Top-Loading Water Dispenser
(MCWD30TS)

Magic Chef® Water Dispenser Product Guide
2
Introduction
Please observe the regulations and laws in the country of use.
Before using your water dispenser, please read this manual carefully.
Incorrect operation can result in serious damage or injury.
Need to Contact Us?
WEBSITE:
www.newair.com
SUPPORT EMAIL ADDRESS:
[e-mail]
TELEPHONE NUMBER:
1-855-963-9247
Manufactured For:
MC Appliance Corp.
940 N. Central Ave.,
Wood Dale, IL 60191 USA
Magic Chef is a registered trademark of
CNA International, Inc. d/b/a
MC Appliance Corporation.
All rights reserved.
NewAir, LLC
6600 Katella Ave, Cypress, CA 90630
Comments/Questions:
[e-mail]

Magic Chef® Water Dispenser Product Guide
3
Contents
Register Your Product Online........................................................................................................................ 4
Safety Information & Warnings .................................................................................................................... 5
Parts List........................................................................................................................................................ 6
Installation & Setup ...................................................................................................................................... 7
Operation Instructions.................................................................................................................................. 9
Cleaning & Maintenance............................................................................................................................. 11
Troubleshooting.......................................................................................................................................... 12
Limited Manufacturer’s Warranty .............................................................................................................. 13
Product Specifications
MODEL: MCWD30TS
RATED VOLTAGE: 110-120V
FREQUENCY: 60 Hz
COOLING POWER: 80 W
HEATING POWER: 500 W
BPA FREE: Yes

Magic Chef® Water Dispenser Product Guide
4
Register Your Product Online
Register Your Magic Chef® Product Online Today!
Take advantage of all the benefits product registration has to offer:
Service and Support
Diagnose troubleshooting and service issues faster and more accurately
Recall Notifications
Stay up to date on safety, system updates and recall notifications
Special Promotions
Opt-in for Magic Chef® promotions and offers
Registering your product information online is safe & secure and takes less than 2 minutes to complete:
Alternatively, we recommend you attach a copy of your receipt below and record the following
information, which can be found located on the manufacturer’s nameplate on the rear of the unit. You
will need this information if it becomes necessary to contact the manufacturer for a service inquiry.
Date of Purchase: ___________________________________________
Serial Number: ____________________________________________
Model Number: ____________________________________________
newair.com/register

Magic Chef® Water Dispenser Product Guide
5
Safety Information & Warnings
To reduce the risk of fire, electrical shock and/or injury to persons or property, please follow the
following basic safety precautions. Be sure to read all instructions before using this appliance and
observe the following safety tips:
Warning:
•Read all instructions before using the water dispenser.
•Never clean parts with flammable fluids. The fumes can create a fire hazard or cause an
explosion.
•Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or
any other water dispenser. The fumes can create a fire hazard or cause an explosion.
•Do not plug the unit into the receptacle until you ensure the water tank switches are off.
Save these instructions!
Electrical Connection:
•This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug that mates with standard three-prong wall outlets to
minimize the possibility of electrical shock.
•Plug the appliance into a properly installed and grounded wall outlet only. Do not, under any
circumstances, cut or remove the third (ground) prong from the power cord. Any questions
concerning power and or grounding should be directed toward a certified electrician or the
manufacturer.
•This appliance requires a standard 115/120-volt 60Hz electrical outlet with three-prong ground.
•The cord should be secured behind the appliance and not left exposed or dangling, in order to
prevent accidental injury.
•Do not use an adapter plug with this appliance.
•Do not use an extension cord with this appliance. If the power cord is too short, have a qualified
electrician or service technician install an outlet near the appliance.
Shock Hazard – Electrical Grounding Required

Magic Chef® Water Dispenser Product Guide
6
Parts List
1
Power ON/OFF switches (on back)
5
Cold Water Button
2
Water Bottle Inlet
6
Hot Water Faucet
3
Indicator Lights
7
Cold Water Faucet
4
Hot Water Button
8
Water Drip Tray

Magic Chef® Water Dispenser Product Guide
7
Installation & Setup
•Remove the exterior and interior packing.
•Place your appliance on a level floor that is strong enough to support the dispenser when it is
fully loaded. If it does not sit level on the floor, adjust either of the front feet to level the unit.
•Place the appliance away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the appliance to malfunction.
•Allow 5 inches of space between the water dispenser and the wall. This allows for proper air
circulation to cool the compressor.
•Plug the appliance into a properly installed and grounded wall outlet only. Do not cut or remove
the third (ground) prong from the power cord under any circumstances. Any questions
concerning power and/or grounding should be directed toward a certified electrician or the
manufacturer.
•This water dispenser is not recommended for outdoor use.
•Do not place the dispenser in an area where the temperature may fall below freezing (32° F).
•Keep the area around the dispenser free of dust and dirt.
•Keep the reserve supply of water bottles away from excessive heat and light.
•Never unplug the water cooler, except for maintenance or transport.
Before connecting the appliance to a power source, let it stand upright for
approximately 2 hours. This will reduce the possibility of a malfunction in the cooling
system from handling during transportation.

