NeuLog NUL-204 User manual

NEULOG LIGHT LOGGER SENSOR GUIDE
NeuLog light logger sensor
NUL-204
The Light Sensor can be used for any science experiment where light intensity
measurements are required for Chemistry, Physics, Biology, Environmental Science,
etc.
The sensor comes pre-calibrated so you can start experimentation right out of the box
using this guide.
This sensor can be used to take light measurements in low, medium and high light
intensity environments such as in classrooms and in open sunlight. The sensor can be
used to measure both fast light changes such as those produced by light bulbs
connected to an AC supply, as well as the light intensity of the bulb or near steady
levels outside on a sunny day.
Among hundreds of possible experiments that can be performed with the NUL-204
sensor are: Monitoring daily light levels in ecological systems, studying
photosynthesis, chemical reactions where light is emitted, studying the effect of
changing the voltage on the intensity of a light source and light intensity with varying
distances and mediums.
The measurement unit for all three data collection ranges (low, medium, high) is the
lux.
Lux (lx, or lux): The SI unit of light intensity.
Quick start procedure:
PC or Mac Computer
Materials needed:
NUL-204 Light Sensor
USB-200 USB Module
USB to mini USB cable (included with the USB-200 module)
Your light sensor needs to be connected to a USB-200 module. The USB-200 module
then connects to a computer via a USB to mini-USB cable. Please note that you
cannot plug the light sensor directly into the computer.
The browser based application can be downloaded for free at www.NeuLog.com as
well as a full application user guide.
Choose "Downloads" on the main menu and then choose "Software and Application".
Procedure:
1. Install the NeuLog application.
2. Connect the USB-200 module to the PC or Mac.
3. Connect the light sensor to the USB-200 module (they directly plug together).
Please note that no calibration is required for this sensor.
4. Open the NeuLog application by clicking on the shortcut on the screen.
5. Once a light sensor module box appears on the left side of the screen the probe
has been automatically identified and you can begin experimentation.
6. If the light sensor is not automatically identified, click the “Search for sensors”
icon to find the sensor.
7. Click on the “On-line experiment” icon; this will open a graph below.
8. Click on the “Module setup” button located on the light sensor module box to
change the sensor's settings if need be.
9. Click on the experiment set up icon to change the experiment settings if need be
(experiment duration for example).
10. The light sensor will give a live reading in its module box to the left of the screen
while plugged in.
11. To run an experiment and collect data, click the “Run experiment” icon.
12. To end data collection early, click the “Stop experiment” icon.
Tablet, smart phone device
Materials needed:
NUL-204 Light Sensor
WIFI-201 WiFi Module
BAT-200 Battery Module
Your light sensor needs to be connected to a WIFI-201 module. The WIFI-201 module
will create a closed NeuLog WiFi network which will stream the NeuLog data to the
device of your choosing. Once your device is wirelessly connected to the NeuLog
network, you can run experiments and collect data through a browser of your
choosing.

NEULOG LIGHT LOGGER SENSOR GUIDE
Procedure:
1. Connect the light sensor directly to the left side of a WIFI-201 module (no wires
required).
2. Connect a BAT-200 module to the right side of the WIFI-201 module.
3. Although not required, we recommend plugging the BAT-200 to an outlet using a
USB to mini USB charger (such as a typical cell phone charger). The WIFI-201
module will run for 60-90 minutes (depending on the sensor) without being
plugged in.
4. The WIFI-201 can be powered directly using a mini to USB cord and plugging it
into your computer or a wall charger. Please note this function is only available
on WIFI-201 units with the USB icon on the cover.
5. For further WIFI-201 instructions or the WIFI-201 quick start guide please visit:
www.NeuLog.com; Choose "Products" on the main menu,
then choose "WiFi Communication module".
6. The WIFI-201 indicator lights will flash; take no action until the LED to the far left
turns blue; this can take up to one minute.
7. Take your tablet or smart phone, go to the WiFi settings and select the NeuLog
network (NeuLog0184 for example) which matches the ID found on the back of
the WIFI-201 module (0184 for example).
8. Give your device about 20 seconds to connect to the WIFI-201 module.
9. Once the device is connected, go to your browser and type the website
wifi201.com into the URL bar, then wait for 30-60 seconds.
10. You will see a “Control mode” icon in the application, click on it.
11. The application will then load a new screen and begin to auto detect the
sensor(s); this can take a minute. (You can stop the search when the sensor is
found.)
12. If the application does not auto detect the sensor(s), select “Search for sensors”.
13. Once the sensor is found, you will see a module box on the left side of the
screen for the light sensor. In this box, real time data will be displayed.
14. Click on the “Module setup” button located in the light sensor module box to
change the light probe settings if need be.
15. Click on the “Experiment setup” icon to change the experiment settings if need
be (Experiment duration for example).
16. To run an experiment and collect data, click on the “On-Line” experiment icon,
then click the "Run experiment" icon.
17. If you have a newer generation WIFI-201 module (with the USB icon on the
cover) this can be used as a USB-200, meaning you can tether the probes
directly to the computer using the WIFI-201. To engage operation in this fashion,
press 3 times on the panel button. Repeating this operation will return the unit to
WiFi mode.
Operation with NeuLog Graphic Display Module (viewer)
Materials needed:
NUL-204 Light Sensor
VIEW-101 Graphic Display Module
BAT-200 Battery Module
Procedure:
1. Connect the light sensor to the left side of the viewer.
2. Connect the BAT-200 module to the right side of the viewer.
3. The VIEW-101 will auto detect the sensor and you will see it appear on the left
side of the screen.
4. Once the sensor appears, it will be monitoring data in real time.
5. To run an experiment and collect data, press the run icon (little green person).
Off-line experiments
(Off-line experiments are when you do not have a sensor connected directly to a
computer, tablet, smartphone, or NeuLog viewer).
Materials needed:
NUL-204 Light Sensor
BAT-200 Battery Module
Materials needed to configure your offline experiment:
USB-200 Module, WIFI-201 module or VIEW-101 Module
USB to mini USB cable (included with the USB-200 module)
Procedure:
1. To determine the experiment settings, first connect to your chosen device (PC,
Mac, tablet, smart device) and click on the “Off-line experiment” icon after the
sensor search has ended. (For more information on how to change the
experiment settings, view the quick start procedure section for your chosen
device in this document.)
2. Connect the light sensor directly to the left side of a charged BAT-200 module.
3. When ready to collect data, press the “Start/Stop” button on the light sensor; a
red light will turn on for the duration of the experiment.

