3 Versions
There is only one version of the ETH-1000MC.
4 Overview
The flashlink ® ETH1000MC is a 1000Base-T to fibre converter module in the Network flashlink family.
The module converts a standard 1000 Mbit/s Ethernet signal on copper to fibre suitable for long haul
applications. The module has one electrical Ethernet port, and one fibre transceiver port (receiver fibre
connector and transmit fibre connector). The speed on the electrical connector is dependent of the DIP
switch setting. Speed will upon link connection automatically be set the highest possible. User can
independently enable or disable 10Mbit, 100Mbit or 1000Mbit. The fibre link can be used in one or two
fibre installations, or occupy two wavelengths in a WDM, CWDM or DWDM installation.
E-mail: [email protected] - Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice. 4

ETH1000MC Rev. 6
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] - Fax: [phone]
E-mail: [email protected] - Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice. 5
5 Specifications
Optical input:
Sensitivity: Better than –25dBm
Optical wavelength: 1200nm – 1610nm
Transmission circuit fibre: Single mode 9/125um compatible
Return loss: >40dB with single mode fibre
Detector damage threshold: >+1dBm
Max input power: -6 dBm
Connector: SC/UPC
Optical output:
Transmission circuit fibre: Single Mode
Light source: F-P/DFB Laser
Optical wavelength: See Laser Options below
Ethernet:
10BaseT/100BaseTx/1000BaseT on RJ-45 connectors, compliant with IEEE 802.3, IEEE 802.3u and
IEEE 802.3z, speed auto sensing and auto MDI/MDI-X. ETH1000MC supports jumbo frames up to
16000 bytes.
Electrical
Power: +5V DC/2W
Control: Control system for access to setup and module status with BITE
(Built-In Test Equipment)

ETH1000MC Rev. 6
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] - Fax: [phone]
E-mail: [email protected] - Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice. 6
6 Laser options
The ETH1000MC card is available in these versions:
Part number Wavelength Laser type Output power Receiver sensitivity
ETH1000MC-13T, -7.5dBm 1310 ±40 nm Fabry-Perot -7.5 dBm Better than –25 dBm
ETH1000MC-C1270, 0dBm 1270 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1290, 0dBm 1290 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1310, 0dBm 1310 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1330, 0dBm 1330 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1350, 0dBm 1350 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1370, 0dBm 1370 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1390, 0dBm 1390 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1470, 0dBm 1470 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1490, 0dBm 1490 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1510, 0dBm 1510 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1530, 0dBm 1530 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1550, 0dBm 1550 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1570, 0dBm 1570 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1590, 0dBm 1590 ±6 nm DFB 0 dBm Better than –25 dBm
ETH1000MC-C1610, 0dBm 1610 ±6 nm DFB 0 dBm Better than –25 dBm

ETH1000MC Rev. 6
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] - Fax: [phone]
7 Connector module
.
The ETH1000MC has a dedicated connector module:
ETH1000MC-C1. This module is mounted at the rear of the sub-
rack
7.1 Mounting the connector module
The details of how the connector module is mounted, is found in the
user manual for the sub-rack frame FR-2RU-10-2.
This manual is also available from our web site:
http://www.network-electronics.com/
E-mail: [email protected] - Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice. 7

ETH1000MC Rev. 6
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] - Fax: [phone]
8 Status indicators
8.1 Front Panel LEDs
The status of the module can be easily monitored visually by
the LED’s at the front of the module
LED Description Green light Yellow light Red light No light
STAT Module
status Module self-test is OK and power is
present.
•Module initialising
(takes approx. 2 sec).
•The laser is turned off.
•Module is faulty (fuse
blown, laser failure,
laser APC out of lock,
etc). The card needs
factory repairment.
Module has no
power.
LOS Loss of
optical
signal
Optical input signal
present. Note: This is
an optical
measurement, a green
light does not imply
that there exists a
valid Ethernet signal
on the optical input.
•No optical input
signal.
•Check fibre
connection.
•Check card in
opposite end.
LINK Ethernet link Ethernet link to
opposite end
established at
1000Mbit
Ethernet link to
opposite end
established at
10 or 100Mbit
Ethernet link to
opposite end
not established.
ACT Ethernet
activity Flashes when Ethernet packets are
sent over the fibre
link. When the
Ethernet activity is
high, this will be on
continuously.
The fibre link is
idle, no packets
are sent on the
link.
E-mail: [email protected] - Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice. 8

ETH1000MC Rev. 6
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] - Fax: [phone]
8.3 Dip switches
The tables below explains the functionality of the dipswitches shown in the below figure.
Dip sw # 1
Dip sw # 8
Dip switch # Description
1 Enable 10Mbit
2 Enable 100Mbit
3 Enable 1000Mbit (GbE)
4 Reserved
5 Reserved
6 Reserved
7 Reserved
8 Gyda override/DIP
When DIP switch 1,2 and 3 are all on or all off, highest speed possible will be used when link
connection.
Switch 1 disables 10Mbit connection when DIP is closest to board edge. Switch 2 enables/disables
100Mbit and switch 3 enables/disables 1000Mbit.
Dip 4, 5, 6 and 7 are reserved.
Dip 8 sets if Gyda is able to configure or not. When Gyda override is set, the actual setting can be read by
using the info command (se Gyda user manual for details).
E-mail: [email protected] - Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice. 9

ETH1000MC Rev. 6
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] - Fax: [phone]
9 Laser safety precautions
Guidelines to limit hazards from laser exposure:
Note: All the available EO (including ETH1000MC) units in the flashlink®range include a laser.
Therefore this note on laser safety should be read thoroughly.
The lasers emit light at wavelengths around 1310 nm or 1550 nm. This means that the human eye cannot
see the beam, and the blink reflex cannot protect the eye. (The human eye can see light between 400 nm
to 700 nm).
A laser beam can be harmful to the human eye (depending on laser power and exposure time). Therefore:
!! BE CAREFUL WHEN CONNECTING / DISCONNECTING FIBRE PIGTAILS (ENDS).
NEVER LOOK DIRECTLY INTO THE PIGTAIL OF THE LASER/FIBRE.
NEVER USE MICROSCOPES, MAGNIFYING GLASSES OR EYE LOUPES TO LOOK INTO A
FIBRE END.
USE LASER SAFETY GOGGLES BLOCKING LIGHT AT 1310 nm AND AT 1550 nm
Instruments exist to verify light output power: Power meters, IR-cards etc.
flashlink®features:
All the laser module cards in the flashlink®product range, are Class 1 laser products according to
IEC 825-1 1993, and class I according to 21 CFR 1040.10 when used in normal operation.
More details can be found in the user manual for the FR-2RU-10-2 frame.
Maximum output power*: 5 mW.
Operating wavelengths: > 1270 nm.
*Max power is for safety analysis only and does not represent device performance.
