New Holland BNAC930HB User manual

user manual
30 GALLON AIR
BNAC930HB
BNAC1330HEB2
BNAC1330HG2
BNAC1330HGW
85.610.360

2
tAbLe Of cONteNts
Introduction
4 Using the Operators Manual
Specifications
4 Specifications
Product Identification
5 Record Identification Numbers
Safety
6 Safety Instructions
7 Safety Rules
7 Hazard Symbols and Meanings
10 General Safety Information
Safety & Installation
11 Spraying Precautions
11 Hose Precautions
11 Installation and Location
11 Extension Cords
Generator Safety
12 Generator Safety
13 Grounding Instructions
Assembly Instructions
14 Assembly
Product Features
15 Automatic ON/OFF
15 Regulator
15 Tank Pressure Gauge
15 Safety Valve
15 Tank Drain Fitting
15 Safety Guard

3
tAbLe Of cONteNts
Operating Instructions
16 Initial Start Up
16 Start Up
16 Storage
16 Shut Down
Maintenance
17 Daily
17 Weekly
17 Monthly
17 Six Months or 250 Operating Hours
17 Oil Change
Troubleshooting
18 Compressor
19 Generator
Components
20 Diagram
21 List
Warranty
22 Warranty Statement

4
Using the Operator’s manual
Thank you for choosing our compressor. The manual gives information
regarding operation and maintenance of the Compressor. Be sure to
read it carefully before operation.
Following the manual can ensure the user’s safety and the best results
from the compressor. All information and diagrams in this manual are in
accordance with the newest products at the publishing time. We strive
for accuracy and this manual is accurate for the models described at the
time of printing. We reserve the right to make improvements or changes
at any time without notice or obligation.
Please keep this manual with the compressor at all times, even if
ownership of the compressor is transferred to someone else.
Attention: Completely read through the manual
prior to the initial use of your compressor.
INtROductION
Model # BNAC930HB BNAC1330HEB2 BNAC1330HG2 BNAC1330HGW
Engine Honda GX270 Honda GX390 Honda GX390 Honda GX390
Watts (Comp. Off) N/A N/A 4000W 5500W
Watts (Comp. On) N/A N/A 3500W 5000W
Max PSI 175 175 175 175
CFM @175 PSI 16 23 16 22
Receptacles N/A N/A 4x NEMA 5-15R 1x 110V, 1x 220V

5
pROduct IdeNtIfIcAtION
Record Identification Numbers
COMPRESSOR/GENERATOR
If you need to contact an Authorized Dealer or Customer Service line
(1-855-850-6668) for information or servicing, always provide the
product model and identification numbers.
You will need to locate the model and serial number for the machine and
record the information in the spaces provided below.
Date of Purchase:
Dealer Name:
Dealer Phone:
Product Identification Numbers
Model Number:
Serial Number:

6
sAfety
Safety Instructions
1. Carefully read through the entire owners manual before operating
this compressor to ensure all safety precautions are adhered to.
2. After unpacking your new air compressor, please inspect it carefully
for any damage that may have occurred during transit.
3. Do not operate this air compressor if damaged during shipment,
handling, or misuse.
4. Damage may result in bursting, which can cause serious injury or
property damage.
5. All damaged parts must be repaired or replaced as needed prior ton
operating this air compressor.
6. Check to see that all nuts, bolts and fittings are secure.
7. Check to see that the engine oil level is within an acceptable range. If
it is too low, refer to the engine user manual for instruction on how to
add or change oil.
8. Inspect hoses and cords to ensure that they are unfrayed and in
good condition.
9. Please contact our customer service department at the numbers
listed on the back of this instruction manual for any questions or
comments regarding this air compressor.

7
The safety alert symbol ( ) is used with a signal word (DANGER,
CAUTION, WARNING), a pictorial and/or a safety message to alert you
to hazards.
DANGER indicates a hazard which, if not avoided, will result in death
or serious injury.
WARNING indicates a hazard which, if not avoided, could result in
death or serious injury.
CAUTION indicates a hazard which, if not avoided, might result in
minor or moderate injury.
NOTICE indicates a situation that could result in equipment damage.
Follow safety messages to avoid or reduce the risk of injury or death.
HAZARD SYMBOLS AND MEANINGS
Save these Instructions
SAFETY RULES
sAfety
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey
all safety messages that follow this symbol to
avoid possible injury or death.
explosion
kickback
fall fluid injection moving parts read manual
hot surface wear eye
protection
slippery
fire electric shock toxic fumes

