NETGEAR FVS336Gv1 - ProSafe Dual WAN Gigabit... User manual

202-10257-05
v1.0
January 2010
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134
ProSafe Dual WAN Gigabit
Firewall with SSL & IPsec
VPN FVS336G Reference
Manual

ii
v1.0, January 2010
© 2007–2010 by NETGEAR, Inc. All rights reserved.
Technical Support
Please refer to the support information card that shipped with your product. By registering your product at
http://www.netgear.com/register, we can provide you with faster expert technical support and timely notices of
product and software upgrades.
NETGEAR, INC. Support Information
Phone: 1-888-NETGEAR, for US & Canada only. For other countries, see your Support information card.
E-mail: [e-mail]
North American NETGEAR website: http://www.netgear.com
Trademarks
NETGEAR and the NETGEAR logo are registered trademarks and ProSafe is a trademark of NETGEAR, Inc.
Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Other brand and product
names are registered trademarks or trademarks of their respective holders.
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to
make changes to the products described in this document without notice.
NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit
layout(s) described herein.
Federal Communications Commission (FCC) Compliance Notice: Radio Frequency
Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
EU Regulatory Compliance Statement
The ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN is compliant with the following EU Council
Directives: 89/336/EEC and LVD 73/23/EEC. Compliance is verified by testing to the following standards: EN55022
Class B, EN55024 and EN60950-1.

v1.0, January 2010
iii
Bestätigung des Herstellers/Importeurs
Es wird hiermit bestätigt, daß das ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN gemäß der im BMPT-
AmtsblVfg 243/1991 und Vfg 46/1992 aufgeführten Bestimmungen entstört ist. Das vorschriftsmäßige Betreiben
einiger Geräte (z.B. Testsender) kann jedoch gewissen Beschränkungen unterliegen. Lesen Sie dazu bitte die
Anmerkungen in der Betriebsanleitung.
Das Bundesamt für Zulassungen in der Telekommunikation wurde davon unterrichtet, daß dieses Gerät auf den Markt
gebracht wurde und es ist berechtigt, die Serie auf die Erfüllung der Vorschriften hin zu überprüfen.
Certificate of the Manufacturer/Importer
It is hereby certified that the ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN has been suppressed
in accordance with the conditions set out in the BMPT-AmtsblVfg 243/1991 and Vfg 46/1992. The operation of some
equipment (for example, test transmitters) in accordance with the regulations may, however, be subject to certain
restrictions. Please refer to the notes in the operating instructions.
Federal Office for Telecommunications Approvals has been notified of the placing of this equipment on the market
and has been granted the right to test the series for compliance with the regulations.
Voluntary Control Council for Interference (VCCI) Statement
This equipment is in the second category (information equipment to be used in a residential area or an adjacent area
thereto) and conforms to the standards set by the Voluntary Control Council for Interference by Data Processing
Equipment and Electronic Office Machines aimed at preventing radio interference in such residential areas.
When used near a radio or TV receiver, it may become the cause of radio interference.
Read instructions for correct handling.
Additional Copyrights
AES Copyright (c) 2001, Dr. Brian Gladman, [e-mail], Worcester, UK.
All rights reserved.
TERMS
Redistribution and use in source and binary forms, with or without modification, are permitted
subject to the following conditions:
1. Redistributions of source code must retain the above copyright notice, this list of
conditions, and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of
conditions, and the following disclaimer in the documentation and/or other materials
provided with the distribution.
3. The copyright holder’s name must not be used to endorse or promote any products
derived from this software without his specific prior written permission.
This software is provided “as is” with no express or implied warranties of correctness or fitness
for purpose.

