New Buck Corporation FP-BR-10-ZC User manual

MODEL FP-BR-10-ZC
VENT-FREE
WA R N I N G : If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
− Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the fire department.
− Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is in-
stalled. Provisions for adequate combustion and ventilation air must be provided. Refer to
section “ Producing Adequate Ventilation” page 14.
This appliance may be installed in an aftermarket, permanently located, manufactured
(mobile) home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appli-
ance is not convertible for use with other gases.
Manufacturer: NEW BUCK CORPORATION
P.O. Box 69 8000 Highway 226 South
Spruce Pine, NC 28777
March 2005
NOTE: An unvented room heater hav-
ing an input rating of more than 6,000
Btu per hour shall not be installed in a
bathroom.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING
This appliance is equipped for (natural or propane) gas .
Field conversion is not permitted.

TABLE OF CONTENTS
Safety Information and Warnings................................................................................. 3
Installation..................................................................................................................... 6
Fireplace and Framing Dimensions .............................................................................. 7
Fireplace Clearances ..................................................................................................... 8
Finishing Your Fireplace .............................................................................................. 9
Mantel Profiles For Zero Clearance............................................................................ 10
Mantel Installation ..................................................................................................... 11
Mobile Home Installation ........................................................................................... 13
Gas Connection…………………………………………………………………… …13
Producing Adequate Ventilation................................................................................. 14
Ventilation Air Indoors ............................................................................................... 16
Ventilation Air Outdoors ............................................................................................ 17
Gas Pressure Check..................................................................................................... 18
Placement of Logs....................................................................................................... 19
Lighting Instructions................................................................................................... 20
Flame Check ............................................................................................................... 24
Wiring Diagrams......................................................................................................... 25
Important Safeguards .................................................................................................. 27
Trouble Shooting ........................................................................................................ 28
Service/Replacement Parts.......................................................................................... 32
Warranty/Owner Registration..................................................................................... 35
Page 1

Page 2

SAFETY INFORMATION
WA R N I N G S
IMPORTANT: READ THIS OWNER’S MANUAL CAREFULLY AND COMPLETELY
BEFORE TRYING TO ASSEMBLE, OPERATE, OR SERVICE THIS APPLIANCE.
IMPROPER USE OF THESE LOGS CAN CAUSE SERIOUS INJURY OR DEATH FROM
BURNS, FIRE, EXPLOSION, AND CARBON MONOXIDE POISONING.
Early signs of carbon monoxide poisoning resemble the flu, with headaches, dizziness, and/or nausea. If
you have these signs, the heater may not be working properly. Get fresh air at once! Have burner
serviced.
Some people-pregnant women, persons with heart or lung disease, anemia, those under the influence of
alcohol, those at high altitudes-are more affected by carbon monoxide than others.
Make certain you understand and read all Warnings. Keep this manual for reference. It is your guide to
safe and proper operation of this heater and logs.
CAUTION: Strong drafts, such as a ceiling fan placed directly in front of the heater
(pulling from either direction) may create sooting. Sooting will discolor
walls.
1. The installation must conform with local codes, or in the absence of local codes, with the National
Fuel Gas Code, ANSI Z223.1/NFPA54.
2. This appliance may be installed in an After-Market* Manufactured (Mobile) Home, where not
prohibited by state or local codes.
* (After-Market: Completion of sale, not for purpose of resale from the manufacturer.)
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is
not convertible for use with other gases.
NOTE: See Page 14, for “Producing Adequate Ventilation”.
IMPORTANT: VENT-FREE HEATERS ADD MOISTURE TO THE AIR. ALTHOUGH
THIS IS BENEFICIAL, INSTALLING HEATER IN ROOMS WITHOUT ADEQUATE
VENTILATION MAY CAUSE MILDEW TO FORM FROM TOO MUCH MOISTURE.
3. Never install this heater:
- in a recreational vehicle, bathroom.
- where curtains, furniture, clothing, or other flammable objects are less than 42" from the
front of the heater
-in high traffic areas
- in windy areas
4. Two models are available. One specific model for propane(LP), and one for natural gas. Use the
correct type gas for your home. Do not convert from one gas type to another.
Page 3

