New Power C Series User manual

C Series
Single Channel
Temperature Transmitter
Website: http://www.anpe.cn
Service Tel: [phone]
Address: New Power industrial Park, Luhe Economic Development Zone, Nanjing, China
Postcode: 211500
Nanjing New Power Electric Co., Ltd.
604040203400001
< 300 ℃
≥ 300 ℃
< 500 ℃
≥ 500 ℃
< 100 ℃
≥ 100 ℃
± 0.3 ℃
± 0.1% F.S.
± 0.5 ℃
± 0.1 % F.S.
± 0.1 ℃
± 0.1 % F.S.
Range Accuracy
Input
K/E/J/N/T
S/B/R/WRe-series
Pt100/Cu100
Cu50/BA1/BA2
1
2
3
4
5
6
4 mA ~ 20 mA
1 V ~ 5 V
0 mA ~ 10 mA
0 V ~ 5 V
0 V ~ 10 V
0 mA ~ 20 mA
X
User customized signal type
Number Output signal
Single input, single output
Power supply
Output
+
-
9
10
5
6
+
-
RL
-
+
R8 R7 R6 R5 R4 R 3 R2 R 1
DIN Rail
R3
R1
DIN Rail
2-wire
Input
3-wire
3
2
1
1
2
3
RTD
RTD
TC
-
+
CJC
Single input, double output
9
10
+
-
Power supply
-
+
R8 R7 R6 R5 R4 R 3 R2 R 1
DIN Rail
R3
R1
DIN Rail
2-wire
Input
3-wire
3
2
1
1
2
3
RTD
RTD
TC
-
+
CJC
Output1
5
6
+
-
RL
Output2
7
8
+
-
RL
mFollow mode: Whatever input fault status (except
breakage), the output follows the input within measuring
range. And the maximum value would not exceed the
110% of the upper limit of the measuring range (e.g.
When the output signal type is 0 ~ 20 mA, the minimum
output value may be 0 mA, the maximum output value
would not exceed 22 mA).
mWhen the thermocouple input, compensation conductor
should be directly connected to the input terminals, do not
connect other material lead, otherwise will cause
measurement error.
mDIN rail power supply function is selectable at ordering.
èDimension
Width × Height × Depth: 12.8 mm × 110 mm × 117 mm
Default: Terminals powered
PB: BUS powered
X
Default: null
The second output signal
note
The first output signal
note
XX
NPWD-C DX
.TC: thermocouple input
.RTD: thermal resistance input
Default: thermocouple or
thermal resistance input
èIntroductions
This temperature transmitter converts the thermocouple/
thermal resistance signals to current or voltage signals. DIN
rail power supply function can be selected in ordering.
The input, output, and power supply are galvanically isolated
from each other. You can use handheld programmer to
modify parameters or to calibrate the apparatus.
èParameters
Power supply:
Connection type: Terminals (9+, 10-) or DIN rail connector
Rated voltage: 18 V DC～60 V DC (Recommended voltage:
24 V DC)
Input (1, 2, 3):
TC: K, E, S, B, J, T, R, N, WRe3 - WRe25, WRe5 - WRe26,
2/3-wire RTD: Pt100, Cu100, Cu50, BA1, BA2
The input signal needs to be determined when ordering and
can also be programmed. Other signal types is required
special customization, please see the product label for details.
