Network Electronics Flashlink SDI-EO-2 User manual

network-electronics.com
Dual SDI Electrical to Optical
Converter
Rev. 2
Flashlink User Manual
SDI-EO-2 / SDI-EO-2-RC

SDI-EO-2 /SDI-EO-2-RC Rev. 2
Network Electronics ASA
Thorøya
P.O. Box 1020
Sandefjord, Norway
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
www.network-electronics.com
Service Phone: [phone]
Revision history
Current revision of this document is the uppermost in the table below.
Revision Replaces Date Change description
2 1 2007-10-05 Added Materials Declaration and EFUP
1 0 18/11/05 Version with reclocker added (SDI-EO-2-RC)
0 A 30/08/05
First official release, also including updated
drawings and text.
A - 01/06/04 Preliminary version.
2

SDI-EO-2 /SDI-EO-2-RC Rev. 2
Contents
Revision history............................................................................... 2
1 Product overview......................................................................... 4
1.1 Product versions ..........................................................................................5
2 Specifications .............................................................................. 6
2.1 Optical output.............................................................................................6
2.2 Electrical ......................................................................................................6
2.3 Electrical input.............................................................................................6
2.4 Electrical output ..........................................................................................7
2.5 Standards ....................................................................................................7
3 Format configuration................................................................... 8
4 Connector module ...................................................................... 9
4.1 Mounting the connector module ................................................................9
4.2 Terminal format support............................................................................10
5 Module status............................................................................ 11
5.1 GPI Alarm – Module status outputs............................................................11
5.2 Front panel – Status monitoring ................................................................12
6 Laser safety precautions ............................................................. 13
General environmental requirements for Flashlink equipment....... 14
Certificate of Conformity .............................................................. 15
Product Warranty ......................................................................... 16
Materials declaration and recycling information............................ 17
Materials declaration .................................................................... 17
Environmentally-friendly use period.............................................. 17
Recycling information................................................................... 18
3

SDI-EO-2 /SDI-EO-2-RC Rev. 2
1Product overview
The Flashlink SDI-EO-2 /SDI-EO-2-RC is an electrical to optical converter
module providing high performance media conversion for various signal
formats from 19.4Mbps up to 540Mbps. Unmatched signal accuracy, even in
critical applications with pathological signal patterns makes the SDI-EO-2 /
SDI-EO-2-RC the first choice for all optical transport demands.
There are two versions of this product, SDI-EO-2 and SDI-EO-2-RC. SDI-EO-2-
RC has reclockers for each channel and cross point functionality. SDI-EO-2
comes without the reclockers and the cross point switch.
The SDI-EO-2 / SDI-EO-2-RC can transport all SD signal formats in addition to
DVB-ASI and SMPTE 310. It performs optical refreshing. High quality optical
transmitters using Fabry-Perot lasers are suitable short and medium haul
applications. The open system platform of Network Electronics Flashlink
system allows easy interoperability with third party fibre optical systems.
The SDI-EO-2 / SDI-EO-2-RC unit has also one electrical output for each
channel, which reduces the need for additional DAs. The electrical input is
equipped with a multi rate cable equaliser providing an equalisation of
typically 300m of high quality coax cable at 270Mbps.
Figure 1: SDI-EO-2-RC Dual SDI E/O converter. Please note that 2x2 cross point switch and
reclockers are not implemented in SDI-EO-2.
4

SDI-EO-2 /SDI-EO-2-RC Rev. 2
1.1 Product versions
SDI-EO-2 is available in the following versions:
Part No. Wavelength Laser type Output power
SDI-EO-2-13T
-7.5dBm 1310 nm F-P -7.5 dBm
SDI-EO-2-15T 0dBm 1550 nm DFB 0 dBm
SDI-EO-2-C1xxx 1xxx nm DFB 0 dBm
In addition, SDI-EO-2-RC xxxxxxxx also contains reclockers and cross point
functionality.
5

