Converters.TV 780 User manual

2-in 1-out HDMI Switcher
- ID# 780
Operation Manual

Introduction
2-in 1-out HDMI Switcher is a high performance HDMI switcher, it offers 70
meters output range@1080p. It a ows two HDMI sources to share one HDTV
disp ay. Simp y pressing input button to se ect your desired HDMI source for
disp ay on the HDTV.
Features
* HDMI 1.2, HDCP 1.1 and DVI 1.0 comp iant.
* Input LED indicators.
* Automatica y provides equa ization to compensate for ong cab e
transmission oss.
* Supports high reso ution input:
PC: VGA, SVGA, XGA, SXGA, and UXGA (1600 x 1200)&
HDTV: 480i, 576i, 480p, 576p, 720p, 1080i and 1080p
* Easy to insta and operate.
Operation Controls
and Functions
Top Panel
1. Input LED Indicator:
The LED wi i uminate when the power is connected.
Red/Green LED wi show the input status, and press the "INPUT" button to
se ect HDMI 1 IN or HDMI 2 IN.
Front Panel Rear Panel

2. HDMI inputs
Connect your various HDMI sources to the HDMI inputs of unit using HDMI
cable.
3. HDMI output
Connect the HDMI out of the unit to the HDMI input of your display using HDMI
cable.
4. Power
Plug the 5VDC power supply into the unit and connect the adaptor to AC
wall outlet.
Connection and
Installation
Specifications
* Frequency Bandwidth: 1.65Gbps(sing e ink)
* Inputs: 2 x HDMI fema e ports (Type A connector)
* Output: 1 x HDMI fema e port (Type A connector)
* 5VDC Power Supply, Center Positi e
* Weight(g): 95
* Dimensions(mm): 100(W) x 64(L) x 18.5(H)
* Silkscreen Color: White
* Operating Temperature: 0°C~40°C