Line resistance: ≤ 20 Ω per line
Output (5, 6; 7, 8):
Output current: 0(4) ~ 20 mA; 0 ~ 10 mA
Output voltage: 0(1) ~ 5 V; 0 ~ 10 V
Output ripple: ≤ 5 mV (Load resistance: 250 Ω)
rms
Load resistance: 0(4) ~ 20 mA: ≤ 550 Ω; 0 ~ 10 mA: ≤ 1.1 kΩ
0(1) ~ 5 V: ≥ 1 MΩ; 0 ~ 10 V: ≥ 2 MΩ
Transmission characteristics (25 ℃ ± 2 ℃):
Response time: ≤ 0.5 s
Temperature drift: 30 ppm/℃
Cold junction compensation accuracy: ± 1 ℃ (Preheated
for 10 minutes)
Cold junction compensation range: -20 ℃ ~ +60 ℃
Electromagnetic compatibility: Accordance to IEC 61326-3-1
Dielectric strength (1 mA leakage current, 1 minute test
time):
≥ 1500 V AC (Input /Output/Power supply)
Insulation resistance: ≥ 100 MΩ (Input /Output/Power supply)
Ambient conditions:
Operation temperature: −20 ℃ ~ +60 ℃
Relative humidity: 10% RH ~ 90% RH (40 ℃)
Atmosphere pressure: 80 kPa ~ 106 kPa
Storage temperature: −40 ℃ ~ +80 ℃
Power dissipation:
0.8 W (24 V DC, single output)
1.2 W (24 V DC, double output)
èModel rules
NOTE：Output signal
èWiring diagram

C. Pry the metal lock off the rail with screwdriver as
arrow shown, pull downward the springs, and rotate the
device.
D. Remove the device as arrow shows.
mAs far as possible to mount it vertically, In order to
dissipation the heat of the apparatus.
Vertically installation
Website: http://www.anpe.cn
Service Tel: [phone]
Address: New Power industrial Park, Luhe Economic Development Zone, Nanjing, China
Postcode: 211500
BUS Electrical Characteristics
Current
Voltage (UL/IEC)
Operation temperature
Max.8 A
1.6 kV
−40 ℃ ~ +105 ℃
DIN 35 rail
BUS socket
A
B
C
D
PWR
A L M
9 10
7 8
5 6
1 2
3 4
PWR
ALM
9 10
7 8
5 6
1 2
3 4
P W R
A L M
9 10
7 8
5 6
1 2
3 4
P W R
ALM
9 10
7 8
5 6
1 2
3 4
PWR
A L M
9 10
7 8
5 6
1 2
3 4
è
Light indication
m
PWR: Power indicator light shows green, it means work
normally.
m
ALM: Input signal state indicator (red), it is off during
normal operation, remain bright when input
over-range;
RTD: It is glitter when input line breakage or short
circuit;
TC: It is glitter when input line breakage.
èAttention
m
The devices degree of protection is IP 20 and must be
protected from undesirable ambient conditions
(waterproofing, small foreign objects). It is suitable for
installation in the control room or high density field
cabinet, DIN 35 mm installation is convenient for
installation and displacement.
mThe devices were designed for use in pollution degree 2
and overvoltage category III as per IEC/EN 60664-1. If
used in areas with higher pollution degree, the devices
need to be protected accordingly.
mInstallation position shall not be affected by strong
mechanical vibration; impact and electromagnetic
induction from signal terminal and power supply, should
conformity with the requirements on electromagnetic
interference resistance of products in Class 3 industrial
field atmosphere stipulated in IEC 61000-4; the
atmosphere shall be free from gases that are corrosive to
metal and plastic components.
m
The apparatus must be installed, connected and adjusted
by qualified personnel in non-hazardous area according
with the instruction manual.
mThe operator must strictly comply with the relevant local
safety standards and guidelines.
è
Supplementary instructions
m
Our company reserves the right to change the product
information without prior notification to the user. If the
contents of the description are different from website or
sample, this description shall prevail.
604040203400001
èBUS Specification
èInstallation
mThe apparatus can be installed on the DIN 35 mm
standard rail which is corresponding to DIN IEC 60715.
The must be snapped onto the rail, and never slanted or
tipped to the side.
mInstallation and disassembly steps are shown in following
figures:
A. Snap the BUS socket on the DIN 35 rail, as figure A;
B. Snap metal lock onto mounting rail, then rotate the device,
as figure B, press down the device onto mounting rail, make
sure that the BUS connector pins of device and BUS socket
are in close contact.
