Dolphin BCL632FS-2 Product manual

November 2019
BCL632F
DOLPHIN PANEL MOUNTED
FOAM SOAP DISPENSER
INSTALLATION AND MAINTENANCE GUIDE
www.divapor.com

2 | Dolphin Blue | BCL632F
3 Technical Data
4 Pre-Installation Information
5 Pack Contents
6-8 Installation
9 Filling The Soap Tank
10 Settings Adjustment
11 Spare Parts List
12 Maintenance
13 Warranty
14-15 Troubleshooting
INDEX
www.divapor.com

BCL632F | Dolphin Blue | 3
TECHNICAL DATA
Capacity
Power Supply
Soap viscosity
Standard discharge
Sensor range
Soap PH 5.5-8.5
1 Litre / 33.8 oz.
12V transformer
'TW
Varies according to viscosity and soap consistency
30-100 mm +/- 10 mm
(Adjustable by remote control)
Soap Type clear foaming liquid, no abrasives
70
• •••••
• •••••
M23x1
POWER
SOURCE
38 160
143
150
332
1
www.divapor.com

4 | Dolphin Blue | BCL632F
PRE INSTALLATION INFORMATION
CHECK CONTENTS
After opening the package, check each part with the “Pack Contents” section.
Make sure all parts are accounted for before discarding any packaging material.
If any parts are missing, do not attempt to install the touch free foam soap
dispenser until you obtain the missing parts.
WARNINGS
› Highly reflective surfaces directly beneath the sensor of this product, in
particular polished finish basin wastes/ strainers, will cause false activation of the
infrared sensors and can result in malfunction. We recommend satin or matt
finish products which can be found on our website.
› It is very important to allow permanent access to the mounting tail/nut of this
product for future servicing and repair. Where this is not possible see our wall
plate mounted products.
› Do not install the system facing a mirror or any electronic system operated by
an infrared sensor.
› To prevent reflection problems, it is recommended to keep a minimum
distance of 300 mm between the soap dispenser and any other objects.
IMPORTANT:
Keep in mind that when using the tap installed next to the soap dispenser, the
user hands should not interfere with the soap dispenser sensor detection area.
Correct Installation Incorrect Installation
Do not aim soap sensor at water stream
www.divapor.com

BCL632F | Dolphin Blue | 5
PACK CONTENTS
2 x screws
2 x anchors
1 x quick connection fittings
1 x pump assembly with
bottle support and soap tank
12 v transformer
1 x foam dispenser body
1 x foam compressor with pipe
www.divapor.com

6 | Dolphin Blue | BCL632F
INSTALLATION
STEP 1 REMOVE ALL MOUNTING HARDWARE
› Drill a hole (23-24 mm) at the
designated installation location of the
foam soap dispenser body.
› Drill a small hole (2-3 mm) above
the previous one for the anti-
rotation pin. Consult the diagram.
› Remove the hexagonal nut and the
disk from the base of the soap
dispenser spout.
STEP 2 – INSTALLING
THE SOAP DISPENSER
1. Insert the Soap dispenser base and
the anti-rotation pin into the drilled
holes. Fix the base behind the wall
with the hexagonal nut and the
disk.
2. Fix the bottle support to the
desired location. The pump MUST
be within reach range of the Com
cable and black supply tube.
www.divapor.com

BCL632F | Dolphin Blue | 7
INSTALLATION
3. Connect the tube extending out of
the soap dispenser body to the
quick connection fitting at the top
of the foam compressor by
snapping it in.
Make sure it is firmly plugged in.
4. Connect the quick connection fitting
to the soap dispenser pump.
Make sure it is firmly plugged in.
5. Connect the tube extending from
the foam compressor to the top of
the soap dispenser pump by
snapping it into the quick
connection.
IMPORTANT: Make sure to cut the tube to the minimum required length
www.divapor.com

8 | Dolphin Blue | BCL632F
INSTLLATION
STEP 3. CONNECTING THE POWER SOURCE
1. Remove the protective sticker
covering the sensor.
2. Connect the matching connector
from the foam dispenser body to the
compressor unit, and the compressor
unit to the pump connector. Please
note that since the connector is water
proof, some pressure must be applied
for a prefect seal.
3. Plug the transformer into the
electricity socket and connect the
transformer connector
4. Wait about 10 seconds before
placing your hands in the sensor
range to avoid adjustment mode.
IMPORTANT: the 4 contacts connector should be connected properly so that the
white o-ring is not visible and a clicking sound is heard.
PAY ATTENTION: If the 4 contacts connectors are not connected properly, the soap
dispenser pump will not operate properly.
www.divapor.com

