ProSafe 10 Gigabit Ethernet SFP+ Fibre Port Adapter AX743
Install Your Adapter
The ProSafe 10 Gigabit Ethernet SFP+ Fibre Port Adapter AX743 enables 10 Gigabit
Ethernet Small Form-Factor Pluggable (SFP+) optics modules, such as the AXM761 and
AXM762, to be utilized with NETGEAR’s GSM73xxS/GSM73xxSv2 series managed
switches. The AX743 plugs into any of the available switch module bays and adapts the
ports for use with SFP+ modules.
The I/O module bays may be located on the front or the rear panel of the depending on the
switch model. Due to configuration requirements you may have to reboot the switch after
installation of the AX743.
Installing an AX743 Adapter
Insert the adapter into one of the available module bays, pressing firmly to seat the module.
Once the adapter is seated, tighten the two set screws to hold the adapter in place. Please
refer to the system switch user manual for a detailed description of the LED function.
Removing an AX743 Adapter
To remove the adapter:
1. Loosen the two set screws on either side of the adapter front panel.
2. Once loose, remove the adapter by holding the screw posts and pulling evenly on the
adapter and sliding it out of the module bay.
Note: The AX743 adapter is hot-swappable. The switch may remain powered-on when
installing or removing the adapter.
AX743
Specifications
Link Active LED
The LED on the faceplate will be continous green when the optical transceiver is installed
and the link is up. When there is active traffic across the fiber cable, the LED will blink to
reflect the activity.
Specifications
Standard SFF-8431
Dimensions (HxWxD) 1.20” x 2.92” x 6.18”
(30.5mm x 74.1mm x 157 mm)
Weight 0.298 lb (0.135kg)
Operating Temperature 32 to 122 ºF (0 to 50 ºC)
Storage Temperature 14 to 158 ºF (0 to 70 ºC)
Operative relative humidity 10 to 90% and noncondensing
Max. Power Consumption 2.74w with Fiber
MTBF 182 years (at 25ºC); 46 years (at
55ºC)