5. If this heater is used with propane gas, do not place propane supply tank (s) inside any structure.
6. What To Do IF You Smell Gas:
Shut off gas supply.
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any phone in your building.
- Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the fire department.
7. When operated for the first time, the logs may emit a “paper burning” smell. This smell will
gradually diminish and will be totally eliminated after the first few hours of operation. Run the gas
logs with the flue damper open during this time. Do not use blower at this time.
8. “This heater shall not be installed in a confined space or unusually tight tight construction
unless provisions are provided for adequate combustion and ventilation air.” See “Producing
Adequate Ventilation”, page 14.
9. Surface of gas logs becomes very hot when operating. Keep children and adults away from hot
surface. Gas logs will remain hot for sometime after shutdown. Allow surface to cool before
touching.
10. Do not place clothing or other flammable material on or near the appliance.
11. If equipped, fresh air damper must be closed.
12. Keep appliance area clean and free from combustible materials, gasoline, and other flammable
flammable vapors and liquids. .
13. If burner shuts off, do not relight until you provide fresh outside air. If burner continues to shut off,
have unit serviced.
14. Do not use this heater if any part has been under water. Immediately call qualified service
technician to inspect the room heater and to replace any part of the control system and any
gas control which has been under water.
15. Turn off the heater and let cool before servicing.
16. These logs are made of bonded fiber. When removing logs and base, do not damage the bonded
material. If the material is damaged extensively, loose fiber dust could be emitted into the air.
17. Any safety screen or guard removed for servicing an appliance must be replaced prior to
operating the heater.
18. This appliance is intended for supplemental heating.
19. “WARNING: Any change to this heater or its controls can be dangerous.”
20. Installation and repairs should be performed by a qualified service person. The appliance
should be inspected before use and at least annually by a professional service person. More
frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc.
It is imperative that control compartments, burners and circulating air passageways of the
appliance be kept clean.
Page 4

21. All heater screens must be kept clean when operating the gas logs.
22. .”WARNING: Failure to keep the primary air opening(s) of the burner(s) clean may result in
sooting and property damage.”
24. Do not use this heater for burning trash or cooking. Never place matches, paper, garbage, or any
other material on top of logs or into the flames.
24. Do not install or operate this heater in areas where impurities in the air exist (such as tobacco
smoke or heavy cooking grease). Particles from impurities may discolor walls.
25. Due to high temperatures, the appliance should be located out of traffic and away from
furniture and draperies.
26. Children and adults should be alerted to the hazards of high surface temperature and should
stay away to avoid burns or clothing ignition.
27. Young children should be carefully supervised when they are in the same room with the
appliance.
28. An unvented room heater having an input rating of more than 6,000 Btu per hour shall not be
installed in a bathroom.
29. The appliance and its appliance main gas valve must be disconnected from the gas supply
pipping system during any pressure testing of that system at test pressure in excess of 1/2 psi
(3.5 kPa).
30. The appliance must be isolated from the gas supply pipping system by closing its equipment
shut-off valve during any pressure testing of the gas supply piping system at test pressures
equal to or less than 1/2 psi (3.5 kPa).
31. “WARNING: Do not allow fans to blow directly into fireplace. Avoid any drafts that alter
burner flame patterns.”
32. “WARNING: Do not use a blower insert, heat exchanger insert or other accessory not
approved for use with this heater.”
Page 5

INSTALLATION
The Model FP-BR10-ZC Vent-Free gas fireplace may be installed in any
room in a Residential home or an After-Market* Manufactured Home.
(Exception: This appliance may not be installed in a bathroom.)
* (After Market: Completion of sale, not for the purpose of resale from the manufacturer).
For After-Market Manufactured Home installation, check with state and local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases.
NOTE: See page 14 for “Producing Adequate Ventilation”.
CHOOSING THE LOCATION FOR YOUR FIREPLACE:
Figure 1 shows some of the many ways your fireplace may be installed. Consider the traffic pattern in
your room and the location of doors and windows. Moving air from ceiling fans, open doors, and hot air
grills may cause the flames to soot. If a disturbance is found that affects the flames, it must be
eliminated by turning off the ceiling fan, closing the door, or closing or moving the hot air register. A
corner location may be best where space is limited.
Your fireplace weighs no more than some of your fine furniture. If the fireplace is located near a load
bearing wall, additional supports to the foundation will not be necessary. HEAVY FACINGS, SUCH
AS BRICK, STONE, ETC., MAY REQUIRE ADDITIONAL FOUNDATION SUPPORT.
NOTE: If this appliance is installed directly on carpeting, tile or other combustible material, other
than wood flooring, the appliance shall be installed on a metal or wood panel extending the full
width and depth of the appliance.
GAS LINES
The gas supply line and electrical supply must
be installed before framing in the fireplace by
a licensed installer.
DRAFTS
Do not locate the fireplace in high traffic areas
or areas exposed to high drafts and winds.
Locate the fireplace away from furniture and
draperies.
FIGURE 1
Page 6