8
sAfety
WARNING
AIR TANK WARNING: Drain liquid from air tank daily,
or after each use, using the drain valve located on the
bottom of the lower air tank. Failure to properly drain
liquid from the tank will cause rust from moisture
buildup. This weakens the tank and could lead to a
violent tank explosion, Periodically inspect the tanks for
unsafe conditions such as corrosion.
Never attempt to repair or make modifications to the tank or its
attachments. Welding, drilling, or any other modifications may weaken
the tank, which may result in damage from rupture or explosion. Never
remove or attempt to adjust the pressure switch, safety valve, or other
factory set operating pressures.
WARNING
FIRE WARNING: Avoid dangerous environments.
Do not use the compressor near gasoline or other
flammable materials. Keep work area well lit. Normal
sparking of a motor or sparking from grinding metal
could ignite fumes. Do not spray flammable materials
in the vicinity of an open flame or other ignition source,
including the air compressor itself. Do not direct paint
or other spray material towards the compressor.
Read and follow all safely instructions for the material you are spraying.
Be sure to use an approved respirator designed for use with your
specific application.
WARNING
BREATHABLE AIR WARNING: This air compressor
is not designed, nor intended to produce breathable air.
Air produced by this unit may contain carbon monoxide
or other toxic vapors.
Do not inhale air from the compressor or from a breathing device
connected to it.

9
sAfety
WARNING
AIR TOOLS AND ACCESSORIES WARNING: Do
not exceed the pressure rating of any air tools, spray
guns, air accessories, or inflatables. Excess pressure
can cause them to explode, resulting in serious injury.
Follow the manufacturers recommended pressure
settings for all air tools and air accessories.
WARNING
Do not direct compressed air stream at people or pets.
The powerful compressed air stream can damage
exposed skin and easily propel loose dirt or other small
objects. Always wear eye protection that meets
ANSI Z28.1 specifications.
WARNING
Keep hands and fingers away from exposed metal parts
on a running air compressor. Air compressors generate
significant heat during normal operation, which can
cause serious burns. The compressor will remain hot for
some time after operation and should not be touched or
moved until cool.

10
sAfety
GENERAL SAFETY INFORMATION
Do not operate unit if damaged during shipping, handling or use. Damage
may result in bursting and cause injury or property damage.
Since the air compressor and other components (filters, lubricators,
hoses, etc.) used, make up a high pressure pumping system, the
following safety precautions must be observed at all times:
1. Read all manuals included with this product carefully. Be thoroughly
familiar with the controls and the proper use of the equipment.
2. Follow all local electrical and safety codes
3. Only persons well acquainted with these rules of safe operation
should be allowed to use the compressor.
4. Keep visitors away and do not allow children in the work area.
5. Wear safety glasses and use hearing protection when operating the
pump or unit.
6. Do not stand on or use any part of the unit as a handhold.
7. Before each use, inspect the compressor system and electrical
components for signs of damage, deterioration, weakness, or
leakage. Repair or replace defective items before using.
8. Check all fasteners at frequent intervals and tighten if needed.
9. Keep fingers away from a running compressor; fast moving and hot
parts will cause injury and/or burns.
10. If the equipment starts to vibrate in an abnormal manner, STOP
the engine/motor and check immediately for the cause. Vibration is
generally a warning of trouble.
11. To reduce the risk of fire, keep engine/motor exterior free of
oil, solvent, or excessive grease. Never remove or attempt to
adjust safety valve. Keep safety valve free from paint and other
accumulations.
12. Never attempt to repair or modify a tank. Welding, drilling or any other
modification will weaken the tank resulting in damage from rupture or
explosion. Always replace worn or damaged tanks. Drain liquid from
tank daily.
13. Tanks rust from moisture build-up, which weakens the tank. Make
sure to drain tank daily and inspect periodically for unsafe conditions
such as rust formation and corrosion.
14. Fast moving air will stir up dust and debris which may be harmful.
Release air slowly when draining moisture or depressurizing the
compressor system.
15. Do not attempt to open/drain the air tank when it contains more than
10 PSI of pressure. Remove excess pressure with an air tool before
opening the drain valve.
16. Ensure that nothing is plugged in to the generator before turning the
engine on.
