ProSafe® Quad WAN Gigabit
SSL VPN Firewall Data Sheet
SRX5308
Ultra High Performance Business-class Firewall Security
The flagship model of the ProSafe firewall family — the SRX5308 is perfect for even the most
demanding business networks. The SRX5308 features a hardware-accelerated data flow
architecture that allows for 1 Gbps of stateful firewall throughput. This powerful VPN router
is a high-performance, SNMP-manageable, network solution that furnishes multidimensional
security including denial-of-service (DoS) protection, stateful packet inspection (SPI), URL
keyword filtering, configurable hardware DMZ port, logging, reporting, and real-time
alerts. QoS, WAN traffic metering, and bandwidth profiling gives you granular bandwidth
management capabilities. VLAN support allows you to separate guest traffic from critical
production servers. Four Gigabit LAN ports allows for maximum internal data transfer speeds,
while the four Gigabit WAN ports provide two modes of session-based load-balancing as well
as failover protection to ensure maximum throughput and reliable connectivity to the Internet.
*
VPNC
CERTIFIED
Basic
Interop
AES
Interop
FEATURES AND BENEFITS
LAN-to-WAN Throughput¹ • Hardware-accelerated 1Gbps LAN-to-WAN firewall throughput
• 200,000 concurrent connections
Secure Firewall • DoS attack protection
• Block TCP/UDP packet floods
• Port/service blocking
• Hardware DMZ port
• Web content filter
Quad Gigabit WAN Ports • 2 modes of session-based WAN load balancing
• WAN failover for maximum uptime
VLAN Support • Create up to 254 individual 802.1Q VLANs
• Allows for secure network segmentation
• Separate guest traffic from critical production servers
SSL and IPsec VPN Remote Access • SSL VPN – clientless remote access, anywhere, anytime
• IPsec VPN – secure site-to-site tunnels and client-based remote access
• Industry-strength encryption algorithms
• IKE authentication protects against unauthorized remote access
• 125 simultaneous IPsec VPN tunnels
• 50 simultaneous SSL VPN tunnels
Bandwidth Management • Control end user bandwidth consumption with Bandwidth Profiles
• Prioritize traffic with Quality of Service (QoS)
• WAN Traffic Metering
Easy to Use • Auto Detect connects to your ISP quickly
• DHCP (client and server) for fast deployment
• Intuitive Web management GUI
• IPsec VPN Wizard allows for easy VPN setup
• SNMP, telnet management support
• SYSLOG and emailed logs enable thorough network monitoring
Reliable NETGEAR Hardware • Industry-grade metal casing
• High-quality electronics
• NETGEAR Lifetime Warranty

ProSafe® Quad WAN Gigabit SSL VPN Firewall SRX5308
PC with GA311
Servers
SRX5308
ProSafe Quad WAN Gigabit
SSL VPN Firewall
SRX5308
ProSafe Quad WAN Gigabit
SSL VPN Firewall
Broadband
modems
VPN Tunnel
encrypts your data
Internet
Broadband
modems
PDA with Web browser
Telecommuter connects with
ProSafe VPN Client Software
(VPN01L or VPN05L)
240-10041-01
© 2004 NETGEAR, INC.
ALL RIGHTS RESERVED
240-10129-01
© 2004 NETGEAR, Inc.
All rights reserved
NMS100 ProSafe Network Management System
Everybody’s connecting.
™
Instructions:
This CD should automatically
run when inserted into your
CD-ROM drive. If the CD
does not start automatically,
browse to the CD drive and
click on NMSsetup.exe
Software CD
Version 1.0
2
7
0
-
1
0
2
6
3
-
0
1
Desktop PCs connect with
10/100/1000 Mbps Gigabit
Ethernet PCI Adapter (GA311)
WNDAP350
ProSafe Dual Band
Wireless-N Access Point
Laptop with SSL VPN
Remote Access
via Kiosk or Laptop
Gigabit Ethernet
Fast Ethernet
Desktop PCs connect with
10/100/1000 Mbps Gigabit
Ethernet PCI Adapter (GA311)
GSM7224-200
ProSafe 24-port Gigabit
Managed Switch
STM300
ProSecure Web and Email
Security Appliance
STM150
ProSecure Secure Threat
Management Appliance
GS724TPS
ProSafe 24-port Gigabit
Stackable PoE Smart Switch
TECHNICAL SPECIFICATIONS
PERFORMANCE
LAN-to-WAN Throughput¹ 924 Mbps
IPsec VPN (3DES) Throughput¹ 180 Mbps
SSL VPN Throughput¹ 21 Mbps
Maximum Concurrent Connections 200,000
Maximum Number of VLANs 254
Dedicated IPsec VPN Tunnels 125
Dedicated SSL VPN Tunnels 50
FIREWALL FEATURES
Stateful Packet Inspection (SPI) Port/Service Blocking, Denial-of-service (DoS) Prevention, Stealth Mode, Block TCP Flood, Block UDP Flood,
WAN/LAN Ping Response Control
Firewall Functions Port Range Forwarding, Port Triggering, DNS proxy, MAC Address Cloning/spoofing, NTP Support, UPnP, Auto-