Fireplace and Framing Dimensions (ins.)
FIGURE 2
24”
25 1/8”
26 1/8”
20 3/8”11 5/8”
26 1/8”
25 1/8”
1 3/4”
13 1/2”
8”
GAS
LINE
WARNING:Installation and repairs should be performed by a qualified service person. The
appliance should be inspected before use and at least annually by a professional service person.
More frequent cleaning may be required due to excessive lint from carpeting, bedding mate-
rial, etc. It is imperative that control compartments, burners and circulating air passageways of
the appliance be kept clean.
Page 7

This list of specific instructions will help you make certain that
every installation operation is performed correctly. Complete the
installation steps in the sequence shown. STATE AND LOCAL
BUILDING CODES SHOULD BE CONSULTED IN ALL
CASES AS TO THE PARTICULAR REQUIREMENTS
CONCERNING THE INSTALLATION OF A FACTORY
BUILT FIREPLACES. Select the location for the fireplace by
taking into consideration the factors previously outlined in the
“Choosing the Location.” See page 5.
Framing the Firebox
The width of the framed opening must be 26 1/8". The height of
the framed opening must be 25 1/8". The entire fireplace can be
elevated above the floor to achieve a raised hearth effect. This can
be done by adding a small platform to achieve the desired height.
NOTE: The wiring for the lower blower must be installed during
the framing stage. The nailing flanges on both sides were designed
to allow the installation of 1/2" wallboard or plywood flush with
the face of the fireplace.
When the framing is inside, the outside wall will be insulated. If
the framing or chase is outside, thin insulation should be used in the
framing on the back, sides, and top. The bottom should be
insulated with a hard insulating board. This will prevent cold from
going into the chase through the fireplace to the living space.
Install the Firebox
Install the firebox into the framed opening by placing it directly in
front of the opening and sliding it into the proper position.
Level the Firebox
Check the level of the firebox on the top edge of the fireplace face.
Shim if necessary.
Secure the Firebox
Secure the fireplace to the framing. The nailing flanges on the
firebox will make securing the firebox to the frame quick and easy.
Use appropriate size nails or screws to secure the firebox.
FIREPLACE CLEARANCES
The fireplace may be placed directly on a combustible floor, against
a combustible wall at marked clear-ances, or on a raised wooden
platform.
If the fireplace is to be installed on a raised wooden platform, the
platform must be a continuous level surface. The fireplace must be
secured in place so it cannot shift positions. The nailing flanges on
the sides of the firebox make securing it to the framing easy. They
were designed to allow the installation of 1/2" wallboard or plywood
flush with the face of the fireplace.
Only the header (see Figure 2) may rest on the stand-offs on top of
the firebox.
When the firebox is installed over carpeting, (vinyl) tile,or any
combustible material other than wood flooring, it must be
installed on a metal or wood panel extending its full width and
depth. Alternatively, the carpeting, (vinyl) tile, etc. may be
removed beneath the fireplace before installing.
COMBUSTIBLE MATERIALS MUST NOT BE
INSTALLED OVER OR TOUCH ANY BLACK
PAINTED SURFACE. DO NOT BLOCK HEAT
CIRCULATING AIR OUTLETS. DOING SO MAY
RESULT IN POTENTIAL FIRE HAZARDS.
1. Sidewall Clearances: Clearances from the side of the
fireplace opening to any adjacent combustible wall should
not be less than 7".
2. Ceiling Clearances: The ceiling height should
not be less than 42" from the top of the fireplace
opening.
INSTALLING THE FIREBOX
26-1/8"
7" *
17-3/4" 1/2"
13-1/2"
25-1/8"
26-1/8"
FRONT
VIEW
SIDE
VIEW
TOP
VIEW
Figure 3
HEADER
FRAMING
13-1/2"
25-1/8"
* Note: Minimum 1/2" clearance
NOT required at this point
Page 8

