Nevir NVR-CB4P User manual

FULL SIZE COOKER WITH GAS
CYLINDER COMPARTMENT
MANUAL DO UTILIZADOR
USER MANUAL
PO
GB
FOGÃO DE TAMANHO REAL
COM COMPARTIMENTO PARA
GARRAFA DE GÁS
NVR-CB4P

2
Dear Customer,
Thank you for relying on this product.
We aim to allow you to optimally and efciently use this environment-
friendly product produced in our modern facilities under precise conditions
with respect to sense of quality in total.
We recommend that you read the user manual carefully and keep it
permanently before using the appliance so that it retains its original
features for a long time.
WARNING: This operating manual is prepared for mul-
tiple models. Your appliance may not feature some
functions specied in the manual.
WARNING: The gures in the manual are schematic
and may not be in exact harmony with your product.
This product has been produced in modern environment-friendly
facilities without harmfully affecting the nature.
WARNING: Features marked with * are optional.
"Complies with AEEE Regulation"
GB

3
Contents
Important warnings ......................................................... 4
Electrical safety.............................................................. 8
Gas safety ......................................................................10
Power connection ...........................................................13
Gas connection...............................................................14
Appliance introduction ....................................................19
Technical specications...................................................20
Setting up the appliance .................................................22
Control Panel .................................................................24
Appliance use.................................................................25
Maintenance and cleaning...............................................28
Troubleshooting .............................................................29
Handling rules................................................................30
Tips for saving energy......................................................30
Disposal of waste product................................................31
Packing information .......................................................31

4
IMPORTANT WARNINGS
1. Installation and repair should always be performed
by “AUTHORISED SERVICE”. Manufacturer shall not be
held responsible for operations performed by unauthor-
ised persons.
2. Please read this operating instructions carefully.
Only by this way you can use the appliance safely and
in a correct manner.
3. The appliance should be used according to operat-
ing instructions.
4. Keep children below the age of 8 and pets away
when operating.
5. WARNING: Fire hazard; do not store the materials on
the cooking surface.
6. WARNING: The appliance and its accessible parts are
hot during operation.
7. Setting conditions of this appliance are specied
on the label. (Or on the data plate)
8. The accessible parts may be hot when the grate is
used. Small children should be kept away.
9. WARNING: This appliance is intended for cooking. It
should not be used for other purposes like heating a room.
10. To clean the appliance, do not use steam cleaners.
11. NEVER try to put out the re with water. Only shut
down the appliance circuit and then cover the ame
with a cover or a re blanket.
GB

5
12. Children under 8 years of age should be kept away,
if they cannot be monitored continuously.
13. Touching the heating elements should be avoided.
14. CAUTION: Cooking process should be supervised.
Cooking process shall always be supervised.
15. The appliance is not suitable for use with an exter-
nal timer or a separate remote control system.
16. This appliance can be used by children over 8
years of age, people with physical, hearing or mental
challenges or people with lack of experience or knowl-
edge; as long as control is ensured or information is
provided regarding the dangers.
17. This appliance has been designed for household
use only.
18. Children should not play with the appliance.
Cleaning or user maintenance of the appliance shall
not be performed by children unless they are older than
8 years and supervised by adults.
19. Keep the appliance and its power cord away from
children less than 8 years old.
20. Put curtains, tulles, paper or any ammable (ignit-
able) material away from the appliance before starting
to use the appliance. Do not put ignitable or ammable
materials on or in the appliance.
21. Keep the ventilation channels open.
22. Do not heat closed cans and glass jars. The pres-
sure may lead jars to explode.

6
23. Do not use the appliance in states like medicat-
ed and/or under inuence of alcohol which may affect
your ability of judgement.
24. Check that the appliance is off after each use.
25. Be careful when using alcohol in your foods. Alco-
hol will evaporate at high temperatures and may catch
re to cause a re if it comes in contact with hot sur-
faces.
26. Do not operate the appliance if it is broken or vis-
ibly damaged.
27. Do not touch the plug with wet hands. Do not pull
the cord to plug off, always hold the plug.
28. Do not place objects that are accessible to chil-
dren on the appliance.
29. The packaging materials are dangerous for chil-
dren. Keep packaging materials away from the reach of
children.
30. The appliance should be disconnected during any
construction work in the house. After completing the
work, re-connecting the appliance should be done by
authorised service.
31. Do not place metal utensils such as knife, fork,
spoon on the surface of the appliance, since they will
get hot.
32. To prevent overheating, the appliance should not
be installed behind of a decorative cover.
GB