SDI-EO-2 /SDI-EO-2-RC Rev. 2
2Specifications
2.1 Optical output
Transmission circuit fibre 9/125µm Single Mode
Light source F-P / DFB laser
Optical power -7.5dBM @ 1310nm (F-P laser)
0 dBm (DFB laser)
Optical centre wavelength 1310nm or 1550nm.
Max. wavelength drift ±20nm (F-P lasers)
±6nm (DFB lasers)
Temperature range 0 - +50 ºC
Jitter (UI = Unit Interval) Max. 0.135UI @ 270Mbps
Connector return loss >40dB w/ SM fibre
Max. reflected power 4%
Connector SC/UPC
2.2 Electrical
Power +5V DC / 2.5W Max (SDI-EO-2)
+5V DC / 3.5W Max (SDI-EO-2-RC)
Control Control system for access to setup and module status
with BITE (Built-In Test Equipment)
2.3 Electrical input
Data rate NRZ 19.4 – 540 Mbps
Equalisation Automatic, cable equaliser and reclocker can be
bypassed to support bitrates down to 2Mbps. Reclocker
is only available in the SDI-EO-2-RC version
Impedance 75 ohm
Return loss >15dB @ 540MHz
Signal level Nom. 800mV
Connector BNC
6

SDI-EO-2 /SDI-EO-2-RC Rev. 2
2.4 Electrical output
Number of outputs 1
Connector BNC
Impedance 75 ohms
Return loss >15dB @ 540MHz
Jitter (UI = Unit Interval) Max. 0.2UI
Peak to peak signal level 0.8V ±0.1V
Signal polarity Non-inverting
2.5 Standards
Supported standards for electrical and optical ports:
SMPTE: SMPTE 259M, SMPTE 297M, SMPTE 305M, SMPTE 310M.
DVB-ASI: EN50083-9.
7

SDI-EO-2 /SDI-EO-2-RC Rev. 2
3Format configuration
The SDI-EO-2 can support a number of different broadcast formats. The
correct configuration can either be set with DIP switch or with the GYDA-SC
System Controller. The layout of SDI-EO-2 is shown in the drawing below with
the DIP switch to the upper left position.
Figure 2: SDI-EO-2 board layout.
DIP switch configuration must be set according to the table below:
Switch # Label Function, DIP = ON Function, DIP = OFF Comment
1 RCL1 Reclocker 1 ON Reclocker 1 OFF RC version only
2 EQ1 Automatic Cable
Equaliser ON
Automatic Cable
Equaliser OFF
Cable equaliser mode
3 ASI1 DVB-ASI Reclocker
support
SDI 177Mbps Reclocker
support
RC version only
4 RCL2 Reclocker 2 ON Reclocker 2 OFF RC version only
5 EQ2 Automatic Cable
Equaliser ON
Automatic Cable
Equaliser OFF
Cable equaliser mode
6 ASI2 DVB-ASI Reclocker
support
SDI 177Mbps Reclocker
support
RC version only
7 SWP Normal operation Swap input 1 and input
2
RC version only
8 OVR Override GYDA-SC
control.
Configuaration with
DIP switch
GYDA-SC control.
Configuration with
GYDA-SC
Select configuration
from GYDA-SC
All DIP switches are off when pointing towards the release handle.
The SWP DIP switch sets normal mode(input 1 to output 1 and input 2 to
output 2) or crossed mode (input 1 to output 2 and input 2 to output 1).
GYDA-SC System Controller can set other combinations like duplication of
either input channel to both output channels.
8

SDI-EO-2 /SDI-EO-2-RC Rev. 2
4Connector module
The SDI-EO-2 / SDI-EO-2-RC has a dedicated connector module: HD-EO-2-C1.
This module is mounted at the rear of the frame. The module is shown in the
figure below.
Figure 3: Connector module for SDI-EO-2.
In typical use, a SDI-EO-2(-RC) / SDI-OE-2(-RC) module at each end will be
used. Two channels can simultaneously be converted from optical to electrical
channels. The electrical input signal is connected to the INx input on the
transmitting SDI-EO-2(-RC), and the electrical output is connected to the
corresponding OUTx+ or OUTx- output BNC on the receiving SDI-OE-2(-RC).
The fibre cable is connected to the corresponding optical port (OPT1 uses
IN1/OUT1- and OUT1+ and OPT2 uses IN2/OUT2- and OUT2+).
4.1 Mounting the connector module
The details of how the connector module is mounted, is found in the user
manual for the Flashlink frame FR-2RU-10-2.
This manual is also available from our web site:
http://www.network-electronics.com/.
9