Uplink on Switch Ports, L3 Quality of Service (QoS),LAN-to-WAN and WAN-to-LAN(ToS), Bandwidth Profiling
Content Filtering Web Components (Proxy, Java, ActiveX, Cookies), Web Keyword Blocking, Trusted Domains
User Authentication for VPN Active Directory, LDAP, Radius, WIKID, MIAS, NT Domain, Local User Database
PCI Compliance Two Factor
Authentication Support •
VoIP SIP ALG Compatibility List Linksys SPA-901, Linksys SPA-941, SNOM M3, Cisco 7940G, X-Lite 3.0 (software for phones),
D-Link DPH-140S, Grandstream GXP-2000, Polycom SoundStation 6000, Siemens C450, Aastra 51i
VPN Pass Through IPsec, PPTP, L2TP
FIREWALL FEATURES
WAN Modes NAT, Classical Routing
ISP Address Assignment DHCP, Static IP Assignment, PPPoE, PPTP
NAT Modes 1-1, NAT, PAT
Routing Static, Dynamic, RIPv1, RIPv2
DHCP DHCP Server, DHCP Relay
DDNS DynDNS.org, TZO.com, Oray.net, 3322.org
VLANs 802.1Q
Quad-WAN Fail-over •
WAN Load Balancing Modes Weighted Load Balancing, Round Robin
VPN
IPsec Encryption/Authentication 56-bit DES, 168-bit 3DES, AES(128, 192, 256 bit)/SHA-1, MD5
Key Exchange IKE, Manual Key, Pre-shared Key, PKI, X.509 v3
IPsec NAT Traversal (VPN Passthrough) •
IPsec Access Modes Client-to-site, Site-to-site
IPsec VPN Wizard •

350 E. Plumeria Drive
San Jose, CA 95134-1911 USA
1-888-NETGEAR (638-4327)
E-mail: [email protected]
www.NETGEAR.com
© 2010 NETGEAR, Inc. NETGEAR, the NETGEAR Logo, NETGEAR Digital Entertainer Logo, Connect with Innovation, FrontView, IntelliFi,
PowerShift, ProSafe, ProSecure, RAIDar, RAIDiator, X-RAID, RangeMax, ReadyNAS and Smart Wizard are trademarks of NETGEAR, Inc. in
the United States and/or other countries. Mac and the Mac logo are trademarks of Apple Inc., registered in the U.S. and other countries.
Other brand names mentioned herein are for identification purposes only and may be trademarks of their respective holder(s). Information
is subject to change without notice. All rights reserved.
*Basic technical support provided for 90 days from date of purchase.
¹Throughput measured in a lab environment. Actual performance may vary.
D-SRX5308-0
ProSafe® Quad WAN Gigabit SSL VPN Firewall SRX5308
TECHNICAL SPECIFICATIONS
VPN
SSL Version Support SSLv3, TLS1.0
SSL Encryption Support DES, 3DES, ARC4, AES(ECB, CBC, XCBC, CNTR)128, 256 bit
SSL Message Integrity MD5, SHA-1, MAC-MD5/SHA-1, HMAC-MD5/SHA-1
SSL Certificate Support RSA, Diffie-Hellman, Self
SSL VPN Platforms Supported Windows 2000/XP/Vista/Windows 7 (32, 64 bit), MAC OS X 10.4+
MANAGEMENT
Management Interface Options HTTP/HTTPS, SNMP v2c, Telnet
Logging Accepted Packets, Dropped Packets, System, Source MAC filter, Session Limit, Bandwidth Limit, SSl VPN, IPsec VPN
Log Delivery Email Delivery, Syslog
Diagnostics Ping, DNS Lookup, Trace Route
Maintenance Save/restore Configuration, Restore to Factory Defaults, Firmware Upgrades via Web Browser, Display Statistics
HARDWARE
Gigabit RJ45 Ports WAN/LAN 4/4
DMZ Interfaces (Configurable) 1
Flash Memory/RAM 64 MB/512 MB
Certifications VPNC (Basic, AES Interop)
Major Regulatory Compliance Environment: RoHS, China RoHS Safety: CE/LVD, cUL EMI: FCC
Part 15 Class A, CE mark commercial, C-Tick Class A, VCCI
Storage and Operating Temperatures Operating Temperature: 0˚ - 45˚C (32˚-113˚ F)
Storage Temperature: -20˚ – 70˚ C (-4˚ – 158˚ F)
Humidity Operation 90% Maximum Relative, Storage 95% Maximum Relative
Electrical Specifications AC 100-240V, 50/60 Hz Universal Input, DC 5V/5A Output Internal Power Supply
Dimensions (W x H x D) cm 33 x 4.3 x 20.9
Dimensions (W x H x D) in 13 x 1.7 x 8.2
Weight kg/lb 2.1/4.6
System Requirements Cable, DSL, or Wireless Broadband Modem, Internet Service, Network Card for Each Connected PC,
Network Software (e.g. Windows), Internet Explorer 5.0 or Higher or Mozilla Firefox 1.0 or Higher
Package Contents ProSafe Quad WAN Gigabit Firewall (SRX5308), Ethernet Cable, Power Cable, Rackmount Kit, Rubber
Feet, Installation Guide, Warranty/Support Information Card, Resource CD With Single User ProSafe
VPN Client Software License
Warranty Lifetime
ORDERING INFORMATION
North America SRX5308-100NAS
Europe SRX5308-100EUS
Asia SRX5308-100AJS
ACCESSORIES
ProSafe Client Software VPN01L (1-User), VPN05L (5-User)
ProSafe Network Management Software NMS100
PROSUPPORT SERVICE PACKS
OnCall 24x7, Category 1 PMB0331-100 (US), PMB0331 (non-US)
XPressHW, Category 1 PRR0331
