WARNING
Disconnect the power line from the device before servicing.
Transport and Handling
When transporting the NP805N, it is recommended to return the product in the original packaging. This ensures the product will not
be damaged.
In the event the product needs to be returned, ensure it is securely packaged with appropriate padding to prevent
damage during courier transport.

NP805N –Gigabit Wireless Router
10
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
Installation and Configuration of
the NP805N
Placement of your NP805N
The wireless connection between your NP805N and your Wi-Fi devices will be stronger the closer your connected devices are to
your NP805N. Your wireless connection and performance will degrade as the distance between your NP805N and connected
devices increases. This may or may not be directly noticeable, and is greatly affected by the individual installation environment.
If you have concerns about your network’s performance that might be related to range or obstruction factors, try moving the
computer to a position between three to five meters from the NP805N in order to see if distance is the problem.
Please note: While some of the items listed below can affect network performance, they will not prohibit your wireless
network from functioning; if you are concerned that your network is not operating at its maximum effectiveness, this
checklist may help.
If you experience difficulties connecting wirelessly between your Wi-Fi Devices and your NP805N, please try the following steps:
In multi-storey homes, place the NP805N on a floor that is as close to the centre of the home as possible. This may
mean placing the NP805N on an upper floor.
Try not to place the NP805N near a cordless telephone that operates at the same radio frequency as the NP805N
(2.4GHz).
Avoid obstacles and interference
Avoid placing your NP805N near devices that may emit radio “noise,” such as microwave ovens. Dense objects that can inhibit
wireless communication include:
Refrigerators
Washers and/or dryers
Metal cabinets
Large aquariums
Metallic-based, UV-tinted windows
If your wireless signal seems weak in some spots, make sure that objects such as those listed above are not blocking
the signal’s path (between your devices and the NP805N).
Cordless Phones
If the performance of your wireless network is impaired after considering the above issues, and you have a cordless phone:
Try moving cordless phones away from your NP805N and your wireless-enabled computers.
Unplug and remove the battery from any cordless phone that operates on the 2.4GHz band (check manufacturer’s
information). If this fixes the problem, your phone may be interfering with the NP805N.
If your phone supports channel selection, change the channel on the phone to the farthest channel from your wireless
network. For example, change the phone to channel 1 and move your NP805N to channel 11. See your phone’s user
manual for detailed instructions.
If necessary, consider switching to a 900MHz or 5GHz cordless phone.
Choose the “Quietest” Channel for your Wireless Network
In locations where homes or offices are close together, such as apartment buildings or office complexes, there may be wireless
networks nearby that can conflict with your wireless network. Use the Site Survey capabilities found in the Wireless Utility of your
wireless adapter to locate any other wireless networks that are available (see your wireless adapter’s user manual), and switch your
Router and computers to a channel as far away from other networks as possible.
Experiment with more than one of the available channels, in order to find the clearest connection and avoid interference from
neighbouring cordless phones or other wireless devices.

www.netcomm.com.au
11
NetComm NP805N –Gigabit Wireless Router
YMLO-805N
Hardware installation
1. Connect the power adapter to the Power socket on the back of the NP805N. Plug the power adapter into the wall socket
and switch on the power.
2. Wait approximately 60 seconds for the NP805N to power up.
Connecting via a cable
1. Connect the yellow Ethernet cable provided to one of the ports marked ‘LAN’at the back of the NP805N.
2. Connect the other end of the yellow Ethernet cable to your computer.
3. Wait approximately 30 seconds for the connection to establish.
4. Open your Web browser, and enter http://192.168.20.1 into the address bar and press enter.
5. Follow the steps to set up your NP805N.
Connecting wirelessly
1. Ensure Wi-Fi is enabled on your device (computer/laptop/Smartphone).
2. Scan for wireless networks in your area and connect to the network name that matches the Wireless network name
configured on the NP805N.
Please note: Refer to the included Wireless Security Card for the default SSID of your NP805N
3. When prompted for your wireless security settings, enter the Wireless security key configured on the NP805N.
Please note: Refer to the included Wireless Security Card for the default wireless security key of your NP805N
4. Wait approximately 30 seconds for the connection to establish.
5. Open your Web browser, and enter http://192.168.20.1 into the address bar and press enter.
6. Follow the steps to set up your NP805N.

NP805N –Gigabit Wireless Router
12
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
Web Based Configuration
Interface
First-time Setup Wizard
Please follow the steps below to configure your NP805N Wireless router via the web based configuration wizard.
Open your web browser (e.g. Internet Explorer/Firefox/Safari) and type http://192.168.20.1/into the address bar at the top of the
window.
At the login screen, type "admin" (without quotes) in the username and password field. Then click on Login.
Please note: admin is the default username and password for the unit.
1. Click on “Yes, let’s get started with the wizard”.
This page enables you to enter the information needed to setup your Internet connection.
2. From the WAN type pull down menu, select the type of Internet connection you would like to utilise. You can select from:
oDynamic IP Address
oStatic IP Address
oPPP over Ethernet
oPPTP
oL2TP

www.netcomm.com.au
13
NetComm NP805N –Gigabit Wireless Router
YMLO-805N
Dynamic IP Address
1. Enter the Host Name (if required).
2. Enter the ISP registered MAC Address (if required).
3. Click “Next”.
Static IP Address
1. Enter the Static IP Address for your connection.
2. Enter the Subnet Mask for your connection.
3. Enter the Static Gateway for your connection.
4. Enter the Static Primary DNS for your connection.
5. Enter the Static Secondary DNS for your connection (if available).
6. Click “Next”.