SDI-EO-2 /SDI-EO-2-RC Rev. 2
4.2 Terminal format support
The different input and output ports on SDI-EO-2 / SDI-EO-2-RC can support
a number of formats. The table below shows which signal formats are
supported on the selected terminals.
Terminal format support:
Terminal Function Supported Format Mode Connector
OPT1
OPT2
Optical output SDI, DVB-ASI, SMPTE310 Output SC/UPC
IN1
IN2
Electrical Input SDI, DVB-ASI, SMPTE310 Input BNC
OUT1
OUT2
Electrical Output SDI, DVB-ASI, SMPTE310 Output BNC
GPI ALARM Open Collector
Alarms
Wired alarms OC Output RJ45
10

SDI-EO-2 /SDI-EO-2-RC Rev. 2
5Module status
The status of the module can be monitored in three ways.
1. GYDA-SC System Controller (optional)
2. GPI at the rear of the frame
3. LEDs at the front of the frame
Of these three, the GPI and the LEDs are mounted on the module itself,
whereas the GYDA-SC System Controller is a separate module giving detailed
information on the card status. The functions of the GPI and the LEDs are
described in sections 5.1 and 5.2. The GYDA-SC System Controller is
described in a separate user manual.
5.1 GPI Alarm – Module status outputs
These outputs can be used for wiring up alarms for third party control
systems. The GPI outputs are open collector outputs, sinking to ground when
an alarm is triggered. The GPI connector is shown in figure below.
SDI-EO-2 module GPI pinning:
Signal Name Pin # Mode
Status General error status for the module Pin 1 Open Collector
LOS1 Loss of Signal 1 Pin 2 Open Collector
LOS2 Loss of Signal 2 Pin 3 Open Collector
Laser fail Laser fail Pin 4 Open Collector
Ground 0 volt pin Pin 8 0V
Figure 4: GPI output.
Electrical Maximums for GPI outputs
Max current: 100mA
Max voltage: 30V
11

SDI-EO-2 /SDI-EO-2-RC Rev. 2
5.2 Front panel – Status monitoring
The status of the module can be easily monitored visually by the LEDs at the
front of the module. The LEDs are visible through the front panel as shown in
the figure below.
Figure 5: Front panel indicators for the SDI-EO-2.
The SDI-EO-2 has four LEDs each showing a status corresponding to the GPI
pinning.
Diode \ State Red LED Green LED Orange LED No light
Status Module is faulty,
or module is
initialising
Module is OK
Module power is
OK
Module has no
power
LOS1 Loss of optical
modulated signal
Signal is present
For RC version:
Reclocker is locked
Signal is present,
but reclocker is
out of lock (RC
version only)
LOS2 Loss of optical
modulated signal
Signal is present.
For RC version:
Reclocker is locked
Signal is present,
but reclocker is
out of lock (RC
version only)
LASER FAIL Fail on both lasers Lasers ok Fail on one laser
12

SDI-EO-2 /SDI-EO-2-RC Rev. 2
6Laser safety precautions
A guideline to limit hazards from laser exposure follows:
All the available EO units in the Flashlink range include a laser.
Therefore, please read the note on laser safety thoroughly.
The lasers emit light wavelength greater than 1270 nm. This means that the
human eye cannot see the beam, and the blink reflex cannot protect the eye.
(The human eye can see light between 400 nm to 700 nm).
A laser beam can be harmful to the human eye (depending on laser power
and exposure time), therefore:
Instruments exist to verify light output power: Power meters, IR-cards etc.
Flashlink features:
All the laser module cards in the Flashlink product range, are Class 1 laser
products according to IEC 825-1 1993, and class I according to 21 CFR
1040.10 when used in normal operation.
Please look at the user manual for more details regarding the FR-2RU-10-
2 frame.
Maximum output power1: 5 mW.
Operating wavelengths: > 1270 nm.
Note!
BE CAREFUL WHEN CONNECTING / DISCONNECTING FIBRE
PIGTAILS (ENDS).
NEVER LOOK DIRECTLY INTO THE PIGTAIL OF THE
LASER/FIBRE.
NEVER USE MICROSCOPES, MAGNIFYING GLASSES OR EYE
LOUPES TO LOOK INTO A FIBRE END.
USE LASER SAFETY GOGGLES BLOCKING LIGHT AT
1310 nm AND AT 1550 nm.
< 5mW
>1270nm
1Max power is for safety analysis only and does not represent device performance.
13