v1.0, January 2010
iv
Open SSL Copyright (c) 1998–2000 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted
provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of
conditions, and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of
conditions, and the following disclaimer in the documentation and/or other materials
provided with the distribution.
3. All advertising materials mentioning features or use of this software must display the
following acknowledgment: “This product includes software developed by the OpenSSL
Project for use in the OpenSSL Toolkit (http://www.openssl.org/).”
4. The names “OpenSSL Toolkit” and “OpenSSL Project” must not be used to endorse or
promote products derived from this software without prior written permission. For written
permission, contact [email protected].
5. Products derived from this software may not be called “OpenSSL” nor may “OpenSSL”
appear in their names without prior written permission of the OpenSSL Project.
6. Redistributions of any form whatsoever must retain the following acknowledgment: “This
product includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit (http://www.openssl.org/).”
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS,” AND ANY
EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS
CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY
OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
This product includes cryptographic software written by Eric Young ([email protected]). This
product includes software written by Tim Hudson ([email protected]).
MD5 Copyright (C) 1990, RSA Data Security, Inc. All rights reserved.
License to copy and use this software is granted provided that it is identified as the “RSA Data
Security, Inc. MD5 Message-Digest Algorithm” in all material mentioning or referencing this
software or this function. License is also granted to make and use derivative works provided
that such works are identified as “derived from the RSA Data Security, Inc. MD5 Message-
Digest Algorithm” in all material mentioning or referencing the derived work.
RSA Data Security, Inc. makes no representations concerning either the merchantability of
this software or the suitability of this software for any particular purpose. It is provided “as is”
without express or implied warranty of any kind.
These notices must be retained in any copies of any part of this documentation and/or
software.

v1.0, January 2010
v
Product and Publication Details
PPP Copyright (c) 1989 Carnegie Mellon University. All rights reserved.
Redistribution and use in source and binary forms are permitted provided that the above
copyright notice and this paragraph are duplicated in all such forms and that any
documentation, advertising materials, and other materials related to such distribution and use
acknowledge that the software was developed by Carnegie Mellon University. The name of
the University may not be used to endorse or promote products derived from this software
without specific prior written permission.
THIS SOFTWARE IS PROVIDED “AS IS” AND WITHOUT ANY EXPRESS OR IMPLIED
WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF
MERCHANTIBILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Zlib zlib.h -- interface of the 'zlib' general purpose compression library version 1.1.4, March 11th,
2002. Copyright (C) 1995-2002 Jean-loup Gailly and Mark Adler.
This software is provided 'as-is', without any express or implied warranty. In no event will the
authors be held liable for any damages arising from the use of this software. Permission is
granted to anyone to use this software for any purpose, including commercial applications,
and to alter it and redistribute it freely, subject to the following restrictions:
1. The origin of this software must not be misrepresented; you must not claim that you wrote
the original software. If you use this software in a product, an acknowledgment in the
product documentation would be appreciated but is not required.
2. Altered source versions must be plainly marked as such, and must not be misrepresented
as being the original software.
3. This notice may not be removed or altered from any source distribution.
Jean-loup Gailly: jl[email protected]; Mark Adler: [email protected]
The data format used by the zlib library is described by RFCs (Request for Comments) 1950
to 1952 in the files ftp://ds.internic.net/rfc/rfc1950.txt (zlib format), rfc1951.txt (deflate format)
and rfc1952.txt (gzip format)
Model Number: FVS336G
Publication Date: January 2010
Product Family: VPN Firewall
Product Name: ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN
Home or Business Product: Business
Language: English
Publication Part Number: 202-10257-05
Publication Version Number 1.0

v1.0, January 2010
vi

vii
v1.0, January 2010
Contents
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G
Reference Manual
About This Manual
Conventions, Formats, and Scope .................................................................................. xv
How to Print This Manual ................................................................................................xvi
Revision History ...............................................................................................................xvi
Chapter 1
Introduction
Key Features ..................................................................................................................1-1
Dual WAN Ports for Increased Reliability or Outbound Load Balancing ..................1-2
Advanced VPN Support for Both IPsec and SSL .....................................................1-2
A Powerful, True Firewall with Content Filtering ......................................................1-3
Autosensing Ethernet Connections with Auto Uplink ...............................................1-3
Extensive Protocol Support ......................................................................................1-4
Easy Installation and Management ................................................................................1-4
Maintenance and Support ..............................................................................................1-5
Package Contents ..........................................................................................................1-5
Front Panel Features ......................................................................................................1-6
Rear Panel Features ......................................................................................................1-7
Default IP Address, Login Name, and Password Location .............................................1-8
Qualified Web Browsers .................................................................................................1-8
Chapter 2
Connecting the FVS336G to the Internet
Understanding the Connection Steps .............................................................................2-1
Logging into the VPN Firewall ........................................................................................2-2
Navigating the Menus .....................................................................................................2-4
Configuring the Internet Connections .............................................................................2-4
Automatically Detecting and Connecting .................................................................2-5
Manually Configuring the Internet Connection .........................................................2-7