BCL632F | Dolphin Blue | 9
FILLING THE SOAP TANK
1. Unscrew the soap tank from the pump assembly and
pull it out from the bottle support.
2. Fill the bottle with JSEQWSET up to the top line.
Make sure the bottle is clean before filling it with soap.
3. Insert the bottle back into the bottle support.
4. Screw the soap tank back into the pump assembly.
Make sure the tank is firmly secured into place.
5. Press and hold the refill button located at the back of
the pump assembly until soap is dispensed from the
soap dispenser spout. Alternately, use the FILL function
on the remote control (if available). see page 10.
Note: When the soap in the soap tank reaches the
bottom line, the tank needs to be refilled.
To refill the soap tank please refer to steps 1-5.
www.divapor.com

$"353*%(&3&'*--*/(
*/4536$5*0/4
BCL632F| Dolphin Blue| 
www.divapor.com

1 | Dolphin Blue| BCL632F
REMOTE CONTROL FUNCTIONS
If available, the foam dispenser remote control can adjust the dispenser’s settings. To
use the remote control hold it in front of the sensor at a distance of 10-15cm.
Attention: The remote control will not operate out of the recommended range
(too closeor too far).
The remote control can be used to adjust the following functions:
1 SOAP QUANTITY Press the + sign on the SOAP button to increase the soap
quantity by increasing the dispensing time. Press the - button to decrease it.
Indication: continuous blinking blue light in the sensor eye.
2 AIR QUANTITY To improve soap consistency (“foamability) change the
amount air to be mixed. Press the + sign on the AIR button to increase the air
quantity and the - to decrease it. Indication: 2 blinks of the blue light in the
sensor eye.
3 RES This function resets the sensor back to its factory settings.
4 TEMPORARY OFF FUNCTION This function temporary disables the
dispenser. Use this function to preform maintenance in front of the sensor
without activating the system (for
example: cleaning) The soap dispenser
will shut off for one minute after this
button is pressed once. To return to
normal operation before the minute is
over, press the On/Off button again.
5 FILL THE SOAP TANK Once the soap
tank has been filled \ refilled, press the
FILL button. The pump will run for one
minute, priming the piping with soap.
Once soap begins dispensing from the
spout, priming is complete. press the FILL
button again to stop the priming before
the minute is over. Indication: continuous
solid blue light in the sensor eye.
www.divapor.com

BCL632F| Dolphin Blue| 1
Seals & Screws Kit ........................................................................................... BC07210098
10-Pack Sensor Kit ........................................................................................... BC07220338
Soap Dispenser Pump ................................................................................... BC07222013
Pump+Compressor Kit ................................................................................. BC07222026
Soap Bottle 1L .................................................................................................... BC07100020
Soap Bottle 1L Support Kit ......................................................................... BC07220087
10-Pack Foam Filter ......................................................................................... BC07212015
12v Transformer (EU) ..................................................................................... BC06522081
12v Transformer (UK)...................................................................................... BC06522086
12v Transformer (US) ..................................................................................... BC06522080
12v Transformer (AU) .................................................................................... BC06522085
Remote Control for Foam Dispenser .................................................. BC07100009
SPARE PARTS LIST
www.divapor.com

CARE AND CLEANING OF CHROME AND SPECIAL
FINISHES
DO NOT use steel wool or cleansing agents containing alcohol, acid, abrasives, or
their like. Use of any prohibited cleaning or maintenance products or substances
could damage the surface of the soap dispenser. For surface cleaning use ONLY
soap and
water, then wipe dry with a clean cloth or towel. When cleaning bathroom tiles, the
soap dispenser should be protected from any splattering of harsh cleansers.
DISASSEMBLE OF THE SOAP PIPE FROM THE PUMP
The soap pipe can be disconnected from the soap pump by a simple slide and pull
action. The sliding ring of the quick connection fixation nipple on the pump should
be pulled down. It releases the open end of the soap pipe which can then be easily
pulled out.
FILTER CLEANING INSTRUCTIONS
(FOAM DISPENSER ONLY)
› This soap dispenser is provided with a foam filter. It is recommended to clean the
filter every six (6) months.
› If the soap supply has decreased, this may be caused by the clogged filter. The
filter can be cleaned as follows:
1. Use a wrench to unscrew the quick connection fitting from the foam
compressor and pull out the filter housing.
2. Remove the filter from the housing.
3. Replace the filter (recommended) or wash it under running water for a
temporary fix.
4. Reassemble the parts.
MAINTENANCE
1 | Dolphin Blue| BC632F
www.divapor.com