Magic Chef® Water Dispenser Product Guide
8
Before Using Your Water Dispenser
The water dispenser is pre-cleaned at the factory, but the reservoir and water lines must be flushed with
fresh water before use as follows:
•Keep the unit unplugged.
•Fill water tank with tap water full to capacity (roughly 3/4 of a gallon). Wait for the water
draining into the tank to settle.
•Press the hot water button until water comes out, then stop.
•Plug the dispenser into the electrical outlet. Both the heating and the cooling indicator lights on
the front will light up. Wait for the hot water indicator light to go off first (approximately 10
minutes), then wait for the cold water indicator light to go off (another 40 minutes,
approximately).
•Unplug the dispenser from the electrical outlet. Proceed to drain the water from the faucets one
at a time until no more water remains.
•Next, drain any water left in the tanks by opening the drain plug located on the back. Make sure
the tanks drain completely. WARNING: DRAINING WATER MAY BE EXTREMELY HOT. EXERCISE
CAUTION WHEN DRAINING WATER FROM THE PLUG ON THE BACK.
•Close the drain cap.
Be sure the drain plug seal is in place. If not, replace with one of the spares included with this
manual. Closing the drain cap without the seal in place will result in leakage and possible
damage to the water dispenser and or its surroundings.
•Place the 5-gallon bottle of water on the water intake, allow water to stand for approximately
one minute.
•Press both the hot and cold water buttons to ensure water flows from both faucets.
•Check the area around the drain valve at the rear of the unit for leakage.
•Plug dispenser into the electrical outlet.
Now your water dispenser is cleaned up and ready to go!
NOTE:
Your water dispenser has been cleaned and sanitized before leaving the factory, but in the event of your
water having a weird taste or smell, place two tablespoons of baking soda into the reservoir and add tap
water. Fill water tank again and repeat basic operations previously outlined, except leave the hot water
switch off for the entire process. This helps to avoid unwanted buildup in the hot water tank.

Magic Chef® Water Dispenser Product Guide
9
Operation Instructions
WARNING:
IMPROPER USE OF THE GROUNDED PLUG CAN RESULT IN THE RISK OF ELECTRICAL SHOCK. IF THE
POWER CORD IS DAMAGED, HAVE IT REPLACED BY AN AUTHORIZED AVANTI PRODUCTS SERVICE
CENTER.
Steps to replace water bottles
To replace the bottle:
1. Remove cap.
2. Use a clean cloth to wipe off the neck of the bottle.
3. Carefully lift the bottle (approx. 40 lbs.) using your legs and not your back. Do not place hands
on the neck or opening of the bottle while placing it into the reservoir.
4. Insert the water bottle into the water intake over the reservoir opening so that it settles
properly on it.
5. When a new bottle is installed, you must open the hot water faucet and remove no less than 4
full cups of water to ensure the water flows properly and the water reservoir is full.
Hot and Cold Power ON/OFF Indicator Lights
Once the power switches on the back of the unit are turned on for the HOT and COLD water systems,
the lights in the switches will illuminate to let you know that your hot and cold water are both
functioning normally.
Hot Water Indicator Light
Turn the heating switch on, on the back of the unit. The red indicator light (on the front of the unit) will
illuminate and the heating process will start. When the water reaches the correct temperature (185°-
203°F / 85° - 95°C), the red light will turn off automatically. When the temperature drops below 176°F
(80°C), the red indicator light (on the front of the unit) will illuminate again, indicating that another
heating process has started.
If you do not plan to use the water heating function for more than three days, we
recommend that you turn the HOT switch to the “OFF” position.

