netvox R831D User manual

Model：R831D
Wireless Relay Switch Control
Wireless Relay Switch Control
R831D
User Manual
Copyright© Netvox Technology Co., Ltd.
This document contains proprietary technical information which is the property of NETVOX Technology. It shall be maintained in strict
confidence and shall not be disclosed to other parties, in whole or in part, without written permission of NETVOX Technology. The
specifications are subject to change without prior notice.

1
Table of contents
1. Introduction ................................................................................................................ 2
2.Appearance.................................................................................................................. 3
3.Main Features..............................................................................................................4
4. Set up Instruction........................................................................................................ 5
5. Data Report................................................................................................................. 6
6. Installation................................................................................................................ 10
7. Maintenance and maintenance ................................................................................. 11

2
1.Introduction
The R831D is a Wireless Relay Switch Control device for Netvox Class C type devices based on the LoRaWAN open protocol and is
compatible with the LoRaWAN protocol.
R831D is designed to control switch devices, mainly for electrical appliances. R831D allows you to connect and control 3 buttons
and 3 dry contacts. The connected buttons and dry contacts will not affect each other. It will report 3 relay status and 3 input status.
LoRa Wireless Technology:
LoRa is a wireless communication technology famous for its long-distance transmission and low power consumption. Compared
with other communication methods, LoRa spread spectrum modulation technique greatly extend the communication distance. It can
be widely used in any use case that requires long-distance and low-data wireless communications. For example, automatic meter
reading, building automation equipment, wireless security systems, industrial monitoring. It has features like small size, low power
consumption, long transmission distance, strong anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and
gateways from different manufacturers.

3
2.Appearance
Port 1
N/A
Port 2
First load
Port 3
First load
Port 4
Second load
Port 5
Second load
Port 6
Third load
Port 7
Third load
Port 8
GND
Port 9
12v
R831D
DIP SW
1
2
3
on
off
1~3
DIP Switch
(Change R831 series mode)
V
N/A
G
GND
K1
input 1
K2
input 2
K3
input 3
Network Indicator
Status Indicator
DIP Switch
Function Key

4
3.Main Features
⚫Apply SX1276 wireless communication module
⚫Three relays switch dry contact output
⚫Compatible with LoRaWANTM Class C
⚫Frequency hopping spread spectrum
⚫Configuration parameters can be configured via a third-party software platform, data can be read and alerts can be set via SMS text
and email (optional)
⚫Applicable to third-party platforms: Actility/ThingPark, TTN, MyDevices/Cayenne
⚫Improved power management for longer battery life
Battery Life:
⁻Please refer to web: http://www.netvox.com.tw/electric/electric_calc.html
⁻At this website, users can find battery life time for variety models at different configurations.
1. Actual range may vary depending on environment.
2. Battery life is determined by sensor reporting frequency and other variables.

5
4. Set up Instruction
On/Off
Power on
External 12V power supply
Turn on
After plug the power, the status indicator will stay on, it means the boot is successful.
Restore to factory setting
Press and hold the function key for 5 seconds till the status indicator flashes for 20 times.
Power off
Remove power
Note:
Press and hold the function key then power on, it will enter engineering mode
Network Joining
If the device has never joined the
network
Turn on the device, and it will search for the network to join.
The network indicator stays on: Joins the network successfully
The network indicator stays off : Fail to join the network
If the device has joined the network
and it is not set to default
Turn on the device, and it will search for the previous network to join.
The network indicator stays on: Joins the network successfully
The network indicator stays off : Fail to join the network
Function Key
Press the function key and hold the
pressing for 5 seconds
The device will be set to default and turned off
The status indicator light flashes for 20 times: success
The status indicator light remains off: fail
Press the function key once
The device is in the network: The status indicator light flashes once and sends a report
The device is not in the network: The status indicator light remains off

6
5. Data Report
Example of ConfigureCmd
FPort：0x07
Bytes
1
1
Var(Fix =9 Bytes)
CmdID
DeviceType
NetvoxPayLoadData
CmdID–1 bytes
DeviceType–1 byte –Device Type of Device
NetvoxPayLoadData–var bytes (Max=9bytes)
Off
R831D
0x90
0XB0
Channel(1Bytes)
bit0_relay1,
bit1_relay2,
bit2_relay3,
bit3_bit7:reserved
Reserved
(8ytes,Fixed 0x00)
On
0x91
Channel(1Bytes)
Reserved
The device will immediately send a version packet report along with an uplink packet including 3 relay status and 3 input status.
The device sends data in the default configuration before any configuration is done.
Default setting:
MaxTime: Max Interval = 900s
MinTime: Min Interval = 2s
Note:
The device report interval will be programmed based on the default firmware which may vary.
The interval between two reports must be the minimum time.
Please refer Netvox LoRaWAN Application Command document and Netvox Lora Command Resolver
http://www.netvox.com.cn:8888/page/index to resolve uplink data.