NP805N –Gigabit Wireless Router
14
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
PPP over Ethernet
1. Enter the Username required for your PPPoE connection.
2. Enter the Password required for your PPPoE connection.
3. Click “Next”.
PPTP
1. Select to use either a static or dynamically assigned IP address for your connection. When selecting to utilise a static IP
address, you will also need to enter the PPTP IP Address, PPTP Subnet Mask and PPTP Default gateway in use for the
connection (Refer to your PPTP administrator for more information).
2. Enter the Username required for your PPTP connection.
3. Enter the Password required for your PPTP connection.
4. Click “Next”.

www.netcomm.com.au
15
NetComm NP805N –Gigabit Wireless Router
YMLO-805N
L2TP
1. Select to use either a static or dynamically assigned IP address for your connection. When selecting to utilise a static IP
address, you will also need to enter the L2TP IP Address, L2TP Subnet Mask and L2TP Default gateway in use for the
connection (Refer to your L2TP administrator for more information).
2. Enter the Username required for your L2TP connection.
3. Enter the Password required for your L2TP connection.
4. Click “Next”.

NP805N –Gigabit Wireless Router
16
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
3. If you want to change the Wireless network settings, you can do so on this page. You can enable or disable the Wireless
network, select whether to broadcast your SSID or not and change the Wireless network name. Change the settings as
needed and click “Next”.
(If you wish to use the default settings, click “Next”)
4. If you want to change the Wireless network security settings, you can do so on this page. You can change the type of
Wireless network security in use or the Wireless Security key. Change the settings as needed and click “Next”.
(If you wish to use the default settings, click “Next”)

www.netcomm.com.au
17
NetComm NP805N –Gigabit Wireless Router
YMLO-805N
5. If you want to change the system username or password, enter the new username to use or the current system password
into the "Old Password" field and then enter the new password into both the "Desired Password" and "Retype Password"
fields and then click “Next”.
(If you do not wish to change the password, leave the fields blank and click “Next”)
6. Confirm the setup information and click “Finish” if everything is correct. You can also click “Back” to go back and change
any of the previously configured settings.
7. The router will then apply your configured settings and restart.
8. Once completed, your router is configured and should be connected to the Internet.

NP805N –Gigabit Wireless Router
18
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
Advanced Configuration
To access the advanced configuration options of your NP805N, you need to login to the web configuration and change to
Advanced view.
To do this, open your web browser (e.g. Internet Explorer/Firefox/Safari), type http://192.168.20.1/ into the address bar at the top
of the window and press the enter key.
At the login screen, type "admin" (without quotes) in the Username and Password field. Then click on Login.
Please note: admin is the default username and password for the unit.
Click on any of the top menu items to access the respective function configuration pages.

www.netcomm.com.au
19
NetComm NP805N –Gigabit Wireless Router
YMLO-805N
Status
ITEM
DESCRIPTION
IP Address
The current WAN IP address of the router
Subnet Mask
The current subnet mask in use by the router
Gateway
The gateway in use by the router to access the internet
Domain Name Server
The Domain name server converts
Connection Time
The time the current connection to the internet has been active
WAN Link-Local Address
The current WAN IPv6 address
Global IPv6 Address
The current IPv6 subnet mask in use
LAN IPv6 Link-Local Address
The current LAN IPv6 address of the NP805N
Link Status
The current IPv6 WAN connection status
Wireless mode
The current status of the wireless network (enabled or disabled)
SSID
The current wireless network name is use by the router
Channel
The current wireless channel in use on your wireless network
Security
The currently selected wireless security in use on your wireless network
Octets
The number of data packets which have passed into and out of the router
Unicast Packets
The number of unicast packets which have passed into and out of the router
Multicast packets
The number of multicast packets which have passed into and out of the router.

NP805N –Gigabit Wireless Router
20
NetComm NP805N - Gigabit Wireless Router
YMLO-805N
www.netcomm.com.au
Network Setup
Network Setup
This page allows you to change the LAN (Local Area Network) and WAN (Wide Area Network) connection settings as well as the
automatic failover function on the NP805N.
OPTION
DEFINITION
LAN IP Address
The local IP address of the NP805N.
(The computers on your network must use this IP address as their Default Gateway. You can change it if necessary.)
Subnet Mask
Enter the subnet mask for use on the local network. This would usually be set to 255.255.255.0.
WAN Interface Types
Ethernet WAN (xDSL/Cable/Satellite)
WAN Type: You can select from the following WAN types:-
Dynamic IP
Static IP
PPP over Ethernet
PPTP
L2TP
Dynamic IP
OPTION
DEFINITION
Host Name
Set the hostname for your connection
(Optional - Refer to your ISP for more information).
ISP Registered MAC Address
You can change the WAN port MAC address if needed to clone your 3G modem
(Optional - Refer to your ISP for more information).
NAT
This option enables or disables "Network Address Translation" for this connection type.
Multicast
Enable multicast support for this connection. Select the appropriate IGMP protocol version from the pull down menu.
IGMP Snooping
This option enables or disables "IGMP" for this connection type.