There is a wide variety of finishing material available
for your fireplace from formal wall treatments with
marble and mantels, to rustic wood paneling, stone or
brick. Non-Combustible materials used in this
installation such as slate, tile, marble, etc. must be at
least 1/2" thick.
IT IS IMPORTANT THAT THE BLACK FACE OF
THE FIREPLACE NOT BE COVERED WITH
ANY TYPE OF COMBUSTIBLE MATERIAL.
Non-combustible facing materials such as marble, brick,
or ceramic tile may overlap the black face of the
fireplace up to the opening on either side of the
fireplace. Seal all joints between the black fireplace face
and the wall covering with a heat-resistant material such
as rock wool insulation or mortar. Be sure to use high
temperature adhesive or mortar when anchoring brick,
stone, or tile to the face of the fireplace.
CLEARANCES
To ensure a safe installation, the following must be
carefully observed.
1. Sidewall Clearances: Clearances from the right or
left side of the fireplace opening to any adjacent
combustible wall should not be less than 7", facing the
unit.
2. Ceiling Clearances: The ceiling height should not
be less than 42" from the top of the fireplace opening.
Check to see whether man-made brick and stone are
made of non combustible materials before using them
on the face of the fireplace. Some of these products
contain combustible materials. Combustible wall
coverings such as paneling or wallboard may not
overlap the black face of the fireplace. The space
between the wall covering and the fireplace should be
sealed with a heat resistant material such as rock wool
insulation or mortar.
NOTE: An “L” shaped steel lintel must be installed
across the top of the firebox opening where facing
materials such as brick or stone is used on the face of
the firebox. It acts as a support/firestop. It should be
attached to the face of the fireplace with screws and
sealed to the fireplace with a heat-resistant sealer.
3. Mantel Clearances: We have provided 4 different
situations to position your mantel. See Figure 5.
4. Floor Clearances: No clearance is required if the
appliance is installed per these instructions.
5. Front Clearances: From the Front of the fireplace
to any combustible materials should not be any less
than 24”.
FINISHING YOUR FIREPLACE
42" MIN.
CLEARANCE
TO CEILING
7" MIN.
FIGURE 4
SIDE WALL
CLEARANCE
FROM FIREPLACE
OPENING TO SIDE WALL
NOTE: Adequate clearance around air openings
must be maintained. Never cover any openings on
the appliance with any type material.
24” CLEARANCE TO FRONT
LEFT SIDE RIGHT SIDE
Page 9

MANTEL PROFILES FOR ZERO CLEARANCE CABINET
MUST BE FOLLOWED
2"
42"
COMBUSTIBLE
MATERIAL
STAND OFF
FP-BR10-ZC
LOUVERS
HOOD
CEILING
MANTELS WITH 3/4" BASE
2"
COMBUSTIBLE
MATERIAL
STAND OFF
FP-BR10-ZC
LOUVERS
HOOD
12"
3"
SUPPORT
10"
2"
COMBUSTIBLE
MATERIAL
STAND OFF
FP-BR10-ZC
LOUVERS
HOOD
Bottom of 3/4" Base or Support
must be Flush with top of Unit
if mantel is 10" wide or less.
12"
2-1/2"
3/4"
3"
3-1/2"
Bottom of 3/4" Base or Support
must be at least 2-1/2" from top
of Unit if mantel is 10" wide or more.
3/4"
3-1/2"
3"
2"
COMBUSTIBLE
MATERIAL
STAND OFF
FP-BR10-ZC
LOUVERS
HOOD
12"
3"
SUPPORT
2-1/2"
2-1/2"
2-1/2"
6"
MANTELS WITH 2-1/2" BASE
Bottom of 2-1/2" Base or Support
must be Flush with top of Unit
if mantel is 12" wide or less.
Bottom of 2-1/2" Base or
Support must be at least
2-1/2" from top of Unit if
mantel is 12" wide or more.
Page 10