7
bit0_relay1,
bit1_relay2,
bit2_relay3,
bit3_bit7:reserved
(8ytes,Fixed 0x00)
Toggle
0x92
Channel(1Bytes)
bit0_relay1,
bit1_relay2,
bit2_relay3,
bit3_bit7:reserved
Reserved
(8ytes,Fixed 0x00)
Red Current Status
0x94
Reserved
(9Bytes,Fixed 0x00)
ConfigReportReq
0x01
MinTime
(2bytes Unit:s)
MaxTime
(2bytes Unit:s)
Reserved
(5Bytes,Fixed 0x00)
ConfigReportRsp
0x81
Status
(0x00_success)
Reserved
(8Bytes,Fixed 0x00)
ReadConfigReportReq
0x02
Reserved
(9Bytes,Fixed 0x00)
ReadConfigReportRsp
0x82
MinTime
(2bytes Unit:s)
MaxTime
(2bytes Unit:s)
Reserved
(5Bytes,Fixed 0x00)
SetSwitchTypeReq
0x03
SwitchType(1byte)
0x00_Toggle,
0x01_Momentary
Reserved
(8Bytes,Fixed 0x00)
SetSwitchTypeRsp
0x83
Status
(0x00_success)
Reserved
(8Bytes,Fixed 0x00)
GetSwitchTypeReq
0x04
Reserved
(9Bytes,Fixed 0x00)
GetSwitchTypeRsp
0x84
SwitchType(1byte)
0x00_Toggle,
0x01_Momentary
Reserved
(8Bytes,Fixed 0x00)
Max Time and Min Time setting
(1)Command Configuration:
MinTime = 1min、MaxTime = 1min
Downlink: 01B0003C003C0000000000

8
Response: 81B0000000000000000000 (Configuration success)
81B0010000000000000000 (Configuration failure)
(2)Read Configuration:
Downlink：02B0000000000000000000
Response:
82B0003C003C0000000000 (Current configuration)
Relay switch control
(3)Relay1, Relay 2, Relay3 normal open (disconnect)
Downlink：90B0070000000000000000 // bit0=relay1, bit1=relay2, bit2=relay3
(4)Relay1, Relay 2, Relay3 normal close (connect)
Downlink：91B0070000000000000000 // bit0=relay1, bit1=relay2, bit2=relay3
(5)Toggle relay normal open/close
Downlink：92B0070000000000000000 // bit0=relay1, bit1=relay2, bit2=relay3
Relay switch Type
Change relay switch type:
a. Toggle: Normal open/close type switch, ex. toggle switch
b. Momentary: Tact type switch, ex. tact switch
(6)Setting switch type is tact type switch
Downlink：03B0010000000000000000
Response：83B0000000000000000000 (Configuration success)
(7)Confirm switch type
Downlink：04B0000000000000000000
Response：84B0010000000000000000 (The switch type is tact type)

9
Example for MinTime/MaxTime logic
Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour
MaxTime MaxTime
(MinTime) (MinTime)
0H 1H 2H
Note:
MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless ON/OFF value.
Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour
MaxTime
MinTime MinTime MinTime MinTime
0H 15th M 30th M 45th M 1H 2H
Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour
MaxTime
MinTime MinTime MinTime MinTime MinTime MinTime
0H 15th M 30th M 45th M 1H 1H15thM1H30thM
Note:
The status has changed, it will be reported at MinTime and recommend the MinTime Interval set as 2 seconds
Collects data
ON
REPORT ON
Collects data
OFF
Does not report
Collects data
REPORTS
OFF
Collects data
REPORTS ON
Collects data
REPORTS ON
Collects data
REPORTS OFF
Collects data
REPORTS OFF
Collects data
REPORTS OFF
Collects data OFF
Does not report
Collects data
ON
Does not report
Collects data
ON
Does not report
Collects data
ON
Does not report
Collects data
ON
REPORT ON
The status changed

10
SW 1
6. Installation
This product does not have a waterproof function. After joined the network, please place it indoors.
The wiring diagram as follow below:
SW 3
SW 2
Adapter
First Load
Second Load
Third Load

11
7. Maintenance and maintenance
Kindly pay attention to the following in order to achieve the best maintenance of the product:
• Keep the device dry. Rain, moisture, or any liquid, might contain minerals and thus corrode electronic circuits. If the device gets wet,
please dry it completely.
• Do not use or store the device in dusty or dirty environment. It might damage its detachable parts and electronic components.
• Do not store the device under excessive heat condition. High temperature can shorten the life of electronic devices, destroy batteries,
and deform or melt some plastic parts.
• Do not store the device in places that are too cold. Otherwise, when the temperature rises to normal temperature, moisture will form
inside, which will destroy the board.
• Do not throw, knock or shake the device. Rough handling of equipment can destroy internal circuit boards and delicate structures.
• Do not clean the device with strong chemicals, detergents or strong detergents.
• Do not apply the device with paint. Smudges might block in the device and affect the operation.
• Do not throw the battery into the fire, or the battery will explode. Damaged batteries may also explode.
All of the above applies to your device, battery and accessories. If any device is not working properly, please take it to the nearest
authorized service facility for repair.
