NETGEAR EX6100 User manual

Quick Start
AC750 WiFi Range Extender
Model EX6100

2
Getting Started
The NETGEAR WiFi Range Extender increases the distance of a WiFi
network by boosting the existing WiFi signal and enhancing the overall
signal quality over long distances. An extender repeats the signals from an
existing WiFi router or access point.
Existing WiFi
Sometimes your router
does not provide the WiFi
coverage you need.
WiFi Range
Extender
Boosts the range of your
existing WiFi and creates
a stronger signal in
hard-to-reach areas.

3
Meet Your Extender
Before you install your extender, familiarize yourself with its LEDs,
buttons, and port.
Front and Side Panel
Access Point/
Extender
switch
Ethernet port
Power On/O
button
Factory
Reset
button
Power LED
Client Link LED
WPS LED
Router Link LED
WPS button

4
LED Descriptions
Router Link LED This LED indicates the connection between the extender and
a router or access point.
Solid green. Best connection.
Solid amber. Good connection.
Solid red. Poor connection.
O. No connection.
Client Link LED This LED indicates the connection between the extender and
a computer or WiFi device.
Solid green. Best connection.
Solid amber. Good connection.
Solid red. Poor connection.
O. No connection.
Power LED Solid amber. The extender is booting.
Solid green. The extender is powered on.
O. The extender is powered o.
WPS LED Solid green. WiFi security is enabled (WPA or WPA2).
Blinking green. A WPS connection is being established.
O. WiFi security is not enabled.

5
Use the Extender in Extender Mode
The extender repeats signals from an existing WiFi router or access point.
Place the extender, apply power, and connect it to your WiFi network.
Place the Extender and Apply Power
1. Set the Access Point/Extender switch to the Extender
position.
2. Place your extender in the same room as your WiFi router.
Proximity to the WiFi router is required only during initial setup.
3. Plug the extender into an electrical outlet.
Wait for the Power LED to light green.
4. If the Power LED does not light, press the Power On/Off button on
the extender.
Connect to an Existing WiFi Network
To extend the range of your WiFi network, you must connect the extender
to your existing WiFi network. You can do this in one of two ways:
• Connect with WPS. For more information, see Connect with WPS on
page 6.
• Connect with web browser setup. For more information, see
Connect with Web Browser Setup on page 8.

6
Connect With WPS
Wi-Fi Protected Setup (WPS) lets you join a secure WiFi network without
typing the network name and password.
Note: WPS does not support WEP network security. If you are using WEP
security, follow the instructions in Connect with Web Browser Setup on
page 8.
1. Press the WPS button on the side panel of the extender.
The WPS LED blinks.
2. Within two minutes, press the WPS button on your router or access
point.
When the extender connects to your existing WiFi network, the WPS
LED on the extender lights solid green and the Router Link LED
lights. If the Router Link LED does not light, try again. If it still
does not light, see Connect with Web Browser Setup on page 8.
3. If your WiFi router supports the 5 GHz band, repeats Steps 1and 2 to
connect the extender to the 5 GHz band.
4. Unplug the extender and move it to a new location that is about
halfway between your router and the area with a poor router WiFi
signal.
The location that you choose must be within the range of your
existing WiFi router network.

7
5. Plug the extender into an electrical outlet and wait for the Power LED
to light green.
6. Use the Router Link LED to help you choose a spot where the
extender-to-router connection is optimal.
7. If the Router Link LED does not light amber or green, plug the
extender into an outlet closer to the router and try again.
Keep moving the extender to outlets closer to the router until this
LED lights amber or green.
8. On your computer or WiFi device, find and connect to the new
extended WiFi network.
The extender creates a new extended WiFi network. The extender’s
new WiFi network names are based on your existing WiFi network
name, with _EXT at the end of the name.
For example:
• Existing WiFi network name. MyNetworkName
• New extended WiFi network names. MyNetworkName_2GEXT
and MyNetworkName_5GEXT.
DO DON’T

8
Use the same WiFi password that you use for your WiFi router.
9. Test the extended WiFi range by moving your computer or WiFi device
to the area with a poor router WiFi signal:
a. Leave your computer or WiFi device in the area with a poor router
WiFi signal and return to the extender.
b. Check the Client Link LED on the extender:
• If the Client Link LED is solid green or amber, your extended
WiFi network reaches the area with a poor router WiFi signal
and your network setup is complete.
• If the Client Link LED is red, your extended WiFi network
does not reach the area with a poor router WiFi signal.
You must move the computer or WiFi device closer to the
extender until the Client Link LED turns solid green or amber.
Connect With Web Browser Setup
1. Use a WiFi network manager on a computer or mobile device to find
and connect to the extender WiFi network
EX6100_NETGEAR_2GEXT.
Aer the connection with the computer or WiFi device is established,
the Client Link LED lights.
2. Launch a web browser.
3. Enter www.mywifiext.net in the address field of the browser.