7
33. Turn off the appliance before removing the safe-
guards. After cleaning, install the safeguards according
to instructions.
34. Cable xing point shall be protected.
35. WARNING: If the glass of the appliance is broken,
turn off any heating element immediately and disconnect
the appliance from power source, do not touch the surface
of the appliance and do not use the appliance.
36. User should not handle the appliance by them-
selves.
37. The user should be careful when cleaning the up-
per hobs of the appliance. It may cause personal inju-
ries.
38. Since the appliance is hot during cooking or right
after cooking, scalding may occur due to extreme tem-
perature and steam.
39. Users may contact hot surfaces and burns may oc-
cur if the appliance is forgotten to be turned off during
cooking.
40. If heavier loads are placed on the appliance, the
loads may overturn. It may cause personal injuries.
41. Do not use the door and/or handle to carry or move
the appliance.

8
Electrical Safety
1. Plug the appliance in a grounded socket protect-
ed by a fuse conforming to the values specied in the
technical specications chart.
2. Have an authorised electrician set grounding equip-
ment. Our company will not be responsible for the dam-
ages that may occur due to using the appliance without
grounding according to local regulations.
3. WARNING: If the surface is cracked, turn off the appli-
ance to avoid risk of electric shock.
4. Never wash the appliance by spraying or pouring
water on it. There is a risk of electrocution.
5. Do not touch the plug with wet hands. Do not pull
the cord to plug off, always hold the plug.
6. Unplug the appliance during installation, mainte-
nance, cleaning, and repair.
7. Make sure the plug of the appliance is inserted
rmly into wall socket to avoid sparks.
8. If the power supply cord (the cord with plug) is
damaged, this cord shall be replaced by the manufac-
turer or its service agent or an equally qualied person-
nel to prevent a hazardous situation.
9. Do not use cut or damaged cords or extension cords
other than the original cord.
10. Do not use steam cleaners for cleaning the appli-
ance, otherwise electric shock may occur.
GB

9
11. Make sure that there is no liquid or humidity in
the outlet where the appliance plug is inserted.
12. The appliance should be installed in such a way
that the electrical installation can be completely dis-
connected. Disconnection from power supply shall be
provided with a switch or an integrated fuse installed
on xed power supply according to building code.
13. The power supply cable should not touch the hot
parts of the appliance.
14. Unplug the appliance during installation, mainte-
nance, cleaning, and repair.
15. The appliance is equipped with a type ‘’Y’’ cord cable.
16. The appliance circuit breaker switches should be
in the workplace accessible to the end user while the
appliance is in place.
17. Fixed connections shall be connected to a power
supply enabling omnipolar disconnection. For appli-
ances with over voltage category below III, disconnec-
tion device shall be connected to xed power supply
according to wiring code.
18. Do not remove ignition switches from the appli-
ance. Otherwise, live electric cables can be accessed.
It may cause an electric shock.

10
Gas Safety
1. This appliance is not connected to burning prod-
ucts evacuation apparatus. This appliance should be
connected and installed according to the installation
regulations in force. Conditions regarding ventilation
should be considered.
2. When a gas cooking appliance is used; humidity,
heat and burning products are generated in the room.
First, make sure the kitchen is well ventilated when op-
erating the appliance and maintain natural ventilation
openings or install a mechanical ventilation equipment.
3. After using the appliance heavily for en extended
period of time, additional ventilation may be required.
For example open a window or adjust a higher speed for
mechanical ventilation, if any.
4. This appliance should be used only in well venti-
lated locations in accordance with the regulations in
force. Please read the manual before installing or using
this appliance.
5. Before positioning the appliance, make sure local
network conditions (gas type and gas pressure) meets
appliance requirements.
6. The mechanism cannot be run for longer than 15
seconds. If the upper hob is not on after 15 seconds,
stop the mechanism and wait for at least one minute
before trying to ignite the upper hob again.
GB

11
7. All kinds of operations to be performed on gas in-
stallation should be performed by authorised and com-
petent people.
8. For proper operation, hood, gas pipe and clamp
should be replaced periodically according to manufac-
turer recommendations and when required.
9. Gas should burn well in gas appliances. Well burn-
ing gas can be understood from blue ame and contin-
uous burning. If gas does not burn sufciently, carbon
monoxide (CO) can be generated. Carbon monoxide is
a colourless, odourless and very toxic gas; even small
amounts have lethal effect.
10. Ask your local gas supplies about the phone num-
bers for emergencies related to gas and the measures
to be taken upon gas odour is detected.