NEULOG LIGHT LOGGER SENSOR GUIDE
4. After the experiment has concluded (the “Start/Stop” button is pressed again or
the data collection period ends) connect the sensor to your chosen device (you
can find full instructions in each device’s quick start procedure section).
5. Open the NeuLog application.
6. Click the “Off-line experiment” icon.
7. Click the “Load data from sensors” icon.
8. Select which experimental data to upload (5 experimental runs can be stored at
one time on the NUL-204 light sensor).
Restoring sensor’s factory default settings:
Procedure:
1. Connect the USB-200 to a PC, Mac, tablet, or smart device.
2. Connect the light sensor to a USB-200 module (they directly plug together).
3. Open the NeuLog application.
4. Click the “Tools” icon.
5. Click the “Restore sensor’s factory defaults” on the menu.
Included with the sensor:
NeuLog NUL-204 Light Sensor Guide (this document)
Sensor specifications:
Range and
operation modes
(in lx)
ADC
resolution
Resolution
Max
sample
rate
(S/sec)
0 to 1,000
16 bit
1 lx
3000
0 to 6,000
1 lx
0 to 150,000
6 lx
Experiment Duration: 50 milliseconds to 31 days.
Sensor's features:
Fully digital data
Rugged plastic ergonomic case
Push button switch for Start/Stop experiments in off line mode
LED indicator of experiment status (blinks while collecting data)
Pre-calibrated sensing equipment
Note: NeuLog products are intended for educational use.
Videos and experiment examples:
Videos, literature and other probes can be found at www.NeuLog.com.
In order to access the light sensor's page, choose "Products" on the main menu
and then "Light logger sensor".
In order to find the science experiments, choose "Experiments" on the main
menu of the NeuLog website, then choose "Physics", "Chemistry", "Biology" or
"Environmental Science".
Physics Experiments:
oHow Incandescent Light Bulbs Work? (P-11)
oColors of Light (P-40)
oLight and Shadow (P-41)
oLight and Dark Colors (P-42)
Environmental Science Experiments:
oRayleigh Scattering (E-6)
Technical background:
The philosophy behind NeuLog’s plug and play technology is based on each sensor’s
ability to store its own data due to an internal flash memory chip and micro-controller
in each plastic NeuLog body. This technology allows the sensor to collect and then
store the digital data in the correct scientific units (oC, oF, Lux, %, ppm, for example).
The sensor is pre-calibrated at the factory. The built-in software in the logger can be
upgraded for free at any time using the provided firmware update.
Inside the hard plastic casing, lies a photodiode which reacts with photons to release
free electrons (photoelectrons). The amount of light striking the sensor is directly
proportional to the voltage generated by the photoelectrons released. The sensor
measures the general voltage released and thus calculates the light intensity.

NEULOG LIGHT LOGGER SENSOR GUIDE
If the light readout is very low, try changing the sensor's mode to a higher sensitivity.
This is done by selecting the “Module setup” button on the light sensor module box in
the NeuLog application.
The NUL-204 is able to adjust to 3 different sensitivity settings for ambient light
because of its ability to change the internal hardware amplifier gain through the
application.
Changing from illumination mode into signal mode is done automatically by the
firmware according to the sampling rate.
Maintenance and storage:
Never submerge the NeuLog plastic body in any liquid
Do not allow liquid into the light sensor’s body
After use, gently wipe away any foreign material from the light sensor
Store in a box at room temperature out of direct sunlight
Warranty:
We promise to deliver our sensor free of defects in materials and workmanship. The
warranty is for a period of 3 years from the date of purchase and does not cover
damage of the product caused by improper use, abuse, or incorrect storage. Should
you need to act upon the warranty, please contact your distributor. Your sensor will be
repaired or replaced.