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
viii
v1.0, January 2010
Configuring the WAN Mode (Required for Dual WAN) .................................................2-11
Network Address Translation .................................................................................2-12
Classical Routing ...................................................................................................2-12
Configuring Auto-Rollover Mode ............................................................................2-13
Configuring Load Balancing ...................................................................................2-14
Configuring Dynamic DNS (Optional) ...........................................................................2-16
Configuring the Advanced WAN Options (Optional) .....................................................2-18
Additional WAN Related Configuration ..................................................................2-20
Chapter 3
LAN Configuration
Choosing the VPN Firewall DHCP Options ....................................................................3-1
Configuring the LAN Setup Options ...............................................................................3-2
Managing Groups and Hosts (LAN Groups) ...................................................................3-6
Viewing the LAN Groups Database .........................................................................3-7
Adding Devices to the LAN Groups Database .........................................................3-8
Changing Group Names in the LAN Groups Database ...........................................3-8
Configuring DHCP Address Reservation .................................................................3-9
Configuring Multi Home LAN IP Addresses ..................................................................3-10
Configuring Static Routes .............................................................................................3-11
Configuring Routing Information Protocol (RIP) ...........................................................3-13
Chapter 4
Firewall Protection and Content Filtering
About Firewall Protection and Content Filtering .............................................................4-1
Using Rules to Block or Allow Specific Kinds of Traffic ..................................................4-2
About Services-Based Rules ...................................................................................4-3
Viewing the Rules ....................................................................................................4-8
Order of Precedence for Rules ................................................................................4-8
Setting the Default Outbound Policy ........................................................................4-8
Creating a LAN WAN Outbound Services Rule .......................................................4-9
Creating a LAN WAN Inbound Services Rule ........................................................4-10
Modifying Rules ......................................................................................................4-11
Inbound Rules Examples .......................................................................................4-11
Outbound Rules Example ......................................................................................4-14
Configuring Other Firewall Features .............................................................................4-15
Attack Checks ........................................................................................................4-15

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
ix
v1.0, January 2010
Configuring Session Limits .....................................................................................4-17
Managing the Application Level Gateway for SIP Sessions ..................................4-18
Creating Services, QoS Profiles, and Bandwidth Profiles ............................................4-19
Adding Customized Services .................................................................................4-19
Setting Quality of Service (QoS) Priorities .............................................................4-21
Creating Bandwidth Profiles ...................................................................................4-22
Setting a Schedule to Block or Allow Specific Traffic ....................................................4-24
Blocking Internet Sites (Content Filtering) ....................................................................4-25
Configuring Source MAC Filtering ................................................................................4-28
Configuring IP/MAC Address Binding ...........................................................................4-30
Configuring Port Triggering ...........................................................................................4-31
E-Mail Notifications of Event Logs and Alerts ...............................................................4-33
Administrator Tips .........................................................................................................4-33
Chapter 5
Virtual Private Networking Using IPsec
Considerations for Dual WAN Port Systems ..................................................................5-1
Using the VPN Wizard for Client and Gateway Configurations ......................................5-3
Creating Gateway to Gateway VPN Tunnels with the Wizard .................................5-3
Creating a Client to Gateway VPN Tunnel ...............................................................5-6
Testing the Connections and Viewing Status Information .............................................5-12
NETGEAR VPN Client Status and Log Information ...............................................5-12
VPN Firewall VPN Connection Status and Logs ....................................................5-14
Managing VPN Policies ................................................................................................5-15
Configuring IKE Policies .........................................................................................5-16
Configuring VPN Policies .......................................................................................5-18
Configuring Extended Authentication (XAUTH) ............................................................5-19
Configuring XAUTH for VPN Clients ......................................................................5-20
User Database Configuration .................................................................................5-22
RADIUS Client Configuration .................................................................................5-22
Assigning IP Addresses to Remote Users (ModeConfig) .............................................5-24
Mode Config Operation ..........................................................................................5-24
Configuring Mode Config Operation on the VPN Firewall ......................................5-25
Configuring the ProSafe VPN Client for ModeConfig .............................................5-30
Configuring Keepalives and Dead Peer Detection .......................................................5-32
Configuring Keepalives ..........................................................................................5-32

