NewAge Products HOMEBAR Series User manual

HOMEBAR SERIES
DRINK CART
Warning: Excessive weight hazard!
Use two or more people to move, assemble or install cabinets to avoid back injury.
Do not leave children unattended near cabinets. High risk of tipping if cabinets are used
incorrectly: do not use on non-level surfaces
For assistance, call 1.877.306.8930; for UK 0800.031.4069; e-mail at [e-mail]

Weight
Capacity
100
lbs.
XX lbs.
25 lbs.
25 lbs.
50 lbs.
Drink Cart
Max 220 lbs.
10 lbs.

Handles
Shelves
Shelf Pins
Screws (#8 x 25mm)
Casters
Handle Bolts ( M4 x 22 mm)
4
8
2
10
16
Drink Cart
44
Parts Supplied
Unpacking
• Begin by placing the package on a covered at surface.
• Remove all cardboard, foam packaging material and clear plastic bags.
• Dispose / recycle all packaging materials.
• Verify all the contents in the box and gather the required tools. See “Parts”and“Tools Needed”in the list below.
Casters
Screws
#8 x 25mm
Tools Needed
1 x #2 Phillips Bit
(opitional)
1 x Cordless Power Drill
(optional)
1 x #2 Phillips head
screwdriver 1 x Flashlight
(optional)
Handle Handle Bolt Shelf Pins
Shelves
M4 x 22mm

Installing the Handles
Parts Needed. Align handle to holes
on doors or drawers.
Screw in bolts.
12
3
2 x Handle 4 x Handle Bolt
(M4 x 22mm)

Align handle to holes
on doors or drawers.
Installing the Side Handles
Parts Needed.
Screw in bolts.
4
6
5
2 x Handle 4 x Handle Bolt
(M4 x 22mm)