12
What To Do When Gas Odour Is Detected
1. Do not use naked ame, and do not smoke.
2. Do not operate any electrical switch.
(For example: lamp switch or doorbell)
3. Do not use telephone or mobile phone.
4. Open the doors and windows.
5. Close all valves on the appliances that utilise gas
and the gas counters.
6. Call re brigade from a telephone outside the home.
7. Check all hoses and their connections against leaks.
If you still smell gas, leave the house and warn your
neighbours.
8. Do not enter into the house until authorities clarify
it is safe.
Intended Use
1. This appliance is designed for domestic use. Com-
mercial use of the appliance is not permitted.
2. This appliance should only be used for cooking pur-
poses. It shall not be used for other purposes like heat-
ing a room.
3. The manufacturer assumes no responsibility for any
damage due to misuse or mishandling.
4. The operational life of the appliance you have pur-
chased is 10 years. This is the period for which the
spare parts required for the operation of this appliance
as dened is provided by the manufacturer.
GB

13
Power Connection
This appliance should be installed and connected correctly according to
the manufacturer's instructions and by the authorised service.
The electrical connections of the appliance should only be made with
(grounded) sockets with a grounding system that is laid in accordance
with the rules. Contact an authorised electrician if there is no suitable
socket for the grounded system where your appliance will be placed. The
manufacturer is absolutely not responsible for the damages caused by the
ungrounded sockets connected to the appliance.
Your appliance should ground the plug; make sure the plug socket is
grounded. The plug should be placed within reach after installation.
Your appliance is manufactured in accordance with 220-240 V AC 50-
60 Hz. electrical supply. If your power network does not provide these
specications, contact an electrician or an authorised service.
Do not allow the power cord of your appliance to contact hot parts of the
appliance. Keep it away from sharp edges and corners.

14
Gas Connection
WARNING: Before starting any work related with gas
installation, turn off gas supply. Risk of explosion.
Check if the appliance settings are compatible with the local distribu-
tion conditions (gas type and gas pressure) before placing the appliance.
For LPG connection, attach the metal clamp
to the hose coming from the LPG cylinder.
Install one end of the hose by pushing it all
the way to the hose inlet record on the back
of the appliance by heating it in boiling
water. And tighten with a screwdriver by
bringing the clamp to the end of the hose.
The hose and gasket inlet record required
for connection is as follows.
For natural gas connection, place the gas-
ket in the nut at the end of the natural gas
connection hose. Turn the nut to attach the
hose to the main gas pipe. Check for gas
leakage and complete the connection. The
hose and gasket inlet record required for
connection is as follows.
WARNING: All kinds of work to be performed on gas
equipment and systems should be carried out by au-
thorised and qualied persons.
WARNING: Do not move a gas connected appliance.
Any force may cause gas leakage as it may loosen the
hose.
Main gas pipe
Gasket
Hose entry record
Metal clamp
LPG connection hose
Main gas pipe
Gasket
Nut
Natural gas connection
hose
GB

15
Conversion from Natural Gas to LPG or from LPG to Natu-
ral Gas
1. Switch off the gas and electricity of the appliance. If the appliance is
hot, wait for it to cool down.
2. Use a screwdriver with the tip as shown in gure 1 for injector
replacement.
3. Remove the burner cover and burner of the appliance as shown in
gure 2 and ensure that the injector is visible.
4. Remove the injector by turning it as shown in gure 3 with a screwdriver
and replace it with a new one.
Figure 1 Figure 2 Figure 3

16
Gas Hose Crossing Path
Connect your appliance to the gas mains cock in the shortest way and
without any leakage. The correct connection shape is shown in the gure
below.
Ensure that the buttons on the control panel are closed and the gas
cylinder is open for sealing and gasket safety control.
WARNING: Never use any lighters, matches, lit ciga-
rettes, or similar ammable materials when checking
for gas leakage.
Apply soap foam to the connection points. There will be foaming here if
there is a leak/leakage.
Ensure that the appliance is at the counter level when placing your
appliance in place.
Adjust the appliance to the counter level by adjusting the feet, if
necessary.
Use your appliance on a at surface and in a well-ventilated environment.
GB