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
x
v1.0, January 2010
Configuring Dead Peer Detection ..........................................................................5-33
Configuring NetBIOS Bridging with VPN ......................................................................5-34
Chapter 6
Virtual Private Networking Using SSL
Understanding the Portal Options ...................................................................................6-1
Planning for SSL VPN ....................................................................................................6-2
Creating the Portal Layout ..............................................................................................6-3
Configuring Domains, Groups, and Users ......................................................................6-7
Configuring Applications for Port Forwarding .................................................................6-7
Adding Servers .........................................................................................................6-8
Adding A New Host Name .......................................................................................6-9
Configuring the SSL VPN Client ...................................................................................6-10
Configuring the Client IP Address Range ..............................................................6-11
Adding Routes for VPN Tunnel Clients ..................................................................6-12
Replacing and Deleting Client Routes ...................................................................6-12
Using Network Resource Objects to Simplify Policies ..................................................6-13
Adding New Network Resources ..........................................................................6-13
Configuring User, Group, and Global Policies ..............................................................6-15
Viewing SSL VPN Policies .....................................................................................6-16
Adding an SSL VPN Policy ....................................................................................6-17
Chapter 7
Managing Users, Authentication, and Certificates
Adding Authentication Domains, Groups, and Users .....................................................7-1
Creating a Domain ...................................................................................................7-1
Creating a Group ......................................................................................................7-5
Creating a New User Account ..................................................................................7-6
Setting User Login Policies ......................................................................................7-7
Changing Passwords and Other User Settings ........................................................7-9
Managing Certificates ...................................................................................................7-11
Viewing and Loading CA Certificates .....................................................................7-12
Viewing Active Self Certificates ..............................................................................7-13
Obtaining a Self Certificate from a Certificate Authority .........................................7-14
Managing your Certificate Revocation List (CRL) ..................................................7-17

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
xi
v1.0, January 2010
Chapter 8
VPN Firewall and Network Management
Performance Management .............................................................................................8-1
Bandwidth Capacity .................................................................................................8-1
Features That Reduce Traffic ...................................................................................8-2
Features That Increase Traffic .................................................................................8-5
Using QoS to Shift the Traffic Mix ............................................................................8-7
Tools for Traffic Management ...................................................................................8-8
Changing Passwords and Administrator Settings ..........................................................8-8
Enabling Remote Management Access .......................................................................8-10
Using the Command Line Interface ..............................................................................8-12
Using an SNMP Manager .............................................................................................8-13
Managing the Configuration File ...................................................................................8-14
Configuring Date and Time Service ..............................................................................8-17
Chapter 9
Monitoring System Performance
Enabling the Traffic Meter ...............................................................................................9-1
Activating Notification of Events and Alerts ....................................................................9-4
Viewing the Logs ............................................................................................................9-6
Viewing VPN Firewall Configuration and System Status ................................................9-8
Monitoring VPN Firewall Statistics ..................................................................................9-9
Monitoring the Status of WAN Ports .............................................................................9-10
Monitoring Attached Devices ........................................................................................9-11
Viewing the DHCP Log .................................................................................................9-12
Monitoring Active Users ................................................................................................9-13
Viewing Port Triggering Status .....................................................................................9-14
Monitoring VPN Tunnel Connection Status ..................................................................9-15
Viewing the VPN Logs ..................................................................................................9-16
Chapter 10
Troubleshooting
Basic Functions ............................................................................................................10-1
Power LED Not On .................................................................................................10-2
LEDs Never Turn Off ..............................................................................................10-2
LAN or WAN Port LEDs Not On .............................................................................10-2
Troubleshooting the Web Configuration Interface ........................................................10-3