BC632F| Dolphin Blue| 1
LIMITED WARRANTY
Dolphin Solutions Ltd warrants that its electronic products will be free of
defects in material and workmanship during normal use for two years from
the date the product is purchased.
If a defect is found in normal use, Dolphin Solutions Ltd will, at its
discretion, repair, provide a replacement part or product, or make
appropriate adjustments. Damage caused by accident, misuse, or abuse is
not covered by this warranty. Improper care and cleaning will void the
warranty. Proof of purchase (original sales receipt) must be provided to
Dolphin Solutions Ltd with all warranty claims.
Dolphin Solutions Ltd is not responsible for labor charges, installation, or
other incidental or consequential costs other than those noted above. In no
event shall the liability of Dolphin Solutions Ltd exceed the purchase price
of the product.
If you believe that you have a warranty claim, contact your Dolphin
Distributor, Dealer or Plumbing Contractor. Please be sure to provide all
pertinent information regarding your claim, including a complete
description of the problem, the product, model number, the date the
product was purchased, from whom the product was purchased and the
installation date. Also include your original invoice.
DOLPHIN AND/OR SELLER DISCLAIM ANY LIABILITY FOR SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES. This warranty excludes
product damage due to installation error, incorrect maintenance, wear and
tear, battery, product abuse, or product misuse, whether performed by a
contractor, service company, or the consumer. This warranty does not cover
product damage caused by the following:
- Incorrect installation.
- Improper manipulation, tampering, bad or lapsed maintenance.
- Use of the soap outside of viscosity specifications.
- Alteration of the original soap/foam dispenser components (including
pipes).
www.divapor.com

1 | Dolphin Blue| BC632F
TROUBLE SHOOTING
SOLUTIONCAUSE INDICATOR PROBLEM
Rell the soap tank.
Refer to page 7
Soap has run low or is completely
out.
Blue light in the
sensor flashes
(once) and the
soap pump
operates.
Foam is not
dispensing
from spout
Press the rell button located
at the bottom of the pump
to prime the soap until it is
dispensed from the spout.
The soap tank has been lled, but
soap has not reached the spout.
Connect the connectors
properly so that the white
o-ring is not visible.
The connectors between the pump
and the electronic unit are not
connected properly.
Make sure the pipe is adjusted
inside the tank for an ideal
soap intake.
The pipe for the specic dispenser
is bent or curved and does not reach
the bottom of the soap tank.
Clean or replace the lter.
Refer to page 10
Filter is clogged.
Eliminate the cause of
reflection.
Sensor is picking up reflections from
the washbasin or another object.
Blue light in the
sensor does not
flash (once) when
the users’ hands
are within the
sensor range. Properly connect the
electronic unit connectors to
the power source connector.
Connectors between the electronic
unit and power source are
disconnected or not properly
connected.
www.divapor.com

TROUBLE SHOOTING
SOLUTIONCAUSE INDICATORPROBLEM
Connect the connectors
properly so that the white
o-ring is not visible.
The connectors between the pump
and the electronic unit are not
connected properly.
Foam does not
stop dispensing
Increase air ratio using the
remote control.
Refer to page 8
Air ratio is too low.
Foam is too
diluted
Decrease air ratio using the
remote control.
Refer to page 8
Air ratio is too high.
Foam is too
dense
Connect the connectors
properly so that the white
o-ring is not visible.
The connectors between the soap
pump and the compressor are not
connected properly.
Blue light flashes
(once) and the
foam compressor
operates.
Soap dispenser
pump does not
work
Connect the connectors
properly so that the white
o-ring is not visible.
The connectors between the
compressor and the electronic unit
are not connected properly.
Blue light flashes
(once) and the
motor operates.
Foam
compressor
does not work
BC632F| Dolphin Blue| 1
www.divapor.com

280
130 x 190
CUT TUBE TO
150 - 300mm
MAX
ENSURE ENOUGH
CLEARANCE FOR
REFILLING ACCESS
6mm BLACK
TUBING
8mm CLEAR
TUBING
MULTIFEED DISPENSERS MANUAL
BCL632 / BCL636 Series | Dolphin | 1917 | Dolphin Blue | BC632F
www.divapor.com

Dolphin Solutions Ltd
Southpoint, Compass Park, Bodiam,
Robertsbridge, TN32 5BS
Tel: [phone]
Fax: [phone]
[email protected].uk
www.dolphinsolutions.co.uk
www.divapor.com