Magic Chef® Water Dispenser Product Guide
10
Cold Water Indicator Light
Turn the cooling switch on, on the back of the unit. The blue indicator light (on the front of the unit) will
illuminate and the cooling process will start. When the water reaches the right temperature (41° - 50°F /
5° - 10°C), the blue indicator light will turn off automatically. Once the water temperature reaches
above 50°F (10°C), the blue indicator light (on the front of the unit) will illuminate again, indicating that
another cooling process has started.
NOTE: THE HOT WATER FAUCET HAS A CHILD-SAFETY GUARD ATTACHMENT
To dispense hot water with the child lock:
•Slide the red safety switch on the hot water button to the right, and hold it there while pressing
downward on the button.
•The safety button will return to its original position when the button is released.
•Ensure that all water has dispensed prior to removing your cup from the dispensing area, to
prevent accidental burns.
To dispense cold water:
•Press and hold down on the cold water button to dispense cold water.
•When you have dispensed the desired amount of water, simply release the cold water button.
•Ensure all water has dispensed prior to removing your cup from the dispensing area.

Magic Chef® Water Dispenser Product Guide
11
Cleaning & Maintenance
Make sure the power switch is in the off position and unplug the unit from the outlet before performing
any maintenance or servicing the product.
Care and Maintenance
•Wash the inside of the reservoir with a warm water and baking soda solution. The solution
should be about 2 tablespoons of baking soda to a quart of water.
•The drip tray and water faucets should be cleaned with mild detergent and warm water.
•About once a month, inspect the coils located across the back of the dispenser. Vacuum any
dust or clean it with a soft bristled brush.
Taking the Dispenser Out of Service
1. If the water dispenser will not be used for a long period of time, unplug the power cord from the
wall outlet.
2. Drain the water through the faucets.
3. Turn the hot water switch to the “OFF” position.
4. Drain the water from the tank by removing the plug from the back of the dispenser.
WARNING:
THE WATER COMING OUT OF THE BACK SIDE MARKED “HOT” MAY BE SCOLDING!
5. Drain the water from the tank by removing the plug from the back of the dispenser.

Magic Chef® Water Dispenser Product Guide
12
Troubleshooting
You can solve many common water dispenser problems easily, saving you the cost of a possible service
call. Try the suggestions outlined below to see if you can solve the problem on without calling the
service department.
Problem Possible cause
Water dispenser does not operate.
•The unit is not plugged in.
•The circuit breaker tripped or a blew a fuse.
Water cooler is not cold enough.
•Check to be sure the cold water switch on the back
is ON.
•The water dispenser does not have the correct
space clearances for proper airflow.
Water dispenser hot water is not hot
enough.
•Check to be sure the hot water switch on the back
is ON.
Compressor turns on and off frequently.
•The room temperature is hotter than normal.
•The temperature control is not set correctly.
•The water dispenser does not have the correct
space clearances for proper airflow.
Vibrations.
•Check to verify that the dispenser is level on the
ground.
The water dispenser seems to make too
much noise.
•The rattling noise may be coming from the flow of
the refrigerant, which is normal.
•As each cycle ends, you may hear gurgling sounds
caused by the flow of refrigerant into your water
dispenser.
•Contraction and expansion of the inside walls may
cause popping and crackling noises.
•The water dispenser is not level on the ground.
Bottle feels warm.
•The water system is overfilled. Dispense cold water
until air is released into the bottle.
Water bottle is hot.
•Water is boiling in the hot tank and bubbling up
into the bottle. Press the hot dispenser button until
water flows to remove air from the hot tank.

Magic Chef® Water Dispenser Product Guide
13
Limited Manufacturer’s Warranty
This appliance is covered by a limited manufacturer’s warranty. For one year from the original date of
purchase, the manufacturer will repair or replace any parts of this appliance that prove to be defective
in materials and workmanship, provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms
During the first year, any components of this appliance found to be defective due to materials or
workmanship will be repaired or replaced at the manufacturer’s discretion, and at no charge to the
original purchaser. The purchaser will be responsible for any removal or transportation costs.
Exclusions
The warranty will not apply if the damage is caused by any of the following:
•Power failure
•Damage in transit or when moving the appliance
•Improper power supply, such as low voltage, defective household wiring, or inadequate fuses
•Accident, alteration, misuse, or abuse of the appliance, such as using non-approved accessories,
inadequate air circulation in the room or abnormal operating conditions (extreme
temperatures)
•Use in commercial or industrial applications
•Fire, water, damage, theft, war, riot, hostility, or acts of God, such as hurricanes, floods, etc.
•Use of force or damage caused by external influences
•Partially or completely dismantled appliances
Obtaining Service
When making a warranty claim, please have the original bill of purchase with purchase date available.
The purchaser will be responsible for any removal or transportation costs. Replacement parts and/or
units will be new, remanufactured, or refurbished and are subject to the manufacturer’s discretion. Do
not use an unauthorized service provider to replace or fix a damaged main cord.
For technical support and warranty service, please email [email protected]