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
xii
v1.0, January 2010
Troubleshooting the ISP Connection ............................................................................10-4
Troubleshooting a TCP/IP Network Using a Ping Utility ...............................................10-5
Testing the LAN Path to Your VPN Firewall ...........................................................10-5
Testing the Path from Your PC to a Remote Device ..............................................10-6
Restoring the Default Configuration and Password ......................................................10-7
Problems with Date and Time .......................................................................................10-7
Using the Diagnostics Utilities ......................................................................................10-8
Appendix A
Default Settings and Technical Specifications
Appendix B
Network Planning for Dual WAN Ports
What You Will Need to Do Before You Begin ................................................................ B-1
Cabling and Computer Hardware Requirements .................................................... B-3
Computer Network Configuration Requirements .................................................... B-3
Internet Configuration Requirements ...................................................................... B-3
Where Do I Get the Internet Configuration Parameters? ........................................ B-4
Internet Connection Information Form .................................................................... B-4
Overview of the Planning Process ................................................................................. B-5
Inbound Traffic ........................................................................................................ B-5
Virtual Private Networks (VPNs) ............................................................................. B-6
The Roll-over Case for Firewalls With Dual WAN Ports .......................................... B-6
The Load Balancing Case for Firewalls With Dual WAN Ports ............................... B-7
Inbound Traffic ...............................................................................................................B-7
Inbound Traffic to Single WAN Port (Reference Case) ........................................... B-7
Inbound Traffic to Dual WAN Port Systems ............................................................ B-8
Virtual Private Networks (VPNs) .................................................................................... B-9
VPN Road Warrior (Client-to-Gateway) .................................................................B-11
VPN Gateway-to-Gateway .................................................................................... B-13
VPN Telecommuter (Client-to-Gateway Through a NAT Router) .......................... B-16
Appendix C
Two Factor Authentication
Why do I need Two-Factor Authentication? ...................................................................C-1
What are the benefits of Two-Factor Authentication? .............................................C-1
What is Two-Factor Authentication .........................................................................C-2
NETGEAR Two-Factor Authentication Solutions ...........................................................C-2

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
xiii
v1.0, January 2010
Appendix D
Related Documents
Index

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
xiv
v1.0, January 2010

xv
v1.0, January 2010
About This Manual
The NETGEAR®ProSafe™ Dual WAN Gigabit Firewall with SSL & IPsec VPN Reference
Manual describes how to install, configure and troubleshoot a ProSafe Dual WAN Gigabit
Firewall with SSL & IPsec VPN. The information in this manual is intended for readers with
intermediate computer and networking skills.
Conventions, Formats, and Scope
The conventions, formats, and scope of this manual are described in the following paragraphs:
•Typographical Conventions. This manual uses the following typographical conventions:
•Formats. This manual uses the following formats to highlight special messages:
Italic Emphasis, books, CDs, file and server names, extensions
Bold User input, IP addresses, GUI screen text
Fixed Command prompt, CLI text, code
italic URL links
Note: This format is used to highlight information of importance or special interest.
Tip: This format is used to highlight a procedure that will save time or resources.
Warning: Ignoring this type of note may result in a malfunction or damage to the
equipment.
Danger: This is a safety warning. Failure to take heed of this notice may result in
personal injury or death.