SDI-EO-2 /SDI-EO-2-RC Rev. 2
General environmental requirements for Flashlink equipment
1. The equipment will meet the guaranteed performance specification under the
following environmental conditions
- Operating room temperature range 0°C to 40°C
- Operating relative humidity range < 90% (non-condensing)
2. The equipment will operate without damage under the following environmental
conditions
- Temperature range -10°C to 55°C
- Relative humidity range < 95% (non-condensing)
3. Electromagnetic compatibility conditions:
- Emissions EN 55103-1 (Directive 89/336/EEC)
- Immunity EN 55103-2 (Directive 89/336/EEC)
14

SDI-EO-2 /SDI-EO-2-RC Rev. 2
Certificate of Conformity
Network Electronics ASA
N-3204 Sandefjord
Norway
Company Registration Number:
NO 976 584 201 MVA
Declares under sole responsibility that the product:
Product Name SDI-EO-2
Product Description Dual SDI Electrical to Optical
Converter
To which this declaration relates are of Norwegian origin and are in conformity with
the following standards:
EN 55103-1: 1996 Generic Emissions Standard
EN 55103-2: 1996 Generic Immunity Standard
15

SDI-EO-2 /SDI-EO-2-RC Rev. 2
Product Warranty
The warranty terms and conditions for the product(s) covered by this manual follow the
General Sales Conditions by Network Electronics ASA. These conditions are available
on the company web site of Network Electronics ASA:
www.network-electronics.com
16

SDI-EO-2 /SDI-EO-2-RC Rev. 2
Materials declaration and recycling information
Materials declaration
For product sold into China after 1st March 2007, we comply with the “Administrative
Measure on the Control of Pollution by Electronic Information Products”. In the first
stage of this legislation, content of six hazardous materials has to be declared. The table
below shows the required information.
Toxic or hazardous substances and elements
組成名稱
Part Name
鉛
Lead
(Pb)
汞
Mercury
(Hg)
镉
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(Cr(VI))
多溴联苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
SDI-EO-2 X O O O O O
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for
this part is below the limit requirement in SJ/T11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous
materials used for this part is above the limit requirement in SJ/T11363-2006.
Environmentally-friendly use period
The manual must include a statement of the “environmentally friendly use period”.
This is defined as the period of normal use before any hazardous material is released to
the environment. The guidance on how the EFUP is to be calculated is not finalised at
the time of writing. See
http://www.aeanet.org/GovernmentAffairs/qfLeOpAaZXaMxqGjSFbEidSdPNtpT.pdf
for an unofficial translation of the draft guidance. For our own products, Network
Electronics has chosen to use the 50 year figure recommended in this draft regulation.
Network Electronics suggests the following statement on An “Environmentally Friendly
Use Period” (EFUP) setting out normal use:
EFUP is the time the product can be used in normal service life without leaking the hazardous materials.
We expect the normal use environment to be in an equipment room at controlled temperature range
(0ºC - 40ºC) with moderate humidity (< 90%, non-condensing) and clean air, not subject to vibration or
shock.
Further, a statement on any hazardous material content, for instance, for a product that
uses some tin/lead solders:
Where a product contains potentially hazardous materials, this is indicated on the product by the
appropriate symbol containing the EFUP. The hazardous material content is limited to lead (Pb) in some
solders. This is extremely stable in normal use and the EFUP is taken as 50 years, by comparison with the
EFUP given for Digital Exchange/Switching Platform in equipment in Appendix A of “General Rule of
Environment-Friendly Use Period of Electronic Information Products”. This is indicated by the product
marking:
50
17

SDI-EO-2 /SDI-EO-2-RC Rev. 2
It is assumed that while the product is in normal use, any batteries associated with real-time clocks or
battery-backed RAM will be replaced at the regular intervals.
The EFUP relates only to the environmental impact of the product in normal use, it does not imply
that the product will continue to be supported for 50 years.
Recycling information
Network Electronics provides assistance to customers and recyclers through our web
site http://www.network-electronics.com. Please contact Network Electronics’
Customer Support for assistance with recycling if this site does not show the
information you require.
Where it is not possible to return the product to Network Electronics or its agents for
recycling, the following general information may be of assistance:
Before attempting disassembly, ensure the product is completely disconnected from
power and signal connections.
All major parts are marked or labelled to show their material content.
Depending on the date of manufacture, this product may contain lead in solder.
Some circuit boards may contain battery-backed memory devices.
18