INSTALLATION OF MODEL FP - BR10- ZC
WITH OPTIONAL WOODEN MANTEL
(1) When choosing the right location for your heater and mantel keep the following in mind:
NOTE: Due to high temperatures, this heater should be located out of traffic and away
from furniture and draperies.
NOTE: Kit No. (PA KDMH10) Deluxe Wooden Mantel for FP-BR10-ZC.
Kit No. (PA KDM10) Standard Wooden Mantel for FP-BR10-ZC
CAUTION: THE INSTALLATION MUST CONFORM WITH LOCAL CODES OR, IN
THE ABSENCE OF LOCAL CODES, WITH THE NATIONAL FUEL GAS CODES,
ANSI Z223.1/NFPA 54.
NOTE: See page 18 for “Gas Pressure Check”.
WARNING: YOUNG CHILDREN SHOULD BE CAREFULLY SUPERVISED WHEN
THEY ARE IN THE SAME ROOM WITH THE APPLIANCE.
DO NOT PLACE CLOTHING OR OTHER FLAMMABLE MATERIAL ON OR NEAR
THE APPLIANCE
(2) Screen(s) can not be removed or altered (Position screen(s) in the closed position before
leaving heater unattended).
(3) Follow instructions for assembly of (Optional) Wooden Mantel. See instructions supplied
with mantel.
(4) After mantel has been assembled, slide the heater from the rear into the opening of the
mantel.
NOTE: Place a cloth or blanket over the front portions of the mantel as not to scar the wood.
(5) Center the heater in the opening of the mantel. See Figure 6.
(6) Fasten mantel to hearth by using ½" wood screws.
(7) Insert the nine (9) ½" wood screws provided with mantel through slots on nailing flange
and secure in place. See Figure 6.
(8) Position mantel and fireplace into desired location.
(9) To light the heater, see “Lighting Instructions” pages 19 through 30. Make sure you have
the right gas valve for Natural or LP gas.
NOTE: Hook gas supply line into heater. Check for leaks using soap and water, not an open
flame.
NOTE: When used as a bedroom fireplace, the unit must be attached to the wall. Use the
angle provided with the mantel. Also the safety screen must be kept mechanically secured
to the unit as it is when it leaves the manufacturer.
Page 11

FIGURE 6
MANTEL BASE
TOP MANTEL
REAR
OF
HEATER
1/2" WOOD
SCREWS (9)
Page 12

CHECK GAS TYPE: Use only the type of gas indicated on the valve rating plate. If the type of gas
vlisted on the plate is not your type of gas supply, DO NOT INSTALL . Contact your dealer for
proper model.
Always use an external regulator for all LP heaters to reduce the supply tank pressure to a maximum
of 13” W.C. This in addition to the regulator furnished with the heater.
WARNING: Connection directly to an unregulated LP tank can cause an explosion.
The normal gas connection is 3/8” N.P.T. made at the right rear side of the appliance.
NOTE: The connecting pipe must be internally tinned copper tubing for use with natural gas. Test
for leaks using a solution of soap and water after completing the connection. DO NOT USE OPEN
FLAME.
INSTALLATION SUPPLIES
Before installing the heater, gather the following materials:
- external regulator - ground joint union
(supplied by installer for propane) - sediment trap
- piping (check local codes) - tee joint
- manual shutoff valve* - pipe wrench
- test gauge connection* - sealant (resistant to LP gas)
WA R N I N G :
ANY CHANGE TO THIS HEATER OR ITS CONTROLS CAN BE DANGEROUS.
INSTALLATION
AFTER-MARKET MOBILE HOMES
WARNING: Installation and repairs should be performed by a qualified service person. The
appliance should be inspected before use and at least annually by a professional service person.
More frequent cleaning may be required due to excessive lint from carpeting, bedding mate-
rial, etc. It is imperative that control compartments, burners and circulating air passageways of
the appliance be kept clean.
THIS APPLIANCE MAY BE INSTALLED IN AN AFTERMARKET*, PERMANENTLY
LOCATED, MANUFACTURED (MOBILE) HOME, WHERE NOT PROHIBITED BY
LOCAL CODES. *After Market: Completion of sale, not for the purpose of resale from the
manufacturer.
THIS APPLIANCE IS ONLY FOR USE WITH THE TYPE OF GAS INDICATED ON THE
RATING PLATE. THIS APPLIANCE IS NOT CONVERTIBLE FOR USE WITH OTHER
GASES.
NOTE: For mobile home installation follow “Installation”, pages 6-19.
GAS CONNECTION
Page 13