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
xvi
v1.0, January 2010
•Scope.This manual is written for the VPN firewall according to these specifications:
For more information about network, Internet, firewall, and VPN technologies, see the links to the
NETGEAR website in Appendix D, “Related Documents.”
How to Print This Manual
To print this manual, your computer must have the free Adobe Acrobat reader installed in order to
view and print PDF files. The Acrobat reader is available on the Adobe website at
http://www.adobe.com.
Revision History
Product Version ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN
Manual Publication Date January 2010
Note: Product updates are available on the NETGEAR, Inc. website at
http://kb.netgear.com/app/home.
Tip: If your printer supports printing two pages on a single sheet of paper, you can save
paper and printer ink by selecting this feature.
Part Number Version
Number Date Description
202-10257-01 1.0 October
2007 First publication
202-10257-02 1.1 November
2007 Text corrections
202-10257-03 1.2 June 2008 Updated to align with router firmware update.

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
xvii
v1.0, January 2010
202-10257-04 1.3 March
2009 Added these corrections and topics for the March 2009 firmware maintenance release:
• WIKID 2 factor authentication
• SIP AGL support
• DHCP Relay support
• Updated VPN configuration procedure topics
• Updated the Certificate management topic
• Corrected the firewall scheduling topic
202-10257-05 1.0 January
2010 Added the following new features for the January 2010 firmware maintenance release:
• Connection reset and delay options on the WAN ISP Settings
screen (see “Manually Configuring the Internet Connection”).
• Support for DNS 3322 in the Dynamic DNS submenu (see
“Configuring Dynamic DNS (Optional)”).
• Support for an address range for inbound LAN rules on the Add
LAN WAN Inbound Service screen (see “Inbound Rules (Port
Forwarding)” and “Creating a LAN WAN Inbound Services Rule”).
• Support for new log options such as Resolved DNS Names and
VPN on the Firewall Logs & E-mail screen (see “Activating
Notification of Events and Alerts”).
In addition, made the following substantial changes to the book:
• Resized many screen captures for better viewing.
• Made various corrections.
• Made global stylistic changes for consistency and clarity.
• Added technical support information to page ii.
• Updated the bottom label image (Figure 1-3).
• Updated the qualified Web browsers in the “Qualified Web
Browsers” and “Computer Network Configuration Requirements”
sections.
• Updated the WAN1 ISP Settings screen (Figure 2-3) and the ISP
Type options in the “Manually Configuring the Internet
Connection” section.
• Updated the Dynamic DNS Configuration screen (Figure 2-12)
and the DDNS providers in the “Configuring Dynamic DNS
(Optional)” section.
• Reorganized Chapter 4, “Firewall Protection and Content
Filtering.”
• Updated the LAN Setup screen (Figure 3-1). Added DHCP Relay
information, LDAP information, and the Enable ARP Broadcast
paragraph to the “Configuring the LAN Setup Options” section.
• Updated the Add LAN WAN Inbound Service screen (Figure 4-3),
related screens in the “Inbound Rules Examples” section, and the
Inbound Rules table (Table 4-2) to show that a range of IP
addresses can be selected for the Send to LAN Server field.
• Updated the “Modifying Rules” section.

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
xviii
v1.0, January 2010
202-10257-05
(continued) 1.0 January 2010 (continued) • Updated the “Attack Checks” section and screen (Figure 4-8) to
show that you can specify an IP address that is allowed to
respond to a ping.
• Added the “Managing the Application Level Gateway for SIP
Sessions” section.
• Updated the “Creating Bandwidth Profiles” section, including
Figure 4-13 and Figure 4-14.
• Added the IKE Policies screen (Figure 5-20 and Figure 5-26) to
respectively the “The IKE Policies Screen” section and the
“Configuring an IKE Policy for Mode Config Operation” section.
• Added the Add IKE Policy screen (Figure 5-22) to “Configuring
XAUTH for VPN Clients” section.
• Updated the VPN-SSL Policies screen (Figure 6-8 and
Figure 6-9) to show the Related Policies Table and added a Note
to the “Viewing SSL VPN Policies” section.
• Revised the “Creating a Domain” section, added the
Authentication Protocols and Methods table (Table 7-1), and
revised the Domains screen (Figure 7-1).
• Revised the “Changing Passwords and Other User Settings”
section and replaced the Local Authentication screen with the
Edit User screen (Figure 7-9).
• Removed the “RADIUS Server External Authentication” section
(with its External Authentication screen) that has been
superseded by the “RADIUS Client Configuration” section and
the “Creating a Domain” section.
• Revised and corrected the “Performance Management” section.
• Updated the “Enabling Remote Management Access” section
and the Remote Management screen (Figure 8-3) to show the
extended secure HTTP management options.
• Updated the Firewall Logs & E-mail screen (Figure 9-2) to show
the new log options and revised Table 9-1.
• Added the (firewall) Logs screen (Figure 9-3).
• Revised and corrected the Router Status information in
Table 9-3.
• Added the “Monitoring VPN Firewall Statistics” section.
• Made screen reference corrections in Chapter 10,
“Troubleshooting.”
• Updated Appendix D, “Related Documents.”

