GS105
5-port Gigabit Ethernet Switch
10/100/1000 Mbps
Potent
Capable
Trim
Easygoing
Everybody’s Connecting. ™
• Help is there when you need it!
NETGEAR provides 24x7
technical support* in English,
with selected local language
support during office hours.
Gigabit Power, 10/100 Simplicity
For a high-speed network on a small scale, nothing delivers likes this compact powerhouse.
Equipped with five auto-speed-sensing 10/100/1000 Mbps UTP ports, this affordable switch
gives your network the capacity to handle huge workloads. It moves very large files across
your network instantly, and lets you painlessly integrate 10, 100, and 1000 Mbps devices on
your network. Packed with ease-of-use features to simplify your networking experience, its
trim design makes it an easy fit for a desk or mounted on a wall. The durable metal chassis
protects interior working parts and the fan-less design results in silent operation. Matched
with NETGEAR’s thorough testing, the GS105 switch provides long-lasting performance you
can count on.
Moves huge files fast! Features five high-speed, auto-switching 10/100/1000 Mbps Ethernet
connections. And because Gigabit Ethernet is a full duplex standard, you get up to 2000 Mbps
on each port.
Integrates 10, 100, and 1000 Mbps devices on the same network. Every port automatically senses
the right speed and full/half duplex mode, and Auto UplinkTM technology automatically adjusts for
straight-through or crossover cables.
Sized to save space, this sturdy metal 5-port switch is compact and fits easily on a desk or mounts
on a wall, making it ideal for home and small office environments.
LEDs embedded in RJ-45 jacks make for easy monitoring. Provides noiseless operation.
Supports PC or Mac®O/S.

Technical Specifications
• Network Ports:
-5 auto-speed sensing UTP ports
• Forwarding Mode:
-Store-and-Forward
-256K On-Chip Packet Buffering
• Performance:
-Bandwidth: 10 Gbps (non-blocking)
-Forward Rate (10 Mbps port): 14,800 packets/sec
-Forward Rate (100 Mbps port): 148,000
packets/sec
-Forward Rate (1000 Mbps port): 1,480,000
packets/sec
-Network Latency (100 to 100 Mbps): 20 µs (max)
-Network Latency (1000 to 1000 Mbps):
10 µs (max)
-Queue Buffer Memory: 12 kbytes per port
-MAC address database: 8,000
-Mean Time Between Failure (MTBF): 87,600
hours (~10 years)
• Status LEDs:
-Power, Collision, Activity, and Duplex indicators
for each port, Link and Speed indicators built into
each RJ-45 port
• AC Power:
-14.4 W
-12VAC, 1.2A
• Physical Specifications:
-Dimensions (w x d x h): 158 x 105 x 25 mm
(6.22 x 4.13 x .98 in.)
-Weight: 0.49 kg (1.08 lb)
• Environmental Specifications:
-Operating Temperature: 0 to 40º C (32 to 104º F)
-Operating Humidity: 10 to 90% noncondensing
• Storage Specifications:
--20 to 70° C (-4 to 158º F)
-10 to 95% Relative Humidity
• Standards Compliance:
-IEEE 802.3i 10BASE-T Ethernet
-IEEE 802.3u 100BASE-TX Fast Ethernet
-IEEE 802.3z 1000BASE-T Gigabit Ethernet
-Windows®, MAC OS, NetWare®, Linux®
• Safety Agency Approvals:
-UL (UL 60950), CUL, C-Tick, CE Mark, TUV
licensed (EN 60950)
• Emissions:
-FCC Class A and VCCI Class A, CE Class A, MIC
• Warranty:
-Switch: NETGEAR 5 year warranty
-Power adapter: NETGEAR 2 year warranty
System Requirements
-UTP Category 5 cables or better
-Network card for each PC or server (e.g. GA302T)
Package Contents
-5-port 10/100/1000 Mbps Gigabit Ethernet
Switch GS105
-Wall-mount kit
-Power adapter
-Installation guide
-Warranty & Support information card
NETGEAR Related Products
-GA302T Copper Gigabit PCI Adapter
-GA622T Copper Gigabit Ethernet Adapter
-GS108 8-port 10/100/1000 Mbps Gigabit
Ethernet Switch