PRODUCING ADEQUATE
VENTILATION
This section is for residential or manufactured (mobile) installation
“This heater shall not be installed in a confined space or unusually tight construction unless
provisions are provided for adequate combustion and ventilation air.”
The National Fuel Gas Code, ANSI Z223.1/NFPA 54 defines a confined space as a space
whose volume is less than 50 cubic feet per 1,000 BTU per hour (4.8m 3 per kw) of the
aggregate input rating of all appliances installed in that space and an unconfined space as a
space whose volume is not less than 50 cubic feet per 1,000 BTU per hour (4.8m 3 per kw) of
the aggregate input rating of all appliances installed in that space. Rooms communicating
directly with the space in which the appliances are installed, through openings not furnished
with doors, are considered a part of the unconfined space.
“WARNING: IF THE AREA IN WHICH THE HEATER MAY BE OPERATED IS
SMALLER THAN THAT DEFINED AS AN UNCONFINED SPACE OR IF THE
BUILDING IS OF UNUSUALLY TIGHT CONSTRUCTION, PROVIDE
ADEQUATE COMBUSTION AND VENTILATION AIR BY ONE OF THE
METHODS DESCRIBED IN THE NATIONAL FUEL GAS CODE, ANSI Z223.1/
NFPA 54, SECTION 5.3 OR APPLICABLE LOCAL CODES.”
Unusually tight construction is defined as construction where:
a) Walls and ceilings exposed to the outside atmosphere have a continuous water vapor
retarder with a rating of 1 perm (6 x 10-11 kg per pa-sec-m2) or less with openings gasketed or
sealed;
b) Weather stripping has been added on openable windows and doors, and
c) Caulking or sealants are applied to areas such as joints around window and door frames,
between sole plates and floors, between wall-ceiling joints, between wall panels, at
penetrations for plumbing, electrical, and gas lines, and at other openings.
NOTE: SOME AREAS IN THE UNITED STATES HAVE HIGHER REQUIREMENTS
FOR CUBIC FEET PER 1000 BTU/ HOUR INPUT. (EX. CINCINNATI, OHIO CODES
REQUIRE 70 CUBIC FEET). CHECK YOUR LOCAL CODE BEFORE
INSTALLATION.
Page 14

DETERMINING FRESH-AIR FLOW FOR
HEATER LOCATION
DETERMINE IF YOU HAVE A CONFINED OR UNCONFINED SPACE
Use this worksheet to determine if you have confined or unconfined space.
SPACE: Includes the room in which you will install heater plus adjoining rooms with
doorless passageways or ventilation grills between the rooms.
1. Determine the volume of the space (length x width x height).
Length x Width x Height =_________cu.ft.(volume of space)
EXAMPLE: 20 ft.(Length) x 16 ft.(Width) x 8 ft.(ceiling Height)=
2560 cu. ft. (volume of space)
If additional ventilation to adjoining room is supplied with grills or openings, add the
volume of these rooms to the total volume of the space.
2. Divide the space volume by 50 cubic feet to determine the maximum BTU/Hr the
space can support.
_________(volume of space)/50 cu. ft. =maximum BTU/Hr the space can support)
EXAMPLE: 2560 cu. ft. (volume of space /50 cu. Ft .= 51.2 or
51200 (maximum BTU/Hr the space can support)
3. Add the BTU/Hr of all fuel burning appliances in the space.
Vent-free heater _______________BTU/Hr
Gas water heater* _______________BTU/Hr
Gas furnace _______________BTU/Hr
Vented gas heater _______________BTU/Hr
Gas fireplace logs _______________BTU/Hr
Other gas appliances* + _______________BTU/Hr
Total = _______________BTU/Hr
Example: Gas water heater 40000 BTU/Hr
Vent-free heater + 18000 BTU/Hr
Total = 58000 BTU/Hr
*Does not include direct-vent gas appliances. Direct-vent draws combustion air
from the outdoors and vents to the outdoors.
4. Compare the maximum BTU/Hr the space can support with the actual amount of BTU/Hr
used.
____________BTU/Hr (maximum the space can support)
____________BTU/Hr (actual amount of BTU/Hr used)
Example: 51200 BTU/Hr (maximum the space can support)
58000 BTU/Hr (actual amount of BTU/Hr used)
The space in the above example is a confined space because the actual BTU/Hr used is more
than the maximum BTU/Hr the space can support. You must provide additional fresh
air. Your options are as follows:
Page 15