1-1
v1.0, January 2010
Chapter 1
Introduction
The ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G connects your local
area network (LAN) to the Internet through one or two external broadband access devices such as
cable modems or DSL modems. Dual wide area network (WAN) ports allow you to increase
throughput to the Internet by using both ports together, or to maintain a backup connection in case
of failure of your primary Internet connection.
As a complete security solution, the FVS336G incorporates a powerful and flexible firewall to
safeguard your network, while providing advanced IPsec and SSL VPN technologies for secure
and simple remote connections.
The use of Gigabit Ethernet LAN and WAN ports ensures extremely high data transfer speeds
The FVS336G is a plug-and-play device that can be installed and configured within minutes.
This chapter contains the following sections:
•“Key Features” on this page
•“Package Contents” on page 1-5
•“Front Panel Features” on page 1-6
•“Rear Panel Features” on page 1-7
•“Default IP Address, Login Name, and Password Location” on page 1-8
•“Qualified Web Browsers” on page 1-8
Key Features
The FVS336G provides the following key features:
• Dual 10/100/1000 Mbps Gigabit Ethernet WAN ports for load balancing or failover protection
of your Internet connection, providing increased system reliability or increased throughput.
• Built-in four-port 10/100/1000 Mbps Gigabit Ethernet LAN switch for extremely fast data
transfer between local network resources.
• Advanced IPsec and SSL VPN support.
• Advanced stateful packet inspection (SPI) firewall with multi-NAT support.

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
1-2 Introduction
v1.0, January 2010
• Easy, web-based setup for installation and management.
• Front panel LEDs for easy monitoring of status and activity.
• Flash memory for firmware upgrade.
• Internal universal switching power supply.
Dual WAN Ports for Increased Reliability or Outbound Load
Balancing
The FVS336G has two broadband WAN ports. The second WAN port allows you to connect a
second broadband Internet line that can be configured on a mutually-exclusive basis to:
• Provide backup and rollover if one line is inoperable, ensuring you are never disconnected.
• Load balance, or use both Internet lines simultaneously for outgoing traffic. The FVS336G
balances users between the two lines for maximum bandwidth efficiency.
See “Network Planning for Dual WAN Ports” on page B-1 for the planning factors to consider
when implementing the following capabilities with dual WAN port gateways:
• Single or multiple exposed hosts.
• Virtual private networks.
Advanced VPN Support for Both IPsec and SSL
The FVS336G supports IPsec and SSL virtual private network (VPN) connections.
• IPsec VPN delivers full network access between a central office and branch offices, or
between a central office and telecommuters. Remote access by telecommuters requires the
installation of VPN client software on the remote computer.
– IPsec VPN with broad protocol support for secure connection to other IPsec gateways and
clients.
– Bundled with the single-user license of the NETGEAR ProSafe VPN Client software
(VPN01L)
– Supports 25 concurrent IPsec VPN tunnels.
• SSL VPN provides remote access for mobile users to selected corporate resources without
requiring a pre-installed VPN client on their computers.
– Uses the familiar Secure Sockets Layer (SSL) protocol, commonly used for e-commerce
transactions, to provide client-free access with customizable user portals and support for a
wide variety of user repositories.