17
LPG bottle sizes
WARNING: The LPG bottle to be used in this product
should comply with the table given below.
Country LPG Bottle Sizes
Spain
Portugal
Italy
France
Romania
55 cm
30 cm
52.5 cm
33.5 cm
65 cm
31.5 cm
52 cm
33 cm
55 cm
30 cm

18
GB
Room Ventilation
Air required for combustion is taken from the room air and gases
produced are returned directly to the room.
A good room ventilation is essential for the safe operation of your
appliance.
If there are no windows or doors to be used for room ventilation,
additional ventilation should be installed. However, if the room has a
door that opens directly to the outside, there is no need for additional
ventilation systems.
Room size Ventilation opening
Less than 5 m³ min. 100 cm²
5 m³ to 10 m³ min. 50 cm²
Greater than 10 m³ is not necessary
In basement or cellar min. 65 cm²
Flame Output Speed Setting
First pull out the buttons on the control panel to do this. Adjust by
turning the screw in the middle of the gas cocks with a small screwdriver,
as shown in the picture below. Use a screwdriver of appropriate size to
adjust the ow adjustment screw. Turn the screw clockwise. Reverse the
procedure to make the appropriate adjustment and reinsert the buttons.
A normal ame length in the low position should be 6-7 mm. Check if the
ame is on or off for the last check.

19
APPLIANCE INTRODUCTION
1. Upper hobs
2. Control panel
3. Cabinet door
4. Large burner
5. Middle burner
6. Small burner *
7. Wok burner *
8. Coffee adapter (coffee pot) *
9. Wok burner adapter *
10. Grate
6
54
7
1
2
3
8 9
10

20
Technical Specication Tables
By gas type
upper hob
specications
G30,28-30 mbar
G31,37 mbar G30.50 mbar G30.37 mbar
LPG LPG LPG
Wok burner
(3.5)
Injector 0.96 mm 0.76 mm 0.96 mm
Gas ow 254 g/h 254 g/h 254 g/h
Power 3.50 kW 3.50 kW 3.50 kW
Wok burner
(1.9)
Injector 0.68 mm 0.60 mm 0.65 mm
Gas ow 182 g/h 182 g/h 182 g/h
Power 1.90 kW 1.90 kW 1.90 kW
Large
burner
Injector 0.85 mm 0.75 mm 0.85 mm
Gas ow 211 g/h 211 g/h 211 g/h
Power 2.90 kW 2.90 kW 2.90 kW
Medium
burner
Injector 0.65 mm 0.60 mm 0.65 mm
Gas ow 124 g/h 124 g/h 124 g/h
Power 1.70 kW 1.70 kW 1.70 kW
Small
burner
Injector 0.50 mm 0.43 mm 0.50 mm
Gas ow 69 g/h 69 g/h 69 g/h
Power 0.95 kW 0.95 kW 0.95 kW
By gas type
upper hob
specications
G20,20 mbar
G25,25 mbar G20,25 mbar
Natural gas Natural gas
Wok burner
(3.5)
Injector 1.40 mm 1.28 mm
Gas ow 0.333 m³/h 0.333 m³/h
Power 3.50 kW 3.50 kW
Wok burner
(1.9)
Injector 1.05 mm 1.05 mm
Gas ow 0.196 m³/h 0.196 m³/h
Power 1.90 kW 1.90 kW
Wok burner
(2.4)
Injector 1.15 mm 1.10 mm
Gas ow 0.243 m³/h 0.243 m³/h
Power 2.40 kW 2.40 kW
Large
burner
Injector 1.15 mm 1.10 mm
Gas ow 0.276 m³/h 0.276 m³/h
Power 2.90 kW 2.90 kW
Medium
burner
Injector 0.97 mm 0.92 mm
Gas ow 0.162 m³/h 0.162 m³/h
Power 1.70 kW 1.70 kW
Small
burner
Injector 0.72 mm 0.70 mm
Gas ow 0.96 m³/h 0.96 m³/h
Power 0.95 kW 0.95 kW
Supply voltage 220-240 V AC 50-60 Hz.
GB