VENTILATION AIR
VENTILATION AIR FROM INSIDE BUILDING
This fresh air would come from an adjoining unconfined space. When venting to an adjoining space,
you must provide two permanent openings: one within 12" of the ceiling and one within 12" of the
floor on the wall connecting the two spaces. (See Options 1 and 2, Figure 7.) You can also remove door
into adjoining room. (See Option 3, Figure 7.)
WA R N I N G
REWORK WORKSHEET, ADDING THE SPACE OF THE ADJOINING UNCONFINED
SPACE. THE COMBINED SPACES MUST HAVE ENOUGH FRESH AIR TO SUPPLY ALL
APPLIANCES IN BOTH SPACES.
NOTE: Each opening shall have a minimum free area of 1 square inch per 1000 BTU’s per hour of the
total input ratings of all gas utilization equipment in the confined space, but not less than 100 square
inches.
Figure 7 Ventilation Air From Inside Building
A. Rework worksheet, adding the space of an adjoining room. If the extra space provides an
unconfined space, remove door to adjoining room or add ventilation grills between rooms. See
“Ventilation Air From Inside Building”, page 21.
B. Vent room directly to the outdoors. See “Ventilation Air From Outdoors”, page 22.
C. Install a lower BTU/Hr heater, if lower BTU/Hr size makes room unconfined.
If the actual BTU/Hr used is less than the maximum BTU/Hr the space can support, the
space is an unconfined space. You will need no additional fresh air ventilation.
WA R N I N G : YOU MUST PROVIDE ADDITIONAL VENTILATION AIR IN A
CONFINED SPACE
Page 16

VENTILATION AIR FROM OUTDOORS
Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent
openings: one within 12" of the ceiling and one within 12" of the floor. Connect these items
directly to the outdoors. These spaces include attics and crawl spaces. Follow the National
Fuel Gas Code NFPA 54/ANSI Z223.1, Section 5.3, “Air For Combustion and Ventilation” for
required size of ventilation grills or ducts.
IMPORTANT: Do not provide openings for inlet air into attic if attic has a thermostat-
controlled power vent. Heated air entering the attic will activate the power unit.
WARNING
THIS HEATER MUST HAVE FRESH AIR FOR PROPER OPERATION. IF NOT,
POOR FUEL COMBUSTION COULD RESULT. READ THE FOLLOWING
INSTRUCTIONS TO INSURE PROPER FRESH AIR FOR THIS AND OTHER FUEL-
BURNING APPLIANCES IN YOUR HOME.
Ventilated Attic
Outlet Air
Inlet Air
Outlet Air
To Attic
To Crawl
Space
Inlet Air
Ventilation
To Crawl Space
Page 17

GAS PRESSURE CHECK
Check the inlet pressure to the burner to insure that it is as shown in the table below.
NOTE: The pressure check point is located on the right side of the valve facing burner.
The appliance and its appliance main gas valve must be disconnected from the gas supply
piping system during any pressure testing of that system at test pressures in excess of 1/2
psi (3.5kPa).
The appliance must be isolated from the gas supply piping system by closing its equipment
shut-off valve during any pressure testing of the gas supply piping system at test pressures
equal to or less than 1/2 psi (3.5 kPa).
MODEL FP-BR10-ZC FP-BR10-ZC
Gas Natural Propane
Maximum Heat Input 10000 10000
Gas Inlet Pressure:
Maximum 10.5 ins. W.C. 13 ins. W.C.
Minimum * 5 ins. W.C. *11 ins. W.C.
Manifold Pressure 3.5 ins. W.C. 9 ins. W.C.
NOTE: On initial installation it may be necessary to bleed out air in the gas lines. Do this by
holding the control knob and turning the knob to the pilot position for about 30 seconds.
To check the Regulator pressure, remove the pressure tag plug at the left side of the Regulator
facing the heater. The pressure should be checked with the heater burning and the control set
on high. After measuring the pressure, replace the pressure tap plug,ensuring that there are no
leaks.
* For the purpose of minimum input adjustment.
WARNING
This appliance is equipped for (natural or propane) gas.
Field conversion is not permitted.
Page 18