9
The New Extender Setup page displays.
4. Click the NEW EXTENDER SETUP button.
The Create Account page displays.
5. Complete the fields on the page to set up your login credentials and
click the NEXT button.
6. Verify that the Access Point/Extender switch is set to Extender
and click the Continue button.
7. Select a WiFi network to extend and click the NEXT button.
If you do not want to extend both WiFi bands, clear the 2.4 GH WiFi
Networks or 5 GHz WiFi Networks check box.
8. In the Password (Network Key) field, type the existing WiFi
network passphrase (also called the passphrase or security key) and
click the NEXT button.
9. Set the network name (SSID) and password for your extender and
click the NEXT button.
Wait for the page to display a list of available extended WiFi networks,
which might take up to one minute.
10. Use a WiFi network manager on the computer or WiFi device to
connect to the new extended WiFi network.
You must connect your computer or WiFi device before you click the
Continue button.

10
11. Click the Continue button.
A message displays confirming that the extender is connected and
ready.
12. Click the Next button.
The registration page displays.
13. Complete the registration fields and click the Finish button to
complete the setup.
If you do not want to register your extender, click the Skip
Registration link. Note that you must register your extender before
you can use NETGEAR telephone support.
The Status page displays.
14. Unplug the extender and move it to a new location that is about
halfway between your router and the area with a poor router WiFi
signal.
The location that you choose must be within the range of your
existing WiFi router network.
DO DON’T

11
15. Plug the extender into an electrical outlet and wait for the Power LED
to light green.
16. Use the Router Link LED to help you choose a spot where the
extender-to-router connection is optimal.
17. If the Router Link LED doesn’t light amber or green, plug the extender
into an outlet closer to the router and try again.
Keep moving the extender to outlets closer to the router until the
Router Link LED lights amber or green.
18. Reconnect your computer or WiFi device to the new extended WiFi
network.
19. Test the extended WiFi range by moving your computer or WiFi device
to the area with a poor router WiFi signal:
a. Leave your computer or WiFi device in the area with a poor router
WiFi signal and return to the extender.
b. Check the Client Link LED on the extender:
• If the Client Link LED is solid green or amber, your extended
WiFi network reaches the area with a poor router WiFi signal
and your network setup is complete.
• If the Client Link LED is red, your extended WiFi network
does not reach the area with a poor router WiFi signal.
You must move the computer or WiFi device closer to the
extender until the Client Link LED turns solid green or amber.

12
Connect Ethernet-Enabled Devices
Aer the extender is connected to your existing WiFi network, you can
connect a device to the extender using an Ethernet cable. Then that device
can access your existing network through the extender-to-router WiFi
connection.
Blu-ray player
Extender
WiFi router

13
Use the Extender in Access Point Mode
You can use the extender as a WiFi access point, which creates a new WiFi
hotspot by using a wired Ethernet connection.
1. Set the Access Point/Extender switch to the Access Point
position.
2. Use an Ethernet cable to connect the Ethernet port on the extender
to an Ethernet LAN port on a router or a remote Ethernet LAN jack
with LAN access.
3. Plug the extender into an electrical outlet and wait for the Power LED
to light green.
4. If the Power LED does not light, press the Power On/Off button.
5. Use a WiFi network manager on a computer or WiFi device to find and
connect to the EX6100_NETGEAR_2GEXT or the
EX6100_NETGEAR_5GEXT WiFi network.

14
Aer the connection with the computer or WiFi device is established,
the Client Link LED lights.
6. Launch a web browser and enter www.mywifiext.net in the address
field.
The New Extender Setup page displays.
7. Click the NEW EXTENDER SETUP button.
The Create Account page displays.
8. Complete the fields on the page to set up your login credentials and
click the NEXT button.
9. Verify that the Access Point/Extender switch is set to Access
Point and click the Continue button.
The extender checks for an Internet connection.
10. Click the HOME NETWORK or PUBLIC NETWORK button.
11. Set the network name (SSID), security option, and password for each
access point network and click the NEXT button.
Your settings are applied and the extender is ready to be used as an
access point.
12. Use a WiFi network manager on the computer or WiFi device to
connect to the new access point WiFi network.
13. Click the Continue button.

15
A page displays that says you successfully created an access point.
14. Click the Next button.
The registration page displays.
15. Follow the onscreen instructions to register your extender.
Access Extender Settings
Aer installation, you can log in to the extender to view or change the
extender’s settings.
1. Use a WiFi network manager on a computer or WiFi device to find and
connect to the new extended WiFi network.
Aer the connection with the computer or WiFi device is established,
the Client Link LED lights.
2. Launch a web browser.
3. Enter www.mywifiext.net in the address field of the browser.
A login window opens.
4. Enter your user name and password and click the LOG IN button.
The Status page displays.
5. Make any needed changes.

16
Frequently Asked Questions
You can find more information about your product in the user manual,
which is available at http://downloadcenter.netgear.com.
The web browser setup keeps asking me for my network password
(passphrase) or security key, and I am sure I entered the correct
password. What can I do?
The extender is probably placed at the borderline of the range covered by
the router or access point. For more information, see Place the Extender
and Apply Power on page 5.
If you are using WEP security, make sure that you are typing the network
password in the correct field.
Can I set up the extender in extender mode if I connect it to the
router with an Ethernet cable?
No. The extender is designed to use WiFi to connect to the router or
access point if it is in extender mode. If the extender is in access point
mode, you can connect it to the router or access point with an Ethernet
connection. For more information about access point mode, see Use the
Extender in Access Point Mode on page 13.

17
I forgot my login user name and password. What can I do?
On the login page, click the Username & Password Help link to answer
the security questions that you set up during the initial setup.
If you forgot the answers to your security questions, do the following to
set up your login credentials again:
1. Restore the extender to its factory default settings.
2. Launch a web browser.
3. Enter www.mywifiext.net in the address field of the browser.
The New Extender Setup page displays.
4. Click the NEW EXTENDER SETUP button.
5. When prompted, complete the fields on the page to set up your login
credentials again.
How do I restore the extender to its factory default settings?
1. Use a sharp object such as a pen or straightened paper clip to press
and hold the Factory Reset button on the extender for at least five
seconds until the Power LED lights amber.
2. Release the Factory Reset button and wait for the extender to
reboot.
The extender resets and returns to the factory default settings.

18
I am connected to the extender WiFi network and launched a
browser. Why can’t I see the web browser setup?
Try these troubleshooting steps:
• Make sure that your computer is set up to use DHCP (most are).
• Make sure that the Device Link LED is green and that you are using a
valid IP address.
• Relaunch the web browser and type www.mywifiext.net in the
address field. Type your user name and password and click the LOG IN
button.
I enabled a WiFi MAC filter, WiFi access control, or access control
list (ACL) on my router. What should I do when installing the
extender?
When a device connects through the extender to your router, the MAC
address of the device shown on the router is translated to another MAC
address. If your router’s MAC filter, WiFi access control, or ACL is enabled,
the device connects to the extender but cannot get an IP address from the
extender and cannot access the Internet.
To allow your device to receive an IP address from the extender and access
the Internet, you must provide the translated MAC address to the router.
1. Log in to your router and disable the MAC filter, WiFi access control, or
ACL.

19
For more information about how to disable your router’s MAC filter,
WiFi access control, or ACL, see your router’s documentation.
2. Power on the extender and connect all of your WiFi devices to the
extender network.
3. Make sure that the Router Link LED remains lit.
4. Log in to your extender:
a. Launch a web browser.
b. Enter www.mywifiext.net in the address field of the browser.
A login window opens.
c. Enter your user name and password and click the LOG IN button.
The Status page displays.
5. Select Settings > Connected Devices.
The Connected Devices section displays the MAC addresses and
virtual MAC addresses for the computers and WiFi devices that are
connected to the extender.
6. On the router, add the extender’s virtual MAC addresses and all of the
virtual MAC addresses of the devices connected to the extender to
your router’s MAC filter table.
7. Enable the router’s MAC filter, WiFi access control, or ACL.

September 2015
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
Support
Thank you for purchasing this NETGEAR product. You can visit
www.netgear.com/support to register your product, get help, access the latest
downloads and user manuals, and join our community. We recommend that you use only
ocial NETGEAR support resources.
Trademarks
© NETGEAR, Inc., NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc.
Any non-NETGEAR trademarks are used for reference purposes only.
Compliance
For the current EU Declaration of Conformity, visit:
http://support.netgear.com/app/answers/detail/a_id/11621/.
For regulatory compliance information, visit:
http://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
